HAZARD WARNING
LIGHTS
CONTROL
Press the button fig. 137 to switch the
lights on/off.
When the hazard warning lights are on,
the
andwarning lights flash.
IMPORTANT The use of hazard warning
lights is governed by the highway code
of the country you are driving in:
comply with legal requirements.
Emergency braking
In the event of emergency braking the
hazard warning lights switch on
automatically as well as warning lights
andin the instrument panel.
The lights switch off automatically when
emergency braking ceases.
BULB
REPLACEMENT
139) 140) 141)
61)
GENERAL
INSTRUCTIONS
Before replacing a bulb check the
contacts for oxidation;
replace blown bulbs with others of
the same type and power;
after replacing a headlight bulb,
always check its alignment;
when a light is not working, check
that the corresponding fuse is intact
before changing the bulb. For the
location of fuses, refer to the paragraph
"If a fuse blows" in this chapter.
IMPORTANT When the weather is cold
or damp or after heavy rain or washing,
the surface of headlights or rear lights
may steam up and/or form drops of
condensation on the inside. This is a
natural phenomenon due to the
difference in temperature and humidity
between the inside and the outside of
the glass which does not indicate a
fault and does not compromise the
normal operation of lighting devices.
The mist disappears quickly when the
lights are turned on, starting from the
centre of the diffuser, extending
progressively towards the edges.137P2000021-000-000
139

Light bulbs Type Power Figure reference
Daytime running lights (DRL) (versions with polyelliptical
headlights)LED – –
Front side lights/Daytime running lights (DRL) (versions with
bi-parabolic headlights)H15 15W 4
Main beam headlights (versions with polyelliptical headlights) H7 55W 3
Main beam headlights (versions with bi-parabolic headlights) H15 55W 4
Dipped headlights H7 55W 3
Main beam/dipped beam headlights (Xenon gas discharge)
(for versions/markets, where provided)D5S 25W 5
Front direction indicators PY21W 21W 2
Side turn light WY5W 5W 1
Number plate W5W 5W 1
Rear side/brake light P21W 21W 2
Rear direction indicators PY21W 21W 2
Reverse gear W16W 16W 1
3rd stop LED – –
Fog lights H11 55W 4
Rear fog light W16W 16W 1
Front ceiling light C5W 5W 1
Front roof lights (sun visors) C5W 5W 1
Rear ceiling light C5W 6W 1
Luggage compartment light W5W 5W 1
Glove compartment light W5W 5W 1
141

REPLACING AN
EXTERNAL BULB
Versions with poly-elliptical
headlights
Front bulb position
1. Dipped beam headlights
2. Fog lights
3. Main beams
4. Daytime running lights (DRL)
5. Direction indicatorsDipped beam headlights
To replace the bulb 1fig. 138, proceed
as follows:
working from inside the engine
compartment, remove rubber
protection cap 1 fig. 139;
disconnect the electrical connector,
then release the retainer clip;
replace bulb 2;
reconnect the electrical connector
and reconnect the lamp-connector
assembly in its housing;
re-engage the retainer clip, making
sure that it is secured;
refit the rubber cap 1.
Main beams
To replace the bulb 3 fig. 138, proceed
as follows:
working from inside the engine
compartment, remove rubber
protection cap 2 fig. 140;
extract the lamp-electrical connector
assembly;
disconnect the electrical connector
3 and replace the bulb 4;
reinsert the lamp-electrical connector
assembly in its housing, making sure
that it is blocked properly.
Front direction indicators
To replace the bulb 5 fig. 138, proceed
as follows:
turn the bulb-bulb holder assembly 1
fig. 141 anticlockwise by approximately
1/4 a turn and extract it;
replace lamp 2 by pressing it lightly
(axially) and simultaneously turning it
anticlockwise (bayonet fitting);
reinsert the bulb-bulb holder
assembly in its housing, then turn the
assembly 2 clockwise, making sure that
it is blocked.
138P1030127-000-000
139P1030234-000-000
140P1030234-000-001
142
IN AN EMERGENCY

Front fog lamps
To replace the bulb 2 fig. 138, proceed
as follows:
steer the car wheels inwards;
undo screw 1 fig. 142 using the
screwdriver provided and remove
inspection flap 2;
turn the bulb-bulb holder assembly
3 anticlockwise by a 1/4 turn and
extract it;
disconnect the electrical connector
and replace the complete assembly;
reconnect the electrical connector to
the new bulb-bulb holder assembly;
fit the assembly in its housing,
turning it clockwise and making sure
that it is blocked properly;
finally, refit the inspection flap 1.
Daytime running lights (DRL)
The daytime running light bulbs 4
fig. 138 are LED to increase their
lifetime; therefore, they should not
require replacing. Contact the Fiat
Dealership in the event of any kind of
problem.
Side turn light
To replace the bulb, proceed as follows:
press the lens 1 fig. 143 to compress
in the internal clip 2, then pull the
cluster outwards; take great care not
damage the paintwork;;
turn the bulb holder 2 anticlockwise,
then extract the press-fit bulb 3 and
replace it;
refit the bulb holder 2 in the lens
1 and turn it clockwise;
refit the cluster making sure that the
internal clip clicks into position.Versions with bi-parabolic
headlights
Front bulb position
1. Dipped headlights
2. Fog lights
3. Main beam headlights / Daytime
running lights (DRL)/ Positions
4. Direction indicator.
141P2000185
142P2000135
143P1030251-000-000
14408026J0002EM
143

Main beam headlights / Daytime
running lights (DRL)/ Positions
To replace the bulb 3 fig. 144, proceed
as follows:
working from inside the engine
compartment, remove rubber cap 1
fig. 145;
rotate the bulb-bulb holder assembly
anticlockwise and extract it;
disconnect the electrical connector
and replace the bulb-bulb holder
assembly 2;
reconnect the electrical connector to
the new assembly;
then insert the assembly in its
housing and turn it clockwise, making
sure that it is locked correctly;
refit the rubber cap 1.
IMPORTANT Only replace the bulb
when the engine is off. Also ensure that
the engine is cold, to prevent the risk of
burns.
Dipped beam headlights
Right headlight
To replace the bulb 1 fig. 144, proceed
as follows:
steer the car wheels completely
inwards;
adjust the tabs indicated in
fig. 146 and remove the flap;
remove the rubber cap;
disconnect the electrical connector;
extract the bulb, releasing it from the
retaining springs;
replace the new bulb and carry out
the procedure described previously in
reverse.Left headlight
working from inside the engine
compartment, remove the rubber cap
from the dipped beam headlight bulb 1
fig. 144;
extract the bulb, releasing it from the
retaining springs;
disconnect the electrical connector
and replace the bulb 1 fig. 144;
reconnect the electrical connector to
the new bulb;
reposition the assembly in the seat;
refit the rubber cap.
IMPORTANT Only replace the bulb
when the engine is off. Also ensure that
the engine is cold, to prevent the risk of
burns.
Front direction indicators
To replace the bulb 4 fig. 144, proceed
as follows:
rotate the bulb-bulb holder assembly
anticlockwise;
replace the "bayonet-fitted" bulb;
then insert the bulb-bulb holder
assembly in its housing and turn it
clockwise, making sure that it is locked
correctly.
Fog lights
To replace the bulbs, proceed as
follows:
steer the car wheels completely
inwards;
14508026J0025EM
14608026J0004EM
144
IN AN EMERGENCY

undo screws 1 fig. 142 using the
screwdriver provided and remove
inspection flap 2;
turn the bulb-bulb holder assembly 1
fig. 147 anticlockwise and then remove
it sliding it outwards;
disconnect the electrical connector;
reconnect the connector to the new
assembly: then insert it, turning it
clockwise, ensuring that it locks
correctly;
finally, refit the inspection flap.
Side turn light
To replace the bulb, proceed as follows:
press the lens 1 fig. 148 to compress
in the internal clip 2, then pull the
cluster outwards;
turn the bulb holder 3 anticlockwise,
extract the press-fitted bulb 4 and
replace it;
refit the bulb holder 3 in the lens and
turn it clockwise;
refit the cluster making sure that the
internal clip 2 clicks into position.
Versions with Xenon gas discharge
headlights
Main/dipped beam headlights
(for versions/markets, where provided)
For replacing these bulbs, contact a
Fiat Dealership.Rear bulb position
1. Positions
2. Tail lights/Brake lights
3. Direction indicator
4. Reverse gear
Light cluster on tailgate
Tail and reversing lights
To change one or more bulbs, proceed
as follows:
open the tailgate and use the
screwdriver provided to remove the
press-fit inspection flap 1 fig. 150;
14708026J0016EM
14808026J0005EM
149P1030154-000-000
145

INDEX
ABS (system)...............74
Active Grille Shutter............44
Active safety systems...........74
Adaptive cruise control.........121
Airbag
Front airbags.............102
Side bags...............106
Airbag (SRS supplementary
restraint system)...........102
Automatic climate control system.......................31
Automatic light control..........23
Automatic transmission.....111 ,166
AUX source.............254 ,268
Battery..................193
Battery recharging............195
Bluetooth® source........254 ,267
Bodywork (cleaning and
maintenance).............201
Bonnet....................33
Carrying children safely.........90
Changing a wheel............155
Checking levels..............184
Child protection systems........90
Child safety device............14
Climate control system..........29
CO2 emissions..............232
Control buttons..............54Control panel and on-board
instruments...............47
Controls
Controls on the front panel. . . .248
Controls on front panel.........260
Courtesy lights...............25
Daytime running lights (DRL)......23
Daytime running lights (DRL) (bulb
replacement)..............143
Dimensions................216
Dipped headlights.............23
Dipped headlights (bulb
replacement)..............142
Direction indicators............25
Display....................52
Doors.....................14
Double load compartment (TIPO
STATION WAGON version)......38
Driving assistance systems.......77
DTC (system)................74
Dual-clutch automatic
transmission..........114 ,168
ECO function...............45
Electric power steering..........34
Electric windows..............33
Electronic Cruise Control........120
Engine...................206
................205
Engine compartment..........184
Engine compartment (washing). . . .201Engine oil (consumption)........192
Engine oil (level check).........192
ERM (system)................75
ESC (system)................74
External lights...............23
Fiat Code (system)............13
Fix&Go Automatic kit..........159
Flashing the headlights..........23
Fluids and lubricants..........225
Fog lights..................24
Front ceiling light..............26
Front fog light (bulb replacement) . .143
Front panel control summary
table...................261
Front seat electric heating........16
Front seats (manual adjustments) . . .16
Fuel consumption............229
Fuel cut-off system...........164
Full Brake Control (system).......77
Fuse boxes................149
Fuses (replacement)...........148
GSI (Gear Shift Indicator)........52
Hazard warning lights.........139
Emergency braking.........139
Head restraints...............20
Headlight alignment corrector.....24
Headlights (cleaning)..........201
Heavy-duty use of the vehicle
(scheduled servicing)........183
Marking

HHC (system)................75
i-Size child restraint systems......96
Identification data
...........205
............205
.......205
Ignition device...............12
Important information and
recommendations..........276
Interior lights................26
Interiors (cleaning)............202
ISOFIX child restraint system
(installation)...............94
iTPMS (indirect Tyre Pressure
Monitoring System)..........81
Jump starting..............162
Key removal (automatic
transmission).............166
Key removal (dual-clutch
automatic transmission).......168
Keys.....................11
key with remote control.......11
Lever release (automatic
transmission).............166
Lever release (dual-clutch
automatic transmission).......168
Lifting the vehicle.............199
Light bulbs
Bulbs types..............140
Luggage Compartment.........35Luggage compartment
(extension)................17
Luggage covering curtain (TIPO
STATION WAGON version)......37
Main beam headlights..........23
Main Beam Headlights (bulb
replacement)..............142
Main menu.................53
Manual climate control..........29
Manual gearbox.............111
Media mode...............266
Multi-functional display - Right
hand drive version...........50
Multi-Functional Reconfigurable
Display - Right hand drive
version..................51
Multifunction display...........47
Multimedia
Uconnect™ LIVE Services .256 ,269
Number plate lights (bulb
replacement)..............147
Occupant protection systems.....84
Official type approvals.........275
Paintwork (cleaning and
maintenance).............201
Parking Brake...............110
Parking lights................23
Parking sensors.............129
Parking the vehicle...........110Passive/active safety (LPG
system)..................41
PBA (system)................75
Performance (top speed)........228
Periodic checks (scheduled
servicing)................183
Pre-tensioners...............88
Load limiters..............88
Prescriptions for handling the
vehicle at the end of its life.....234
Radio mode...............266
Rain sensor.................28
Rear seats..................17
Rear view camera............131
Rear View Camera............131
Rear view mirrors.............21
Reconfigurable Multifunction
Display..................48
Refuelling.................222
Refuelling procedure..........135
Emergency refuelling........135
Refuelling the vehicle..........134
Replacing a bulb.............139
Replacing an external bulb......142
Rims and tyres (dimensions)......210
Roof rack/ski rack.............40
SBR (Seat Belt Reminder).......86
SBR (Seat Belt Reminder) system . . .86
Scheduled servicing...........172
INDEXChassis marking
Engine marking
Identification data plate
