2018 Lexus ES300h navigation

1
ES300h_QG_OM33D51U_(U)
The Quick Guide is not intended as a substitute for your Owner’s
Manual. We strongly encourage you to review the Owner’s
Manual and supplementary manuals so you will have a better
understanding of your vehicle’s capabilities and limitations.
Air Conditioning System ................................................................................................................. 72
Audio System (with Lexus Display Audio System) Lexus Display Audio operation buttons............. ..................................................................68
Using the steering wheel switches to change audio sources......................................68
Audio menu screen .............................................................................................................. ........69
Operating the audio system using the steering wheel switches..................................71
Audio System (with navigation system)
*
Audio control screen ........................................................................................................... ........59
Remote control (steering wheel audio switches).............................................................59
Basic operation................................................................................................................ ...............60
Radio ...................................................................................................................................................60
DVD player/CD player ........................................................................................................... .... 61
Operating an iPod.............................................................................................................. ........... 62
Automatic High Beam ......................................................................................................................36
BSM (Blind Spot Monitor) .............................................................................................................. 47
Door Locks ............................................................................................................................... ..............89
Driving Mode Select Switch ..........................................................................................................48
Driving Position Memory ................................................................................................................ 23
Dynamic Radar Cruise Control ................................................................................................... 41
Energy Monitor/Consumption Screen .................................................................................... 14
EV Drive Mode ............................................................................................................................... ..... 29
Floor mat installation ............................................................................................................................ 11
Front Seats .............................................................................................................................................. 21
Fuel Tank Cap ....................................................................................................................................... 92
Garage Door Opener ......................................................................................................................82
Contents
*: These features may be operated by Voice Command (See P.75)

2
ES300h_QG_OM33D51U_(U)
Hands-free System For Cellular Phone (with Lexus Display Audio System)
How to register a Bluetooth
® phone ....................................................................................65
Registering favorites.......................................................................................................... ...........65
Dialing.................................................................................................................................................65
Dialing from the phonebook ..................................................................................................... 65
When the phonebook is empty................................................................................................66
Dialing from favorites ......................................................................................................... ..........66
To answer the phone ............................................................................................................ ........ 67
To refuse a call ............................................................................................................... ................. 67
Operating a phone using the steering wheel switches.................................................. 67
Hands-free System For Cellular Phone (with navigation system)
*
Bluetooth® phone pairing .........................................................................................................56
Contact transfer ............................................................................................................... .............. 57
Calling by name................................................................................................................ ............. 58
Receiving a call .............................................................................................................................. 58
Steering switches .............................................................................................................. ............ 58
Headlights ..............................................................................................................................................35
Head Restraints ............................................................................................................................... .... 22
Hybrid System ............................................................................................................................... ....... 12
Hybrid Transmission ........................................................................................................................ 30
Intuitive Parking Assist .....................................................................................................................46
Keys ............................................................................................................................................................ 18
LDA (Lane Departure Alert with steering control) ...........................................................45
Lexus Display Audio Controller (with Lexus Display Audio System) ........................63
LEXUS Enform ............................................................................................................................... .... 86
LEXUS Enform Safety Connect ..................................................................................................84
*: These features may be operated by Voice Command (See P.75)

3
ES300h_QG_OM33D51U_(U)
Moon Roof.............................................................................................................................................. 91
Multi-information Display ..............................................................................................................33
Navigation System
*
Register home .................................................................................................................. ...............54
Destination search ............................................................................................................. ...........55
Outside Rear View Mirrors ........................................................................................................... 25
Portable Audio Device Ports ....................................................................................................... 80
Power (Ignition) Switch ................................................................................................................... 26
Power Windows ............................................................................................................................... ...90
Rear Sunshade/Rear Door Sunshades ..................................................................................... 81
Remote Touch (with navigation system) ................................................................................. 50
Seat Heaters and Ventilators ....................................................................................................... 80
Smart Access System with Push-button Start ....................................................................... 19
Theft Deterrent System ...................................................................................................................20
Tire Pressure Warning System ....................................................................................................49
Trunk .........................................................................................................................................................93
Turn Signal Lever ............................................................................................................................... .32
Voice Command System Basic operation................................................................................................................ ............... 75
Command list ................................................................................................................... ............... 76
Windshield Wipers and Washer ..................................................................................................38
XM Satellite Radio ............................................................................................................................ 88
*: These features may be operated by Voice Command (See P.75)

6
ES300h_QG_OM33D51U_(U)
∗: If equipped
*: Refer to “OWNER’S MANUAL”.
Remote Touch screen∗
Navigation system∗
Lexus Display Audio system
∗
P.50
P.54
P.63
Clock*
Trunk opener main switch
P.93
Audio system P.59, 68
Air conditioning system P.72
Emergency flasher switch*
See P.9 Power (ignition) switch
P.26
Parking brake*
Tilt and telescopic st
eering control switch∗*
Floor mats P.11

14
ES300h_QG_OM33D51U_(U)
Energy Monitor/Consumption Screen
■Energy monitor
● How to display on the navigation system screen
Press the “MENU” button on the Remote Touc h, then select on the “Menu” screen,
and then select “Fuel Consumption”.
If the “Trip Information” or “Past Record” screen is di splayed, select “Energy”.
● How to display on the Lexus Display Audio screen
Press the “MENU” button on the Lexus Display Audio controller, then select “Info” on the
“Menu” screen, and then select “Fuel Consumption”.
If the “Energy Monitor” scre en does not appear, move the controller to the right and
select “Energy”.
You can view the status of your hybrid syst em on the multi-information display and the
navigation system screen or Le xus Display Audio system screen.
The flow of energy is displayed on the navigation system
screen.
Red: gasoline energy
Amber: electrical energy
Light blue: energy recovery
A light blue arrow appears when regenerative braking
occurs.
The flow of energy is displayed on the Lexus Display Audio
system screen.
Red: gasoline energy
Amber: electrical energy
Light blue: energy recoveryA light blue arrow appears when regenerative braking
occurs.

15
ES300h_QG_OM33D51U_(U)
●How to display on the mu lti-information display
Press or of the meter control switch es and select , and then press or
to select the energy monitor display.
■ Fuel Consumption
● Trip information
Navigation system screen
Press the “MENU” button on the Remote Touch, then select on the “Menu” screen,
and then select “Fuel Consumption”.
If the “Trip Information” screen does not appear, select “Trip Information”.
Resetting the consumption data
Fuel consumption in the past 15 min-
utes
Current fuel consumption
Regenerated energy in the past 15
minutes
One symbol indicates 50 Wh. Up to 5
symbols are shown.
Average vehicle speed since the hybrid
system was started
Elapsed time since the hybrid system
was started
Cruising range
The flow of energy is indicated by the movement of the
arrows on the multi-information display.
Red: gasoline energy
Amber: electrical energy
Light blue: energy recovery A light blue arrow appears when regenerative braking
occurs.
The displayed energy flow, battery level, etc. wi ll change in response to the current driving
conditions.
1
2
3
4
5
6
7

16
ES300h_QG_OM33D51U_(U)
Lexus Display Audio screen
Press the “MENU” button on the Lexus Display Audio controller, then select “Info” on the
“Menu” screen, and then select “Fuel Consumption”.
If the “Trip Information” screen does not appe ar, move the controller to the right and select
“Trip Information”.
Fuel consumption in the past 15 min-
utes
Current fuel consumption
Regenerated energy in the past 15
minutes
One symbol indicates 50 Wh. Up to 5
symbols are shown.
Average vehicle speed since the hybrid
system was started
Elapsed time since the hybrid system
was started
Cruising range
Average fuel consumption for the past 15 minutes is divided by color into past averages and
averages attained since the power switch was last turned to ON mode. Use the displayed
average fuel consumption as a reference.
The image is an example only.
● Past record
Navigation system screen
Press the “MENU” button on the Remote Touch, then select on the “Menu” screen,
and then select “ Fuel Consumption”.
If the “Past Record” screen does not appear, select “Past Record”.
Resetting the past record data
Best recorded fuel consumption
Average fuel consumption
Previous fuel consumption record
Updating the average fuel consump-
tion data
1
2
3
4
5
6
1
2
3
4
5

33
ES300h_QG_OM33D51U_(U)
Multi-information Display
Drive information
Select to display various drive data.
Navigation system-linked display (if equipped)
Select to display the following navigation system-linked information.
• Route guidance
• Compass display (north-up display/heading-up display)
Audio system-linked display
Select to enable selection of an audio source or track on the display using the
meter control switches.
Driving assist information
Select to display the dynamic radar cr uise control/LDA (Lane Departure Alert
with steering control) informatio n, when the system is used. (→P.41, 45)
Warning message display
Select to display warning messages and measures to be taken if a malfunction
is detected.
Settings display
Select to change the meter display settings.
The multi-information display presents the driver with a variety of vehicle data.
