2018 MAZDA MODEL CX-9 sensor

▼Obstruction Detection Indication
The position of a sensor which has detected an obstruction is i
ndicated. The gauge
illuminates in different areas d epending on the distance to an obstruction detected by the
sensor.
As the vehicle approaches closer to an obstruction, the zone in the gauge closer to the
vehicle illuminates.

Front left corner
sensor gauge Front right corner
sensor gauge
Rear right corner
sensor gauge
Rear left corner
sensor gauge Front sensor gauge
Rear sensor gauge Some models.
NOTE
The detection indicator can switch between display and non-display.
Refer to Personalization Features on page 9-11.
When Driving
Parking Sensor System
4-176
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

System problem notification
If any of the problems indicated in the table occurs, the driver is notified of the problem
depending on the type of system as shown.
Detection Indicator
Solution
With front sensor
and front corner sensor Without front sen-
sor and front corner sensor
Disconnection
The system may have a malfunction. Have
the vehicle inspected at an Authorized Maz-
da Dealer as soon as possible.
System malfunc- tion
The system may have a malfunction. Have
the vehicle inspected at an Authorized Maz-
da Dealer as soon as possible.
Frost/soiling
Foreign matter may b e on the sensor area
corresponding to the obstruction detection
indication shown. If the system does not re-
cover, have the vehicle inspected at an Au-
thorized Mazda Dealer.
When Driving
Parking Sensor System
4-177
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

▼Parking Sensor Warning Beep
The beeper sounds as follows while the system is operating.
Front Sensor
*, Rear Sensor
Distance Detec-
tion area Distance between vehicle and obstruction
Beeper sound*1Front Sensor*Rear Sensor
Farthest distance Approx. 100―60 cm (39.3―23.6
in)
Approx. 150―60 cm (59.0―23.6in)
Slow intermittent
sound
Far distance Approx. 60―45 cm (23.6―17.7
in)
Approx. 60―45 cm (23.6―17.7in)
Medium intermit-
tent sound
Middle distance Approx. 45―35 cm (17.7―13.7
in)
Approx. 45―35 cm (17.7―13.7in)
Fast intermittent
sound
Close distance Within approx. 35 cm (13.7 in)
Within approx. 35 cm (13.7 in)
Continuous sound
*1 The rate at which the interm
ittent sound beeps increases as the vehicle approaches the obstruction.
When Driving
Parking Sensor System
4-178*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Front Corner Sensor*, Rear Corner Sensor
Distance Detection areaDistance between vehicle and obstruction
Beeper sound*1Front*/Rear Corner Sensor
Far distance Approx. 55―38 cm (21.7―15.0 in)
Medium intermittent sound
Middle distance Approx. 38―25 cm (15.0―9.8 in)
Fast intermittent sound
Close distance Within approx. 25 cm (9.8 in)
Continuous sound
*1 The rate at which the intermitte
nt sound beeps increases as the vehicle approaches the obstruction.
NOTE
If an obstruction is detected in a zone for 6 seconds or more, the beep sound is stopped
(except for the close-distance zone). If the same obstruction is detected in another zone, the
corresponding beep sound is heard.
When Driving
Parking Sensor System
*Some models.4-179
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

▼When Warning Indicator/Beep is Activated
The system notifies the driver
of an abnormality by activating the beep sound and the
indicator light.
Indicator/Beep How to check
The indicator light flashes when
the parking sensor switch is
pressed at a vehicle speed of 10
km/h (6 mph) or less. The system may have a malfunctio
n. Have the vehicle inspected at an Author-
ized Mazda Dealer as soon as possible.
The beep sound is not heard. The system may have a malfunctio
n. Have the vehicle inspected at an Author-
ized Mazda Dealer as soon as possible.
The intermittent sound of the
buzzer is heard five times. Remove any foreign material from the sensor area. If the system
does not re-
cover, have the vehicle inspect ed at an Authorized Mazda Dealer .
A certain obstruction detection
indicator is continuously dis-
played. Refer to Obstruction Detection Indication on page 4-176.
When Driving
Parking Sensor System
4-180
CX-9_8GC3-EA-17G_Edition1
2017-5-29 10:13:38

▼Sunlight/Interior Temperature
Sensor
Sunlight sensor
Do not place objects on the sunlight
sensor. Otherwise, the interior temperature
may not adjust correctly.
Sunlight sensor
Interior temperature sensor
Do not cover the interior temperature
sensor. Otherwise, the interior temperature
may not adjust correctly.
Interior temperature sensor
Interior Features
Climate Control System
