6218-2. Steps to take in an emergency
RAV4_OM_OM0R005U_(U)
8
When trouble arises
■If the tire pressure warning system is not functioning
The tire pressure warning system will be disabled in the following condi-
tions:
(When the condition becomes normal, the system will work properly.)
●If tires not equipped with tire pressure warning valves and transmitters
are used
●If the ID code on the tire pressure warning valves and transmitters is not
registered in the tire pressure warning computer
●If the tire inflation pressure is 70 psi (480 kPa, 4.9 kgf/cm2 or bar) or
higher
The tire pressure warning system may be disabled in the following condi-
tions:
(When the condition be comes normal, the system will work properly.)
●If electronic devices or facilities using similar radio wave frequencies are
nearby
●If a radio set at a similar frequency is in use in the vehicle
●If a window tint that affects the radio wave signals is installed
●If there is a lot of snow or ice on the vehicle, particularly around the
wheels or wheel housings
●If non-genuine Toyota wheels are used (Even if you use Toyota wheels,
the tire pressure warning system may not work properly with some types
of tires.)
●If tire chains are used
●If the spare tire is in a location subject to poor radio wave signal reception.*
●If a large metallic object which can interfere with signal reception is put
in the luggage compartment.
*
*
: Vehicles with full-size spare tire only
■
If the tire pressure warning light frequently comes on after blinking
for 1 minute (vehicles with the tire pressure warning system)
If the tire pressure warning light frequently comes on after blinking for 1
minute when the engine switch is turned to the “ON” position (vehicles
without smart key system) or IGNITI ON ON mode (vehicles with smart
key system), have it checked by your Toyota dealer.

RAV4_OM_OM0R005U_(U)
6739-1. Specifications
9
Vehicle specifications
Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the
factory.
Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent
of matching quality to satisfy the above specification. Please contact your
Toyota dealer for further details.
*: The fluid capacity is the quantity of reference.If replacement is necessary, contact your Toyota dealer.
Electrical system
Battery
Open voltage at 68 °F
(20 °C):12.3 V or higher
(Voltage is checked 20 minutes after the engine
and all lights are turned off.)
Charging rates5 A max.
Rear differential (AWD models)
Oil capacity0.5 qt. (0.5 L, 0.4 Imp.qt.)
Oil type and viscosityToyota Genuine Differential gear oil LT
75W-85 GL-5 or equivalent
Automatic transaxle
Fluid capacity*6.9 qt. (6.5 L, 5.7 Imp.qt.)
Fluid typeToyota Genuine ATF WS
NOTICE
■ Automatic transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause
deterioration in shift quality, locking up of your transmission accompanied
by vibration, and ultimately damage the transmission of your vehicle.

722What to do if... (Troubleshooting)
RAV4_OM_OM0R005U_(U)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (→P. 156)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. ( →P. 200)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? ( →P. 616)
●The brake system warning light is on
Is the parking brake released? (→P. 212)
Depending on the situation, other types of warning buzzer may also sound.
( →P. 615, 625)
●Is the message displayed on the multi-information display?
Check the message on the multi-information display. ( →P. 636)
●When a warning light turns on or a warning message is displayed, refer to
P. 615, 625.
The windows do not open or close by operating the power
window switches
The engine switch is turned off automatically
(vehicles with smart key system)
A warning buzzer sounds during driving
A warning buzzer sounds when leaving the vehicle
(vehicles with smart key system)
A warning light turns on or a warning message is displayed

726Alphabetical index
RAV4_OM_OM0R005U_(U)
Cargo capacity ......................... 668
Cargo hooks............................. 508
Catch protection function ....... 157
CD player .......................... 336, 409
Chains....................................... 314
Child restraint system ............... 57Booster seats, definition ......... 57
Booster seats, installation ....... 67
Convertible seats, definition ............................... 57
Convertible seats,
installation ............................ 64
Front passenger occupant classification syst em............. 49
Infant seats, definition ............. 57
Infant seats, installation .......... 64
Installing CRS with LATCH system ..................... 62
Installing CRS with seat belts ...................................... 64
Installing CRS with top tether strap ........................... 69
Child safety ................................ 56
Airbag precautions .................. 39
Back door precautions .......... 123
Battery precautions ....... 563, 661
Child restraint system ............. 57
How your child should wear the seat belt ................. 32
Installing child restraints ......... 61
Moon roof precautions .......... 163
Power window lock switch .... 156
Power window
precautions ......................... 159
Rear door child-protectors .... 110
Removed key battery precautions ......................... 587
Seat belt extender precautions ........................... 35
Seat belt precautions .............. 33
Seat heater precautions........ 499 Child-protectors ...................... 110
Cleaning ........................... 536, 539
Aluminum wheels ................. 537
Exterior ................................. 536
Interior .................................. 539
Radar sensor ................ 234, 300
Seat belts.............................. 540
Clock......................................... 398
Coat hooks ............................... 521
Compass .................................. 530
Condenser................................ 560
Console box ............................. 505
Coolant ..................................... 558 Capacity................................ 672
Checking............................... 558
Preparing and checking before winter ...................... 314
Cooling system Engine overheating............... 662
Cruise control
Cruise control ....................... 273
Dynamic radar cruise control ................................ 261
Warning message................. 630
Cup holders ............................. 506
Curtain shield airbags............... 36
Customizable features ............ 693
Daytime running light system.................................... 215
Defogger Outside rear view
mirrors ........................ 486, 493
Rear window ................. 486, 493
Windshield ............................ 485
Differential................................ 673
Dimension ................................ 668
Dinghy towing.......................... 195
D

728Alphabetical index
RAV4_OM_OM0R005U_(U)
Emergency flashers ................ 604
Engine“ACC” position ...................... 196
Accessory mode ................... 199
Compartment ........................ 554
Engine switch................ 196, 198
Hood ..................................... 551
How to start the engine......................... 196, 198
Identification number ............ 670
If the engine will not start ...... 654
Ignition switch (engine switch) ........... 196, 198
Overheating .......................... 662
Engine coolant ......................... 558 Capacity ................................ 672
Checking ............................... 558
Preparing and checking before winter....................... 314
Engine immobilizer system ...... 73
Engine oil ................................. 555
Capacity ................................ 671
Checking ............................... 555
Preparing and checking before winter....................... 314
Engine switch (ignition switch)............. 196, 198
Engine switch light (ignition switch light) ............ 501 Entune Audio ........................... 390
AUX Port/USB port ............... 393
Basic Audio Operations ........ 394
CD player.............................. 409
iPod ...................................... 416
Listening to Bluetooth
®
Audio .................................. 439
Radio .................................... 407
Steering wheel audio
switches ............................. 392
USB memory ........................ 421
Using a Bluetooth
®
Phone ................................. 441
Using the AUX port ............... 426
Entune Audio Plus
*
EPS (Electric Power Steering) ................................ 308
Function ................................ 308
Warning light......................... 616
Event data recorder (EDR)........ 10
Exhaust gas precautions .......... 72
Flat tire ..................................... 641
Floor mats .................................. 24
Fluid Automatic transaxle .............. 673
Brake .................................... 674
Washer ................................. 564
Fog lights ................................. 221
Replacing light bulbs ............ 594
Switch ................................... 221
Wattage ................................ 676
Front passenger occupant classification system .............. 49
F

735Alphabetical index
RAV4_OM_OM0R005U_(U)
Talk switch*.......................... 478
Telephone switches ...... 364, 455
Tire pressure warning
reset switch ........................ 567
VSC OFF switch ................... 309
Window lock switch............... 156
Windshield wipers and washer switch ..................... 222
Tachometer ................................ 84
Tail lights .................................. 213 Light switch ........................... 213
Replacing light bulbs............. 598
Wattage ................................ 676
Talk switch
*............................. 478
Telephone switches ........ 364, 455
Theft deterrent system
Engine immobilizer system ..... 73
Tire inflation pressure ............. 675
Maintenance data ................. 675
Warning light ......................... 618
Tire information ....................... 680
Glossary................................ 687
Size ....................................... 683
Tire identification number ..... 682
Uniform Tire Quality Grading............................... 685
Tire pressure warning system .................................... 567
Function ................................ 567
Initializing .............................. 567
Installing tire pressure warning valves and
transmitters......................... 567
Registering ID codes ............ 569
Tire pressure warning
reset switch ........................ 567
Warning light ......................... 618 Tires .......................................... 565
Chains .................................. 314
Checking............................... 565
If you have a flat tire ............. 641
Inflation pressure .................. 675
Information............................ 680
Replacing.............................. 641
Rotating tires ........................ 566
Size....................................... 675
Snow tires ............................. 316
Spare tire .............................. 641
Tire pressure warning
system .......... ...................... 567
Warning light......................... 618
Tools ......................................... 642
Top tether strap ......................... 69
Total load capacity .................. 668
Touchless power back door ........................................ 115
Towing
Dinghy towing ....................... 195
Emergency towing ................ 609
Towing eyelet ....................... 609
Trailer Sway Control ............. 308
Trailer towing ........................ 181
Toyota Safety Sense P ............ 232
TRAC (Traction Control) ......... 307
Trailer Sway Control ............... 308
Trailer towing ........................... 181
Transmission Automatic transmission ........ 203
If the shift lever cannot be shifted from P ..................... 209
Paddle shift switches ............ 206
Selecting the driving mode ... 205
Trip information ......................... 94
Trip meters ................................. 85
Troubleshooting ...................... 720
T
*: Refer to “NAVIGATION AND MULT IMEDIA SYSTEM OWNER’S MANUAL”.
