2018 LEXUS LS500H key

446 7-2. Steps to take in an emergency
LS500h_OM_OM50F42U_(U) 1 Pull the driver’s door handle and
insert the mechanical key.
2 Unlock the door.
3 Remove the key, return the handle,
and then pull the handle again. ■
Locking the door
1 With the door open, push down the
inside lock button.
2 Close the door. ■
Trunk
Turn the mechanical key clockwise to
open. ( → P.68) ■
Key linked functions
1 Closes the windows and the moon
roof (turn and hold)
2 Opens the windows and the moon
roof (turn and hold) These settings must be customized at your
Lexus dealer.
1 Depress the brake pedal. WARNING■
When using the mechanical key and
operating the power windows or
moon roof
Operate the power window or moon
roof after checking to make sure that
there is no possibility of any passenger
having any of their body parts caught in
the window or moon roof.
Also, do not allow children to operate the
mechanical key. It is possible for children
and other passengers to get caught in
the power window or moon roof.
Starting the hybrid system

4477-2. Steps to take in an emergency
LS500h_OM_OM50F42U_(U) 7
When trouble arises 2 Touch the Lexus emblem side of the
electronic key to the power switch.When the electronic key is detected, a
buzzer sounds and the power switch will
turn to ON mode.
When the smart access system with
push-button start is de activated in custom-
ization setting, the powe r switch will turn to
ACCESSORY mode.
3 Firmly depress the brake pedal and
check that is shown on the
multi-information display.
4 Press the power switch.
In the event that the hybrid system still
cannot be started, contact your Lexus
dealer. ■
Stopping the hybrid system
Set the parking brake, shift the shift position
to P and press the power switch as you nor-
mally do when stopping the hybrid system.
■
Electronic key battery
As the above procedure is a temporary
measure, it is recomme nded that the elec-
tronic key battery be replaced immediately
when the battery is depleted. ( → P.413)
■
Changing power switch modes
Release the brake pedal and press the
power switch in step 3 above. The hybrid
system does not start and modes will be
changed each time the switch is pressed.
( → P.170) If you have a set of jumper (or booster)
cables and a second vehicle with a
12-volt battery, you can jump start your
vehicle by following the steps below. 
Method connecting jumper (or
booster) cables to the 12-volt bat-
tery
1 Confirm that the electronic key is
being carried. When connecting the jumper (or booster)
cables, depending on the situation, the
alarm may activate and doors locked.
( → P.69)
2 Open the trunk lid and remove the
luggage mat. ( → P.348)In the event that the trunk opener cannot
be used, use the mechanical key to open
the trunk. ( → P.445)If the 12-volt battery is dis-
charged The following procedures may be
used to start the hybrid system if the
12-volt battery is discharged.
You can also call your Lexus dealer
or a qualified repair shop.
Restarting the hybrid system

448 7-2. Steps to take in an emergency
LS500h_OM_OM50F42U_(U) 3 Connect a positive jumper cable clamp to on your vehicle and connect the
clamp on the other end of the positive cab le to on the second vehicle. Then,
connect a negative cable clamp to on the second vehicle and connect the
clamp at the other end of the negative cable to .
Positive (+) battery terminal (your vehicle)
Positive (+) battery terminal (second vehicle)
Negative (-) battery terminal (second vehicle)
Negative (-) battery terminal (your vehicle)
4 Start the engine of the second vehi-
cle. Increase the engine speed
slightly and maintain at that level for
approximately 5 minutes to
recharge the 12-volt battery of your
vehicle.
5 Open and close any of the doors of
your vehicle with the power switch
off.
6 Maintain the engine speed of the
second vehicle and start the hybrid
system of your vehicle by turning
the power switch to ON mode.
7 Make sure the “READY” indicator
comes on. If the indicator does not
come on, contact your Lexus
dealer.
8 Once the hybrid system has
started, remove the jumper cables in the exact reverse order from
which they were connected. 
Method connecting jumper (or
booster) cables to the exclusive
jump starting terminal
1 Confirm that the electronic key is
being carried. When connecting the jumper (or booster)
cables, depending on the situation, the
alarm may activate and doors locked.
( → P.69)
2 Open the hood. Remove the driver
side engine compartment cover A
B
C
D
A
B
C
D

450 7-2. Steps to take in an emergency
LS500h_OM_OM50F42U_(U) 6 Open and close any of the doors of
your vehicle with the power switch
off.
7 Maintain the engine speed of the
second vehicle and start the hybrid
system of your vehicle by turning
the power switch to ON mode.
8 Make sure the “READY” indicator
comes on. If the indicator does not
come on, contact your Lexus
dealer.
9 Once the hybrid system has
started, remove the jumper cables
in the exact reverse order from
which they were connected.
10 Close the exclusive jump starting
terminal cover and install the fuse
box cover and en gine compart-
ment cover.
Once the hybrid system starts, have
the vehicle inspected at your Lexus
dealer as soon as possible. ■
Starting the hybrid system when the
12-volt battery is discharged
The hybrid system cannot be started by
push-starting. ■
To prevent 12-volt battery discharge●
Turn off the headlights and the audio sys-
tem while the hybrid system is off.
●
Turn off any unnecessary electrical com-
ponents when the vehicle is running at a
low speed for an extended period, such
as in heavy traffic.
■
When the 12-volt battery is removed or
discharged
●
Information stored in the ECU is cleared.
When the 12-volt battery is depleted,
have the vehicle inspected at your Lexus
dealer.
●
Some systems may require initialization. ( → P.495)■
When removing the 12-volt battery ter-
minals
When the 12-volt battery terminals are
removed, the information stored in the
ECU is cleared. Before removing the
12-volt battery terminals, contact your
Lexus dealer. ■
Charging the 12-volt battery
The electricity stored in the 12-volt battery
will discharge gradually even when the
vehicle is not in use, due to natural dis-
charge and the draining effects of certain
electrical appliances. If the vehicle is left for
a long time, the 12-volt battery may dis-
charge, and the hybrid system may be
unable to start. (The 12-volt battery
recharges automatically while the hybrid
system is operating.) ■
When recharging or replacing the
12-volt battery ●
In some cases, it may not be possible to
unlock the doors using the smart access
system with push-button start when the
12-volt battery is discharged. Use the
wireless remote control or the mechani-
cal key to lock or unlock the doors. ●
The hybrid system may not start on the
first attempt after the 12-volt battery has
recharged but will start normally after the
second attempt. This is not a malfunction. ●
The power switch mode is memorized by
the vehicle. When the 12-volt battery is
reconnected, the system will return to the
mode it was in before the 12-volt battery
was discharged. Before disconnecting
the 12-volt battery, turn the power switch
off.
If you are unsure what mode the power
switch was in before the 12-volt battery
discharged, be especially careful when
reconnecting the 12-volt battery.
■
When replacing the 12-volt battery
●
Use a Central Degassing type 12-volt
battery (European Regulations).
●
Use a 12-volt battery with the same case
size as the previous 12-volt battery and an
epuivalent 20 hour rate capacity (20HR)
or greater.

484 8-2. Customization
LS500h_OM_OM50F42U_(U) ■
Head-up Display *
( → P.92)
*
:If equipped ■
Door lock ( → P.108, 112, 445)Function Default setting Customized set-
ting
Gauge information Hybrid System
Indicator Tachometer
— O — —
No content
Route guidance to destina-
tion/street name *
On Off — O — —
Driving support system dis-
play On Off — O — —
Compass *
On Off — O — —
Audio system operation sta-
tus On Off — O — —
Function Default setting Customized set-
ting
Unlocking using a mechani-
cal key Driver’s door
unlocked in one
step, all doors
unlocked in two
step All doors
unlocked in one
step — — — O
Automatic door locking func-
tion Shift position
linked door lock-
ing operation Off
O — — OSpeed linked
door locking
operation
Automatic door unlocking
function Shift position
linked door
unlocking opera-
tion Off
O — — ODriver’s door
linked door
unlocking opera-
tion
Locking/unlocking of the
trunk when all doors are
locked/unlocked On Off — — — O A B C D
A B C D

488 8-2. Customization
LS500h_OM_OM50F42U_(U) ■
Power windows and moon roof ( → P.151, 153)
■
Automatic light control system ( → P.185)
■
Lights ( → P.185)
*1
:Except for Canada *2
: If equipped Function Default setting Customized set-
ting
Mechanical key linked opera-
tion Off On — — — O
Wireless remote control
linked operation Off On (open only) — — — O
Wireless remote control
linked operation signal
(buzzer) On Off — — — O
Function Default setting Customized set-
ting
Light sensor sensitivity Standard -2 to 2 O — — O
Time elapsed before head-
lights automatically turn off
after doors are closed 30 seconds Off
O — — O60 seconds
90 seconds
Windshield wiper linked
headlight illumination On Off — — — O
Function Default setting Customized set-
ting
Daytime running lights On
Off *1
O — — O
Welcome lighting On Off — — — O
AFS (Adaptive Front-lighting
System) *2
On Off — — — O A B C D
A B C D
A B C D

4938-2. Customization
LS500h_OM_OM50F42U_(U) 8
Vehicle specifications *
:If equipped ■
Heated steering wheel *
( → P.336)*
:If equipped ■
Illumination ( → P.340)Right-hand rear seat tem-
perature preference in auto-
matic mode *
Standard -2 (cooler) to 2
(warmer) O — — O
Power switch linked auto-
matic activation of the
left-hand rear seat
heater/ventilator *
Off On O — — O
Power switch linked auto-
matic activation of the
right-hand rear seat
heater/ventilator *
Off On O — — O
Function Default setting Customized set-
ting
Steering wheel heating pref-
erence in automatic mode Standard -2 (low) to 2
(high) O — — O
Function Default setting Customized set-
ting
Time elapsed before the inte-
rior lights turn off 15 seconds Off
O — — O7.5 seconds
30 seconds
Operation after the power
switch is turned off On Off — — — O
Operation when the doors
are unlocked On Off — — — O
Operation when you
approach the vehicle with the
electronic key on your person On Off — — — O
Footwell lights On Off — — — OFunction Default setting Customized set-
ting A B C D
A B C D
A B C D

494 8-2. Customization
LS500h_OM_OM50F42U_(U) ■
Vehicle customization●
When the smart access system with
push-button start is off, the entry unlock
function cannot be customized.●
When the doors remain closed after
unlocking the doors and the timer acti-
vated automatic door lock function acti-
vates, signals will be generated in
accordance with the operation buzzer
volume and operational signal (Emer-
gency flashers) function settings.
●
Some settings can be changed using a
switch or the audio system screen. If a
setting is changed using a switch, the
changed setting will not be reflected on
the audio system screen until the power
switch is turned of f and then to ON
mode.
■
Clock settings screen
If the clock adjustment screen is displayed
continuously when attempting to change
the clock settings, the system may be mal- functioning. Have the vehicle inspected by
your Lexus dealer.Instrument panel ornament
light and door trim ornament
lights On Off — — — O
Time elapsed before the outer
foot lights turn off 15 seconds Off
O — — O7.5 seconds
30 seconds
Operation of the outer foot
lights when you approach the
vehicle with the electronic
key on your person On Off — — — O
Operation of the outer foot
lights when the doors are
unlocked On Off — — — O
Operation of the outer foot
lights when a door is opened On Off — — — O
Fading out of the outer foot
lights when they turn off Long Short — — — OFunction Default setting Customized set-
ting A B C D
