Smart key system
EAU77201
Smart key system
The smart key system enables the ve-
hicle to be operated without using a
mechanical key.
WARNING
EWA14704
Keep implanted pacemakers or
cardiac defibrillators, as well as
other electric medical devices
away from the vehicle mounted
antenna (see illustration).
Radio waves transmitted by the
antenna may affect the opera-
tion of such devices when close
by.
If you have an electric medical
device, consult a doctor or the
device manufacturer before us-
ing this vehicle.
In addition to the vehicle mounted an-
tenna, the smart key system consists of
the smart key, smart key system indica-
tor light, “ON/ ” switch, and the
“OFF/LOCK” and “ / ” switches.
1. Vehicle mounted antenna
1
1. Smart key
1. Smart key system indicator light “ ”
1. “ON/ ” switch
1
1
1
BV1-28199-E0.book 1 ページ ２０１６年１２月１９日　月曜日　午前１１時２５分

Smart key system
3-6
1
2
3
4
5
6
7
8
9
10
11
12
13
14
EAU79070
Replacing the smart key
battery
Replace the battery in the following sit-
uations.
The smart key system indicator
light flashes for about 20 seconds
when the power of the vehicle is
turned on.
When the smart key indicator light
does not come on when the
“ON/OFF” switch is pushed.
WARNING
EWA14724
The battery and other remov-
able parts may cause injury if
swallowed. Keep the battery
and other removable parts away
from children.
Do not expose the battery to di-
rect sunlight or other heat
sources.
NOTICE
ECA24010
Do not apply excessive force to
the smart key when replacing
the battery.
Do not use a screwdriver or oth-
er hard object to force open the
key.
Take precautions to prevent the waterproof seal from being
damaged or contaminated by
dirt.
Do not touch the internal cir-
cuits and terminals. This may
cause malfunctions.
Make sure the battery is in-
stalled correctly. Confirm the di-
rection of the positive/“+” side
of the battery.
To replace the smart key battery 1. Gently pry open the smart key case.
2. Remove the battery cover and O- ring.
3. Remove the battery.
TIP
Dispose of the removed battery in ac-
cordance with local regulations.
1. Smart key system indicator light “ ”
1
1. Battery cover
2. O-ring
1 2
BV1-28199-E0.book 6 ページ ２０１６年１２月１９日　月曜日　午前１１時２５分

Smart key system
3-9
1
2
3
4
5
6
7
8
9
10
11
12
13
14
ering off the vehicle again.
TIP
Without the smart key, the vehicle pow-
er can be turned off by pressing the
“OFF/LOCK” switch again while the
smart key system indicator light is
flashing.
Auto lock function
After the engine is stopped via the
“OFF/LOCK” switch, (or whenever the
vehicle power is turned from on to off),
all storage compartment locks (if
equipped) and the fuel tank cap lid lock
are released and these compartments
can be accessed temporarily. When 60
seconds have passed, all compart-
ments will automatically lock.
When the compartment locks are re-
leased via the “ / ” switch, the com-
partments will automatically lock after
10 seconds have passed.
EAU80000
How to lock the steering
After moving the vehicle to a safe park-
ing place, turn off the power of the vehi-
cle. Turn the handlebars fully to the left
and then briefly press the “OFF/LOCK”
switch.
TIP
If the steering lock function locks
correctly, the beeper will sound
once.
If the steering lock function does
not lock correctly, the beeper will
sound for three seconds and the
smart key system indicator light
will flash. Turn the handlebar fully
to the left one more time and press
the “OFF/LOCK” switch again for
one second.
WARNING
EWA14742
Do not operate the steering lock
while the vehicle is moving.
BV1-28199-E0.book 9 ページ ２０１６年１２月１９日　月曜日　午前１１時２５分
