2018 CHRYSLER PACIFICA HYBRID seat memory

HIGH VOLTAGE BATTERY
Your vehicle is equipped with a Lithium-ion high voltage
battery that is used to power the electric powertrain
systems and the 12 volt vehicle electrical system.
The high voltage battery is located under the middle
section of the vehicle, below and in front of the second row
seating. The high voltage battery is maintenance free and
designed to last for the life of the vehicle.
Lithium-ion batteries provide the following benefits:
•Lithium-ion batteries are much lighter than other types
of rechargeable batteries of the same size.
• Lithium-ion batteries hold their charge; they only lose
approximately 3 percent of their charge per month.
• Lithium-ion batteries have no memory, which means
that you do not have to completely discharge them
before recharging, as with some other batteries.
• Lithium-ion batteries can be recharged and discharged
thousands of times. High Voltage Battery Service Disconnect
The High Voltage Battery Service Disconnect is located
under the access panel, in front of the second row passen-
ger seating.
If your vehicle requires high voltage battery service, see
your authorized dealer.
WARNING!
Never try to remove the high voltage service discon-
nect. The high voltage service disconnect is used when
your vehicle requires service by a trained technician at
an authorized dealer. Failure to follow this warning
can cause severe burns or electrical shock that may
result in serious injury or death.
Disposal of the High Voltage Battery
Your vehicle’s high voltage battery is designed to last the
life of your vehicle. See your authorized dealer for infor-
mation on the disposal of the battery if it should require
replacement.
18 GETTING TO KNOW YOUR VEHICLE

If the system is set when the vehicle speed is below 20 mph
(32 km/h), the set speed shall be defaulted to 20 mph
(32 km/h). If the system is set when the vehicle speed is
above 20 mph (32 km/h), the set speed shall be the current
speed of the vehicle.
NOTE:ACC cannot be set if there is a stationary vehicle in
front of your vehicle in close proximity.
Remove your foot from the accelerator pedal, after the
ACC has been set. If you do not, the vehicle may continue
to accelerate beyond the set speed. If this occurs:
• The message “ACC DRIVER OVERRIDE” will display
in the instrument cluster display.
• The system will not be controlling the distance between
your vehicle and the vehicle ahead. The vehicle speed
will only be determined by the position of the accelera-
tor pedal.
To Cancel
The following conditions cancel the system:
• The brake pedal is applied.
• The CANC (cancel) button is pushed.
• An Anti-Lock Brake System (ABS) event occurs. •
The gear selector is removed from the DRIVE position.
• The Electronic Stability Control/Traction Control Sys-
tem (ESC/TCS) activates.
• The vehicle parking brake is applied.
• Driver seatbelt is unbuckled at low speeds.
• Driver door is opened at low speeds.
To Turn Off
The system will turn off and clear the set speed in memory
if:
•The Adaptive Cruise Control (ACC) on/off button is
pushed.
• The Normal (Fixed Speed) Cruise Control on/off button
is pushed.
• The ignition is turned OFF.
To Resume
If there is a set speed in memory push the RES (resume)
button and then remove your foot from the accelerator
pedal. The instrument cluster display will display the last
set speed.
6
STARTING AND OPERATING 301

Setting NameSelectable Options
Personal Settings Linked to Key Fob — If Equipped On
Off
NOTE:
The “Personal Settings Linked to Key Fob” feature provides automatic recall of all settings stored to a memory loca-
tion (driver ’s seat, exterior mirrors, steering column position and radio station pre-sets) to enhance driver mobility
when entering and exiting the vehicle.
The seat returns to the memorized seat location, if the settings is set to “On,” when the key fob is used to unlock the
door.
Auto- On Comfort — If Equipped
After pressing the “Auto-On Comfort” button on the
touchscreen, the following settings will be available:
Setting Name Selectable Options
Auto-On Driver Heated/
Ventilated Seat & Steering Wheel With Vehicle Start — If Equipped Off
Remote Start All Starts
NOTE:
When this feature is selected, the driver ’s heated seat and heated steering wheel will automatically turn on when
temperatures are below 40° F (4.4° C). When temperatures are above 80° F (26.7° C) the driver vented seat will turn
on.
526 MULTIMEDIA

Side Marker........................ .387, 388
SmartBeams .............................95
Tire Pressure Monitoring (TPMS) ..........180, 207
Traction Control ........................ .194
Turn Signal ....................93, 182, 274, 387
Warning (Instrument Cluster Description) . . . .174, 182
Load Floor, Cargo ......................... .134
Loading Vehicle ....................... .134, 370
Tires................................. .467
Load Shed Battery Saver Mode ...................... .170
Battery Saver On ........................ .170
Electrical Load Reduction ...................170
Intelligent Battery Sensor ...................170
Low Tire Pressure System .....................207
Lubrication, Body ......................... .445
Luggage Rack (Roof Rack) ....................150
Lug Nuts ............................... .492
Maintenance Free Battery .....................437
Maintenance Schedule ...................... .431
Malfunction Indicator Light (Check Engine) ........185
Manual, Service ........................... .592
Map/Reading Lights .........................98
Marker Lights, Side ........................ .387Master Cylinder (Brakes)
.....................459
Memory Feature (Memory Seat) .................68
Memory Seat ..............................68
Memory Seats And Radio .....................68
Methanol ............................... .495
Mirrors ..................................89
Automatic Dimming .......................89
Electric Remote ...........................91
Exterior Folding ..........................92
Heated ............................. .89, 92
Outside ............................. .89, 90
Rearview ........................... .89, 378
Vanity .................................93
Modifications/Alterations, Vehicle ................6
Monitor, Tire Pressure System ..................207
Mopar

Parts ............................. .591
Multi-Function Control Lever ...................93
New Vehicle Break-In Period ..................281
Occupant Restraints ........................ .213
Octane Rating, Gasoline (Fuel) ..............494, 499
Oil, Engine ........................... .438, 499
Capacity .............................. .498
Change Interval ........................ .438
12
INDEX 601

Seat Belt Extender....................... .225
Seat Belt Pretensioner .....................226
Seat Belt Reminder ...................... .214
Seat Belt Maintenance ...................... .488
Seat Belt Reminder ........................ .214
Seat Belts ............................ .214, 272
Adjustable Shoulder Belt ...................219
Adjustable Upper Shoulder Anchorage .........219
Child Restraint ......................... .248
Extender .............................. .225
Front Seat ...................... .214, 215, 217
Inspection ............................. .272
Operating Instructions .....................217
Pregnant Women ........................ .225
Pretensioners .......................... .226
Rear Seat ............................. .215
Reminder ............................. .173
Untwisting Procedure .....................219
Seats .............................. .68, 73, 74
Adjustment ....................... .68, 70, 73
Easy Entry ..............................68
Heated ............................. .68, 74
Memory ................................68
Power .................................72
Rear Folding .............................68 Reclining
...............................69
Seatback Release ...................... .68, 70
Tilting .............................. .68, 70
Vented .................................68
Ventilated ...............................68
Security Alarm ........................... .176
Arm The System ..........................54
Disarm The System ........................54
Selection Of Coolant (Antifreeze) ...............499
Sentry Key Key Programming .........................53
Sentry Key Replacement ......................53
Service Assistance ......................... .588
Service Contract .......................... .590
Service
Manuals .......................... .592
Shoulder Belts ............................ .215
Side View Mirror Adjustment ...................89
Signals, Turn .....................93, 182, 274, 387
Siri .................................... .581
SiriusXM Guardian Vehicle Health Alert ...................... .579
SmartBeams ...............................95
Snow Chains (Tire Chains) ....................482
Snow Tires .............................. .478
Spare Tire ............................ .478, 480
604 INDEX
