WARNING!
•Do not start or run an engine in a closed garage or
confined area. Exhaust gas contains Carbon Monox-
ide (CO) which is odorless and colorless. Carbon
Monoxide is poisonous and can cause serious injury
or death when inhaled.
• Keep Remote Keyless Entry key fobs away from
children. Operation of the Remote Start System,
windows, door locks or other controls could cause
serious injury or death.
ENGINE BREAK-IN RECOMMENDATIONS
The diesel engine does not require a break-in period due to
its construction. Normal operation is allowed, providing
the following recommendations are followed:
• Warm up the engine before placing it under load.
• Do not operate the engine at idle for prolonged periods.
• Use the appropriate transmission gear to prevent engine
lugging. •
Observe vehicle oil pressure and temperature indicators.
• Check the coolant and oil levels frequently.
• Vary throttle position at highway speeds when carrying
or towing significant weight.
NOTE: Light duty operation such as light trailer towing or
no load operation will extend the time before the engine is
at full efficiency. Reduced fuel economy and power may be
seen at this time.
The engine oil installed in the engine at the factory is a
high-quality energy conserving type lubricant. Oil changes
should be consistent with anticipated climate conditions
under which vehicle operations will occur. The recom-
mended viscosity and quality grades are shown under
“Fluids, Lubricants and Genuine Parts”, under “Maintain-
ing Your Vehicle” in this manual. NON-DETERGENT OR
STRAIGHT MINERAL OILS MUST NEVER BE USED.
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11

REMOTE STARTING SYSTEM — IF EQUIPPED
This system uses the key fob to start the engine
conveniently from outside the vehicle while still
maintaining security. The system has a range of
approximately 300 ft (91 m).
NOTE:
• The vehicle must be equipped with an automatic trans-
mission to be equipped with Remote Start.
• The Remote Start system will wait for the “Wait To Start”
telltale to extinguish before cranking the engine. This
allows time for the intake heater to pre-heat the incom-
ing air, and is normal operation in cold weather. Refer to
“Wait To Start” located in “Warning and Indicator
Lights” within “Understanding Your Instrument Panel”.
How To Use Remote Start
All of the following conditions must be met before the
engine will remote start:
• Transmission in PARK
• Doors closed
• Hood closed •
HAZARD switch off
• BRAKE switch inactive (brake pedal not pushed)
• Ignition key removed from ignition switch
• Battery at an acceptable charge level
• PANIC button not pushed
• Fuel meets minimum requirement
• Water In Fuel Indicator Light is not illuminated
• Wait To Start Light is not illuminated
WARNING!
•Do not start or run an engine in a closed garage or
confined area. Exhaust gas contains Carbon Monox-
ide (CO) which is odorless and colorless. Carbon
Monoxide is poisonous and can cause serious injury
or death when inhaled.
• Keep Remote Keyless Entry key fobs away from
children. Operation of the Remote Start System,
windows, door locks or other controls could cause
serious injury or death.
92 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

•PTO must be correctly installed using the vehicle pro-
vided circuits.
The instrument cluster will display a PTO Onmessage for
five seconds if the above conditions are met. Otherwise, the
instrument cluster will display a message To Operate PTO
Shift To Park indicating what operator action should be
taken to engage the PTO mode.
The customer has the choice to operate the PTO by utilizing
the cruise control switches or by utilizing a remote control
(provided by the PTO supplier). To operate the feature
using the cruise control switches, the customer must first
activate the PTO switch which will turn on the PTO. In
order to increase or decrease the engine idle speed, to
optimize the PTO function, the “RESUME/ACCEL” and
“DECEL” cruise switches can be used respectively. To
disengage PTO operation and return to “standard vehicle
operation” simply toggle the PTO switch to the OFF
position.
The torque converter clutch (TCC) will automatically en-
gage at engine speeds above 1,200 RPM (engine speed) in
PTO stationary mode. Once engaged, the TCC will remain
applied and will not disengage until the engine speed falls
below 1,000 RPM. TCC engagement is desirable for certain
types of PTO applications (Automatic Transmission Only). To operate the PTO via a remote switch, the customer must
make sure the above conditions are met. It is vital for
proper operation that the PTO and remote have been
installed correctly, paying special attention to ensure the
vehicle provided wiring has been connected properly. This
is the responsibility of the installer of the PTO and
switches/remote system. It is the responsibility of the PTO
manufacturer to ensure that their electrical (switches and
remote) system is compatible with the vehicle’s electrical
architecture and software functionality.
NOTE:
Single set speed can be programmed via the PTO
menu on the instrument cluster display. Further details are
available at the Ram Truck Bodybuilders web site located
at
rambodybuilder.com
Mobile Mode
To operate the PTO in this mode the vehicle must meet the
following conditions:
• Mobile mode is activated via the menu on the instru-
ment cluster display.
• (ON/OFF) switch has been activated.
• Vehicles with automatic transmission must be in PARK
or DRIVE.
5
STARTING AND OPERATING 155

Keyless Enter-N-Go........................ .122
Maintenance Procedures ..................... .176
Maintenance Schedule ...................... .210
Manual Transmission ....................... .150
Fluid Level Check ....................... .197
Shift Speeds ........................... .151
New Vehicle Break-In Period ...................94
Noise Control Maintenance ........................... .200
Tampering Prohibited .....................200
Noise Emission Warranty .....................200
Oil Change Indicator ....................... .210
Oil, Engine .............................. .176
Capacity .............................. .204
Change Interval ........................ .177
Dipstick .............................. .176
Disposal .............................. .179
Filter ............................ .179 , 205
Filter Disposal .......................... .179
Identification Logo ...................... .178
Materials Added To ...................... .179
Recommendation ........................ .177Synthetic
............................. .179
Viscosity .............................. .178
Overdrive ............................... .148
Overdrive OFF Switch ...................... .148
Perform Service Indicator, Reset ................211
Power Take-Off Adapter ........................ .154
Take-Off Operation ...................... .154
PTO (Power Take-Off) ...................... .154
Radiator Cap (Coolant Pressure Cap) .............191
Remote Starting System .......................92
Resetting Perform Service Indicator ..............211
Selection Of Coolant (Antifreeze) ...............205
Shifting ................................ .140
Automatic Transmission ....................141
Manual

Transmission ..................... .150
Speed Control Accel/Decel .............................99
Cancel .................................97
Speed Control (Cruise Control) ..................96
Starting ................................ .121
Automatic Transmission ....................121
8
INDEX - RAM 2500 / 3500 / 4500 / 5500 223

Engine Block Heater..................125 , 137
Manual Transmission ..................... .121
Remote ................................92
Starting Procedures ........................ .121
Starting Procedures (Diesel Engines) .............121
Synthetic Engine Oil ....................... .179
Tip Start ................................ .121
Torque Converter Clutch .....................149
Traction Control .......................... .197
Transfer Case Fluid ................................ .207
Transmission Automatic ............................ .141
Fluid ................................ .207
Manual ........................... .121 , 150
Shifting .............................. .140
Viscosity, Engine Oil ....................... .178
Voltmeter ............................... .130
Water Separator, Diesel Fuel ...................184
