Rear brake• Check operation, and correct if necessary.
• Lubricate cables if necessary.
• Check lever and pedal free play, and adjust if necessary. 5-3, 8-26, 8-29
Throttle lever • Make sure that operation is smooth. Lubricate cable and lever
housing if necessary.
• Check lever free play, and adjust if necessary. 5-4, 8-24
Control cables • Make sure that operation is smooth. Lubricate if necessary. 8-35
Wheels and tires • Check wheel condition, and replace if damaged.
• Check tire condition and tread depth. Replace if necessary.
• Check air pressure. Correct if necessary. 5-4
Brake pedal • Make sure that operation is smooth. Lubricate pedal pivoting point
if necessary. 8-36
Brake levers • Make sure that operation is smooth. Lubricate lever pivoting points
if necessary. 8-35
Chassis fasteners • Make sure that all nuts, bolts and screws are properly tightened. 5-6
Instruments, lights and
switches • Check operation, and correct if necessary. 5-6
ITEM ROUTINE PAGE
UB1463E0.book Page 2 Thursday, August 4, 2016 2:12 PM

5-6
5
Aftermarket tires and rims
The tires and rims that came with your ATV were
designed to match the performance capabilities
and to provide the best combination of handling,
braking, and comfort. Other tires, rims, sizes, and
combinations may not be appropriate.
EBU19841Chassis fastenersMake sure that all nuts, bolts and screws are
properly tightened.EBU19851Instruments, lights and switchesCheck that all instruments, lights and switches are
working properly. Correct if necessary.
Front:
Manufacturer/model:CHENG SHIN/C828 (AUS, NZL)
MAXXIS/MU13 (EUR, FRA, GBR)
Size: AT25 x 8-12
Ty p e : Tu b e l e s s
Rear: Manufacturer/model:CHENG SHIN/C828 (AUS, NZL)
MAXXIS/MU14 (EUR, FRA, GBR)
Size: AT25 x 10-12
Ty p e : Tu b e l e s s
UB1463E0.book Page 6 Thursday, August 4, 2016 2:12 PM

8-8
8
EBU28392TIPSome maintenance items need more frequent service if you are riding in unusually wet, dusty, sandy or
muddy areas, or at full-throttle.
 Hydraulic brake service
• Regularly check and, if necessary, correct the brake fluid level.
• Every two years replace the internal components of the brake master cylinder and calipers, and chan-
ge the brake fluid.
• Replace the brake hoses every four years and if cracked or damaged. 23 *Lights and switches • Check operation and correct if necessary.
• Adjust headlight beams. √√√√√
NO. ITEM
CHECK OR MAINTENANCE
JOB INITIAL EVERY
Whichev- er comes first month136612
km (mi) 320
(200) 1300
(800) 2500
(1600) 2500
(1600) 5000
(3200)
hours 20 80 160 160 320UB1463E0.book Page 8 Thursday, August 4, 2016 2:12 PM

8-46
8
EBU25721TroubleshootingAlthough Yamaha ATVs receive a thorough in-
spection before shipment from the factory, trouble
may occur during operation. Any problem in the
fuel, compression, or ignition systems, for exam-
ple, can cause poor starting and loss of power.
The following troubleshooting chart represents a
quick and easy procedure for checking these vital
systems yourself. However, should your ATV re-
quire any repair, take it to a Yamaha dealer, whose
skilled technicians have the necessary tools, ex-
perience, and know-how to service the ATV prop-
erly.
Use only genuine Yamaha replacement parts. Im-
itation parts may look like Yamaha parts, but they
are often inferior, have a shorter service life and
can lead to expensive repair bills.
WARNING
EWB02281Do not smoke when checking the fuel system.
Fuel can ignite or explode, causing severe inju-
ry or property damage. Make sure there are no
open flames or sparks in the area, including pi-
lot lights from water heaters or furnaces. UB1463E0.book Page 46 Thursday, August 4, 2016 2:12 PM

12-1
12
INDEX
AAccessories and loading ................................................ 6-6
Air filter element, cleaning ........................................... 8-18BBattery ......................................................................... 8-37
Brake fluid, changing ................................................... 8-29
Brake fluid level, checking ........................................... 8-27
Brake lever free play, checking the front ..................... 8-29
Brake lever, front ........................................................... 4-5
Brake levers, checking and lubricating ........................ 8-35
Brake light switches ..................................................... 8-34
Brake pads and shoes, checking ................................ 8-26
Brake pedal and rear brake lever ................................... 4-6
Brake pedal, checking and lubricating ........................ 8-36
Brakes .......................................................................... 8-26
Brakes, front and rear .................................................... 5-3CCables, checking and lubricating ................................ 8-35
Carburetor, adjusting ................................................... 8-23
Carrier, front ................................................................. 4-14
Carrier, rear .................................................................. 4-14
Chassis fasteners .......................................................... 5-6
Cleaning ......................................................................... 9-1DDrive select lever ........................................................... 4-7
Drive select lever and driving in reverse ........................ 6-3
Drive select lever safety system cable, adjusting ........ 8-26EEngine break-in .............................................................. 6-4Engine, cold start ........................................................... 6-1
Engine idling speed ..................................................... 8-23
Engine oil ....................................................................... 5-3
Engine oil and oil filter cartridge .................................. 8-11
Engine, starting a warm ................................................. 6-3
Engine stop switch ........................................................ 4-3
FFinal gear oil ......................................................... 5-3, 8-15
Fuel ......................................................................... 4-8, 5-3
Fuel cock ..................................................................... 4-10
Fuel tank cap ................................................................. 4-8
Fuses, replacing .......................................................... 8-40HHandlebar switches ....................................................... 4-3
Headlight beam, adjusting ........................................... 8-43
Headlight bulb, replacing ............................................. 8-42
Horn switch .................................................................... 4-4IIdentification numbers ................................................. 11-1
Indicator lights and warning light ................................... 4-2
Instruments, lights and switches ................................... 5-6LLabel locations ............................................................... 1-1
Light switch ................................................................... 4-4MMain switch .................................................................... 4-1
Maintenance and lubrication chart ................................ 8-5
Maintenance chart, emission control system ................ 8-3
Model label .................................................................. 11-1
