Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
Vehicle Care 347
1. Display the OIL LIFEREMAINING on the DIC. If the
vehicle does not have DIC
buttons, the vehicle must be in
P (Park) to access this display.
See Driver Information Center
(DIC) (Base Level) 0155 or
Driver Information Center (DIC)
(Uplevel) 0156.
2. Press and hold
V, or the trip
odometer reset stem if the
vehicle does not have DIC
buttons, for several seconds.
The oil life will change
to 100%.
The oil life system can also be reset
as follows:
1. Display the OIL LIFE REMAINING on the DIC.
See Driver Information Center
(DIC) (Base Level) 0155 or
Driver Information Center (DIC)
(Uplevel) 0156.
2. Fully press the accelerator pedal slowly three times within
five seconds. 3. Display the OIL LIFE
REMAINING on the DIC. If the
display shows 100%, the
system is reset.
If the vehicle has a CHANGE
ENGINE OIL SOON message and it
comes back on when the vehicle is
started and/or the OIL LIFE
REMAINING is near 0%, the engine
oil life system has not been reset.
Repeat the procedure.
Automatic Transmission
Fluid (6-Speed
Transmission)
When to Check and Change
Automatic Transmission Fluid
It is usually not necessary to check
the transmission fluid level. The only
reason for fluid loss is a
transmission leak or overheated
transmission. If a small leak is
suspected, then use the following
checking procedures to check the
fluid level. However, if there is a
large leak, then it may be necessary
to have the vehicle towed to a dealer service department and have
it repaired before driving the vehicle
further.
Caution
Use of the incorrect automatic
transmission fluid may damage
the vehicle, and the damage may
not be covered by the vehicle
warranty. Always use the
automatic transmission fluid listed
in
Recommended Fluids and
Lubricants 0451.
Change the fluid and filter at the
scheduled maintenance intervals
listed in Maintenance Schedule
0 443. Be sure to use the
transmission fluid listed in
Recommended Fluids and
Lubricants 0451.

Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
Vehicle Care 399
If the vehicle has a base level
DIC, use the trip odometer
reset stem to scroll to the Tire
Pressure screen.
5. If the vehicle has an uplevel DIC, press and hold the
V
(Set/Reset) button located in
the center of the DIC controls.
If the vehicle has a base level
DIC, press and hold the trip
odometer reset stem for about
five seconds. A message
asking if the process should
begin should appear. Select
yes and press the trip
odometer reset stem to confirm
the selection.
The horn sounds twice to
signal the receiver is in relearn
mode and the TIRE
LEARNING ACTIVE message
displays on the DIC screen.
6. Start with the driver side front tire.
7. Place the relearn tool against the tire sidewall, near the valve
stem. Then press the button to
activate the TPMS sensor. A horn chirp confirms that the
sensor identification code has
been matched to this tire and
wheel position.
8. Proceed to the passenger side front tire, and repeat the
procedure in Step 7.
9. Proceed to the passenger side rear tire, and repeat the
procedure in Step 7.
10. Proceed to the driver side rear tire, and repeat the procedure
in Step 7. The horn sounds two
times to indicate the sensor
identification code has been
matched to the driver side rear
tire, and the TPMS sensor
matching process is no longer
active. The TIRE LEARNING
ACTIVE message on the DIC
display screen goes off.
11. Turn the vehicle off.
12. Set all four tires to the recommended air pressure
level as indicated on the Tire
and Loading Information label.
Tire Inspection
We recommend that the tires,
including the spare tire, if the
vehicle has one, be inspected
for signs of wear or damage at
least once a month.
Replace the tire if:
.The indicators at three or
more places around the tire
can be seen.
.There is cord or fabric
showing through the tire's
rubber.
.The tread or sidewall is
cracked, cut, or snagged
deep enough to show cord or
fabric.
.The tire has a bump, bulge,
or split.
.The tire has a puncture, cut,
or other damage that cannot
be repaired well because of
the size or location of the
damage.

Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
Vehicle Care 407
Wheel Replacement
Replace any wheel that is bent,
cracked, or badly rusted or
corroded. If wheel nuts keep coming
loose, the wheel, wheel bolts and
wheel nuts should be replaced.
If the wheel leaks air, replace it.
Some aluminum wheels can be
repaired. See your dealer if any of
these conditions exist.
Your dealer will know the kind of
wheel that is needed.
Each new wheel should have the
same load-carrying capacity,
diameter, width, offset and be
mounted the same way as the one it
replaces.
Replace wheels, wheel bolts, wheel
nuts, or Tire Pressure Monitor
System (TPMS) sensors with new
GM original equipment parts.{Warning
Using the wrong replacement
wheels, wheel bolts, or wheel
nuts can be dangerous. It could
affect the braking and handling of
the vehicle. Tires can lose air,
and cause loss of control, causing
a crash. Always use the correct
wheel, wheel bolts, and wheel
nuts for replacement.
Caution
The wrong wheel can also cause
problems with bearing life, brake
cooling, speedometer or
odometer calibration, headlamp
aim, bumper height, vehicle
ground clearance, and tire or tire
chain clearance to the body and
chassis.
Whenever a wheel, wheel bolt,
or wheel nut is replaced on a dual
wheel setup, check the wheel nut
torque after 160,1 600, and 10 000 km (100,1,000, and
6,000 mi) of driving. For proper
torque, see
“Wheel Nut Torque”
under Capacities and Specifications
0 457.
See If a Tire Goes Flat 0408 for
more information.
Used Replacement Wheels
{Warning
Replacing a wheel with a used
one is dangerous. How it has
been used or how far it has been
driven may be unknown. It could
fail suddenly and cause a crash.
When replacing wheels, use a
new GM original equipment
wheel.

Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
Service and Maintenance 455
Maintenance Records
After the scheduled services are performed, record the date, odometer reading, who performed the service, and the
type of services performed in the boxes provided. Retain all maintenance receipts.Date Odometer
Reading Serviced By Services Performed

Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
Customer Information 465
.Find the
Chevrolet-recommended
maintenance services.
GM Mobility
Reimbursement Program
This program is available to
qualified applicants for cost
reimbursement, up to certain limits,
of eligible aftermarket adaptive
equipment required for the vehicle,
such as hand controls or a
wheelchair/scooter lift for the
vehicle.
To learn about the GM Mobility
program, see www.gmmobility.com
or call the GM Mobility Assistance
Center at 1-800-323-9935. Text
Telephone (TTY) users, call
1-800-833-9935. General Motors of Canada also has
a Mobility program. See www.gm.ca
or call 1-800-GM-DRIVE
(800-463-7483) for details. TTY
users call 1-800-263-3830.
Roadside Assistance
Program
For U.S.-purchased vehicles, call
1-800-243-8872. (Text Telephone
(TTY): 1-888-889-2438.)
For Canadian-purchased vehicles,
call 1-800-268-6800.
Service is available 24 hours a day,
365 days a year.
Calling for Assistance
When calling Roadside Assistance,
have the following information
ready:
.
Your name, home address, and
home telephone number
. Telephone number of your
location
. Location of the vehicle .
Model, year, color, and license
plate number of the vehicle
. Odometer reading, Vehicle
Identification Number (VIN), and
delivery date of the vehicle
. Description of the problem
Coverage
Services are provided for the
duration of the vehicle’s powertrain
warranty.
In the U.S., anyone driving the
vehicle is covered. In Canada, a
person driving the vehicle without
permission from the owner is not
covered.
Roadside Assistance is not a part of
the New Vehicle Limited Warranty.
General Motors North America and
Chevrolet reserve the right to make
any changes or discontinue the
Roadside Assistance program at
any time without notification.
General Motors North America and
Chevrolet reserve the right to limit
services or payment to an owner or

Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
Index 491
F
FanEngine . . . . . . . . . . . . . . . . . . . . . . . . 358
Fast Idle System . . . . . . . . . . . . . . . . 251
Features Memory . . . . . . . . . . . . . . . . . . . . . . . . . 13
Filter, Engine Air Cleaner . . . . . . . . . . . 351
Fixed Mast Antenna . . . . . . . . . . . . 189
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 174
Flashers, Hazard Warning . . . . . . 175
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 408 Changing . . . . . . . . . . . . . . . . . . . . . 410
FlexFuel
E85 . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
Floor Console Storage . . . . . . . . . . 126
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 439
Fluid Automatic
Transmission . . . . . . . . . . . 347, 350
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 361
Four-Wheel Drive Transfer Case . . . . . . . . . . . . . . . 265
Power Steering . . . . . . . . . . . . . . . 359
Washer . . . . . . . . . . . . . . . . . . . . . . . 359
Fog Lamps . . . . . . . . . . . . . . . . . . . . . 176 Bulb Replacement . . . . . . . . . . . . 373
Folding Mirrors . . . . . . . . . . . . . . . . . . 49 Forward Automatic Braking . . . . . 287
Forward Collision Alert
(FCA) System . . . . . . . . . . . . . . . . . 285
Four-Wheel Drive . . . . . . . . . . 265, 363
Four-Wheel-Drive Light . . . . . . . . . 150
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 471
Front Axle . . . . . . . . . . . . . . . . . . . . . . 364
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Front Seats
Adjustment . . . . . . . . . . . . . . . . . . . . . 59
Heated and Ventilated . . . . . . . . . . 65
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292 Additives . . . . . . . . . . . . . . . . . . . . . 293
Economy Driving . . . . . . . . . . . . . . . 32
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 296
Filling the Tank . . . . . . . . . . . . . . . 294
Foreign Countries . . . . . . . . . . . . 293
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 140
Low Fuel Warning Light . . . . . . . 153
Management, Active . . . . . . . . . . 256
Requirements, California . . . . . 293
Full-Size Spare Tire . . . . . . . . . . . . 420
Fuses
Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 376 Fuses (cont'd)
Fuses and Circuit Breakers . . . 376
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . 380, 381
G
Garage Door Opener . . . . . . . . . . . 168
Programming . . . . . . . . . . . . . . . . . 168
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 370
Gauges Engine CoolantTemperature . . . . . . . . . . . . . . . . 142
Engine Oil Pressure . . . . . . . . . . 141
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Odometer . . . . . . . . . . . . . . . . . . . . . 140
Speedometer . . . . . . . . . . . . . . . . . 140
Tachometer . . . . . . . . . . . . . . . . . . . 140
Trip Odometer . . . . . . . . . . . . . . . . 140
Voltmeter . . . . . . . . . . . . . . . . . . . . . 143
Warning Lights and Indicators . . . . . . . . . . . . . . . . . . . 136
General Information Service and Maintenance . . . . . 441
Towing . . . . . . . . . . . . . . . . . . . . . . . . 296
Vehicle Care . . . . . . . . . . . . . . . . . . 335
Glove Box . . . . . . . . . . . . . . . . . . . . . . 124
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 465

Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
494 Index
Manual Transmission . . . . . . . . . . . 263Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 350
Manual Windows . . . . . . . . . . . . . . . . 52
Media Avoiding Untrusted Devices . . 190
Memory Features . . . . . . . . . . . . . . . . 13
Memory Seats . . . . . . . . . . . . . . . . . . . 62
Messages Engine Power . . . . . . . . . . . . . . . . 160
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 159
Vehicle Speed . . . . . . . . . . . . . . . . 160
Mirrors Automatic Dimming . . . . . . . . . . . . . 50
Automatic DimmingRearview . . . . . . . . . . . . . . . . . . . . . . 52
Blind Spot . . . . . . . . . . . . . . . . . . . . . . 50
Convex . . . . . . . . . . . . . . . . . . . . . . . . . 47
Folding . . . . . . . . . . . . . . . . . . . . . . . . . 49
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 50
Manual . . . . . . . . . . . . . . . . . . . . . . . . . 47
Manual Rearview . . . . . . . . . . . . . . . 52
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Tilt in Reverse . . . . . . . . . . . . . . . . . . 51
Trailer Tow . . . . . . . . . . . . . . . . . . . . . . 48
Mirrors, Interior Rearview . . . . . . . . 51
Monitor System, Tire
Pressure . . . . . . . . . . . . . . . . . . . . . . 394
Multi-band Antenna . . . . . . . . . . . . . 189N
Navigation OnStar . . . . . . . . . . . . . . . . . . . . . . . 477
New Vehicle Break-In . . . . . . . . . . . 247
Noise Control System . . . . . . . . . . 366
O
Odometer . . . . . . . . . . . . . . . . . . . . . . . 140 Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Off-Road . . . . . . . . . . . . . . . . . . . . . . . 231 Driving . . . . . . . . . . . . . . . . . . . . . . . . 231
Recovery . . . . . . . . . . . . . . . . . . . . . 230
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . 343
Engine Oil Life System . . . . . . . 346
Engine Oil Pressure Gauge . . . 141
Older Children, Restraints . . . . . . . 92
Online Owner Center . . . . . . . . . . . 464
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . 474
OnStar Additional Information . . . . . . . . . . . . . . . . . . . . 481
OnStar Connections . . . . . . . . . . . . 478
OnStar Diagnostics . . . . . . . . . . . . . 480
OnStar Emergency . . . . . . . . . . . . . 476
OnStar Navigation . . . . . . . . . . . . . . 477
OnStar Overview . . . . . . . . . . . . . . . 475
OnStar Security . . . . . . . . . . . . . . . . 477 Operating Mode
Overheated Engine
Protection . . . . . . . . . . . . . . . . . . . 358
Operation Fog Lamps . . . . . . . . . . . . . . . . . . . 176
Ordering Service Publications . . . . . . . . . . 470
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . 132
Overheated Engine Protection Operating Mode . . . . 358
Overheating, Engine . . . . . . . . . . . . 356
Overview . . . . . . . . . . . . . . . . . . . . . . . 183
P
Park Shifting Into . . . . . . . . . . . . . . . . . . . 253
Shifting Out of . . . . . . . . . . . . . . . . 255
Parking . . . . . . . . . . . . . . . . . . . . . . . . . 255 Brake . . . . . . . . . . . . . . . . . . . . . . . . . 273
Brake and P (Park)Mechanism Check . . . . . . . . . . 368
Over Things That Burn . . . . . . . 255
Parking Assist . . . . . . . . . . . . . . . . . . 282
Parking or Backing Assistance Systems . . . . . . . . . . 282
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . 146

Chevrolet Silverado Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
11349200) - 2018 - CRC - 2/27/18
498 Index
Traction Control/ElectronicStability Control . . . . . . . . . . . . . . . 276
Trademarks and License Agreements . . . . . . . . . . . . . . . . . . . 210
Trailer Sway Control (TSC) . . . . . . . . . . 327
Tow Mirrors . . . . . . . . . . . . . . . . . . . . . 48
Towing . . . . . . . . . . . . . . . . . . . . . . . . 300
Transfer Case . . . . . . . . . . . . . . . . . . 265
Transmission Automatic . . . . . . . . . . . . . . . . . . . . . 257
Fluid, Automatic . . . . . . . . . 347, 350
Fluid, Manual . . . . . . . . . . . . . . . . . 350
Transportation Program, Courtesy . . . . . . . . . . . . . . . . . . . . . . 467
Trip Odometer . . . . . . . . . . . . . . . . . . 140
Truck-Camper Loading
Information . . . . . . . . . . . . . . . . . . . . 245
Turn and Lane-Change Signals . . . . . . . . . . . . . . . . . . . . . . . . 175
Turn Signal
Bulb Replacement . . . . . . . . . . . . 373
U
Uniform Tire Quality Grading . . . 405
Universal Remote System . . . . . . 168Operation . . . . . . . . . . . . . . . . . . . . . 170
Programming . . . . . . . . . . . . . . . . . 168 Updates
Software . . . . . . . . . . . . . . . . . . . . . . 185
USB Port . . . . . . . . . . . . . . . . . . . . . . . 190
Using This Manual . . . . . . . . . . . . . . . . 2
V
Vehicle Alarm System . . . . . . . . . . . . . . . . . . 44
Canadian Owners . . . . . . . . . . . . . . . 2
Control . . . . . . . . . . . . . . . . . . . . . . . 228
Identification Number (VIN) . . . 456
Load Limits . . . . . . . . . . . . . . . . . . . 239
Messages . . . . . . . . . . . . . . . . . . . . 159
Personalization . . . . . . . . . . . . . . . 160
Remote Start . . . . . . . . . . . . . . . . . . . 39
Security . . . . . . . . . . . . . . . . . . . . . . . . 44
Speed Messages . . . . . . . . . . . . . 160
Towing . . . . . . . . . . . . . . . . . . . . . . . . 425
Vehicle Ahead Indicator . . . . . . . . 152
Vehicle Care Tire Pressure . . . . . . . . . . . . . . . . . 392
Vehicle Data Recording and Privacy . . . . . . . . . . . . . . . . . . . . . . . . 473
Ventilation, Air . . . . . . . . . . . . . . . . . . 223
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Voice Recognition . . . . . . . . . . . . . . 197
Voltage Devices and Wiring . . . . 375
Voltmeter Gauge . . . . . . . . . . . . . . . 143
W
Warning Brake System Light . . . . . . . . . . . 149
Caution and Danger . . . . . . . . . . . . . 3
Lane Departure (LDW) . . . . . . . 288
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . . . . . . 136
Warnings Hazard Flashers . . . . . . . . . . . . . . 175
Washer Fluid . . . . . . . . . . . . . . . . . . . 359
Wheels
Alignment and Tire Balance . . 406
Different Size . . . . . . . . . . . . . . . . . 404
Replacement . . . . . . . . . . . . . . . . . 407
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 402
Where to Put the Restraint . . . . . . 98
Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . 478
Windows . . . . . . . . . . . . . . . . . . . . . . . . 52 Manual . . . . . . . . . . . . . . . . . . . . . . . . . 52
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Windshield Replacement . . . . . . . . . . . . . . . . . 369
Wiper/Washer . . . . . . . . . . . . . . . . 130
Winter Driving . . . . . . . . . . . . . . . . . . . . . . . . 237
Winter Tires . . . . . . . . . . . . . . . . . . . . 385
