Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-205
5
 There is a fault in the Forward Collision Mitigation System (FCM).
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked. Refer to “FCM and Ultras
onic misacceleration Miti-
gation System ON/OFF swit
ch: When a problem is
detected” on page 5-123.
 FCM braking function of the Forward Collision Mit- igation System (FCM) has been activated.
Refer to “FCM braking
function” on page 5-119.
 The Forward Collision Mitig
ation System (FCM) is
temporarily unavailable for some reason. This is not a malfunction.  The Lane Departure Warning system (LDW) has detected that your vehicle is
about to leave or has left
the lane.
Refer to “Lane Departure
Warning system (LDW)” on
page 5-139.
 There is a fault in the La
ne Departure Warning sys-
tem (LDW).
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked.Refer to “Lane Departure
Warning system (LDW)”
on page 5-139.
Screen
Cause
Do this (Reference)
BK0239700US.book 205 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
5
 The Ultrasonic misacceler
ation Mitiga
tion System
sensor is temporarily not available for some reason such as the environmental
condition or increase of
the sensor temperature.
 When the warning display does not disappear after waiting for a while, contac
t an authorized Mitsubishi
Motors dealer to have the system checked. Refer to “Ultrasonic misacc
eleration Mitigation Sys-
tem: Warning display” on page 5-131.
 The Ultrasonic misacceler
ation Mitiga
tion System
does not operate normally because there are some malfunctions in the se
nsor or the system.
 Immediately have your ve
hicle inspected at an
authorized Mitsubishi Motors dealer. Refer to “Ultrasonic misacc
eleration Mitigation Sys-
tem: Warning display” on page 5-131.
Screen
Cause
Do this (Reference)
BK0239700US.book 206 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-207
5
 The Ultrasonic misacceleration Mitigation System is activated.
Refer to “Ultrasonic misacceleration Mitigation Sys- tem” on page 5-127.
 The Blind Spot Warning (BSW) sensor is temporar- ily not available for some
reason such as the environ-
mental condition or incr
ease of the sensor
temperature.
 When the warning display does not disappear after waiting for a while, contact an authorized Mitsubishi Motors dealer.Refer to “Blind Spot Warning (BSW): When the sen- sor is temporarily not available” on page 5-135.
 The Blind Spot Warning (BSW) does not operate normally because there are
some malfunctions in the
sensor or the system.
 Immediately have your ve
hicle inspected at an
authorized Mitsubishi Motors dealer. Refer to “Blind Spot Warni
ng (BSW): When there is
a malfunction in the system
or the sensor” on page
5-135.
 Foreign objects, such as dirt
, snow or ice, adhere to
the bumper surface around the sensor.
 Remove a foreign object on the bumper surface around the sensor. When the warning display does not disappear after having cleaned the bumper
surface around the sen-
sor, contact an authorized
Mitsubishi Motors dealer.
Refer to “Blind Spot Warni
ng (BSW): When there is
a foreign objects on the
sensor” on page 5-135.
Screen
Cause
Do this (Reference)
BK0239700US.book 207 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
5
 The Rear Cross Traffic Alert (RCTA) is detected the vehicle approaching your vehicle.
 Pay special attention to the rear of your vehicle. Refer to “Rear Cross Traffic Alert (RCTA)” on page 5-136.
 There is a fault in the sensor.
Contact an authorized Mitsubishi Motors dealer. Refer to “Forward Coll
ision Mitigation System
(FCM): When a problem is detected” on page 5-123.Refer to “Lane Departure Warning System (LDW): System problem warning” on page 5-141. Refer to “Automatic high
beam system: System
problem warning” on page 5-227.
 The Forward Collision Mi
tigation System (FCM),
Lane Departure Warning system (LDW) and auto- matic high beam system is
temporarily unavailable
due to the high or low temperature of the sensor.
 After the temperature of the sensor has been in range, the system will automatically return to opera- tion. Refer to “Forward Coll
ision Mitigation System
(FCM): When a problem is detected” on page 5-123. Refer to “Lane Departure Warning System (LDW): System problem warning” on page 5-141.Refer to “Automatic high
beam system: System
problem warning” on page 5-227.
 The sensor is temporarily
unavailable due to condi-
tions such as the adhesion of contaminants to the sensor or windshield.This is not a malfunction.
Refer to “Lane Departure Wa
rning System (LDW): Sys-
tem problem warning”
on page 5-141.
Refer to “Automatic high be
am system: System problem
warning” on page 5-227.
Screen
Cause
Do this (Reference)
BK0239700US.book 208 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-209
5
N00579100026
On vehicles equipped with Mitsubishi Multi- Communication System, the following infor- mation on navigation will be displayed whenguidance location such
as junction and desti-
nation is approached after you set the destina- tion and started the route guidance.
 There is a fault in the system of automatic high beam.
 Contact an authorized Mitsubishi Motors dealer. Refer to “Automatic hi
gh beam system: System
problem warning” on page 5-227.
Screen
Cause
Do this (Reference)
(if
so equipped)1- Guidance display
Shows the direction of vehicle travel and the guidance location.
2- Remaining di
stance display
Shows the distance to the location where the guidance is displayed.
Direction of vehicle travel (Example) Destination Ferry terminal Tollbooth Intermediate destination (Example)
NOTE
 Please read this section and also the separate owner’s manual for Mi
tsubishi Multi-Com-
munication System.
BK0239700US.book 209 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
5
N00558201324
The operation status of each system is displayed on the inform
ation screen. For further details,
refer to the appropriate page
for each system.
Other interrupt displays
Screen
Cause
Do this (Reference)
 When starting the engine, the selector lever is in a position other than the “P” tion, or you pressed
the engine switch
without depressing the brake pedal.
 Place the selector lever in the “P” brake pedal with the right foot, and then press the engine sw
itch to start the
engine. Refer to “Starting and stopping the engine” on page 5-25.
Screen
System operation status
Reference
 When “4WD ECO” drive mode is selected with the drive mode selector.
Refer to “Electronica
lly controlled 4WD
system” on page 5-82.
 When “4WD AUTO” mode is selected with the drive mode selector.  When “4WD LOCK” mode is selected with the drive mode selector.
BK0239700US.book 210 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-211
5
 When “AWC ECO” mode of S-AWC is selected.
Refer to “S-AWC (Super-All Wheel Con- trol)” on page 5-85.
 When “NORMAL” mode of S-AWC is selected.  When “SNOW” mode of S-AWC is selected.  When “LOCK” mode of S-AWC is selected.  When the ECO mode is activated. Refer
to “ECO mode switch” on page 5-231.
 When the parking se
nsor detects an
obstacle.
Refer to “Parking sens
ors (Front/Rear)” on
page 5-147.
Screen
System operation status
Reference
BK0239700US.book 211 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
5
 When the Forward Collision Mitigation System (FCM) is activated or the timing of an alarm is changed.
Refer to “FCM and Ultrasonic misaccelera- tion Mitigation System ON/OFF switch” on page 5-122.
 When the Forward Collision Mitigation System (FCM) is
deactivated.
Refer to “FCM and Ultrasonic misaccelera- tion Mitigation System ON/OFF switch” on page 5-122.
 When the Ultrasonic misacceleration Mitigation System
is deactivated.
Refer to “To turn on/off the Ultrasonic misacceleration Mitiga
tion System” on page
5-131.
 When the operation mode of the Lane Departure Warning system (LDW) is switched.
Refer to “Lane Depart
ure Warning system
(LDW): Turning off
the LDW” on page
5-139.
Screen
System operation status
Reference
