2017 MITSUBISHI OUTLANDER engine

Power door locks 5-36 Features and controls
5
display. (Color liquid crystal display type only)
N00517301052
If the key is in the ignition switch or the oper-ation mode is in any mode other than OFF,when you push the lock knob forward with the driver’s door or passenger’s door open, the lock knob will automatically return to the unlocked position.
N00503801157
If the driver’s door is opened while the engineis stopped and the operation mode is in any mode other than OFF, the operation mode ONbuzzer will sound interm
ittently to remind
you put the operation mode in OFF. The warning display will be displayed on theinformation screen in the multi-information display. (Color liquid crystal display type only)
N00509301617
All of the doors and the liftgate can be lockedor unlocked by pressing the power door lockswitch on the driver’s or the front passenger door.
Lock out protection Operation mode ON reminder system (vehicles equipped with F.A.S.T.-key)
Power door locks
NOTE
 When locking or unlocking with the key on the driver’s door, only the driver’s door willlock or unlock.  Repeated continuous
operation between lock
and unlock could activate the power door locking system’s built
-in protection circuit,
and prevent the system from operating. Ifthis occurs, wait about 1 minute before oper- ating the power door lock switch.
To lock and unlock the doors and liftgate Using the power door lock switch 1- Lock 2- Unlock
BK0239700US.book 36 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Child safety locks for rear door Features and controls 5-37
5
N00563401119
All doors and the liftg
ate will unlock when
the ignition switch is turned to the “OFF” or“LOCK” position or the operation mode is put in OFF. All doors and the liftg
ate will unlock when
the selector lever is moved to the “P” (PARK) position with the ignition switch or the opera-tion mode in ON.
N00509401298
Child safety locks help prevent rear passen-gers, especially children, from opening therear door using the inside door handle. A lock lever for the child safety lock is pro- vided on each rear door.When the lever is in the lock position (1), the rear door cannot be opened using the inside door handle.To open the rear door when the child safety lock lever is in the lock position, pull the out- side door handle.When the lever is in the release position (2), the child safety lock is released and the rear
To unlock the doors and liftgate You can select the functions to unlock the doors and liftgate eith
er using the ignition
switch position or the engine switch, or using the selector lever position. These functions are not activated when thevehicle is shipped from the factory. To acti- vate or deactivate th
ese functions, please
contact your authori
zed Mitsubishi Motors
dealer.Using the ignition switch or the engine switch Using the selector lever position
NOTE
 On a vehicle equippe
d with a Mitsubishi
Multi-Communication System, the functionscan be adjusted on the screen. For details, refer to a separa
te operation manual.
Child safety locks for rear door 1- To lock 2- To release
BK0239700US.book 37 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Power liftgate (if so equipped) Features and controls 5-41
5
N00576100038
The power liftgate ca
n be opened automati-
cally when all of the
following conditions are
met.  The operation mode is in OFF.  The power liftgate is completely closed.  The power liftgate is unlocked.
 The operation mode is in ON with the selector lever in the “P” (PARK) position.
 The power liftgate is completely closed.  The power liftgate is unlocked.
 The power liftgate is unlocked.  The F.A.S.T.-key is within the operating range (2.3 feet (70 cm) from the powerliftgate open switch) and the power lift- gate is locked.
The power liftgate can be closed automati- cally when all of the following conditions are met.  The operation mode is in OFF.  The power liftgate is completely open.  Nothing is touching th
e auto reverse sen-
sors (A) on the power liftgate.
CAUTION Do not apply excessive force to the power liftgate when opening or closing it. Doing socould damage to th
e power liftgate.
NOTE
Do not start the engine while the power lift- gate is operating. The sudden operation pre- vention mechanism c
ould operate, making
the power liftgate stop intermittently while itmoves.  The power liftgate cannot be opened when the battery is discha
rged or disconnected.
The liftgate must be then opened using the inside liftgate release.Refer to “Inside lift
gate release” on page
5-46.  If the keyless entry system or close switch is operated when the pow
er liftgate main
switch is off, the warning buzzer sounds 4times to notify the driver that the power lift- gate cannot
be operated.
 The power liftgate does not operate normally under the following conditions: • When parked on an incline • In strong winds • When the power liftga
te is covered with
snow
 Repeated continuous
opening and closing
operation of the power lif
tgate will activate a
built-in protection ci
rcuit and switch the
power liftgate to
manual operation.
If one of the power lift
gate switches is oper-
ated while the power lift
gate is operating, the
power liftgate will reve
rse and return to the
full open or close position.  If the selector lever is moved from “P” the power liftgate is operating or completely open, a warning buzzer will sound forapproximately 10 sec
onds to notify the
driver that the power liftgate is open.  If the battery or fuse is replaced while the power liftgate is open,
it cannot be closed
automatically.In this case close the power liftgate manu- ally.
Operating conditions

NOTE
BK0239700US.book 41 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Power liftgate (if so equipped) 5-44 Features and controls
5
After the power liftgate has opened automati- cally, if it is detected that the power liftgate is dropping due to factors such as accumulated snow, the power liftgate will close automati-cally. A warning buzzer w
ill sound continuously
while the drop prevention mechanism is oper-ating.
If the engine is starte
d while the power lift-
gate is operating, the power liftgate may intermittently move or stop moving to pre- vent the power liftgate
from moving abruptly.
Approximately 10 seconds after the power liftgate has fully closed
or opened, power lift-
gate operation will again resume.
N00576300030
When the power liftgate main switch is off,the power liftgate can be manually openedand closed. After unlocking the power
liftgate, push the
power liftgate open
switch (A) and pull up
the power liftgate.
WA R N I N G The auto reverse mech
anism will not oper-
ate just before the power liftgate becomesfully closed. Therefore, be careful not to trap a hand, part of your body or an object at this time. When the power liftgate is closed manu- ally, the auto reverse mechanism will notoperate.  If the auto reverse mechanism has been repeatedly activated
, the power liftgate
may stop and then, de
pending on its posi-
tion, may abruptly open
or close. Once the
power liftgate is completely closed or open, automatic operation will be resumed.
CAUTION Do not damage the auto reverse sensor, when loading or unloading luggage. If the sensor isdamaged, the power lift
gate will not close
automatically.
Drop prevention mechanism

NOTE
 If snow has accumula
ted on the power lift-
gate, remove it befo
re operating the power
liftgate.  Do not install any accessory other than Mit- subishi Motors Genui
ne parts on the power
liftgate. The drop prevention mechanismmay be activated due to
the weight of the
accessory.  The drop prevention mechanism could be activated if you attempt to close the liftgate manually immediately af
ter the power lift-
gate has been comple
tely opened automati-
cally.
Sudden operation prevention mechanism

CAUTION The auto reverse will not operate while the sudden operation preven
tion mechanism is
activated.
Manual operation

BK0239700US.book 44 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Theft-alarm system
Features and controls 5-47
5
N00510301226
Park the vehicle and st
op the engine. Arm the
system as described below. 1. Except for vehicles equipped with the F.A.S.T.-key, remove the key from theignition switch. For vehicles equipped with the F.A.S.T.- key, put the operation mode in OFF.2. Make sure that the engine hood is closed. 3. Lock all doors and the liftgate by using the keyless entry system or the F.A.S.T.-key operation.
At this time, the theft-alarm indicator (A)mation. 4. The system has entered the armed stage after about 20 seconds, when the theft-alarm indicator (A) flashing becomes slower. The theft-alarm indicator (A) continues toflash while the system is in the armed stage.
N00510401230
The alarm will be activated if any of the fol- lowing occur while the ve
hicle is parked and
the system is armed.  One of the doors and the liftgate is opened without using the keyless entry system or the F.A.S.T.-key operation. The engine hood is opened.
CAUTIONDo not modify or add parts to the theft-alarm system. Doing so could cause the theft-alarmto malfunction.
Armed stage Arm the system and leave
NOTE
 If the engine hood is open, the theft-alarm indicator (A) illuminates and the system can- not enter the armed stage. The system enters the armed stage about 20seconds after the e
ngine hood is closed.
 The system will be disarmed if, while the theft-alarm indicator (A) is illuminated, all doors and the liftgate are unlocked by using the keyless entry system or the F.A.S.T.-keyoperation.
 The system will be disarmed if, while the theft-alarm indicator is illuminated, the fol-lowing operation is performed. • Except for vehicles equipped with the F.A.S.T.-key, if the ignition switch is turnedto the “ON” position. • For vehicles equippe
d with the F.A.S.T.-
key, if the operation mode is put in ON.
 The system will not be armed if a door, the liftgate or the engine
hood is not completely
closed. If this happens, rearm the system as described above.  The theft-alarm system can be activated when people are riding inside the vehicle orwhen the windows are open. To prevent acci- dental activati
on of the alarm, do not set the
system to the system armed mode while peo-ple are riding in the vehicle.
Alarm stage
NOTE
BK0239700US.book 47 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Power window control
Features and controls 5-49
5
N00510601157
Use the following procedure to test the sys- tem: 1. Lower the driver’s window. 2. Arm the system as explained in “Armedstage”. comes on and flashe
s for approximately
20 seconds. 4. Wait a few seconds and then unlock thedriver’s side door by using the inside door lock knob. Open the door. 5. Make sure that the horn sounds intermit-tently and the headlights blink when a door is opened. 6. Disarm the system by unlocking all doorsand the liftgate by using the keyless entry system or the F.A.S.T.-key operation.
N00510800383
Testing the theft-alarm system
Power window control 1- Open (down) 2- Close (up)
NOTE
 Never try to operate the main switch and sub-switch in different
directions at the same
time. This will free
ze the window in posi-
tion.  Operating the power windows repeatedly with the engine stoppe
d will run down the
battery. Use the window
switches only while
the engine is running.WA R N I N G Before operating the power windows, make sure that nothing can be trapped (head, hands, fingers, etc.) in the window.
 Never leave the vehicle without carrying the key. Never leave children
or unreliable adults
unattended inside the vehicle.WA R N I N G
BK0239700US.book 49 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Power window control 5-50 Features and controls
5
N00548701137
The main switch located on the driver’s door can be used to operate all the windows.A window can be opened or closed by operat- ing the corresponding switch. Press the switch down to open the window,and pull up the switch to close it. If the driver’s door window switch is fully pressed down/pulled up, the driver’s door window automatically opens/closes com- pletely.If you want to stop the window movement, operate the switch lightly in the reverse direc- tion.
N00548800102
Each sub-switch can be used for it’s own pas-senger door window, unless the driver’s win-dow lock switch is activated.
N00548901155
The power windows can be run up or downwhen the ignition switch or the operationmode is in ON. The door windows can be opened or closed for a 30-second period after the engine is
stopped. However, once the driver’s door or the front passenger’s door is opened, thepower windows cannot be operated.
N00549001166
When this switch is in the lock mode, the pas-senger door switches cannot be used to open or close the door windows, and the main switch will open or
close only the driver’s
door window. To unlock the switch, press it again.
Main switch 1- Driver’s door window switch2- Front passenger door window switch 3- Left rear door window switch 4- Right rear door window switch5- Lock switch
Sub switch 1- Close2- Open
NOTE
 The rear door windows open only half-way.
Power window timer function
Lock switch 1- Lock 2- Unlock
BK0239700US.book 50 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Sunroof (if so equipped) 5-52 Features and controls
5
Press the switch (1), the sunroof automati- cally opens. To stop the moving sunroof, press the switch. Press the switch (3), the sunroof automati- cally closes. To stop the moving sunroof, press the switch. When the switch (2) is pressed, the rear of the sunroof raises for ventilation. Press the switch (3).
The sunroof can be operated when the igni- tion switch or the operation mode is in ON.The sunroof can be opened or closed for a 30- second period after th
e engine is stopped.
However, when the driver’s door or the frontpassenger door is opene
d, the sunroof cannot
be operated. Turn on the ignition switch again to operate. If a hand or head is trapped in the closing sunroof opening, the safety mechanism willcause the sunroof to re-open automatically. The opened sunroof will
become operational
again after a few seconds. If the safety mechanism is activated 5 or more times consecutively, normal closing ofthe sunroof will be aborted. As an emergency measure, the sunroof can be closed bit by bit until the sunroof is com-pletely closed by re
peatedly pressing the
switch (2).
After that, the sunroof can be set the initial- ized state in the following procedure. 1. Move the sunroof
in slide open position.
2. Press the tilt up switch (2) continually in 10 seconds. 3. The sunroof will be moved to tilt up posi-tion automatically bit by bit. 4. The initialize is completed when the sun- roof is stopped at tilt up position.If the sunroof does not return to normal, consult an authorized Mitsubishi Motors dealer.
To open

NOTE
 The sunroof stops just before reaching the fully open position. If
the vehicle is driven
with the sunroof in this position, wind buf- feting is lower than with the sunroof fullyopen.
To close

To t i l t u p

To t i l t d o w n

NOTE
 Be sure to tilt down the sunroof before clos- ing the sunshade.
Sunroof timer function

Safety mechanism

NOTE
 The safety mechanism can be activated if the driving conditions or other circumstances cause the sunroof to be
subjected to a physi-
cal shock similar to th
at caused by a trapped
hand or head.CAUTION The safety mechanism is deactivated while the switch (2) is pressed. Therefore be espe- cially careful that fi
ngers are not trapped in
the sunroof opening. Do not deliberately trap your hands or head in order to activate the safety mechanism.Personal injury and malfunction of the sun- roof could result.
BK0239700US.book 52 ページ ２０１６年６月１６日　木曜日　午前１０時５８分
