2017 TESLA MODEL S Owner's Manual

12V Power SocketYour Model S has a power socket located onthe front of the center console. Power is
available whenever the instrument panel and
touchscreen are on.
The 12V power socket is suitable for
accessories requiring up to 11A continuous
draw (15A peak) or a maximum of 150
continuous watts (180 watts peak).
Note: In situations where Model S is unable to detect the key (low battery, interference, etc.),
place it immediately below the 12V power
socket where Model S can best detect it.
Warning: The power socket and an
accessory

Bluetooth

Connecting to a Paired Phone
Model S automatically connects with the last
phone to which it was connected, provided it
is within operating range and has Bluetooth turned on. If the last phone is not within range,
it attempts to connect with the next phone
that it has been paired with.
To connect to a
different phone, touch the
Bluetooth icon on the touchscreen

Overview
Touch the Maps (or Nav) icon to view and
search for a location on Google Maps TM
. If
Model S is equipped with the Navigation option, the application is labeled Nav, and
onboard maps are available. Onboard maps
allow you to navigate to any location, even if a
data connection is not available, but you must
enter the location

North Up - North is always at the
top of the screen.Heading Up - The direction you are
heading is always at the top of the
screen. The map rotates when you
change direction. This icon has an
integrated compass that indicates
the direction you are driving.
You can rotate the map in any direction using
your fingers. When you rotate the map, the
North/Heading Up icon turns gray to indicate
the map is no longer tracking your position.
Touch the icon again to adjust the orientation
and track your position.
To maximize the size of the map, the
touchscreen

During Navigation
During navigation, the touchscreen displays a
turn-by-turn direction list that includes estimated mileage, driving time, arrival time,
and an estimate of how much energy is
remaining when you reach the destination.
Note: If Model S requires charging to reach the
destination and Trip Planner is turned on (see Trip Planner on page 118), the navigation
route includes Supercharger stops.
The touchscreen also displays your location on
the map. Depending on the map

Note: For security reasons, if you sell Model S,
erase your Home and Work locations, and
your favorite destinations (see Erasing
Personal Data on page 101).
Updated Maps To receive updated maps, periodically connectModel S to a Wi-Fi network (see Connecting
to Wi-Fi on page 125). As updated maps
become available, they are sent to Model S
over Wi-Fi only. The touchscreen displays a
message informing you when new maps have
been installed.
Maps and Navigation
Using the Touchscreen119
