2017 TOYOTA 4RUNNER check engine

4527-2. Steps to take in an emergency
4RUNNER (U)_(OM35B37U)
Ensure that the shift lever is in P and depress the brake pedal.
Touch the Toyota emblem side
of the electronic key to the
engine switch.
If any of the doors is opened or
closed while the key is being
touched to the switch, an alarm will
sound to indicate that the start
function cannot detect the key.
Press the engine switch.
In the event that the engine still ca nnot be started, contact your Toyota
dealer.
■ Stopping the engine
Shift the shift lever to P and press the engine switch as you normally do when
stopping the engine.
■ Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the
electronic key battery be replaced immediately when the battery is depleted.
(→P. 384)
■ Changing engine switch modes
Within 10 seconds of the buzzer sounding, release the brake pedal and press
the engine switch.
The engine does not start and modes will be changed each time the switch is
pressed.( →P. 197)
Starting the engine
1
2
3
CAUTION
■When using the mechanical key and operating the power windows,
power back window or moon roof
Operate the power windows, power back window or moon roof after check-
ing to make sure that there is no possibility of any passenger having any of
their body parts caught in the window or moon roof.
Also, do not allow children to operate the mechanical key. It is possible for
children and other passengers to get caught in the power windows, power
back window or moon roof.

4587-2. Steps to take in an emergency
4RUNNER (U)_(OM35B37U)
Add engine coolant if neces-
sary. (→P. 355)
Water can be used in an emer-
gency if engine coolant is unavail-
able.
Start the engine to check that the radiator cooling fan operate and
to check for coolant leaks fr om the radiator or hoses.
If the fan are not operating:
Stop the engine immediately and contact your Toyota dealer.
If the fan are operating:
Have the vehicle in spected at the nearest Toyota dealer.
5
CAUTION
■When inspecting under the hood of your vehicle
Observe the following precautions.
Failure to do so may result in serious injury such as burns.
● If steam is seen coming from under the hood, do not open the hood until
the steam has subsided. The engine compartment may be very hot.
● Keep hands and clothing (especially a tie, a scarf or a muffler) away from
the fans and belts.
6
7
●Do not loosen the radiator cap and the
coolant reservoir cap while the engine
and radiator are hot.
High temperature steam or coolant
could spray out.

4658-1. Specifications
8
Vehicle specifications
4RUNNER (U)_(OM35B37U)
*: The engine oil capacity is a reference quantity to be used when changingthe engine oil. Warm up and turn off the engine, wait more than 5 minutes,
and check the oil level on the dipstick.
■
Engine oil selection
Except for Puerto Rico
“Toyota Genuine Motor Oil” is us ed in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat-
isfy the following grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice
for good fuel economy and
good starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.
Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which
allows cold startability. Oils with a lower value before the W allow
for easier starting of the engine in cold weather.
• The 20 in 0W-20 indicates the viscosity characteristic of the oil when the oil is at high temperature. An oil with a higher viscosity
(one with a higher value) may be better suited if the vehicle is
operated at high speeds, or under extreme load conditions.
Lubrication system
Oil capacity
(Drain and refill ⎯ reference
*)
With filter
Without filter6.6 qt. (6.2 L, 5.5 Imp. qt.)
6.0 qt. (5.7 L, 5.0 Imp. qt.)
Outside temperature

4698-1. Specifications
8
Vehicle specifications
4RUNNER (U)_(OM35B37U)
*: Your Toyota vehicle is filled with “Toyota Genuine Transfer Gear oil LF” atthe factory. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or
an equivalent of matching quality to satisfy the above specification. Pl\
ease
contact your Toyota dealer for further details.
Electrical system
Battery
Open voltage* at
68° F (20 °C):
12.6 ⎯ 12.8 V Fully charged
12.2 ⎯ 12.4 V Half charged
11 . 8 ⎯ 12.0 V Discharged
(
*: Voltage checked 20 minutes after the
engine and all the lights are turned off.)
Charging rates5 A max.
Transfer (4WD models)
Oil capacity
Part-time 4WD models
1.1 qt. (1.0 L, 0.9 Imp. qt.)
Full-time 4WD models
1.5 qt. (1.4 L, 1.2 Imp. qt.)
Oil type*Toyota Genuine Transfer gear oil LF or
equivalent
Recommended oil viscositySAE 75W

512
4RUNNER (U)_(OM35B37U)
What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
●If you lose your keys or mechanical keys, new genuine mechanical keys
can be made by your Toyota dealer. ( →P. 93)
●If you lose your keys or electronic keys, the risk of vehicle theft increases
significantly. Contact your Toyota dealer immediately. (→P. 96)
●Is the key battery weak or depleted? ( →P. 383)
●Vehicles with a smart key system:
Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. ( →P. 197)
●Vehicles with a smart key system:
Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of the radio
wave. ( →P. 107)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (→P. 100)
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened

515What to do if... (Troubleshooting)
4RUNNER (U)_(OM35B37U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts?
(→P. 420)
●The brake system warning light is on
Is the parking brake released? ( →P. 207)
●The open door warning indicator is on
Are all the doors closed? (→P. 97, 115)
Depending on the situation, other types of warning buzzer may also sound.
( →P. 417, 426)

●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( →P. 72)
To stop the alarm, turn the engine switch to IGNITION ON mode (vehicles
with a smart key system) or start the engine.
●Is the electronic key left inside the vehicle?
Check the message on the multi-information display.
●When a warning light turns on, refer to P. 417.
●When a warning light turns on or a warning message or indicator is dis-
played, refer to P. 417, 426.
A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart key system)
A warning light turns on or a warning message is displayed

520Alphabetical index
4RUNNER (U)_(OM35B37U)
EngineACCESSORY mode ............. 197
Compartment ........................ 354
Engine switch................ 193, 196
Hood ..................................... 353
How to start the
engine......................... 193, 196
Identification number ............ 463
If the engine will not start ...... 448
Ignition switch (engine switch) ........... 193, 196
Overheating .......................... 457
Engine coolant ......................... 359 Capacity ................................ 468
Checking ............................... 359
Preparing and checking before winter....................... 272
Engine coolant temperature gauge........................................ 81
Engine immobilizer system ...... 70
Engine oil ................................. 356
Capacity ................................ 465
Checking ............................... 356
Preparing and checking before winter....................... 272
Engine switch .................. 193, 196
Event data recorder (EDR) ........ 10
Flat tire...................................... 433
Floor mats .................................. 26
Fluid Automatic transmission......... 471
Brake .................................... 471
Power steering ...................... 472
Washer ................................. 367
Fog lights ................................. 214 Replacing light bulbs............. 389
Switch ................................... 214
Wattage ................................ 473
Four-wheel drive
system ............................ 235, 239 Front passenger occupant
classification system .............. 46
Front personal lights............... 298
Front seats ............................... 120 Adjustment............................ 120
Cleaning ............................... 341
Correct driving posture ........... 28
Driving position memory ....... 133
Head restraints ..................... 137
Seat heaters ......................... 295
Seat position memory ........... 133
Seat ventilators ..................... 295
Front side marker lights ......... 208 Light switch ........................... 208
Replacing light bulbs ............ 396
Wattage ................................ 473
Front turn signal lights ........... 206
Replacing light bulbs ............ 394
Turn signal lever ................... 206
Wattage ................................ 473
Fuel ........................................... 222 Capacity................................ 464
Fuel gauge.............................. 81
Fuel pump shut off system ... 416
Information............................ 474
Refueling .............................. 222
Type.............................. 222, 464
Warning light......................... 419
Fuel filler door ......................... 222 Refueling .............................. 222
Fuel pump shut off system..... 416
Fuses ........................................ 386
Garage door opener ................ 324
Gauges ....................................... 81
Glove box ................................. 301
Grocery bag hooks.................. 310
F
G

525Alphabetical index
4RUNNER (U)_(OM35B37U)
StuckIf the vehicle becomes
stuck ................................... 460
Sun visors ................................ 312
Switches Cruise control switch............. 225
“DISP” button .......................... 84
Door lock switches .................. 99
Driving position memory switches.............................. 133
Emergency flashers switch ... 406
Engine switch................ 193, 196
Fog light switch ..................... 214
Garage door opener
switches.............................. 324
Ignition switch ............... 193, 196
Light switches ....................... 208
Moon roof switches ............... 154
Outside rear view mirror switches.............................. 144
Power back window switch ................................. 150
Power door lock switch ........... 99
Power window switches ........ 146
Rear window and outside
rear view mirror defoggers
switch ......................... 284, 290
Rear window wiper and washer switch ..................... 219
Seat heater switches ............ 295
Seat ventilator switches ........ 295
“SOS” button ......................... 331
Telephone switches
*
VSC OFF switch ................... 265
Window lock switch............... 146
Windshield wipers
and washer switch .............. 216 Tachometer ................................ 81
Tail lights.................................. 208
Light switch ........................... 208
Telephone switches
*
Theft deterrent system
Alarm ...................................... 72
Engine immobilizer system ..... 70
Tire inflation pressure............. 375 Maintenance data ................. 472
Warning light......................... 420
Tire information ....................... 477 Glossary ............................... 483
Size....................................... 479
Tire identification number ..... 478
Uniform Tire Quality Grading .............................. 481
Tire pressure warning system.................................... 371 Function ................................ 371
Installing tire pressure warning
valves and transmitters ...... 371
Registering ID codes ............ 371
Warning light......................... 420
Tires .......................................... 369 Chains .................................. 274
Checking............................... 369
If you have a flat tire ............. 433
Inflation pressure .................. 472
Information............................ 477
Replacing.............................. 433
Rotating tires ........................ 370
Size....................................... 472
Snow tires ............................. 275
Spare tire .............................. 433
Tire pressure warning system .......... ...................... 371
Warning light......................... 420
T
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
