2017 VOLKSWAGEN SCIROCCO Owners Manual

Step Action:
Pay attention to the message in the display: Look! Safe to move? ⇒
5. Align the vehicle in the parking space B so that the green orientation lines are parallel with the parking space (3).
6. Stop the vehicle C before (or at the very latest, when) the horizontal red line reaches the rear boundary, for example, a curb (4).

Park Distance Control (PDC)
Applicable only in the United States

NOTICE
x Things like trailer draw bars, thin rods, fences, trees, narrow painted vertical poles, posts, or a rear hatch that is opening may not be detected by the Park Distance Control sensors and could damage the vehicle.
x If you continue driving closer to an object that the Park Distance Control has already detected and reported, the object may disappear from the sensor range and may no longer be detected. This is especially true for low or high objects. The system will no longer sound warnings about these objects. Ignoring signals from the Park Distance Control system could result in serious damage to the vehicle.
x The sensors in the bumpers can be damaged or become misaligned in low speed impacts and parking maneuvers. Damaged or misaligned sensors cannot accurately detect or report objects that might be within range of the PDC system.
x To help make sure that the system works properly, always keep the sensors in the bumpers clean and free of snow and ice; do not cover the sensors with stickers or other objects.
x When cleaning the sensors with power washers or steam cleaners, only spray the sensors directly for a very short time, and always keep the washer nozzle at least 4 inches (10 cm) from the sensors.
x Noise from rough roads, cobblestones, other vehicles and the surrounding area, for example, can prevent the Park Distance Control system from accurately detecting and reporting people and objects that may be within range of the sensors.
x Aftermarket components such as bicycle racks can impair the function of the Park Distance Control system.
Volkswagen recommends practicing with the Park Distance Control system in a location or parking space with no traffic in order to become familiar with the system and how it works.
Applicable only in the United States
Operation

Fig. 145 In the front and rear bumpers: Park Distance Control system sensors.

Fig. 146 In the center console: Button to switch the Park Distance Control system on or off.

In order to Operation (when the ignition is switched on)
Switch to the rearview camera display (if equipped):
Shift into Reverse (R).
OR: Tap the Z function key.

The indicator light in the  button ⇒ fig. 146 lights up and stays on as long as the feature is active.
Automatic activation
When the PDC is activated automatically, a mini PDC display will appear on the left-hand side of the
screen ⇒ fig. 148.
Automatic activation of the PDC when driving slowly towards an obstacle located in front of the vehicle only works when the speed falls below about 6–9 mph (10–15 km/h) for the first time. If the PDC was switched off using the  button, performing one of the following actions with the ignition switched on can automatically reactivate the PDC:
x If the vehicle accelerates to a speed greater than 6–9 mph (10–15 km/h) and then drops below that speed again.
x OR: if the selector lever is moved to Park (P) and then out of that position again.
x OR: if automatic activation is activated and deactivated in the Infotainment system menu.
Automatic activation with mini PDC display can be activated and deactivated in the Infotainment
system ⇒ Infotainment system.
When automatic activation is activated, signal chimes are sounded from a distance of about 20 inches (50 cm) from the obstacle.
WARNING
Never rely completely on the PDC for information about people and objects that might be in the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The PDC sensors have blind spots where they cannot detect people or objects.
x Always watch for people, especially small children and animals, because the sensors may not always be able to detect them.
If you hear a long beep of about 3 seconds when you first turn PDC on or the indicator light in the button starts blinking, this means there is a malfunction in the Park Distance Control system. Switch off the Park Distance Control system with the button and have it immediately checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.

Applicable only in the United States
PDC signal chimes and displays

Fig. 147 PDC display of the area surrounding the vehicle.

Fig. 148 Mini PDC display of the area surrounding the vehicle.

Signal chimes
When the vehicle approaches an obstacle located in the range of the ultrasonic sensors, there are audible signal chimes. An intermittent signal chime means that a sufficiently short distance between the vehicle and an obstacle is detected. The shorter the distance, the shorter the intervals between the chimes. The signal chime will sound continuously if the obstacle is very close.
When there is an imminent risk of collision at the front area of the vehicle, the signal chimes beep at the front of the vehicle. When there is a risk of imminent collision at the rear area of the vehicle, the signal chimes beep at the rear of the vehicle.
If you continue to drive the vehicle closer to the obstacle despite a continuous signal chime, the system will no longer be able to measure the distance.
The intermittent signal chime volume decreases after a few seconds if the distance remains the same. The volume remains constant if the signal chime is continuous. As soon as the vehicle moves away from an obstacle again, the intermittent signal chime switches off automatically. If the vehicle moves towards an obstruction again, the intermittent signal chimes beep automatically.
Display
The graphic on the screen displays the scanned areas in several segments. The closer the vehicle drives towards an obstacle, the closer the segment will move to the vehicle in the display. The collision area has been reached at the latest when the second to last segment is displayed. Do not keep driving!

Vehicles with PDC at the front and rear
Area of the vehicle Distance of the vehicle from an obstacle
Signal tone Segment color if an obstacle has been detected color display only)
(A) Rear center Obstacle not in the vehicle’s path
about 12 – 63 in. (31 – 160 cm) – Grey
Rear side about 12 – 23 in. (31 – 60 cm)
(B) Front center about 12 – 47 in. (31 – 120 cm)
Front side about 12 – 23 in. (31 – 60 cm)
(A) Rear center Obstacle in the vehicle’s path
about 12 – 63 in. (31 – 160 cm) Intermittent tone Yellow
Rear side about 12 – 23 in. (31 – 60 cm)
(B) Front center about 12 – 47 in. (31 – 120 cm)
Front side about 12 – 23 in. (31 – 60 cm)

Vehicles with PDC at the front and rear
Area of the vehicle Distance of the vehicle from an obstacle
Signal tone Segment color if an obstacle has been detected color display only)
(A), (B) Obstacle outside of the collision area about 0 – 12 in. (0 – 30 cm) Intermittent tone Red
(A), (B) Obstacle in the collision area about 0 – 12 in. (0 – 30 cm) Constant tone Red

WARNING
Do not allow the images shown on the screen to distract you from the traffic around you.
NOTICE
Failure to observe the illuminated text messages can lead to the vehicle being damaged.
It can take a few seconds before the area scanned by the sensors is displayed on the screen of the factory-installed Infotainment system.
Applicable only in the United States
PDC menu
