2017 MITSUBISHI OUTLANDER engine

Multi Information display - Type 1 5-172 Features and controls
5
N00556601180
Shows the amount of fuel remaining.
N00578300050
When the fuel level runs low, the information screen switches to the interrupt display of the fuel remaining warning display and the mark(B) on the fuel remaini
ng display flashes. If
the warning display appear
s, refuel as soon as
possible.
N00556501118
Shows the temperature outside the vehicle.
N00574901026
Shows the total distance traveled.
N00575001024
Shows the distance traveled between twopoints.
CAUTION If the engine is overheating, “ ” will blink. In this case, the bar graph is on the red zone. Immediately park the vehicle in a safe place and take the require
d measures. Refer to
“Engine overheating” on page 8-4.
Fuel remaining display screen F- Full E- Empty
CAUTION Running out of gas coul
d damage the cata-
lytic converter. If the warning display appears, refuel as soon as possible.
NOTE
 It may take several se
conds to stabilize the
display after re
filling the tank.
 If fuel is added with
the ignition switch or
the operation mode in ON, the remaining fuel display may incorre
ctly indicate the fuel
level.  The arrow (A) indicates that the fuel tank filler door is located on
the left side of the
vehicle. (Refer to “F
illing the fuel tank” on
page 3-3.)
Fuel remaining warning display
NOTE
 On hills or curves, the display may be incor- rect due to the movement
of fuel in the tank.
Outside temperature display screen
NOTE
 The display setting ca
n be changed to the
preferred units (°F or °C).
e function settings” on
page 5-177.  Depending on factors such as the driving conditions, the displa
yed temperature may
vary from the actual outside temperature.
Odometer Trip odometer
BK0239700US.book 172 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Multi Information display - Type 1
Features and controls 5-179
5
 When the engine switch or the operation mode is in the following conditions, theaverage fuel consumption display and the average speed display will automatically reset. [Except for vehicles equipped with the F. A . S . T. - k e y ] The ignition switch has been set to the “ACC”, “LOCK” or
“OFF” position for
about 4 hours or more. [For vehicles equipped with the F.A.S.T.- key]The operation mode has been in ACC or OFF for about 4 hours or more.
N00557101166
The fuel consumption display unit can be changed. The distan
ce, speed, and amount
units are also changed to match the selected fuel consumption unit. 1. Press and hold the multi information dis- play switch (for about 2 seconds or more) to change from the setting mode screen to the menu screen. Refer to “Changing the function settings” on page 5-177.2. Lightly press the multi information dis- play switch to select “AVG UNIT” (fuel consumption display unit setting). 3. Press and hold the multi information dis- play switch (for about 2 seconds or more) to display “AVG UNIT” (fuel consump- tion display unit setting).
4. Lightly press the multi information dis- play switch to switch to select the units.5. Press and hold the multi information dis- play switch (for about 2 seconds or more) to change the setting to the selected unit.
The distance and speed units are also changed in the following combinations to match theselected fuel consumption unit.
NOTE
 The average fuel consumption display and average speed display ca
n be reset separately
in both auto reset mode and manual reset mode.  Disconnecting the batter
y cable wi
ll erase
from memory the manual reset mode or auto reset mode setting for
the average speed dis-
play and average fuel consumption display.  The initial (default) setting is “Auto reset mode”.
Changing the fuel consumption display unit
NOTE
 The display units for the driving range, the average fuel consumption, the average speed and the momentary fuel consumption are changed, but the units
for the indicating nee-
dle (speedometer), the odometer and the trip odometer will remain unchanged.  If the battery is disconnected, the memory of the unit setting is erased and is automatically set to {mpg (US) or L/100 km}.Fuel economy
Distance (driving range)
Speed (average speed)
mpg (UK) mile (s) mph km /L km km /h L /100 km km km /h
BK0239700US.book 179 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-191
5
N00557701074 N00557801349
Indicator light, warning light, and information
screen display list (multi information display -
Type 1) Indicator and warning light list 1- Position indicator
 P.5-215
2- Front fog light indicator (if so
equipped)
 P.5-215
3- Turn signal indicators/hazard warning
lights
 P.5-215
4- High beam indicator
 P.5-215
5- Charging system warning light
 P.5-217
6- Blind Spot Warning (BSW) indicator
light (if so equipped)
 P.5-131
7- Automatic high beam system indicator
(if so equipped)
 P.5-224
8- LED headlight warning light (if so
equipped)
 P.5-223
9- Active stability control (ASC) indicator
 P.5-101
10- Active stability
control (ASC) OFF
indicator
 P.5-101
11- Anti-lock braking
system warning light
 P.5-98
12- Supplemental Restra
int System (SRS)
warning light
 P. 4 - 4 0
13- Engine malfuncti
on indicator (“SER-
VICE ENGINE SOON” or “Check engine light”)
 P.5-217
14- Electric parking
brake warning light
(yellow) (if so equipped)
 P.5-216
BK0239700US.book 191 ページ ２０１６年７月１日　金曜日　午後３時１５分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-195
5
 The F. A. S. T. -key is not detected.
Insert the F. A. S. T. -key into the key slot. Refer to “If the F. A. S. T. -key
is not operating properly” on
page 5-27.
 You have forgotten to remove
the F. A. S. T. -key
from the key slot.
 Remove the F. A. S. T.
-key from the key slot.
 The steering wheel is locked.
Press the engine switch wh
ile turning steering wheel.
Refer to “Steering wheel lock” on page 5-65.
 The engine switch is pre
ssed to stop the engine and
the selector lever is in a position other than the “P”
 Place the selector lever in
the “P” (PARK) position
to put the operati
on mode in OFF.
 The driver’s door is opened with the steering wheel unlocked.
 Refer to “Steering wheel lock” on page 5-65.
 There is a fault in the EPS.
Have the vehicle inspected by an authorized Mit- subishi Motors dealer or a
repair facility of your
choice as soon as possible. Refer to “Electric power
steering system (EPS)” on
page 5-99.
Screen
Cause
Do this (Reference)
BK0239700US.book 195 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
5
 There is a fault in the Anti-lock braking system.
Avoid sudden braking and high-speed driving, park the vehicle in a safe place, and take corrective mea-sures. Refer to “Anti-lock
braking system warning”
on page 5-98.
 The tire pressure in one of the tires (except spare tire) is low.
Refer to “Tire Pressure Monitoring System” on page 5-143.
 There is a fault in the Tire Pressure Monitoring Sys- tem.
Refer to “Tire Pressure Monitoring System” on page 5-143.
 One of the doors or the liftgate is not completely closed. The open door is displayed.
 Close the door or liftgate. Refer to “Door ajar warnin
g display screen” on page
5-171.
 The engine hood is open.
Close the engine hood. Refer to “Engine hood” on page 9-3.
 There is a fault in the electronic immobilizer (Anti- theft starting system).
 Put the operation mode in OFF, and then start the engine again.If the warning is not cancel
led, please contact an
authorized Mitsubishi Motors dealer or a repair facil- ity of your choice.
Screen
Cause
Do this (Reference)
BK0239700US.book 196 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-197
5
 The driver's door is open when the operation mode is in any mode other than OFF.
 Put the operation mode in OFF. Refer to “Operation mode
ON reminder system” on
page 5-36.
 An attempt was made to lock all the doors and the liftgate when the operati
on mode is in any mode
other than OFF.
 Put the operation mode in OFF. Refer to “Operation mode
OFF reminder system” on
page 5-20.
 There is a fault in the steering wheel lock.
Park your vehicle in a safe
place as soon as possible
and contact an authorized
Mitsubishi Motors dealer
or a repair facility of your
choice to have the system
checked.
 There is a fault in the electrical system.
Park your vehicle in a safe
place as soon as possible
and contact an authorized
Mitsubishi Motors dealer
or a repair facility of your
choice to have the system
checked.
 The engine is overheated.
Park the vehicle in a safe place and take corrective measures. Refer to “Engine overh
eating” on page 8-4.
 The automatic transaxle or CVT fluid temperature is increased.
 Park the vehicle in a safe place and take corrective measures. Refer to “Automatic tr
ansaxle” on page 5-67.
Refer to “Continuously variable transmission (CVT)” on page 5-75.
Screen
Cause
Do this (Reference)
BK0239700US.book 197 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
5
 The Electric parking brake is not automatically applied because there is a fa
ult in the Electric park-
ing brake system.
 When the ignition switch is
turned off or the opera-
tion mode is put in OFF, place the selector lever in the “P” (PARK) position and depress the brake pedal more firmly than usual with the right foot. Then, operate the ignition
switch or the engine
switch.  We recommend you to have the brake auto hold sys- tem inspected by a MITSUBISHI MOTORS Autho-rized Service Point. Refer to “Brake auto hold” on page 5-93.
 The brake auto hold system does not turn on because the driver’s seat belt is not fastened.
 Press the brake auto hold switch after fastening the driver’s seat belt. Refer to “Brake auto hold” on page 5-93.
 The brake auto hold system does not turn off because the brake pedal is not pressed.
 Depress the brake pedal more firmly than usual with the right foot. Then, press
the brake auto hold switch.
Refer to “Brake auto hold” on page 5-93.
 There is a fault in the engi
ne oil circulation system.
Park your vehicle in a safe place as soon as possible and contact an authorized
Mitsubishi Motors dealer
or a repair facility of your
choice to have the system
checked.Refer to “Oil pressure wa
rning display” on page
5-220.
Screen
Cause
Do this (Reference)
BK0239700US.book 200 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
5
N00558201324
The operation status of each system is displayed on the inform
ation screen. For further details,
refer to the appropriate page
for each system.
Other interrupt displays
Screen
Cause
Do this (Reference)
 When starting the engine, the selector lever is in a position other than the “P” tion, or you pressed
the engine switch
without depressing the brake pedal.
 Place the selector lever in the “P” brake pedal with the right foot, and then press the engine sw
itch to start the
engine. Refer to “Starting and stopping the engine” on page 5-25.
Screen
System operation status
Reference
 When “4WD ECO” drive mode is selected with the drive mode selector.
Refer to “Electronica
lly controlled 4WD
system” on page 5-82.
 When “4WD AUTO” mode is selected with the drive mode selector.  When “4WD LOCK” mode is selected with the drive mode selector.
