2018 MAZDA MODEL 3 HATCHBACK rear view mirror

Interior Equipment (View D)
ƒSeat belts............................................................................................................... page 2-12
„ SRS air bag............................................................................................................page 2- 44
… Bottle holder.................................................. ..................................................... page 5-135
† Overhead lights...................................................................................................page 5-130
‡ Moonroof switch................................................................................................... page 3-38
ˆ Sunvisor....................................................... ....................................................... page 5-1 29
‰ Vanity mirror...................................................................................................... page 5-129
Š Rearview mirror................................................ .................................................... page 3-33
‹ Cup holders.................................................... .....................................................page 5-134
ΠFront seat................................................................................................................. pag e 2-5
 Center console................................................. ................................................... page 5-136
Ž Accessory sockets............................................................................................... page 5-132
 External input terminal........................................ .................................................. page 5-54
 Rear seat...................................................... ............................................................ page 2-7
Pictorial Index
Interior Overview
The equipment and installation position varies by vehicle1-5
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

(5-Door)
ƒHood...................................................................................................................... page 6-20
„ Windshield wiper blades....................................................................................... page 6-29
… Moonroof...............................................................................................................page 3- 38
† Doors and keys...................................................................................................... page 3-13
‡ Fuel-filler lid......................................................................................................... page 3 -28
ˆ Wheels and Tires............................................... .................................................... page 6-38
‰ Exterior lights................................................ ........................................................ page 6-42
Š Rear window wiper blade........................................ ..............................................page 6-31
‹ Liftgate.................................................................................................................. page 3-21
ΠChild safety locks.................................................................................................. page 3-19
 Outside mirror....................................................................................................... page 3-32
Pictorial Index
Exterior Overview
The equipment and installation position varies by vehicle1-7
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Mirrors
Before driving, adjust the inside and
outside mirrors.
▼Outside Mirrors
WA R N I N G
Be sure to look over your shoulder before
changing lanes:
Changing lanes without taking into
account the actual distance of the vehicle
in the convex mirror is dangerous. You
could have a serious accident. What you
see in the convex mirror is closer than it
appears.
Mirror type
Flat type (driver's side)
Flat surface mirror.
Convex type (front passenger side)
The mirror has single curvature on its
surface.
Power mirror adjustment
The ignition must be switched to ACC or
ON position.

To adjust:
1. Rotate the mirror switch to the left
or
right
to choose the left or right side
mirror.
2. Press the mirro r switch in the
appropriate direction.
Center position
Mirror switch
After adjusting the mirror, lock the control
by rotating the switch in the center
position.
Folding mirror
WA R N I N G
Always return the outside mirrors to the
driving position before you start driving:
Driving with the outside mirrors folded in is
dangerous. Your rear view will be restricted,
and you could have an accident.
Manually fold the outside mirror rearward
until it is flush with the vehicle.
Before Driving
Mirrors
3-32
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

▼Rearview Mirror
WA R N I N G
Do not stack cargo or objects higher than
the seatbacks:
Cargo stacked higher than the seatbacks is
dangerous. It can block your view in the
rearview mirror, which might cause you to
hit another car when changing lanes.
Rearview mirror adjustment
Before driving, adjust
the rearview mirror
to center on the scene through the rear
window.

NOTE
For the manual day/night mirror, perform
the adjustment with the day/night lever in
the day position.
Reducing glare from headlights
Manual day/night mirror
Push the day/night lever forward for day
driving. Pull it back to reduce glare of
headlights from vehicles at the rear.

Night
Day Day/Night lever
Auto-dimming mirror
The auto-dimming mirror automatically
reduces the glare
of headlights from
vehicles at the rear when the ignition is
switched ON.

(With Homelink wireless control
system)
Press the OFF button (
) to cancel the
automatic dimming function. The
indicator light will turn off.
To reactivate the automatic dimming
function, press the ON button (
). The
indicator light will illuminate.
Indicator lightOFF button
ON button
Before Driving
Mirrors
3-33
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

▼Pre-Crash Safety Technology
Pre-crash safety technology is designed to assist the driver in
averting collisions or reduce
their severity in situations where they cannot be avoided.
Collision damage reduction in low vehicle speed range
Forward driving
Smart City Brake Support (SCBS).......................................................................... page 4-124
Collision damage reduction in medium/high speed range
Smart Brake Support (SBS)..................................................................................... page 4-128
▼Camera and Sensors
Forward Sensing Camera (FSC)
The Forward Sensing Camera (FSC) detects lane indications and r
ecognizes headlights,
taillights and city lights during nighttime driving. In addition, it also detects the vehicle
ahead, pedestrians, or obstructions. The following systems also use the Forward Sensing
Camera (FSC).
High Beam Control system (HBC)
Lane-keep Assist System (LAS) & Lane Departure Warning System ( LDWS)
Traffic Sign Recognition System (TSR)
Smart City Brake Support (SCBS)
Smart Brake Support (SBS)
The Forward Sensing Camera (FSC) is installed at the top of the windshield near the
rearview mirror.
Refer to Forward Sensing Camera (FSC) on page 4-131.
Radar sensor (front)
The radar sensor (front) function s by detecting the radio waves reflected off a vehicle ahead
sent from the radar sensor. The following systems also use the radar sensor (front).
Mazda Radar Cruise Control (MRCC)
Distance Recognition Support System (DRSS)
Smart Brake Support (SBS)
The radar sensor (front) is moun ted behind the radiator grille.
Refer to Radar S ensor (Front) on page 4-136.
When Driving
i-ACTIVSENSE
4-78
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

In the following case, the flashing of the BSM warning indicator light, and the activation
of the warning sound and the warning screen indicator display may not occur or they may
be delayed.
A vehicle makes a lane change from a driving lane two lanes over to an adjacent lane.
Driving on steep slopes.
Crossing the summit of a hill or mountain pass.
When there is a difference in the height between your driving lane and the adjacent
lane.
Directly after the BSM system becomes operable by changing the setting.
If the road width is extremely narrow, vehicles two lanes over may be detected. The
detection area of the radar sensors (rear) is set according to the road width of
expressways.
The BSM warning indicator light may turn on and the vehicle detection screen may be
displayed in the display in reaction to stationary objects (guardrails, tunnels, sidewalls,
and parked vehicles) on the road or the roadside.
The walls at the entrance and exits of tunnels,
turnouts.
Objects such as guardrails and concrete walls
running alongside the vehicle. Places where the width between guardrails or
walls on each side of the vehicle narrows.
A BSM warning indicator ligh
t may flash or the warning beep and the warning screen
indicator display may be activated several times when making a turn at a city
intersection.
Turn off the BSM while pulling a trailer or while an accessory such as a bicycle carrier is
installed to the rear of the vehicle. Otherwis e, the radar’s radio waves will be blocked
causing the system to not operate normally.
In the following cases, it may be difficult to view the illumination/flashing of the BSM
warning indicator lights equipped on the door mirrors.
Snow or ice is adhering to the door mirrors.
The front door glass is fogged or covered in snow, frost or dirt.
When Driving
i-ACTIVSENSE
4-86
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

In the following cases, it may be difficult to view the illumination/flashing of the Blind
Spot Monitoring (BSM) warning indicator lights equipped on the door mirrors.
Snow or ice adheres to the door mirrors.
The front door glass is fogged or covered in snow, frost or dirt.
Turn off the RCTA system while pulling a trailer or while an accessory such as a bicycle
carrier is installed to the rear of the vehic le. Otherwise, the radio waves emitted by the
radar will be blocked causing the system to not operate normally.
When Driving
i-ACTIVSENSE
4-101
Mazda3_8GE4-EA-17F_Edition1 2017-4-7 11:59:21

Forward Sensing Camera (FSC)
Your vehicle is equipped with a Forward Sensing Camera (FSC). The Forward Sensing
Camera (FSC) is positioned near t he rearview mirror and used by the following systems.
High Beam Control System (HBC)
Lane-keep Assist System (LAS) & Lane Departure Warning System ( LDWS)
Traffic Sign Recognition System (TSR)
Smart City Brake Support (SCBS)
Smart Brake Support (SBS)
Forward Sensing Camera (FSC)
The Forward Sensing Camera (FSC) determines the conditions ahead of the vehicle while
traveling at night and detects traffic lanes. The distance in w hich the Forward Sensing
Camera (FSC) can detect objects varies depending on the surroun ding conditions.
WA R N I N G
Do not modify the suspension:
If the vehicle height or inclination is changed, the system will not be able to correctly detect
vehicles ahead. This will result in the system not operating normally or mistakenly operating,
which could cause a serious accident.
CAUTION
 Do not apply accessories, stickers or film to the windshield near the Forward Sensing
Camera (FSC).
If the area in front of the Forward Sensing Camera (FSC) lens is obstructed, it will cause the
system to not operate correctly. Consequently, each system may not operate normally
which could lead to an unexpected accident.
When Driving
i-ACTIVSENSE
4-131
