2018 OPEL MOKKA X Infotainment system

In brief7Backrest inclination
Pull lever, adjust inclination and
release lever. Allow the seat to
engage audibly.
Seat position 3 39, Seat adjustment
3 40.
Seat height
Lever pumping motion
up:seat higherdown:seat lower
Seat position 3 39, Seat adjustment
3 40.
Seat inclination
Press switch
top:front end higherbottom:front end lower
Seat position 3 39, Seat adjustment
3 40.

8In briefHead restraint adjustment
Pull the head restraint upwards.
Press the catch (1) to release and
push the head restraint downwards.
Head restraints 3 38.
Seat belt
Pull out the seat belt and fasten in belt
buckle. The seat belt must not be
twisted and must fit close against the
body. The backrest must not be tilted back too far (maximum approx. 25°).
To unfasten belt, press red button on belt buckle.
Seat position 3 39, Seat belts
3 43, Airbag system 3 46.
Mirror adjustment
Interior mirror
To adjust the mirror, move the mirror
housing in the desired direction.
Manual anti-dazzle interior mirror
3 33, Automatic anti-dazzle interior
mirror 3 34.

In brief9Exterior mirrors
Select the relevant exterior mirror andadjust it.
Convex exterior mirrors 3 32,
Electric adjustment 3 32, Folding
exterior mirrors 3 32, Heated
exterior mirrors 3 33.
Steering wheel adjustment
Unlock the lever, adjust the steering
wheel, then engage the lever and
ensure it is fully locked.
Do not adjust the steering wheel
unless the vehicle is stationary and the steering wheel lock has been
released.
Airbag system 3 46, Ignition
positions 3 136.

10In briefInstrument panel overview

In brief111Central locking system ..........24
2 Power windows .....................34
3 Exterior mirrors .....................32
4 Light switch ......................... 116
5 Cruise control ...................... 153
Speed limiter ....................... 155
Forward collision alert .........156
6 Side air vents ...................... 132
7 Turn and lane-change
signals ................................. 123
Headlight flash ....................118
Low beam and high beam ..117
Buttons for Driver
Information Centre ................98
8 Instruments ........................... 85
9 Steering wheel controls .......78
10 Windscreen wiper,
windscreen washer system ...79
Rear window wiper, rear
window washer system .........81
11 Centre air vents ................... 132
12 Anti-theft alarm system
status LED ........................... 3013Info-Display ........................ 102
14 Controls for Info-Display
operation ............................. 102
15 Glovebox .............................. 60
16 Descent control system ......... 95
Fuel selector ......................... 87
Stop-start system ................139
17 Climate control system ........ 127
18 Electronic Stability Control
(ESC) .................................. 151
19 Control indicator for airbag
deactivation .......................... 94
20 Front storage ......................... 61
Power outlet .......................... 84
USB port, AUX input
21 Selector lever, manual
transmission ....................... 147
Selector lever, automatic
transmission ....................... 144
22 Parking brake ......................149
23 Hazard warning flashers ....122
24 Parking assist ..................... 159
Lane departure warning ......16625Ignition switch with
steering wheel lock ............136
Power button ....................... 136
26 Horn ..................................... 79
Driver airbag ........................ 49
27 Steering wheel adjustment ..78
28 Bonnet release lever ..........180
29 Front storage ......................... 61
Fuse box ............................ 193

12In brief

In brief13Exterior lighting
Turn light switch:
m:lights off8:sidelights9:low beam
Automatic light control
AUTO:automatic light control:
exterior lighting is switched
on and off automaticallym:activation or deactivation of
the automatic light control8:sidelights9:low beam
Fog lights
Press light switch:
>:front fog lightsø:rear fog light
Lighting 3 116.
Headlight flash, high beam and
low beamheadlight flash:pull leverhigh beam:push leverlow beam:push or pull lever
Automatic light control 3 117, High
beam 3 117, Headlight flash 3 118,
Adaptive forward lighting 3 120.

14In briefTurn and lane-change signalslever up:right turn signallever down:left turn signal
Turn and lane-change signals
3 123.
Hazard warning flashers
Operated by pressing ¨.
Hazard warning flashers 3 122.
Horn
Press j.
