2017 MERCEDES-BENZ SLC-Class ESP

RDynamicTRF.RouteAfterRequest(only
available in the USA and Canada)
You can decide whether or not current traffic
reports should be taken into account for route
calculation.
RCalculate Alternative Routes
Different routes are being calculated. In order
to do so, instead of Start,select the menu
item Continue.
Notes for route options:
RUse Toll Roads
The route calculation includes roads which
require you to pay ausage fee (toll).
RNumber of Occupants in the Vehicle:(only available in the USA)
Prerequisite: your vehicle meets the access
conditions for carpool lanes.
Carpool lanes will be included if the carpool
lanes option is activated.
Entering an address
Multimedias ystem:
XSelectNaviQNavigation.
The map shows the vehicle's current position.
XSlide 6the controller.
XSelect DestinationQAddress Entry.
Enter an address, e.g. as follows:
Rcity or ZIP code, street, house number
Rstate/province, city or ZIP code
Rcity or ZIP code, center
Rstreet, city or ZIP code, intersection
XSelect City.
The city in which the vehicle is currently loca-
ted (current vehicle position) is at the top.
Below this, you will see locations for which
route guidance has already been carried out.
XEnter the city.
The Gsymbol: the location is contained on
the digital map multiple times.
XTo switch to the list: slide the5control-
ler.
XSelect the location.
If available, the ZIP code is shown. If there are
different ZIP codes available for the location,
the corresponding digits are displayed with an
X
.
XEnter the street and house number.
The address is in the menu. Further options for destination entry:
Rsearch for
akeyword
The keyword search finds destinations using
fragments of words.
Rselect the last destination
Rselect acontact
Rselect aPOI
You can search for aPOI by location, name or
telephone number.
Rselect destination on the map
Renter intermediate destination
You can map the route to the destination
yourselfw ith up to four intermediate destina-
tions.
Rselect destinations from Mercedes-Benz
Apps
Rselect geo-coordinates
Calculating the route
Prerequisite: the address has been entered and
is in the menu.
XSelect StartorContinue.
The route is calculated with the selected route
type and the selected route options.
If route guidance has already been activated,
ap rompt will appeara sking whether you wish
to end the current route guidance.
XSelect YesorSet as Intermediate Des‐tination.
Yescancels the current route guidance and
starts route calculation to the new destina-
tion.
Set as Intermediate Destination
adds
the new destination in addition to the existing
destination and opens the intermediate des-
tinations list.
Connecting amobile phone
Prerequisites
For telephony via the Bluetooth®interface, you
require aBluetooth®-capable mobile phone. The
mobile phone must support Hands-Free Profile
1.0 or above.
214Operating system
Multimedia system

XTo turn over:lift reversible floor panel ;
using tab :.
XTurn overand then re-inser treversible floor
panel ;.
Twoflexible straps ;are attachedtot he rever-
sibl efloor panel ,use thes etos ecure objects,
such as wind screen =,whenr eversibl efloor
panel :hasb eent urne dover.
Roo fcarrier
!
Thi svehicl eisn ot designed to transport
items on the roof. Roof carriers and other
device swhich are mounted on the roo fthat
have not been specifically approved for this
model by Mercedes-Benz must not be used as
they could damag ethe vehicl eand the
retractable hardto p(vario-roof).
At the time of going to print, Mercedes-Benz
does not offe rany roo fcarrie roro therroof-
installe ddevice sfor thism odel.
!Thisvehicl eisn ot designed to transport any
items on the trunk li dortoallowluggage car-
riers or equipment of any kind to be installed
to the trunk lid. Otherwise the vehicl eand the
retractable hardto pcould be damaged.
Features
Cup holder
Important safety notes
GWARNING
If objects in the passenger compartment are
stowed incorrectly ,they can slid eorbe
thrown around and hitv ehicleoccupants. In
addition, cupholders, open stowag espaces
and mobil ephone brackets canno talway s
retain al lobjects they contain. There is arisk
of injury,p articularly in the event of sudden
braking or asudde nchange in direction.
RAlway sstow objects so thatt hey cannotbe
thrown around in such situations.
RAlway smakes uret hato bjects do not pro-
trud efrom stowag espaces, parcel nets or
stowag enets.
RClose the lockable stowag espaces before
starting ajourney.
RAlway sstow and secure heavy,h ard, poin-
ted,s harp-edged ,fragile or bulky objects in
the trunk.
!Onlyu sethe cup holders for containers of
the right size and which have lids. The drinks
could otherwise spill.
!Do not expose drinks bottle sinthe cup
holde rinthe cente rconsole to continuous,
strong and direct sunlight. The passenger
compartment in the are aofthe cente rcon-
sol ec an otherwise be damaged by the con-
centrated and reflecte dsunlight.
Cup holder in the centerc onsole
Features219
Stowageand featur es
Z

XTo open:slidecover ;back.
XTo remove the insert: slidecatch :inwards
on both side sinthe direction of the arrow.
XRemove the cup holde rinsert upwards.
XTo re-install the insert: place the insert in
the stowag espace.
XSlide catch :outwards in the direction of the
arrow unti litengages.
Yo uc an remove the cup holde rinsert for clean-
ing .Clean with clear, lukewarm water only.
Bottl eholder
Observe the "Important safety notes "int he
"Stowage compartments" section (Ypage 217).
!Make sure thata ny bottlesweighin gmore
than1 .1 lb(0.5 kg) thata re stored in the bottle
holder, res tonthe vehicl efloor. The bottle
holde rcould otherwise be damaged.
XPress the outer edge of button :and slid ein
the direction of the arrow unti lthe bottle fits
into the opening.
XInsert the bottle into the bottle holder.
The bottle holde rissuitabl efor bottle switha
capacity of 25 fl. oz. (0.7 l)to 54 fl. oz. (1.5 l).
The bottle holde rdoesn ot secur ethe bottles; it
merel yprevents themf romtipping over.
Sun visors
Overview
GWARNING
If the mirrorc overoft he vanity mirrorisf olded
up when the vehicl eisinmotion, yo ucould be
blinded by incident light. There is ariskofa n
accident.
Alway skeept he mirrorc overfolde ddown
whil edriving.
:Mirro rlight
;Bracket
=Retaining strip, e.g .for ap arking lo tticket
?Vanity mirror
AMirro rcover
iWhen drivin gathighs peeds with the side
windo worroofo pen:
If yo uhavei nserte dacar park ticke tinto
retaining strip =,makes uret hatiti snot
blow nawaybyt he wind.
Ashtray
XTo open: push the lowe rsectio nofc over:.
The cove ropens.
XTo remove the insert: lift insert=up; and
out.
XTo re-install the insert: press insert=into
the holde runtilite ngages.
220Features
Stowag eand featur es

The system is availableif:
Rit has been activated and is operational
Rthe corresponding mobile phone network is
availablefor transmitting data to the Cus-
tomer Center
Ras ervice subscription is available
Rthe starter battery is sufficiently charged
iDetermining the location of the vehicle on a
map is only possible if:
RGPS reception is available.
Rthe vehicle position can be forwarded to
the Customer Assistance Center.
The mbrace system
To adjust the volume during acall, proceed as
follows:
XPress the WorX button on the multi-
function steerin gwheel.
or
XUse the volume controller of the audio sys-
tem/COMAND.
The system offers various services, e.g.:
RAutomatic and manual emergencyc all
RRoadside Assistance call
RMB Info call
USA only: you can find information and a
description of all availablef eatures under "Own-
ers Online" at http://www.mbusa.com.
System self-test
After you have switched on the ignition, the sys- tem carries out aself-diagnosis.
Am alfunction in the system has been detected
if one of the following occurs:
RThe indicator lamp in the SOS button does not
come on during the system self-test.
RThe indicator lamp in the FRoadside
Assistance button does not light up during
self-diagnosis of the system.
RThe indicator lamp in the ïMB Info call
button does not light up during self-diagnosis
of the system.
RThe indicator lamp in one or more of the fol-
lowing button scontinues to light up red after
the system self-diagnosis:
-SOS button
-F Roadside Assistance call button
-ïMB Info call button
RAfter the system self-diagnosis, the Inoper‐ativeorServiceNotActivatedmessage
appears in the multifunction display.
If am alfunction is indicated as outlined above,
the system may not operate as expected. In the
event of an emergency, help will have to be
summoned by other means.
Have the system checked at the nearest author-
ized Mercedes-Benz Center or contact the fol-
lowing service hotlines:
RUSA: Mercedes-Benz Customer Assistance
Center at 1-800-FOR-MERCedes
(1-800-367-6372)o r1-866-990-9007
RCanada: Customer Service at
1-888-923-8367
Emergency call
Important safety notes
GWARNING
It can be dangerous to remain in the vehicle,
even if you have pressed the SOS button in an emergencyi f:
Ryou see smoke inside or outside of the vehi-
cle, e.g. if there is afire after an accident
Rthe vehicle is on adangerous section of
road
Rthe vehicle is not visible or cannot easily be seen by other road users, particularly when
dark or in poor visibility conditions
There is arisk of an accident and injury.
Leave the vehicle immediately in this or simi-
lar situations as soon as it is safe to do so.
Move to asafe location along with other vehi-
cle occupants. In such situations, secure the
vehicle in accordanc ewith national regula-
tions, e. g. with awarning triangle.
You must have alicense agreement to activate
the mbrace service. Make sure that your system
is activated and operational. To register, press
the ï MB Info call button .Ifany of the steps
222Features
Stowage and features

mentioned are not carried out, the system may
not be activated.
If you have questions aboutthe activation, con-
tact one of the following telephone hotlines:
RUSA: Mercedes-Benz Customer Assistance
Center at 1-800-FOR-MERCedes
(1-800-367-6372) or 1-866-990-9007
RCanada: Customer Service at
1-888-923-8367
General notes
An emergency call is dialed automatically if an
air bag or Emergency Tensioning Device is trig-
gered.
iYou cannot end an automatically triggered
emergency call yourself.
An emergency call can als obeinitiated man-
ually.
As soon as the emergency call has been initi-
ated, the indicator lamp in the SOS button
flashes. The multifunction display shows the
ConnectingC all
message.
The audio outpu tismuted.
Once the connection has been made ,the Call
Connectedmessage appears in the multifunc-
tion display.
All important informatio nonthe emergency is
transmitted, for example:
Rcurrent location of the vehicle( as determined
by the GPS system)
Rvehiclei dentification number
Rinformatio nonthe severity of the accident
Shortly after the emergency call has been initi-
ated, avoice connection is automatically estab-
lished betwee nthe Customer Assistance Center
and the vehicleo ccupants.
RIf the vehicleoccupants respond, the
Mercedes-Benz Customer Assistance Center
attempts to get more informatio nonthe
emergency.
RIf there is no response from the vehicleo ccu-
pants, an ambulance is immediately sent to
the vehicle.
If no voice connection can be established to the
Mercedes-Benz Customer Assistance Center,
the system has been unable to initiate an emer-
gency call.
This can occur, for example, if the relevant
mobilep hone network is not available. The indi- cator lamp in the SOS button flashes continu-
ously.
The
Call Failed
message appears in the mul-
tifunction display and must be confirmed.
In this case, summon assistance by other
means.
Making an emergency call
XTo initiate an emergency call manually:
press cover :briefl ytoo pen.
XPress SOS button ;briefly.
The indicator lamp in SOS button ;flashes
until the emergency call is concluded.
XWai tfor av oice connection to the Mercedes-
Benz Customer Assistance Center.
XAfter the emergency call ,close cover :.
iIf the mobilep hone network is unavailable,
mbrace wil lnot be abl etomake the emer-
gency call .Ifyou leave the vehiclei mmedi-
ately after pressing the SOS button, you will
not know whether mbrace placed the emer-
gency call .Inthis case, alwayss ummon assis-
tance by other means.
Roadside Assistanceb utton
Features223
Stowage and features
Z

XPress Roadside Assistance button:.
This initiates acall to the Mercedes-Benz Cus-
tomer Assistance Center.
The indicator lamp in Roadside Assistance
button :flashes while the call is active. The
multifunction display shows the Connect‐
ing Callmessage. The audio output is
muted.
If ac onnection can be made, the Call Con‐
nectedmessage appears in the multifunction
display.
If am obile phone networ kand GPS reception
are available, the system transfers data to the
Mercedes-Benz Customer Assistance Center,
for example:
Rcurrentl ocation of the vehicle
Rvehicle identification number
iThe display of the multimedia system indi-
cates that acall is active. During the call, you
can change to the navigation menu by press-
ing the NAVI button on COMAND,f or exam-
ple.
iVoice output is not available.
Av oice connection is established between the
Mercedes-Benz Customer Assistance Center
and the vehicle occupants.
From the remotem alfunction diagnosis, the
Mercedes-Benz Customer Assistance Center
can ascertain the nature of the problem
(
Ypage 225).
The Mercedes-Benz Customer Assistance Cen-
ter either sends aqualified Mercedes-Benz tech-
nician or makes arrangements for your vehicle
to be transported to the nearest authorized
Mercedes-Benz Center.
You may be charged for services such as repair
work and/or towing.
Further details are availableiny our mbrace
manual.
iThe system has not been able to initiate a
Roadside Assistance call, if:
Rthe indicator lamp for Roadside Assistance
call button :is flashing continuously.
Rno voice connection to the Mercedes-Benz
Customer Assistance Center was estab-
lished.
This can occur if the relevant mobile phone
networ kisnot available, for example.
The Call Failed
message appears in the
multifunction display.
XTo end acall: press the ~button on the
multifunction steerin gwheel.
or
XPress the corresponding multimedia system
button for ending aphone call.
MB Info call button
XPress MB Info call button :.
This initiates acall to the Mercedes-Benz Cus-
tomer Assistance Center.
The indicator lamp in MB Info call button :
flashes while the connection is being made.
The multifunction display shows the Con‐
nectingCallmessage. The audio system is
muted.
If ac onnection can be made, the Call Con‐
nectedmessage appears in the multifunction
display.
If am obile phone networ kand GPS reception
are available, the system transfers data to the
Mercedes-Benz Customer Assistance Center,
for example:
Rcurrentl ocation of the vehicle
Rvehicle identification number
iThe display of the multimedia system indi-
cates that acall is active. During the call, you
can change to the navigation menu by press-
ing the NAVI button on COMAND,f or exam-
ple.
Voice output is not available.
Av oice connection is established between the
Mercedes-Benz Customer Assistance Center
and the vehicle occupants.
You receive information about operating your
vehicle, about the nearest authorized
Mercedes-Benz Center and about other prod-
ucts and services from Mercedes-Benz.
224Features
Stowage and features

USA only: you can find further information on
the mbrace system under "Owners Online" at
http://www.mbusa.com.
iThe system has not been able to initiate an
MB Info call, if:
Rthe indicator lamp in MB Info call button :
is flashing continuously.
Rno voice connection to the Mercedes-Benz
Customer Assistance Center was estab-
lished.
This can occur if the relevant mobile phone
network is not available, for example.
The Call Failed
message appears in the
multifunction display.
XTo end acall: press the ~button on the
multifunction steering wheel.
or
XPress the corresponding multimedia system
button for ending aphone call.
Call priority
When service calls are active, e.g. Roadside
Assistance or MB Info calls, an emergency call
can still be initiated. In this case, an emergency
call will take priority and override all other active
calls.
The indicator lamp of the respective button
flashes until the call is ended.
An emergency call can only be terminated by the
Mercedes-Benz Customer Assistance Center.
All other calls can be ended by pressing:
Rthe ~ button on the multifunction steering
wheel
Rthe corresponding button on the audios ys-
tem or on COMAND for ending atelephone
call
iWhen acall is initiated, the audios ystem is
muted. The mobile phone is no longer con-
nected to COMAND. However, if you want to
use your mobile phone, do so only when the
vehicle is stationary and in asafe location.
Vehicle Health Check
With the Vehicle Health Check, the Customer
Assistance Center can provide improved sup-
port for problems with your vehicle. During an
existing call, vehicle data is transferred to the
Customer Assistance Center. The customer ser-
vice representative can use the received data to decide what kind of assistance is required.Y
ou
are then, for example, guidedtot he nearest
authorized Mercedes-Benz Center or arecovery
vehicle is called.
If vehicle data needs to be transferred during an
MB Info call or aRoadside Assistance call, this is
initiated by the Customer Assistance Center.
You will see the Roadside Assistance Con‐
nectedmessage in the COMAND display. If the
vehicle remote malfunction diagnosis can be
started, the Request for vehicle diagno‐
sisreceived.Startvehiclediagnosis?message appears in the display.
XConfirm the message with Yes.
XWhen theVehicle Diagnosis Pleasestart ignitionmessage appears, turn the
SmartKey to position 2in the ignition lock
(
Ypage 115).
XWhen the Please follow the instruc‐tions received by phone and moveyour vehicle to asafe positionmes-
sage appears, follow the customer service
representative's instructions.
The message in the displayd isappears.
If you select Cancel
the remote malfunction
diagnosis is canceled completely.
The vehicle operating state check begins. You
will see the Vehicle
diagnosisactivatedmessage.
When the diagnosis is completed, the Trans‐
fer vehicle diagnostics data (Voiceconnection may be interrupted duringdatatransfer)message appears. The vehicle
data can now be sent to the Customer Assis-
tance center.
XPress OKto confirm the message.
The voice connection with the Customer
Assistance Center is terminated.
You will see the Vehicle diagnosis:
Transferring data...message.
The vehicle data is sent to the Customer
Assistance Center.
Depending on what the customer service rep-
resentative agreed with you, the voice connec-
tion is re-established after the transfer is com-
plete. If necessary, you will be contacted at a
later time by another means, e.g. by e-mail or
phone.
Another function of the Vehicle Health Check is
the transfer of service data to the Customer
Assistance Center. If aservice is overdue, the
Features225
Stowage and features
Z

XTo start programmingmode: press and
hol done of buttons ;to? on the integrated
garag edooro pener.
The garag edooro penerisn ow in program-
ming mode. After ashort time ,indicator
lamp :lights up yellow.
Indicato rlam p: lights up yellow as soo nas
button ;,=or? is stored for the first time.
If the selecte dbutton hasa lready been pro-
gramed ,indicator lamp :will onlyl ight up
yellow afte rten seconds have elapsed.
XReleas ebutton ;, =or?.I ndicator
lamp :flashe syellow.
XTo program the remote control: point
garag edoorremote control Atoward sbut-
tons ;to? on the rear-view mirror at adis-
tance of 2to8in(5t o20cm).
XPress and hol dbutton Bon remote control
A unti lindicator lamp :lights up green.
Whe nindicator lamp :lights up green: pro-
gramming is finished.
Whe nindicator lamp :flashe sgreen: pro-
gramming wa ssuccessful. The next step is to
synchronize the rolling cod e(
Ypage 227).
XReleasebutton Bon remote control Afor
the garag edoord rive system.
If indicator lamp :lights up red :repea tthe
programing procedur efor the corresponding
button on the rear-view mirror. Whe ndoing
so, var ythe distance between remote control
A a
nd the rear-view mirror.
The required distance between remote con-
trol Aand the integrated garag edooropener
depends on the garag edoord rive system.
Several attempts might be necessary.Y ou
shoul dtest every positio nfor at least
25 seconds before trying another position.
Synchronizin gthe rolling code
Paya ttentio ntothe "Important safety notes"
(Ypage 226).
If the garag edoors ystem uses arolling code,
yo uw illa lsoh avetos ynchronize the garage
door system with the integrated garag edoor
opene rinthe rear-view mirror. To do thisy ouwill
nee dtou sethe programming button on the door
drive contro lpan el.T he programming button
maybel ocate dind ifferent place sdepen ding on
the manufacturer. It is usuall yloc ate dont he
door drive uni tonthe garag eceiling.
Familiarize yoursel fwitht he garag edoord rive
operating instructions, e.g .under "Program- ming additional remote controls", before carry-
ing outt
he following steps.
Your vehicl emustbew ithinr each of the garage
door or gate opene rdrive. Make sure thatn ei-
ther your vehicl enor any persons/objects are
present withint he sweepofthe door or gate.
XTurn the SmartKey to position 2in the ignition
lock (Ypage 115).
XGe toutof the vehicle.
XPress the programming button on the door
drive unit.
Usually ,you now have 30 seconds to initiate
the next step.
XGe tinto the vehicle.
XPress previously programed button ;,=
or ? on the integrated garag edooro pener
repeatedly and in quick succession unti lthe
door closes.
The rolling cod esynchronizatio nist hen com-
plete.
Note sonp rogrammin gthe remote con-
trol
Canadia nradio frequency laws require a"break"
(o ri nterruption) of the transmission signals
afte rbroadcasting for afew seconds. Therefore,
thes esignals mayn ot last long enough for the
integrated garag edooro pener. The signalisn ot
recognized during programming. Comparable
with Canadia nlaw ,som eU .S. garag edoorope n-
ers also feature a"break".
Procee dasfollows:
Rif youliveinC anada
Rif yo uhaved ifficultie sprogramming the
garag edooro pener(regardless of where you
live) when using the programming steps
XPress and hol done of buttons ;to? on the
integrated garag edooro pener.
After ashort time ,indicator lamp :lights up
yellow.
XReleas ethe button.
Indicato rlam p: flashe syellow.
XPress button Bof garag edoorre mote con-
trol Afor two seconds, then release it for two
seconds.
XPress button Bagai nfor two seconds.
XRepeat thiss equence on button Bof remote
control Aunti lindicator lamp :lights up
green.
Whe nindicator lamp :lights up green: pro-
gramming is finished.
Features227
Stowag eand featur es
Z
