Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
Driving and Operating 329
Warning (Continued)
(20-25 mph) and fully apply
the manual trailer brake
apply lever. Also check that
the trailer brake lamps and
other lamps are functioning
correctly.
. If the trailer brakes are not
operating properly at any
time, or if a DIC message
indicates problems with the
trailer connections or trailer
brakes, carefully pull the
vehicle over to the side of
the road when traffic
conditions allow.
Conversions and
Add-Ons
Add-On Electrical
Equipment
{Warning
The Data Link Connector (DLC) is
used for vehicle service
and Emission Inspection/
Maintenance testing. See
Malfunction Indicator Lamp
(Check Engine Light) 0147.
A device connected to the DLC —
such as an aftermarket fleet or
driver-behavior tracking device —
may interfere with vehicle
systems. This could affect vehicle
operation and cause a crash.
Such devices may also access
information stored in the vehicle’s
systems.
Caution
Some electrical equipment can
damage the vehicle or cause
components to not work and
would not be covered by the
vehicle warranty. Always check
with your dealer before adding
electrical equipment.
Add-on equipment can drain the
vehicle's 12-volt battery, even if the
vehicle is not operating.
The vehicle has an airbag system.
Before attempting to add anything
electrical to the vehicle, see
Servicing the Airbag-Equipped
Vehicle 090 and Adding Equipment
to the Airbag-Equipped Vehicle
0 90.
For information on wiring auxiliary
switches, see www.gmupfitter.com
or contact your dealer.

Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
356 Vehicle Care
Turn the pressure cap slowly
counterclockwise about one full
turn. If a hiss is heard, wait for
that to stop. A hiss means
there is still some pressure left.
2. Keep turning the pressure cap slowly, and remove it.
3. Fill the coolant surge tank with the proper mixture to the full
cold mark.
4. With the coolant surge tank pressure cap off, start the
engine and let it run until the
engine coolant temperature
gauge indicates approximately
90 °C (195 °F).
By this time, the coolant level
inside the coolant surge tank
may be lower. If the level is
lower, add more of the proper
mixture to the coolant surge
tank until the level reaches the
full cold mark.
5. Replace the pressure cap tightly. 6. Verify coolant level after the
engine is shut off and the
coolant is cold. If necessary,
repeat coolant fill procedure
Steps 1–6.
Caution
If the pressure cap is not tightly
installed, coolant loss and engine
damage may occur. Be sure the
cap is properly and tightly
secured.
Engine Overheating
If the vehicle has the Duramax
diesel engine, see the Duramax
diesel supplement.
Caution
Do not run the engine if there is a
leak in the engine cooling system.
This can cause a loss of all
coolant and can damage the
system and vehicle. Have any
leaks fixed right away. The vehicle has several indicators
to warn of engine overheating.
There is a coolant temperature
gauge in the vehicle's instrument
cluster. See
Engine Coolant
Temperature Gauge 0142.
In addition, there are ENGINE
OVERHEATED STOP ENGINE,
ENGINE OVERHEATED IDLE
ENGINE, and ENGINE POWER IS
REDUCED messages in the Driver
Information Center (DIC).
If the decision is made not to lift the
hood when this warning appears,
get service help right away. See
Roadside Assistance Program
0 465.
If the decision is made to lift the
hood, make sure the vehicle is
parked on a level surface.
4.3L V6, 5.3L V8, and 6.2L
V8 Engines
Check to see if the engine cooling
fans are running. If the engine is
overheating, the fans should be

Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
360 Vehicle Care
Adding Washer Fluid
The vehicle has a low washer fluid
message on the DIC that comes on
when the washer fluid is low. The
message is displayed for
15 seconds at the start of each
ignition cycle. When the WASHER
FLUID LOW ADD FLUID message
displays, washer fluid will need to
be added to the windshield washer
fluid reservoir.
Open the cap with the washer
symbol on it. Add washer fluid until
the tank is full. SeeEngine
Compartment Overview 0338 for
reservoir location.
Caution
. Do not use washer fluid that
contains any type of water
repellent coating. This can
cause the wiper blades to
chatter or skip.
. Do not use engine coolant
(antifreeze) in the
windshield washer. It can
damage the windshield
washer system and paint.
. Do not mix water with
ready-to-use washer fluid.
Water can cause the
solution to freeze and
damage the washer fluid
tank and other parts of the
washer system.
. When using concentrated
washer fluid, follow the
manufacturer instructions for
adding water.
. Fill the washer fluid tank
only three-quarters full when
it is very cold. This allows
(Continued)
Caution (Continued)
for fluid expansion if
freezing occurs, which could
damage the tank if it is
completely full.
Brakes
Disc brake pads have built-in wear
indicators that make a high-pitched
warning sound when the brake pads
are worn and new pads are needed.
The sound can come and go or be
heard all the time the vehicle is
moving, except when applying the
brake pedal firmly.
{Warning
The brake wear warning sound
means that soon the brakes will
not work well. That could lead to
a crash. When the brake wear
warning sound is heard, have the
vehicle serviced.

Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
450 Service and Maintenance
Shocks and Struts
Shocks and struts help aid in control
for a smoother ride.
.Signs of wear may include
steering wheel vibration, bounce/
sway while braking, longer
stopping distance, or uneven
tire wear.
. As part of the multi-point
inspection, trained dealer
technicians can visually inspect
the shocks and struts for signs
of leaking, blown seals,
or damage, and can advise
when service is needed.
Tires
Tires need to be properly inflated,
rotated, and balanced. Maintaining
the tires can save money and fuel,
and can reduce the risk of tire
failure.
. Signs that the tires need to be
replaced include three or more
visible treadwear indicators; cord
or fabric showing through the rubber; cracks or cuts in the
tread or sidewall; or a bulge or
split in the tire.
. Trained dealer technicians can
inspect and recommend the right
tires. Your dealer can also
provide tire/wheel balancing
services to ensure smooth
vehicle operation at all speeds.
Your dealer sells and services
name brand tires.
Vehicle Care
To help keep the vehicle looking like
new, vehicle care products are
available from your dealer. For
information on how to clean and
protect the vehicle’s interior and
exterior, see Interior Care 0436 and
Exterior Care 0430.
Wheel Alignment
Wheel alignment is critical for
ensuring that the tires deliver
optimal wear and performance.
. Signs that the alignment may
need to be adjusted include
pulling, improper vehicle
handling, or unusual tire wear. .
Your dealer has the required
equipment to ensure proper
wheel alignment.
Windshield
For safety, appearance, and the
best viewing, keep the windshield
clean and clear.
. Signs of damage include
scratches, cracks, and chips.
. Trained dealer technicians can
inspect the windshield and
recommend proper replacement
if needed.
Wiper Blades
Wiper blades need to be cleaned
and kept in good condition to
provide a clear view.
. Signs of wear include streaking,
skipping across the windshield,
and worn or split rubber.
. Trained dealer technicians can
check the wiper blades and
replace them when needed.

Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
Index 489
California (cont'd)Perchlorate Materials
Requirements . . . . . . . . . . . . . . . 336
California
Proposition
65 Warning . . . . . . . . . .336, 362, 421, Back Cover
Canadian Vehicle Owners . . . . . . . . 2
Capacities and Specifications . . . . . . . . . . . . . . . . . 457
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 256
Tailgate . . . . . . . . . . . . . . . . . . . . . . . . . 43
Winter Driving . . . . . . . . . . . . . . . . 237
Cargo Tie-Downs . . . . . . . . . . . . . . . . . . . . 126
Cargo Lamp . . . . . . . . . . . . . . . . . . . . 177
Caution, Danger, and Warning . . . . 3
Center Console Storage . . . . . . . . 125
Center High-Mounted Stoplamp (CHMSL) and
Cargo Lamp . . . . . . . . . . . . . . . . . . . 375
Center Seat . . . . . . . . . . . . . . . . . . . . . 59
Chains, Tire . . . . . . . . . . . . . . . . . . . . 408
Charging
Wireless . . . . . . . . . . . . . . . . . . . . . . 134
Charging System Light . . . . . . . . . 147 Check
Engine Light (Malfunction
Indicator) . . . . . . . . . . . . . . . . . . . . 147
Ignition Transmission Lock . . . 368
Child Restraints Infants and Young Children . . . . . 94
Lower Anchors and Tethersfor Children . . . . . . . . . . . . . . . . . . . 99
Older Children . . . . . . . . . . . . . . . . . . 92
Securing . . . . . . . . . . . . . 111, 114, 115
Systems . . . . . . . . . . . . . . . . . . . . . . . . 96
Circuit Breakers . . . . . . . . . . . . . . . . 376
Cleaning Exterior Care . . . . . . . . . . . . . . . . . 430
Interior Care . . . . . . . . . . . . . . . . . . 436
Climate Control
Systems . . . . . . . . . . . . . . . . . 216, 218
Air Conditioning . . . . . . . . . 216, 218
Dual Automatic . . . . . . . . . . . . . . . 220
Heating . . . . . . . . . . . . . . . . . . 216, 218
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Cluster, Instrument . . . . . . . . . . . . . 137
Clutch, Hydraulic . . . . . . . . . . . . . . . 351
Collision Damage Repair . . . . . . . 468
Compartments
Storage . . . . . . . . . . . . . . . . . . . . . . . 124
Compass . . . . . . . . . . . . . . . . . . . . . . . 131 Connections
OnStar . . . . . . . . . . . . . . . . . . . . . . . 478
Control Hill Descent . . . . . . . . . . . . . . . . . . 277
Traction and ElectronicStability . . . . . . . . . . . . . . . . . . . . . 276
Control Light
Hill Descent . . . . . . . . . . . . . . . . . . 151
Control of a Vehicle . . . . . . . . . . . . . 228
Convex Mirrors . . . . . . . . . . . . . . . . . . 47
Coolant Engine Temperature Gauge . . 142
Cooling . . . . . . . . . . . . . . .216, 218, 220
Cooling System . . . . . . . . . . . . . . . . . 352
Courtesy Transportation Program . . . . . . . . . . . . . . . . . . . . . . . 467
Cruise Control . . . . . . . . . . . . . . . . . . 279 Light . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Cupholders . . . . . . . . . . . . . . . . . . . . . 125
Customer Assistance . . . . . . . . . . . 464 Offices . . . . . . . . . . . . . . . . . . . . . . . . 463
Text Telephone (TTY)
Users . . . . . . . . . . . . . . . . . . . . . . . 464
Customer Information Service Publications
Ordering Information . . . . . . . . 470
Customer Satisfaction Procedure . . . . . . . . . . . . . . . . . . . . . 461

Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
Index 491
F
FanEngine . . . . . . . . . . . . . . . . . . . . . . . . 358
Fast Idle System . . . . . . . . . . . . . . . . 251
Features Memory . . . . . . . . . . . . . . . . . . . . . . . . . 13
Filter, Engine Air Cleaner . . . . . . . . . . . 351
Fixed Mast Antenna . . . . . . . . . . . . 189
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 174
Flashers, Hazard Warning . . . . . . 175
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 408 Changing . . . . . . . . . . . . . . . . . . . . . 410
FlexFuel
E85 . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Floor Console Storage . . . . . . . . . . 126
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 439
Fluid Automatic
Transmission . . . . . . . . . . . 347, 350
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 361
Four-Wheel Drive Transfer Case . . . . . . . . . . . . . . . 265
Power Steering . . . . . . . . . . . . . . . 359
Washer . . . . . . . . . . . . . . . . . . . . . . . 359
Fog Lamps . . . . . . . . . . . . . . . . . . . . . 176 Bulb Replacement . . . . . . . . . . . . 373
Folding Mirrors . . . . . . . . . . . . . . . . . . 49 Forward Automatic Braking . . . . . 287
Forward Collision Alert
(FCA) System . . . . . . . . . . . . . . . . . 285
Four-Wheel Drive . . . . . . . . . . 265, 363
Four-Wheel-Drive Light . . . . . . . . . 150
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 471
Front Axle . . . . . . . . . . . . . . . . . . . . . . 364
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Front Seats
Adjustment . . . . . . . . . . . . . . . . . . . . . 59
Heated and Ventilated . . . . . . . . . . 65
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292 Additives . . . . . . . . . . . . . . . . . . . . . 293
Economy Driving . . . . . . . . . . . . . . . 32
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 296
Filling the Tank . . . . . . . . . . . . . . . 294
Foreign Countries . . . . . . . . . . . . 293
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 140
Low Fuel Warning Light . . . . . . . 153
Management, Active . . . . . . . . . . 256
Requirements, California . . . . . 293
Full-Size Spare Tire . . . . . . . . . . . . 420
Fuses
Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 376 Fuses (cont'd)
Fuses and Circuit Breakers . . . 376
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . 380, 381
G
Garage Door Opener . . . . . . . . . . . 168
Programming . . . . . . . . . . . . . . . . . 168
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 370
Gauges Engine CoolantTemperature . . . . . . . . . . . . . . . . 142
Engine Oil Pressure . . . . . . . . . . 141
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Odometer . . . . . . . . . . . . . . . . . . . . . 140
Speedometer . . . . . . . . . . . . . . . . . 140
Tachometer . . . . . . . . . . . . . . . . . . . 140
Trip Odometer . . . . . . . . . . . . . . . . 140
Voltmeter . . . . . . . . . . . . . . . . . . . . . 143
Warning Lights and Indicators . . . . . . . . . . . . . . . . . . . 136
General Information Service and Maintenance . . . . . 441
Towing . . . . . . . . . . . . . . . . . . . . . . . . 296
Vehicle Care . . . . . . . . . . . . . . . . . . 335
Glove Box . . . . . . . . . . . . . . . . . . . . . . 124
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 465

Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
494 Index
Manual Transmission . . . . . . . . . . . 263Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 350
Manual Windows . . . . . . . . . . . . . . . . 52
Media Avoiding Untrusted Devices . . 190
Memory Features . . . . . . . . . . . . . . . . 13
Memory Seats . . . . . . . . . . . . . . . . . . . 62
Messages Engine Power . . . . . . . . . . . . . . . . 160
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 159
Vehicle Speed . . . . . . . . . . . . . . . . 160
Mirrors Automatic Dimming . . . . . . . . . . . . . 50
Automatic DimmingRearview . . . . . . . . . . . . . . . . . . . . . . 52
Blind Spot . . . . . . . . . . . . . . . . . . . . . . 50
Convex . . . . . . . . . . . . . . . . . . . . . . . . . 47
Folding . . . . . . . . . . . . . . . . . . . . . . . . . 49
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 50
Manual . . . . . . . . . . . . . . . . . . . . . . . . . 47
Manual Rearview . . . . . . . . . . . . . . . 52
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Tilt in Reverse . . . . . . . . . . . . . . . . . . 51
Trailer Tow . . . . . . . . . . . . . . . . . . . . . . 48
Mirrors, Interior Rearview . . . . . . . . 51
Monitor System, Tire
Pressure . . . . . . . . . . . . . . . . . . . . . . 394
Multi-band Antenna . . . . . . . . . . . . . 189N
Navigation OnStar . . . . . . . . . . . . . . . . . . . . . . . 477
New Vehicle Break-In . . . . . . . . . . . 247
Noise Control System . . . . . . . . . . 366
O
Odometer . . . . . . . . . . . . . . . . . . . . . . . 140 Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Off-Road . . . . . . . . . . . . . . . . . . . . . . . 231 Driving . . . . . . . . . . . . . . . . . . . . . . . . 231
Recovery . . . . . . . . . . . . . . . . . . . . . 230
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . 343
Engine Oil Life System . . . . . . . 346
Engine Oil Pressure Gauge . . . 141
Older Children, Restraints . . . . . . . 92
Online Owner Center . . . . . . . . . . . 464
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . 474
OnStar Additional Information . . . . . . . . . . . . . . . . . . . . 481
OnStar Connections . . . . . . . . . . . . 478
OnStar Diagnostics . . . . . . . . . . . . . 480
OnStar Emergency . . . . . . . . . . . . . 476
OnStar Navigation . . . . . . . . . . . . . . 477
OnStar Overview . . . . . . . . . . . . . . . 475
OnStar Security . . . . . . . . . . . . . . . . 477 Operating Mode
Overheated Engine
Protection . . . . . . . . . . . . . . . . . . . 358
Operation Fog Lamps . . . . . . . . . . . . . . . . . . . 176
Ordering Service Publications . . . . . . . . . . 470
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . 132
Overheated Engine Protection Operating Mode . . . . 358
Overheating, Engine . . . . . . . . . . . . 356
Overview . . . . . . . . . . . . . . . . . . . . . . . 183
P
Park Shifting Into . . . . . . . . . . . . . . . . . . . 253
Shifting Out of . . . . . . . . . . . . . . . . 255
Parking . . . . . . . . . . . . . . . . . . . . . . . . . 255 Brake . . . . . . . . . . . . . . . . . . . . . . . . . 273
Brake and P (Park)Mechanism Check . . . . . . . . . . 368
Over Things That Burn . . . . . . . 255
Parking Assist . . . . . . . . . . . . . . . . . . 282
Parking or Backing Assistance Systems . . . . . . . . . . 282
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . 146
