2018 INFINITI QX30 buttons

5[USB1]/[USB2]:
Touch to switch to the other connected
USB memory device.
6Album artwork (if equipped):
An image of the CD cover is displayed
when available.
7Track number:
This indicates the track number and the
total number of tracks.
8[]/[]:
Touch to play or pause the track.
9USB menu:
USB menu items are displayed. Touch an
icon to display the list or to change the
setting.
- [Folder/Track]
- [Artists]
- [Albums]
- [Previous List]
- [Scan]
- [Play Mode]
10Play mode indicator:
This indicates the current play mode.
Touch to change the play mode.
Mode Screen display
All Track Repeat
All
1 Folder Repeat
1 Folder
1 Track Repeat
1 Track
All Random
All
1 Folder Random
1 Folder
11Folder number:
This indicates the folder, artist or album
number and the total number of folders/
lists.
USB memory device player
operation
Activation and playing:
USB memory device mode can also be acti-
vated from the audio source list and the audio
source bar by the touch panel operation or by
pushing .
Selecting audio source page 4-65
Main audio buttons page 4-64
To play the USB memory device touch [
],
and to pause the USB memory touch []
on the USB operation screen. Selecting play list:
Select a play list by touching an icon in the
USB menu.
•Folder/Track (List)
•Artist (List)
•Album (List)
•Previous List
Skipping tracks/folders:
Push to skip to the next
or previous track.
To skip to the next or previous folder, Push
.
Fast-forwarding/rewinding:
Push and hold to fast-
forward or rewind the track. Release •CAT•TRACK> to play the track at normal
speed.
Scanning:
Touch [Scan] on the display to scan the
tracks in the USB memory device. While
scanning, the USB memory device will play
the first 10 seconds of each track and move
on to the next track. Touching [Scan] again
within the 10 seconds will stop scanning.
4-74Display screen, heater and air conditioner, and audio system

- [Audiobooks]
- [Shuffle]
- [Repeat]
11Repeat mode indicator:
Touch to change the repeat mode.
Mode Screen display
All Track Repeat
All
1 Track Repeat
1 Track
Repeat Off
OFF
iPod player operation
Activation and playing:
Inserting the iPod cable into the connector
will activate the iPod mode.
iPod can also be selected from the audio
sources list and the source bar by touch panel
operation or by pushing .
Selecting audio source page 4-65
Main audio buttons page 4-64
To play and pause the iPod, touch [Play]/
[Pause] in the iPod menu.
Selecting search method:
A list of search methods is displayed in the
iPod menu. Touch and select an item to play
the iPod in your preferred settings. Fast-forwarding/rewinding:
Push and hold
to fast-
forward or rewind the song. Release •CAT•TRACK> to play the song at normal
speed.
Changing play mode:
Touch [Shuffle] or [Repeat] from the iPod
menu to select the play mode.
Skipping songs:
Push to skip to the
next or previous song.
Even when iPods or iPhones are inserted into
both of the two USB connectors, the system
recognizes only one of the connected iPods
or iPhones at a time.
BLUETOOTH® STREAMING
AUDIO
Your vehicle is equipped with Bluetooth®
Streaming Audio.
If you have a compatible Bluetooth® device
with streaming audio (A2DP profile), you can
set up a wireless connection between your
Bluetooth® device and the in-vehicle audio
system. This connection allows you to listen
to the audio from the Bluetooth® device us-
ing your vehicle speakers. It may also allow
basic control of the device for playing and skipping audio files using the AVRCP
Bluetooth® profile. Not all Bluetooth® de-
vices have the same level of controls for
AVRCP. Please consult the manual for your
Bluetooth® device for more details.
Wireless LAN (Wi-Fi) and the Bluetooth®
functions share the same frequency band
(2.4 GHz). Using the Bluetooth® and the
wireless LAN functions at the same time may
slow down or disconnect the communication
and cause undesired noise. It is recom-
mended that you turn off the wireless LAN
(Wi-Fi) when using the Bluetooth® functions.
Regulatory Information
FCC Regulatory information:
FCC ID : HYQDNNS075
NOTE: This device complies with part 15 of
the FCC Rules. Operation is subject to the
following two conditions: (1) This device may
not cause harmful interference, and (2) this
device must accept any interference received,
including interference that may cause unde-
sired operation.
FCC WARNING: Changes or modifications
not expressly approved by the party respon-
sible for compliance could void the user’s au-
thority to operate the equipment.
CAUTION : Radio Frequency Radiation Ex-
posure
4-78Display screen, heater and air conditioner, and audio system

9Random mode indicator:
Touch to change the random mode.
Mode Screen display
All Random
All
1 Folder Random
1 Folder
Random Off
OFF
Depending on the audio device that is con-
nected to the vehicle, track information may
not be displayed.
Bluetooth® streaming audio
operation
The ability to pause, change tracks, fast-
forward, rewind, randomize and repeat music
may be different between devices. Some or
all of these functions may not be supported
on each device.
•Depending on the Bluetooth® streaming
audio device that is connected, it may not
be possible to perform audio operations.
•Depending on the Bluetooth® streaming
audio device that is connected, a time lag
may occur before music is played back.
•Depending on the application except for
the native audio application that is played
on the Bluetooth® streaming audio device,
incorrect behavior (information lacking,
timer skipping, etc.) may occur.
Activation and playing:
Bluetooth® streaming audio device can be
selected from audio sources list by touching
[Source] or by pushing .
Selecting audio source page 4-65
Main audio buttons page 4-64
To play the Bluetooth® streaming audio de-
vice, touch [Play], and to pause the
Bluetooth® streaming audio device touch
[Pause] in the Bluetooth® streaming audio
menu.
Selecting folder/track:
Touch [Folder/Track] to select a folder/
track.
Changing play mode:
Touch [Repeat] or [Random] in the
Bluetooth® streaming audio menu to change
the play mode. Fast-forwarding/rewinding:
Push and hold
to fast-
forward or rewind the song. Release •CAT•TRACK> to play the song at normal
speed.
Skipping songs/folders:
Push to skip to the next
or previous song.
To skip to the next or previous folder, Push
.
Bluetooth® streaming audio
controls
Touch [Control] on the Bluetooth® Audio
operation screen to display the control
screen.
[Select Au-
dio Device] Touch to select a different
Bluetooth® streaming audio device
from a list of registered Bluetooth®
devices.
See "Bluetooth® settings" later in
this section
[Connect
Device] Touch to connect a new
Bluetooth® device.
Display screen, heater and air conditioner, and audio system4-81

ASettings key
B

4. Fit the replacement battery in the vehicle.
REINITIALISATION PROCEDURE
AFTER BATTERY
RECONNECTION
If the battery has been reconnected, check
the following items:
•Clock setting (if so equipped). For details,
see "Clock" in the "2. Instruments and con-
trols" section, or the separately provided
navigation system Owner's Manual, or the
audio device descriptions in " Audio system
(if equipped)" in the "4. Display screen,
heater and air conditioner, and audio sys-
tem" section.
•Reset the desired radio stations to the pre-
set station buttons. For details, see the
audio device descriptions in the “4. Heater
and air conditioner, and audio system”.
JUMP-STARTING
If jump-starting is necessary, see "Jump
starting" in the "6. In case of emergency" sec-
tion. If the engine does not start by jump
starting, the battery may have to be replaced.
It is recommended that you visit an INFINITI
retailer for this service.
WARNING
Be sure the ignition switch is in the OFF
position before servicing drive belt. The en-
gine could rotate unexpectedly.
1. Visually inspect each belt for signs of un- usual wear, cuts, fraying or looseness. If
the belt is in poor condition or loose, have
it replaced or adjusted. It is recommended
that you visit an INFINITI retailer for this
service.
2. Have the belts checked regularly for con- dition and tension in accordance with the
maintenance schedule as shown in a
separately provided Warranty Informa-
tion and Maintenance booklet.
NDI1635
DRIVE BELT
8-12Do-it-yourself

4. Repeatedly tap the key against your palmuntil battery
1falls out. 5. Insert the new battery with the positive
terminal facing upwards. Use a lint-free
cloth to do so.
6. Make sure that the surface of the battery is free of lint, grease and other contami-
nation.
7. Insert the front tabs of battery cover
1and then press to close it.
8. Insert emergency key element into the key (see "Mechanical key" in the "3. Pre-
driving checks and adjustments" section).
9. Check the function of all key buttons on the vehicle.
If you need assistance with replacement, it is
recommended that you visit an INFINITI re-
tailer for this service. FCC Notice:
For USA:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not
cause harmful interference, and (2) this de-
vice must accept any interference received,
including interference that may cause unde-
sired operation.
NOTE
Changes or modifications not expressly ap-
proved by the party responsible for compli-
ance could void the user’s authority to oper-
ate the equipment.
For Canada:
This device complies with Industry Canada
license-exempt RSS standard(s). Operation
is subject to the following two conditions: (1)
this device may not cause interference, and
(2) this device must accept any interference,
including interference that may cause unde-
sired operation of the device.
NPA1473SPA0784Z
Do-it-yourself8-21
