2017 VAUXHALL ASTRA J Infotainment system

Phone145The submenu prompts you with a
question. To reset all values to the factory defaults, select Yes.
Emergency call9 Warning
Connection setup cannot be
guaranteed in all situations. For
this reason you should not rely
exclusively on a mobile phone
when a vitally important
communication (e.g. a medical
emergency) is concerned.
In some networks it may be
necessary for a valid SIM card to
be properly inserted in the mobile
phone.
9 Warning
Bear in mind that you can make
and receive calls with the mobile
phone, if it is in a service area with
a sufficiently strong signal. Under
certain circumstances emergency
calls cannot be made on all mobile
phone networks; it is possible that
they cannot be made when certain network services and/or telephone
functions are active. You can
enquire about this with the local
network operators.
The emergency call number can
differ depending on the region and country. Please enquire
beforehand about the correct
emergency call number for the
relevant region.
Making an emergency call
Dial the emergency call number (e.g.
112 ).
The telephone connection to the
emergency call centre is set up.
Answer when the service personnel
questions you about the emergency.
9 Warning
Do not end the call until you are
requested to do so by the
emergency call centre.
Operation
As soon as a Bluetooth connection
has been set up between your mobile
phone and the Infotainment system,
you can also operate many functions
of your mobile phone via the
Infotainment system.
Via the Infotainment system, you can, e.g., set up a connection to the
telephone numbers stored in your
mobile phone or change the
telephone numbers.
Notice
In the handsfree mode, mobile
phone operation is still possible,
e.g. taking a call or adjusting the
volume.
After the setup of a connection
between the mobile phone and the
Infotainment system, mobile phone
data is transmitted to the Infotainment
system. This can take several
minutes depending on the phone
model. During this period, operation
of the mobile phone is possible via the
Infotainment system only to a limited extent.

146PhoneNotice
Not every mobile phone supports all
functions of the Phone portal.
Therefore deviations from the range
of functions described with these
specific mobile phones are possible.
Prerequisites
The following prerequisites must be met in order to use the handsfree
mode of the Infotainment system:
● The Bluetooth function of the Infotainment system must be
activated 3 143.
● The Bluetooth function of the mobile phone must be activated
(see user guide of the device).
● The mobile phone must be set to
"visible" (see user guide of the
device).
● The mobile phone must be paired
to the Infotainment system
3 143.
Activating the handsfree mode
Press PHONE on the control panel of
the Infotainment system. The phone
main menu is displayed.Notice
If there is no mobile phone
connected to the Infotainment
system, No phone available is
displayed. For a detailed description of how to establish a Bluetooth
connection 3 143.
Many functions of the mobile phone
can now be controlled via the phone
main menu (and associated
submenus) and via the phone-
specific controls on the steering
wheel.
Initiating a phone call
Entering a number manually
Being in the phone main menu, press
the multifunction knob to open the
Phone Menu .
Select Enter number . The following
screen is displayed.
Enter the desired number and select
y on the display to start dialling.
Notice
To open the Search screen of the
phone book, select 4.
Using the phone book Notice
The phone book may only be
downloaded if this function is
supported by your mobile phone.
For further information, please
consult the user guide of your mobile phone.
The phone book contains contact
names and numbers.

Phone147
With the phone main menu active,
press the multifunction knob to open
the Phone Menu .
Select Phone book . Select Search
and then First Name or Last Name .
The following screen is displayed.As on a telephone or mobile phone,
the letters are organised in
alphabetical groups on the display:
abc , def , ghi , jkl , mno , pqrs , tuv , and
wxyz .
Select the desired group of letters.
The phone book is displayed showing the entries starting with one of theletters in the letter group.
Scroll through the list and select the
desired entry name.
Scroll through the list of phone
numbers and select the desired
number. The corresponding phone
number is dialled.
Deleting the phone book
To delete all entries in the phone book
on the Infotainment system, press
PHONE . Select Phone book and then
Delete all .
Using the call lists
All incoming, outgoing, or missed
calls are registered in corresponding
call lists.
With the phone main menu active,
press the multifunction knob to open
the Phone Menu . Select Call lists .
The following screen is displayed.

148PhoneSelect the desired call list, e.g.
Missed calls . A menu with the
corresponding call list is displayed.
To initiate a phone call: select the
desired list entry. The corresponding
phone number is dialled.
Redialling a phone number
The last dialled phone number can be
redialled.
Press 7 on the steering wheel to
open the Redial menu.
Press 7 again to start dialling.
Press xn on the steering wheel to
exit the Redial menu. You may
optionally use the multifunction knob
to select No on the display.
Incoming phone call
If an audio mode, e.g. the radio or CD
mode, is active at the time of an
incoming call, the relating audio
source will be muted and stay muted until the call ends.
To answer the call: select Answer on
the display.
To reject the call: select Decline on
the display.Second incoming phone call
If a second phone call comes in
during an ongoing call, a message is
displayed.
To answer the second call and end
the ongoing call: select Answer on the
display.
To reject the second call and continue the ongoing call: select Decline on the
display.
Changing the ring tone
Press CONFIG to open the Settings
menu.
Select Phone settings , Sound &
Signals and then Ring tone. A list of
all ring tones available is displayed.
Select the desired ring tone.
For a detailed description of the ring
tone volume 3 123.
Functions during a phone call During an ongoing phone call, the
phone main menu is displayed.
Select Menu on the display to open
the menu Connected .
Select Hang up on the display to end
the call.Activating the private mode
In the Connected menu, select
Private call to switch the call to the
mobile phone.
To switch the call back to the
Infotainment system, select Menu on
the display and then Transfer call.
Deactivating/activating the
microphone
In the Connected menu, set Mute
Mic to On . The caller cannot hear you
any more.
To reactivate the microphone: set
Mute Mic to Off again.
Mobile phones and CB radio equipment
Installation instructions and
operating guidelines
The vehicle specific installation
instructions and the operating
guidelines of the mobile phone and
handsfree manufacturer must be observed when installing and
operating a mobile telephone. Failure

Phone149to do so could invalidate the vehicle
type approval (EU directive 95/54/
EC).
Recommendations for fault-free
operation:
● The exterior antenna needs to be
professionally installed to obtain
the maximum range possible.
● Maximum transmission power: 10 watts.
● The mobile phone needs to be installed in a suitable spot.
Consider relevant note in the
Owner's manual, section Airbag
system .
Seek advice on predetermined
installation points for the external
antenna or equipment holder and
ways of using devices with a
transmission power exceeding
10 watts.
Use of a handsfree attachment
without external antenna with mobile
telephone standards
GSM 900/1800/1900 and UMTS is
only permitted if the maximumtransmission power of the mobile telephone is 2 watts for GSM 900 or
1 watt for the other types.
For reasons of safety, do not use the
phone while driving. Even use of a handsfree set can be a distraction
while driving.9 Warning
Operation of radio equipment and
mobile telephones which fail to
meet above mentioned mobile
telephone standards is only
permitted using an antenna
located outside of the vehicle.
Caution
Mobile telephones and radio
equipment may lead to
malfunctions in the vehicle
electronics when operated inside
the vehicle with no exterior
antenna, unless the above
mentioned regulations are
observed.

150IndexAActivating Bluetooth music .........140
Activating CD player ...................134
Activating the AUX function ........136
Activating the handsfree Phone mode ....................................... 145
Activating the radio .....................124
Activating the USB function ........138
Autostore lists ............................. 125
Retrieving stations................... 125
Storing stations .......................125
Auto volume control ....................123
AUX input Activating................................. 136
Adjusting the volume ...............136
General information ................136
Operation ................................ 136
B Basic operation ........................... 120
Blocking out traffic announcements ......................129
Bluetooth Bluetooth connection ..............143
Bluetooth music....................... 140
Phone ...................................... 145
Bluetooth connection ..................143
Bluetooth music Activating................................. 140General information ................140Operation................................ 140
Prerequisites ........................... 140
C Call Functions during a call ............145
Incoming call ........................... 145
Initiating a phone call ..............145
Ring tone ................................. 145
Call lists ...................................... 145
Category list................................ 126
CD menu .................................... 134
CD player Activating................................. 134
CD menu ................................. 134
General information ................133
Inserting a CD ......................... 134
Removing a CD .......................134
Starting CD playback ..............134
Usage ...................................... 134
Control elements Infotainment system ................116
Phone ...................................... 142
Steering wheel ........................ 116
Control elements overview .........116
D DAB ............................................ 130
Date settings............................... 119
Digital audio broadcasting ..........130
Dynamic audio adaption .............130

151EEmergency call ........................... 145
F
Favourite lists ..................... 125, 126
Retrieving stations................... 125
Storing stations .......................125
G General information ...133, 136,
137, 140, 142
AUX input ................................ 136
Bluetooth music....................... 140
CD player ................................ 133
Infotainment system ................114
Phone ...................................... 142
USB port.................................. 137
I
Infotainment control panel ..........116
L
Language settings ......................119
M
Maximum start-up volume ..........123
Menu operation .......................... 120
Mobile phones and CB radio equipment .............................. 148
Multifunction knob....................... 120 Mute............................................ 119O
Operation ............................ 140, 145
AUX input ................................ 136
Bluetooth music....................... 140
CD player ................................ 134
Menu ....................................... 120
Phone ...................................... 145
Radio ....................................... 124
USB port.................................. 138
P Phone Activating................................. 145
Bluetooth ................................. 142
Bluetooth connection ..............143
Call lists ................................... 145
Control elements .....................142
Dialling a number ....................145
Emergency calls ......................145
Functions during a call ............145
General information ................142
Important information ..............142
Incoming call ........................... 145
Phone book ............................. 145
Prerequisites ........................... 145
Redialling a phone number .....145
Selecting the ring tone ............145
Phone book ................................ 145
Playing saved audio files ............138R
Radio Activating................................. 124Autostore lists.......................... 125
Band selection ........................ 130
Category list ............................ 126
Configuring DAB .....................130
Configuring RDS .....................129
DAB announcements ..............126
Digital audio broadcasting
(DAB) ...................................... 130
Dynamic audio adaption .........130
Favourite lists ..................125, 126
Radio data system (RDS) .......129
Radio traffic service................. 129
Regionalisation ....................... 129
Retrieving stations................... 125
Selecting the waveband ..........124
Station lists .............................. 126
Station search ......................... 124
Station tuning .......................... 124
Storing stations .......................125
Traffic announcements ...........129
Updating station lists ...............126
Usage ...................................... 124
Waveband menus ...................126
Radio data system (RDS) ..........129
Radio traffic service ....................129
RDS ............................................ 129
Redial function ............................ 145

152Regionalisation........................... 129
Retrieving stations ......................125
Ring tone Ring tone volume ....................123
Selecting the ring tone ............145
S
Selecting the waveband .............124
Starting CD playback ..................134
Station lists ................................. 126
Station search............................. 124
Steering wheel audio controls ....116
Storing stations ........................... 125
Switching the Infotainment system on ................................ 119
Switching the radio on ................124
System settings Language ................................ 119
Restore factory settings ..........119
Time and date ......................... 119
Vehicle settings .......................119
T
TA volume .................................. 123
Theft-deterrent feature ..............115
Time settings .............................. 119
Tone settings .............................. 122
Traffic announcements ...............129U
Updating station lists ..................126
Usage ................. 119, 124, 134, 136
AUX input ................................ 136
Bluetooth music....................... 140 CD player ................................ 134
Menu ....................................... 120
Phone ...................................... 145
Radio ....................................... 124
USB port.................................. 138
USB menu .................................. 138
USB port Activation................................. 138
Connecting the USB device ....137
General information ................137
Important information ..............137
Operation ................................ 138
Removing the USB device ......138
USB menu ............................... 138
V Volume Auto volume control ................123
Maximum start-up volume .......123
Mute function........................... 119
Ring tone volume ....................123
Setting the volume ..................119
Speed compensated volume ..123TA volume ............................... 123
Volume limitation at high
temperatures ........................... 119
Volume settings .......................... 123
W
Waveband menus....................... 126
