2017 MITSUBISHI OUTLANDER ECO mode

Listen to an iPod 7-32 Comfort controls
7
Play the tracks in the folder in a random order. Hold down the 2RDM key. Play all tracks in folders on the disc in a ran- dom order. Press the SCAN key. Play the first 10 seconds of each of the tracks in the folder currently being played in order.
Search folders and files, and select a track. 1. Turn the /SEL key to select the folder. 2. Press the /SEL key. Files within the selected folder are dis- played. 3. Turn the /SEL key to select the file.4. Press the /SEL key. This plays the selected file (track).
N00717300103
By connecting comme
rcially-available
iPod/iPhone devices to
this product, you can
play back tracks on these through the product.
NOTE
 Pressing again will cancel.
Folder Random Playback
NOTE
Pressing again will cancel.
Scan Playback (SCAN)
NOTE
Press this button again during playback if you wish to hear that track, and that track will play normally.
Search Tracks
NOTE
 While the folder is selected, press the 6 key to cancel track search mode.  If there is no operation for 10 seconds after selecting the folder, then track search mode will be cancelled.  Select the folder, and hold down the /SEL key to start playback from the first track inthat folder.  While the file is selected, press the 6 key to return to the previous operation.  While the file is selected, hold down the 6 key to cancel tr
ack search mode.
 If there is no operation
for five seconds after
selecting the file, that file is played back.  Disc operations such as
selecting a track will
cancel track search mode.
Listen to an iPod
CAUTION Do not leave the iP
od/iPhone unattended in
the vehicle. Never hold these devices in your hand to operate while driving, as this is dangerous. No indemnification for data loss resulting when the iPod/iPhone is
connected to the
product will be possible. Depending on how the devices are handled, audio files being damage
d or lost, therefore
it is recommended that
data be backed up.
NOTE
Depending on the generation, model, or soft- ware version of th
e iPod/iPhone, playback
on this product may not be possible. ( P.7-15) Additionally, playback as
explained in this docum
ent may not be possi-
ble.
BK0239700US.book 32 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Listen to an iPod
Comfort controls 7-33
7
Press the MEDIA key to set the iPod as the source. The selected source is indicated on the dis- play.
Press the key or key to select the track. This enables selection of the next or previous track. Hold down the 3 key or the 4 key. Fast forward/rewind is possible. Repeat playback and
shuffle playback are
possible. Press the 1RPT key. Repeat playback of the track currently being played.
 The types of devices
that can be connected
may vary.[For vehicles sold in U.S.A.]For details, access the Mitsubishi Motors North America website. [For vehicles sold in Canada and Mexico]For details, access the Mitsubishi Motors website. Please read and agree to the “Warn- ing about Links to the Web Sites of OtherCompanies”. The webs
ites mentioned above
may connect you to websites other than the Mitsubishi Motors website.http://www.mitsubishi-motors.com/en/prod- ucts/index.html  Regarding how to connect the iPod/iPhone, refer to “How to connect an iPod” on page 5-264.  When connecting the iPod/iPhone, use a commercially-availab
le iPod connection
cable.  Set up the device in
order that no unsafe
actions, such as plugging in the connection cable are taken while driving.  When inserting and removing the iPod/iPhone, for safety’s
sake first stop the
vehicle.  Depending on the status of the iPod/iPhone, it may take some time unt
il the device is rec-
ognized, or playback starts.  Buttons on the product will not operate while iPod/iPhone is
connected.
NOTE
iPod/iPhone spec
ifications and settings may
mean that connection
is not possible, or
result in differences
in operation or display.
 Depending on audio data
in the iPod/iPhone,
track information may
not be displayed cor-
rectly.  Depending on the status of the vehicle and device, the iPod/iPhone
may not play back
after starting
the engine.
 Data containing copyri
ght information may
not play back.  It is recommended that the iPod/iPhone equalizer settings be set to flat.  Operate the iPod/iPhone
while connected to
this product.  If the iPod/iPhone is c
onnected via Bluetooth
as a Bluetooth-capable
audio device, then do
not connect the iPod/
iPhone using an iPod
cable. Connection us
ing both methods will
result in err
oneous operation.
 If an iPod/iPhone does not
operate correctly,
then remove the iPod/iPhone from the prod- uct, reset, then reconnect.
Play iPod
NOTE
Select the Track (File) Fast Forward or Rewind Switch Playback Mode Repeat Playback (RPT)
NOTE
 Pressing again will cancel.
BK0239700US.book 33 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Listen to Audio Files on a USB Device 7-34 Comfort controls
7
Press the 2RDM key. Play tracks in the category currently being played in a random order. Hold down the 2RDM key. Play back the album in a random order (tracks in any order on the album). Search categories or track names, and select a track. 1. Turn the /SEL key to select the cate- gory.
2. Press the /SEL key. Categories or tracks within the selected category aredisplayed. 3. Turn the /SEL key to select the cate- gory or track. 4. Press the /SEL key. Repeat steps 1 to 4,
and search for tracks.
Select the track, and press the /SEL key to play.
N00717400117
By connecting commerci
ally-available USB
devices such as USB me
mory to this product,
you can play back audio files on thesethrough the product.
Shuffle Playback (RDM)
NOTE
 Pressing again will cancel.
Album Shuffle Playback
NOTE
Pressing again will cancel.
Search Tracks
NOTE
While the category (1st level) is selected, press the 6 key to cancel track search mode.  If there is no operation for 10 seconds after selecting the category, then track searchmode will be cancelled.  Select the category, and hold down the
/SEL key to start playback from the first
track in that category.  While the track is selected, press the 6 key to return to the previous operation.  While the track is se
lected, hold down the
6 key to cancel tr
ack search mode.
 If there is no operation
for five seconds after
selecting the track, that file is played back.  iPod operations such as selecting a track will cancel track search mode.
Listen to Audio Files on a USB Device
CAUTION Do not leave the USB
device unattended in
the vehicle. Never hold these devices in your hand to operate while driving, as this is dangerous. Do not use hard discs, card readers, or mem- ory readers, as damage may occur to these orto the data contained therein. If these are erroneously connected, th
en turn the ignition
switch to the “OFF” or “LOCK” position orput the operation mode in
OFF, then remove.
Because of the risk of data loss, it is recom- mended that files be backed up. No guarantee is made
as regards damage to
the USB device, nor re
garding loss or dam-
age to data contained therein. Depending on how the devices are handled, audio files being damage
d or lost, therefore
it is recommended that
data be backed up.
BK0239700US.book 34 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Listen to Audio Files on a USB Device
Comfort controls 7-35
7
Press the MEDIA key to set USB as the source. The selected source is indicated on the dis- play.
Press the key or key to select the track. This enables selection of the next or previous track. Hold down the 3 key or the 4 key. Fast forward/rewind is possible. Repeat playback, random
playback, and scan
playback are possible. Press the 1RPT key. Repeat playback of the track currently being played.
NOTE
 Digital audio players
that support the mass
storage class specific
ations can be con-
nected.  For details regarding the types of USB devices that can be c
onnected and the types
of files that can be
played back, refer to
“Types of connectable
devices and supported
file specifications” on page 5-265.  Regarding how to c
onnect USB devices,
refer to “How to connect a USB memorydevice” on page 5-263.  When connecting a US
B device, use a con-
nection cable. Failur
e to use a connection
cable when connecti
ng may place undue load
on, or damage the USB connector.  Set up the device in
order that no unsafe
actions, such as plugging in the connectioncable are taken while driving.  When inserting and removing the USB device, for safety’s sa
ke first stop the vehi-
cle.  Do not insert other than audio devices into the USB port. Damage to the device or equipment may result.  Depending on the status of the USB device, it may take some time unt
il the device is rec-
ognized, or playback starts.  Depending on USB device
s, buttons on the
product will not opera
te while the USB
device is connected.  USB device specificati
ons and settings may
mean that connection is not possible, or result in differences
in operation or display.
Depending on audio data
in the USB device,
track information may
not be displayed cor-
rectly.  Depending on the status of the vehicle and device, the iPod/iPhone
may not play back
after starting
the engine.
 Data containing copyri
ght information may
not play back.  This product can play back MP3, WMA, and AAC format audio files.  Depending on the type of
USB device, usage
may not be possible, or functions that can be used may be restricted.  The recommended file system for USB memory is FAT32.  The maximum supported capacity for USB memory is 32GB.  Operate the USB device containing recorded audio files while conne
cted to this product.
Play Back of Audio Files on a USB Device
NOTE
Select the Track (File) Fast Forward or Rewind Switch Playback Mode Repeat Playback (RPT)
NOTE
 Pressing again will cancel.
BK0239700US.book 35 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

To play iPod/USB memory de
vice tracks via voice operation
Comfort controls 7-37
7
This plays the selected file (track).
N00772001070
When connected to the USB input terminal desired tracks on the iPod/USB memory device can be selected
and played via voice
operation.For information concerning the voice recog- nition function or spea
ker registration func-
tion, refer to “Bluetooth
® 2.0 interface” on
page 5-240.The following explains how to prepare for voice operation and play the tracks.
N00772101039
To use the voice operation, press theSPEECH button (excep
t for vehicles with
Mitsubishi Multi-Comm
unication System) or
PICK-UP button (for vehi
cles with Mitsubi-
shi Multi-Communication System) first.
N00772200017
1. Say “Play” on the main menu.
2. After the voice guide says “Would you like to play by Artist, Album, Playlist orGenre?,” say “Artist”. 3. After the voice guide says “What Artist would you like to play?,” say the artist name.4. If there is only one match, the system pro- ceeds to step 6. 5. If there are two or more matches, thevoice guide will say “More than one match was found, would you like to play ?” If you say “Yes,” the sys-tem proceeds to step 6. If you say “No,” the next matching artist is uttered by the system.
NOTE
 While the folder is selected, press the 6 key to cancel track search mode.  If there is no operation for 10 seconds after selecting the folder, then track search mode will be cancelled.  Select the folder, and hold down the /SEL key to start playback from the first track inthat folder.  While the file is selected, press the 6 key to return to the previous operation.  While the file is selected, hold down the 6 key to cancel tr
ack search mode.
 If there is no operation
for five seconds after
selecting the file, that file is played back.  Operations such as sele
cting a trac
k will can-
cel track search mode.
To play iPod/USB memory device tracks via voice oper-ation
Preparation for voice operation 1- SPEECH button 2- PICK-UP buttonTo search by artist name
NOTE
 The Bluetooth
® 2.0 interface
starts recogniz-
ing the connected device. If the connected device
cannot be recognized
or a connection error
occurs, the Bluetooth
®
2.0 interface starts an appropriate voice guide. Follow th
e voice guide.
NOTE
If you say “Artist ,” you can skip step 3.
BK0239700US.book 37 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

To play iPod/USB memory de
vice tracks via voice operation
7-38 Comfort controls
7
6. After the voice guide
says “Playing name>,” the system creates a playlistindex for the artist. 7. The system exits the voice recognition mode and starts playback.
N00772300018
1. Say “Play” on the main menu.
2. After the voice guide says “Would you like to play by Artist, Album, Playlist orGenre?,” say “Album”. would you like to play?” say the album title.4. If there is only one match, the system pro- ceeds to step 6. 5. If there are two or more matches, thevoice guide will say “More than one match was found, would you like to play ?” If you say “Yes,” the sys-tem proceeds to step 6. If you say “No,” the name of the next matching album is uttered by the system.
6. After the voice gui
de says “Playing
,” the system creates a playl- ist index for the album title. 7. The system exits the voice recognition mode and starts playback.
N00772400019
1. Say “Play” on the main menu.
NOTE
 If you say “No” to three or all artist names uttered by the system, the voice guide willsay “Artist not found, please try again” andthe system returns to step 2.  Search time depends
on the number of songs
on your connected devi
ce. Devices contain-
ing a large number of songs may take longer to return search results.NOTE
 If the confirmation function is active, the voice guide confirms
if the artist name is
correct. If the artist name is correct, say“Yes”. If not, say “No”. After the voice guide says “Artist not found, please try again,” the system returns to step 2.
To search by album title
NOTE
 The Bluetooth
® 2.0 interface
starts recogniz-
ing the connected device. If the connected device
cannot be recognized
or a connection error
occurs, the Bluetooth
®
2.0 interface starts an appropriate voice guide. Follow the voice guide.NOTE
 If you say “Album <
title>,” you can skip
step 3.
NOTE
 If you say “No” to three or all album titles uttered by the system, the voice guide willsay “Album not found, please try again” andthe system returns to step 2.NOTE
 If the confirmation function is active, the voice guide confirms if
the album title is cor-
rect. If the album title is correct, say “Yes”.
the voice guide says
“Album not found, please try again,” the sys-tem returns to step 2.
To search by playlist
BK0239700US.book 38 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

To play iPod/USB memory de
vice tracks via voice operation
Comfort controls 7-39
7
2. After the voice guide says “Would you like to play by Artist, Album, Playlist orGenre?,” say
“Playlist”.
3. After the voice guide says “What Playlist would you like to play?,” say the playlist name.4. If there is only one match, the system pro- ceeds to step 6. 5. If there are two or more matches, thevoice guide will say “More than one match was found, would you like to play ?” If you say “Yes,” the systemproceeds to step 6. If you say “No,” the next matching playl- ist name is uttered by the system.
6. After the voice gui
de says “Playing
,” the system creates an index for the playlist. 7. The system exits the voice recognition mode and starts playback.
N00772500010
1. Say “Play” on the main menu.
2. After the voice guide says “Would you like to play by Artist, Album, Playlist orGenre?,” say “Genre”. 3. After the voice guide says “What Genre would you like to play?,” say the music type.4. If there is only one match, the system pro- ceeds to step 6. 5. If there are two or more matches, thevoice guide will say “More than one match was found, would you like to play ?” If you say “Yes,” the systemproceeds to step 6. If you say “No,” the next matching genre is uttered by the system.
NOTE
 The Bluetooth
® 2.0 interface
starts recogniz-
ing the connected device. If the connected device
cannot be recognized
or a connection error
occurs, the Bluetooth
®
2.0 interface starts an appropriate voice guide. Follow th
e voice guide.
NOTE
If you say “Playlist ,” you can skip step 3. If the device has no pl
aylist, the voice guide
will say “There are no
playlists stored on
device” and the system returns to step 2.
NOTE
 If you say “No” to three
or all playlist names
uttered by the system, the voice guide willsay “Playlist not found,
please try again” and
the system returns to step 2.NOTE
 If the confirmation function is active, the voice guide confirms if
the playlist name is
correct. If the playlist name is correct, say “Yes”. If not, say “No”. After the voice guide says “Playlist not fou
nd, please try again,”
the system returns to step 2. Refer to “Con- firmation function se
tting” on page 5-244.
To search by genre
NOTE
The Bluetooth
® 2.0 interface
starts recogniz-
ing the connected device. If the connected device
cannot be recognized
or a connection error
occurs, the Bluetooth
®
2.0 interface starts an appropriate voice guide. Follow th
e voice guide.
NOTE
If you say “Genre ,” you can skip step 3.
BK0239700US.book 39 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Listen to Bluetooth Audio 7-40 Comfort controls
7
6. After the voice gui
de says “Playing
,” the system creates an index forthe genre. 7. The system exits the voice recognition mode and starts playback.
N00717500062
This product can play back tracks on com-mercially-available Bl
uetooth-capable audio
devices.
Regarding how to connect your Bluetooth device, refer to “Conne
cting the Bluetooth
®
2.0 interface and Blue
tooth device” on page
5-247. Operation methods belo
w describe situations
once connection has been completed. 1. Press the MEDIA key to set Bluetooth Audio as the source. The selected source is indicated on the display.
NOTE
 If you say “No” to three
or all genres uttered
by the system, the voice guide will say“Genre not found, please try again” and thesystem returns to step 2.NOTE
 If the confirmation function is active, the voice guide confirms if the genre is correct. If the genre is correct, say “Yes”. If not, say“No”. After the voice
guide says “Genre not
found, please try again,” the system returns to step 2. Refer to
“Confirmation function
setting” on page 5-244.
Listen to Bluetooth Audio
CAUTION Never hold these devices in your hand to operate while driving,
as this is dangerous.
Do not leave the Bluetooth audio device unattended in the vehicle. Depending on how the de
vices are handled,
audio files being damage
d or lost, therefore
it is recommended that data be backed up.NOTE
 Depending on the type of
Bluetooth-capable
audio devices, usage ma
y not be possible, or
functions that can be us
ed may be restricted.
 Confirm together with the user manuals for the commercially-availab
le Bluetooth-capa-
ble audio devices.  Depending on the type of
Bluetooth-capable
audio devices, volume
levels may differ.
There is the danger of loud volumes, so prior to use, it is recommended that you turn the volume down. “Adjust Volume” (P.7-24)
 Depending on the status of the Bluetooth audio device, it may ta
ke some time until the
device is recognized,
or playback starts.
 Bluetooth audio device
specifications and
settings may mean th
at connection is not
possible, or result in
differences in operation
or display.  Depending on audio data in the Bluetooth audio device, track in
formation may not be
displayed correctly.
 Depending on the status of the vehicle and device, the iPod/iPhone
may not play back
after starting
the engine.
Connect a Bluetooth-capable Audio Device
NOTE
 If the iPod/iPhone is c
onnected via Bluetooth
as a Bluetooth-capable
audio device, then do
not connect the iPod/
iPhone using an iPod
cable. Connection us
ing both methods will
result in err
oneous operation.
Play Bluetooth Audio
NOTE
BK0239700US.book 40 ページ ２０１６年６月１６日　木曜日　午前１０時５８分
