9
FIRST DRIVE FEATURES
NISSAN INTELLIGENT KEY® SYSTEM
The Nissan Intelligent Key® system allows you to
lock or unlock the vehicle, open your lif tgate and
start the engine. It is important to make sure the
Intelligent Key is with you (that is, in your pocket
or purse).
The operating range of the Intelligent Key is
within 31.5 in (80 cm) from each
request switch.
To lock the vehicle, push either door handle request switch
1, push the lif tgate request
switch
2 or press the button 3 on
the key fob.
To unlock the vehicle, perform one of the following procedures:
•
Push an
y door handle request switch
1
once; the corresponding door will unlock.
Push the request switch
1 again within 1
minute; all other doors will unlock, or
•
Pr
ess the
button 4 on the key fob to
unlock the driver’s side door. Press the
button
4 again; all other doors will unlock.
The Intel ligent Key can also be used to
activate the panic alarm by pressing and
holding the
button 5 for more than 1
second. Once activated, the panic alarm and
headlights will stay on for a period of time.
INTELLIGENT KEY BATTERY DISCHARGE
If the bat tery of the Intelligent Key is
discharged or environmental conditions
interfere with the Intelligent Key operation,
start the engine according to the
following procedure:
1.
Mo
ve the shif t lever to the P (PARK) position
(Continuously Variable Transmission) or to
the N (NEUTRAL) position
(manual transmission).
2.
Firmly apply the foot brake.
3.
Push the ignition switch with the Intel
ligent Key, and a chime will sound.
4.
Within 10 sec
onds af ter the chime sounds, push the ignition switch while
depressing the brake pedal and the engine will start.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Pre-driving checks and adjustments (section 3)”, the “Starting and
driving (section 5)” and the “Do-it-yourself (section 8)” of your Owner’s Manual.
1
3
4
5
2
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
11
STARTING/STOPPING THE ENGINE
CONTINUOUSLY VARIABLE TRANSMISSION
(if so equipped)
It is impor tant to make sure the Nissan
Intelligent Key® is with you (that is, in your
pocket or purse).
Depress the brake pedal.
Move the shif t lever to the P (PARK) position.
Press the ignition switch START/STOP button to start the engine.
MANUAL TRANSMISSION (if so equipped)
Depress the brake pedal.
Move the shif t lever to the N (NEUTRAL) position.
Depress the clutch pedal to the floor while pressing the ignition switch START/STOP button to start the engine.
TURNING THE ENGINE OFF
For a Continuously Variable Transmission, move the shif t lever to the P (PARK) position, apply the parking brake and press the ignition switch
START/STOP button
For a manual transmission, apply the foot brake and place the vehicle in 1st (FIRST) gear, then apply the parking brake and press the ignition switch
START/STOP button.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
2
1
OUTSIDE MIRROR CONTROL SWITCH
The outside mirr or control switch is located
on the lef t side of the instrument panel.
To select the lef t or right mirror, move the switch
1.
Adjust each mirror to the desired position using the control switch
2.
To prevent accidentally moving the mirror, move the switch
1 to the center
(neutral) position.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your
Owner’s Manual.
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
