2018 MAZDA MODEL CX-9 bulb

Overhead lights (Front)/Map lights
(Front) (bulb type), Map lights (Center)
(bulb type), Overhead light (Rear) (bulb
type), Vanity mirror lights
1. Wrap a small flathead screwdriver with
a soft cloth to prevent damage to the
lens, and then remove the lens by
carefully prying on the edge of the lens
with the flathead screwdriver.
2. Disconnect the bulb by pulling it out. Overhead lights (F ront)/Map lights
(Front)


Map lights (Center)

Forward

Overhead light (Rear)

Edge
Forward
Maintenance and Care
Owner Maintenance
6-51
CX-9_8GC3-EA-17G_Edition1
2017-5-29 10:13:38

Vanity mirror lights

3. Install the new bulb in the reverseorder of the removal procedure.
Luggage compartment light
(LED type)
The LED bulb cannot be replaced as a
single unit because it is an integrated unit.
The LED bulb has to be replaced with the
unit. We recommend an Authorized
Mazda Dealer when the replacement is
necessary.
(Bulb type)
1. Wrap a small flathead screwdriver with a soft cloth to prevent damage to the
lens and remove the lens unit by
carefully prying on th e edge of the lens
unit with the flathead screwdriver.

2. Disconnect the electrical connector
from the bulb by pressing the tab on
the connector with your finger and
pulling the connector.

CAUTION
When replacing the bulb always
disconnect the connector first.
Otherwise, electric and electronic
devices could be shorted.
3. Insert the flathead s crewdriver into the
gap between the lens and the lens unit,
and then slide the screwdriver to
detach the lens.

Maintenance and Care
Owner Maintenance
6-52
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

4. Disconnect the bulb by pulling it out.
5. Install the new bulb in the reverseorder of the removal procedure.
Fuses
Your vehicle's electrical system is
protected by fuses.

If any lights, accessories, or controls do
not work, inspect the appropriate circuit
protector. If a fuse has blown, the inside
element will be melted.

If the same fuse blows again, avoid using
that system and consult an Authorized
Mazda Dealer as soon as possible.
▼ Fuse Replacement
Replacing the fuses on the vehicle's left
side
If the electrical system does not work, first
inspect the fuses on the vehicle's left side.

1. Make sure the ignition is switched off,
and other switches are off.
2. Open the fuse panel cover.
Maintenance and Care
Owner Maintenance
6-53
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

▼Light Bulbs
Exterior light
With Adaptive Front Li
ghting System (AFS)
Light bulb Category
Wattage UNECE*1 (SAE)
Headlights High beam
LED
*2― (―)
Low beam LED
*2― (―)
Daytime running lights/Parking lights LED
*2― (―)
Front side-marker lights LED
*2― (―)
Front turn signal lights LED
*2― (―)
Fog lights LED
*2― (―)
Signature wing illumination
*LED*2― (―)
Side turn signal lights LED
*2― (―)
High-mount brake light LED
*2― (―)
Rear turn signal lights 21 WY21W (7443NA)
Rear side-marker lights LED
*2― (―)
Brake lights/Taillights LED
*2― (―)
Brake lights LED
*2― (―)
Taillights LED
*2― (―)
Reverse lights 18 W16W (921)
License plate lights 5W5W (―)
*1 UNECE stands for United Nations Economic Commission for Europe.*2 LED is the abbreviation for Light Emitting Diode.

Specifications
Specifications
*Some models.9-7
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Without Adaptive Front Lighting System (AFS)
Light bulbCategory
Wat tage UNECE*1 (SAE)
Headlights High beam
LED
*2― (―)
Low beam LED
*2― (―)
Daytime running lights LED
*2― (―)
Parking lights/Front side-marker lights 5 WY5W (―)
Front turn signal lights 21WY21W (7443NA)
Fog lights
*LED*2― (―)
Side turn signal lights LED
*2― (―)
High-mount brake light LED
*2― (―)
Rear turn signal lights 21 WY21W (7443NA)
Rear side-marker lights LED
*2― (―)
Brake lights/Taillights LED
*2― (―)
Brake lights LED
*2― (―)
Reverse lights 18 W16W (921)
License plate lights 5W5W (―)
*1 UNECE stands for United Nations Economic Commission for Europe.*2 LED is the abbreviation for Light Emitting Diode.

Specifications
Specifications
9-8*Some models.
CX-9_8GC3-EA-17G_Edition1 2017-5-29 10:13:38

Interior light
Light bulbCategory
Wattage UNECE*1
Overhead lights (Front)/Map lights
(Front) Bulb type 8 ―
LED type
LED*2―
Map lights (Center) Bulb type 8 ―
LED type
LED
*2―
Overhead light (Rear) Bulb type 10 ―
LED type
LED
*2―
Ambient lights
*LED*2―
Vanity mirror lights
*2―
Luggage compartment light Bulb type 8 ―
LED type
LED
*2―
*1 UNECE stands for United Nations Economic Commission for Europe.*2 LED is the abbreviation for Light Emitting Diode.
