2018 Alfa Romeo Giulietta Owner's Manual

Use Features SpecificationOriginal fluids and
lubricantsApplications
Lubricants and greases
for drive transmissionSAE 75W grade synthetic
lubricant.9.55550-MZ6 or
MS.90030–M1TUTELA TRANSMISSION
GEARFORCE
Contractual Technical
Reference N° F002.F10Mechanical differentials
and gearboxes
Molybdenum disulphide
grease, for use at high
temperatures. N.L.G.I.
consistency 1-2FIAT 9.55580 – GRASS IITUTELA ALL STAR
Contractual Technical
Reference N° F702.G07Wheel side constant
velocity joints
Grease for constant
velocity joints with low
friction coefficient.
N.L.G.I. consistency 0-1FIAT 9.55580 – GRASS IITUTELA STAR 700
Contractual Technical
Reference N° F701.C07Differential side constant
velocity joints
Lubricant for
electro-hydraulic
actuator (versions with
Alfa TCT)Fully synthetic oil with
dedicated additive9.55550-SA1 or
MS.90030-H1TUTELA CS SPEED
Contractual Technical
Reference N° F005.F98Lubricant for
electro-hydraulic actuator
Brake fluid DOT 4 9.55597TUTELA BRAKE FLUID
EXTREME HT
Contractual Technical
Reference N° F001.N15Hydraulic brakes and
hydraulic clutch controls
Protective agent for
radiatorsRed protective with
antifreeze action, based on
inhibited monoethyl glycol
with organic formula.
Exceeds CUNA NC
956-16, ASTM D
3306 specifications.9.55523 or MS.90032PARAFLU
UP(*)
Contractual Technical
Reference N° F101.M01Percentage of use: 50%
distilled water 50%
PARAFLUUP(**)
Diesel fuel additiveAntifreeze additive for
diesel, with protective
action for diesel engines.DIESEL ART
Contractual Technical
Reference N° F601.L06To be mixed with diesel
(25 cc per 10 litres)
(*)IMPORTANT Do not top up or mix with other fluids which have different specifications from those described.
(**)When the vehicle is used in particularly harsh weather conditions, we recommend using a mixture of 60%PARAFLUUPand 40% demineralised water.
167
PETRONAS DURANCE

Use Features SpecificationOriginal fluids and
lubricantsApplications
Washer fluid for
windscreen/rear
window/headlampsMixture of alcohol,water
and surfactants CUNA NC
956-119.55522 or MS.90043PETRONAS DURANCE SC
35
Contractual Technical
Reference N° F001.D16To be used diluted or
undiluted in windscreen
washer/wiper systems
IMPORTANT
51)The use of products with different specifications than those indicated above could cause damage to the engine that is not covered by the
warranty.
168
TECHNICAL SPECIFICATIONS

PERFORMANCE
Versions Maximum speed (km/h)Acceleration from 0-100 km/h
(sec)
1.4 Turbo petrol 120 HP195 9.4
1.4 Turbo Multi Air 163 HP TCT
(*)218 7.8
1.4 Turbo Multi Air 150 HP210 8.2
1.4 Turbo Multi Air 170 HP TCT218 7.7
1.4 Turbo Petrol/LPG 120 HP195 9.4
1750 Turbo Petrol 240 HP
(*)244 6.0
1.6 JTD
M115 HP(*) (**)192 10.5
1.6 JTD
M120 HP(**)195 10
2.0 JTD
M136 HP205 9.2
2.0 JTD
M150 HP210 8.8
2.0 JTD
M163 HP TCT(*)215 8.2
2.0 JTD
M175 HP TCT219 7.8
(*) For versions/markets, where provided
(**) For versions with manual transmission or TCT
169

FUEL CONSUMPTION
The fuel consumption figures given in the tables below are determined on the basis of the type-approval tests laid down by specific
European Directives.
The following procedures are used to measure the fuel consumption:
urban cycle: cold starting followed by driving that simulates urban use of the car;
extra-urban cycle: frequent accelerating in all gears, simulating extra-urban use of the car: speed varies between 0 and 120 km/h;
combined fuel consumption: calculated with a weighting of approximately 37% of the urban cycle and 63% of the extra-urban
cycle.
IMPORTANT The type of route, traffic conditions, weather conditions, driving style, general condition of the car, trim
level/equipment/accessories, use of the climate control system, car load, presence of roof racks and other situations that adversely
affect the aerodynamics or wind resistance lead to different fuel consumption values than those measured.
FUEL CONSUMPTION ACCORDING TO THE CURRENT EUROPEAN DIRECTIVE (litres/100 km)
Versions Urban Extra-urban Combined
1.4 Turbo Petrol8.1 5.1 6.2
1.4 T
urbo Petrol/LPG 120 HP
10.8
(*)/ 8.4(**)6.7(*)/ 5.1(**)8.2(*)/ 6.3(**)
1.4 Turbo Multi Air 150 HP7.4 4.4 5.5
1.4 Turbo Multi Air 163 HP TCT
(***)/170 HP
TCT6.3 4.1 4.9
1750 Turbo Petrol 240 HP
(***)9.5 5.2 6.8
1.6 JTD
M115 HP(***) (*****)4.9/4.7(****)3.3/3.2(****)3.9/3.8(****)
1.6 JTDM120 HP(***)4.9/4.7(****)3.3/3.2(****)3.9/3.8(****)
(*) Running on LPG
(**) Running on petrol
(***) Where provided
(*****) For versions with manual transmission or TCT
(****) ECO version
170
TECHNICAL SPECIFICATIONS

Versions Urban Extra-urban Combined
2.0 JTDM136 HP5.0 3.7 4.2
2.0 JTD
M150 HP
5.0/4.8(****)3.7/3.5(****)4.2/4.0(****)
2.0 JTDM163 HP TCT(***)5.1 3.8 4.3
2.0 JTD
M175 HP TCT5.1 3.8 4.3
(****) ECO version
(***) Where provided
171

CO2EMISSIONS
The CO2emission levels given in the following tables refer to combined consumption.
VersionsCO emissions2according to the European Directive in force (g/km)
1.4 Turbo Petrol144
1.4 Turbo Petrol/LPG 120 HP
133
(*)/ 147(**)
1.4 Turbo MultiAir 150 HP127
1.4 Turbo MultiAir 163 HP TCT
(***)114
1.4 Turbo MultiAir 170 HP TCT114
1750 Turbo Petrol 240 HP
(***)157
1.6 JTD
M115 HP(****)103/99(*****)
1.6 JTDM120 HP(****)103/99(*****)
2.0 JTDM136 HP110
2.0 JTD
M150 HP
110/105(*****)
2.0 JTDM163 HP TCT(***)113
2.0 JTD
M175 HP TCT113
(*) Running on LPG
(**) Running on petrol
(***) For versions/markets, where provided
(****) For versions with manual transmission or TCT
(*****) ECO version
172
TECHNICAL SPECIFICATIONS

PRESCRIPTIONS FOR HANDLING THE VEHICLE AT THE END OF ITS LIFE
(where present)
FCA has been committed for many years to safeguarding the environment through the constant improvement of its production
processes and manufacturing products that are increasingly "eco-compatible". To grant customers the best possible service in terms
of respecting environmental laws and in response to European Directive 2000/53/EC governing vehicles at the end of their life, FCA
is offering its customers the chance to hand over their vehicle at the end of its life without incurring any additional costs. The
European Directive sets out that when the vehicle is handed over, the last keeper or owner should not incur any expenses as a result
of it having a zero or negative market value.
To hand your vehicle over at the end of its life without extra cost, contact one of our dealerships if you are purchasing another vehicle
or an FCA-authorised collection and scrapping centre. These centres have been carefully chosen to offer high quality service for the
collection, treatment and recycling of vehicles at their end of life, respecting the surrounding environment.
You can find further information on these collection and scrapping centres either from an FCA dealership or by calling the number in
the Warranty Booklet or by consulting the websites of the various FCA brands.
