2017 Ram ProMaster City display

Instrument Cluster Display
1. Speedometer•Indicates vehicle speed.
2. Fuel Gauge •The pointer shows the level of fuel in the fuel tank
when the ignition switch is in the ON/RUN position.
•
The fuel pump arrow symbol points to the side
of the vehicle where the fuel door is located.
3. Temperature Gauge
•
The temperature gauge shows engine coolant tempera-
ture. Any reading within the normal range indicates that
the engine cooling system is operating satisfactorily.
• The gauge pointer will likely indicate a higher tem-
perature when driving in hot weather or up mountain
grades. It should not be allowed to exceed the upper
limits of the normal operating range.
WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call an authorized dealer for
service if your vehicle overheats. If you decide to look
(Continued)
WARNING! (Continued)
under the hood yourself, see “Maintaining Your Ve-
hicle”. Follow the warnings under the Cooling System
Pressure Cap paragraph.
CAUTION!
Driving with a hot engine cooling system could dam-
age your vehicle. If the temperature gauge reads “H”
pull over and stop the vehicle. Idle the vehicle with the
air conditioner turned off until the pointer drops back
into the normal range. If the pointer remains on the
“H”, turn the engine off immediately and call an
authorized dealer for service.
4. Tachometer •Indicates the engine speed in revolutions per minute
(RPM x 1000).
5. Instrument Cluster Display •When the appropriate conditions exist, this display
shows the Instrument Cluster Display messages. Refer
to “Instrument Cluster Display” in “Understanding
Your Instrument Panel” for further information.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 119

INSTRUMENT CLUSTER DISPLAY
Your vehicle may be equipped with an Instrument Cluster
Display, which offers useful information to the driver. With
the ignition in the STOP/OFF position (and the key
removed, for vehicles with mechanical key), opening/
closing of a door will activate the display for viewing, and
display the total miles or kilometers in the odometer. Your
Instrument Cluster Display is designed to display impor-
tant information about your vehicle’s systems and features.
Using a driver interactive display located on the instru-
ment panel, your Instrument Cluster Display can show you
how systems are working and give you warnings when
they aren’t. The steering wheel mounted controls allow
you to scroll through and enter the main menus and
submenus. You can access the specific information you
want and make selections and adjustments.
Instrument Cluster Display Location and Controls
The Instrument Cluster Display features a driver-
interactive display that is located in the instrument cluster.The Instrument Cluster Display Menu may consist of the
following items depending on the configuration of vehicle
options:
•
Speed Beep
• Trip B Data
• Set Time
• Set Date
• Autoclose
• Units
Instrument Cluster Display Location
120 UNDERSTANDING YOUR INSTRUMENT PANEL

•Language
• Buzzer Volume
• Seat Belt Buzzer
• Service
• Daylights
• Exit Menu
The system allows the driver to select information by
pushing the following buttons mounted on the instrument
panel to the right of the steering column: •
MENU Button
Push and release the MENUbutton for a time longer than
1 second to access/select the information screens or sub-
menu screens of a main menu item. Push and hold the
MENU button for two seconds to reset displayed/selected
features that can be reset.
• UP Arrow Button
Push and release the UParrow button to scroll
upward through the main menu and submenus.
• DOWN Arrow Button
Push and release the DOWNarrow button to
scroll downward through the main menu and
submenus.
Dimmer:
With headlights on and without entering in the menu, push
the UP
orDOWNarrow button to increase or
decrease the brightness of the instrument panel, graph-
ics and command buttons.
Selecting An Option Of The Main Menu With Submenu:
1. Briefly push and release the MENUbutton to display
the first submenu option.
Instrument Cluster Display Control Buttons
4
UNDERSTANDING YOUR INSTRUMENT PANEL 121

2. Push and release theUPorDOWNarrow
button (by single pushes) to scroll through all the
submenu options.
3. Briefly push and release the MENUbutton to select the
displayed submenu option and to open the relevant
setup menu.
4. Push and release the UP
orDOWNarrow
button (by single pushes) to select the new setting for
this submenu option.
5. Briefly push and release the MENUbutton to store the
new setting and go back to the previously selected
submenu option.
6. Push and hold the MENUbutton to return to the main
menu (short hold) or the main screen (longer hold).
Instrument Cluster Display Menu Items
Speed Beep
This function is used to set a speed limit (MPH or km/h);
the driver is alerted when this limit is exceeded. To set the desired speed limit:
1. Push the
MENUbutton briefly. The display will show
the wording (SPEED) and the unit (MPH) or (km/h)
previously set.
2. If the function is on, push and release the UP
or
DOWN
arrow button to select the required speed
limit and then push MENUto confirm.
NOTE: The speed may be set in the range from 20 to
125 MPH (30 to 200 km/h) according to the previously
chosen unit (see “Setting The Unit”) described below.
The setting will increase/decrease by five units each time
the UP
orDOWNarrow button is pushed. Hold
down the UP
orDOWNarrow button to auto-
matically increase/decrease the setting rapidly. Com-
plete the adjustment when you approach the desired
value.
Push the MENUbutton briefly to return to the menu
screen or hold the MENUbutton down to return to the
standard screen without storing.
To cancel the setting:
1. Briefly push the MENUbutton. “ON” will flash in the
display.
122 UNDERSTANDING YOUR INSTRUMENT PANEL

2. Push theDOWNarrow button. “OFF” will flash in
the display
3. Push the MENUbutton briefly to return to the menu
screen or hold the MENUbutton down to return to the
standard screen without storing.
Trip B Data
This function can be used to activate (On) or deactivate
(Off) the Trip B display (Partial Trip).
Refer to Trip Computer in this section for further infor-
mation.
To switch the function On/Off:
1. Push the MENUbutton briefly. The display will flash
On or Off according to the previous setting.
2. Push and release the UP
orDOWNarrow
button to select.
Push the MENUbutton briefly to return to the menu
screen or hold the MENUbutton down to return to the
standard screen without storing.
Set Time
With this function, it is possible to set the time through two
submenus: TimeandMode. To set the time:
1. Push the
MENUbutton; the display will show the two
submenus “Time” and “Mode”.
2. Push and release the UP
orDOWNarrow
button to switch between the two submenus.
3. Select the required option and then push MENU.
4. If selecting the “Time” submenu, briefly push MENU,
the “hours” will flash on the display.
5. Push and release the UP
orDOWNarrow
button to adjust.
6. Push the MENUbutton; the “minutes” will flash on the
display.
7. Push and release the UP
orDOWNarrow
button to adjust.
8. Push the MENUbutton briefly to return to the menu
screen or hold the MENUbutton down to return to the
standard screen without storing.
The setting will increase or decrease by one unit each time
theUP
or DOWNarrow button is pushed. Hold 4
UNDERSTANDING YOUR INSTRUMENT PANEL 123

down the button to increase/decrease the setting rap-
idly and automatically. Complete the adjustment when
you approach the desired value.
When you select “Mode”, pushing theMENUbutton
makes the mode flash on the display.
1. Push UP
orDOWNarrow button to select 24h
or 12h.
2. When you have made the required settings, push the
MENU button briefly to go back to the submenu screen
or hold the button down to go back to the main menu
screen without saving.
3. Hold the MENUbutton down again to return to the
standard screen or to the main menu according to where
you are in the menu.
Set Date
With this function, it is possible to set the date.
To adjust the date:
1. Push the MENUbutton; the “year” will flash on the
display.
2. Push and release the UP
orDOWNarrow
button to adjust.
3. Push the MENUbutton; the “month” will flash on the
display.
4. Push and release the UP
orDOWNarrow
button to adjust.
5. Push the MENUbutton; the “day” will flash on the
display.
6. Push and release the UP
orDOWNarrow
button to adjust.
The setting will increase or decrease by one unit each time
the UP
orDOWNarrow button is pushed. Hold
down the UP
orDOWNarrow button to
increase/decrease the setting rapidly and automatically.
Complete the adjustment when you approach the de-
sired value.
Push the MENUbutton briefly to return to the menu
screen or hold the MENUbutton down to return to the
standard screen without storing.
Autoclose
When activated (On), this function locks the doors auto-
matically when the vehicle speed exceeds 12 mph
(20 km/h).
124 UNDERSTANDING YOUR INSTRUMENT PANEL

To activate or deactivate this function:
1. Push theMENUbutton briefly to display a submenu.
2. Push the MENUbutton briefly to make the display flash
On or Off according to the previous setting
3. Push the UP
orDOWNarrow button to select.
4. Push the MENUbutton briefly to return to the submenu
screen or hold the button down to return to the main
menu screen without saving.
5. Hold the MENUbutton down again to return to the
standard screen or to the main menu according to where
you are in the menu.
Setting The Units
With this function, it is possible to set the unit of measure-
ment in three submenus: “Distance”, “Consumption” and
“Temperature”.
To set the required unit of measurement:
1. Push the MENUbutton to display the three submenus.
2. Push and release the UP
orDOWNarrow
button to navigate through the three submenus.
3. Select the required option and then push the MENU
button.
4. If selecting the Distancesubmenu, briefly push the
MENU button and the display will show “mi” or km
depending on the previous setting.
5. Push and release the UP
orDOWNarrow
button to select.
When you select the “Consumption” submenu: briefly
pushing the MENUbutton makes “mpg” or “km/l” ap-
pear on the display, depending on the previous setting.
1. If the set distance unit of measurement is mi(km) the
fuel consumption unit will be displayed in mpg(km/l
or l/100 km).
2. Push and release the UP
orDOWNarrow
button to select.
When you select the Temperaturesubmenu: briefly push-
ing the MENU button the display will show °Cor°F
depending on the previous setting.
1. Push and release the UP
orDOWNarrow
button to select. 4
UNDERSTANDING YOUR INSTRUMENT PANEL 125

2. When you have made the required settings, push theMENU button briefly to go back to the submenu screen
or hold the MENUbutton down to go back to the main
menu screen without saving.
3. Hold the MENUbutton down again to return to the
standard screen or to the main menu according to where
you are in the menu.
Language
Display messages can be shown in different languages. To
set the desired language, proceed as follows:
1. Push the MENUbutton, the previously set language
will flash on the display.
2. Push and release the UP
orDOWNarrow
button to select.
3. Push the MENUbutton to return to the menu screen or
hold the MENUbutton down to return to the standard
screen without storing.
Buzzer Volume
With this function, the volume of the acoustic signal which
accompanies the display of failure/warning can be ad-
justed according to 8 levels. To set the desired volume:
1. Push the
MENUbutton, the previously set volume level
will flash on the display.
2. Push and release the UP
orDOWNarrow
button to adjust.
3. Push the MENUbutton to return to the menu screen or
hold the MENUbutton down to return to the standard
screen without storing.
Service
Using this function you can display information about the
mileage intervals for vehicle servicing.
To consult the information:
1. Push the MENUbutton, which makes the display show
the service interval in mi or km according to the
previous setting.
2. Push the MENUbutton to go back to the menu screen or
hold the MENUbutton down to go back to the standard
screen.
NOTE: The “Scheduled Servicing Plan” includes vehicle
maintenance at fixed intervals. Refer to “Maintenance
Schedules” for further information.
126 UNDERSTANDING YOUR INSTRUMENT PANEL
