2017 JEEP RENEGADE warning lights

WARNING!(Continued)
•Seats should be adjusted before fastening the seat
belts and while the vehicle is parked. Serious injury
or death could result from a poorly adjusted seat belt.
• Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your chest.
In a collision you could slide under the seat belt,
which could result in serious injury or death.
CAUTION!
Do not place any article under a power seat or impede
its ability to move as it may cause damage to the seat
controls. Seat travel may become limited if movement
is stopped by an obstruction in the seat’s path.
Power Lumbar Adjustment— If Equipped
Push the switch forward or rearward to increase or de-
crease the lumbar support. Push the switch upward or
downward to raise or lower the lumbar support. NOTE:
Power seat adjustments are only allowed when the
ignition device is turned to ON, and for about 30 minutes
after it is turned to OFF. The seats can also be moved after
opening/closing the doors for about 30 minutes, locking or
unlocking the doors, or switching on of the front courtesy
lights.
Heated Seats — If Equipped
The heated seat switches are located on the instrument
panel.
You can choose between two heating levels:
• Push the heated seat button
once to turn the HI
setting on.
• Push the heated seat buttona second time to turn
the LO setting on.
• Push the heated seat buttona third time to turn the
heating elements off.
If the HI-level setting is selected, the system will automati-
cally switch to LO-level after approximately 145 minutes of
continuous operation. At that time, the display will change
from HI to LO, indicating the change. The LO-level setting
will turn off automatically after approximately 60 minutes.
3
GETTING TO KNOW YOUR VEHICLE 41

GETTING TO KNOW YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT CLUSTER ..................122
▫ Instrument Cluster Descriptions .............123
 INSTRUMENT CLUSTER DISPLAY ...........124
▫ Instrument Cluster Display Location And
Controls ............................ .125
▫ Oil Change Reset ..................... .127
▫ Instrument Cluster Display Menu Items ......127
 TRIP COMPUTER ....................... .133
 WARNING/INDICATOR LIGHTS AND
MESSAGES ........................... .134
▫ Red Telltale Lights .....................134 ▫
Yellow Telltale Lights ....................144
▫ Green Telltale Lights .....................159
▫ Blue Telltale Lights ..................... .161
▫ White Telltale Lights .....................162
▫ Gray Telltale Lights .....................163
 ONBOARD DIAGNOSTIC SYSTEM (OBD II) . . . .164
▫ Onboard Diagnostic System (OBD II)
Cybersecurity ........................ .164
 EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS .......................... .1654

Settings
This menu item allows you to change the settings for the
following:
•Display
• Units
• Clock and Date
• Security
• Safety and Assistance
• Lights
• Doors and Locks
• Compass
Vehicles Equipped With Multifunctional Display Re-
configurable:
The following menu/submenu items are
available in the cluster display.
“Display”
By selecting the Display,you can access the following
settings:
• Language: allows you to select the language in which to
display the information/warnings. •
Phone
• Navigation
Units Of Measure
By selecting the item Units of Measure,you can select the
unit of measure to use for displaying various magnitudes.
Possible options are:
• US
• Metric
• Custom
Clock & Data
By selecting the item, Clock & Dateyou can adjust the
clock.
Possible options are:
• Set Time: adjust hours/minutes
• Set Format: adjust the time format 12h(12 hours) or
24h (24 hours)
• Set Date: adjust day/month/year
130 GETTING TO KNOW YOUR INSTRUMENT PANEL

•Lanesense Strength (If Equipped)
• Side Distance Warning (If Equipped)
• Side Distance Warning Volume (If Equipped)
Lights
By selecting the item Lights,you can make the following
adjustments:
• Headlight Off Delay: set the delay for headlight shutoff
after engine shutoff
• Headlight Sensitivity (If Equipped): adjust the sensitiv-
ity of headlight brightness
• Daytime Running Lights (If Equipped): activate/
deactivate the daytime running lights
• Cornering lights (If Equipped): activate/deactivate the
cornering lights (If Equipped)
• Greeting Lights (If Equipped): activate / deactivate
greeting lights
Doors & Locks
By selecting the item Doors & Locks,you can make the
following adjustments: •
Auto Door Lock (If Equipped): activate/deactivate the
automatic locking of the doors with the vehicle moving
• Auto Unlock On Exit (If Equipped): automatic unlocking
of the doors when exiting the vehicle
• Flash Light with Lock (If Equipped): activate the direc-
tion indicators when closing the doors
• Sound Horn With Lock (If Equipped): activate/
deactivate the horn when pushing the LOCK button on
the key fob. The options are Off,First Press,” and
Second Press
• Horn With Remote Start (If Equipped): activate/
deactivate the horn at the Remote Starting of the engine
with the key fob
• Remote Door Unlock (If Equipped): allows you to open
the driver door only on the first push of the UNLOCK
button on the key fob
• Passive Entry (If Equipped): activate the automatic
locking of the doors
132 GETTING TO KNOW YOUR INSTRUMENT PANEL

WARNING/INDICATOR LIGHTS AND MESSAGES
The warning/indicator light switches on in the instrument
panel together with a dedicated message and/or acoustic
signal when applicable. These indications are indicative
and precautionary and as such must not be considered as
exhaustive and/or alternative to the information contained
in the Owner Manual, which you are advised to read
carefully in all cases. Always refer to the information in this
chapter in the event of a failure indication.All active telltales will display first, if applicable. The
system check menu may appear different based upon
equipment options and current vehicle status. Some tell-
tales are optional and may not appear.
The following warning lamps and indicators will alert you
to a vehicle condition that may become serious. Some
lamps will illuminate when you start your vehicle to make
sure they work. If any lamps remain on after starting your
vehicle, refer to the respective system warning lamp for
further information.
Red Telltale Lights
Seat Belt Reminder Warning Light
Red Telltale
Light What It Means
Seat Belt Reminder Warning Light
When the ignition switch is first turned to ON/RUN, this light will turn on for four to eight sec-
onds as a bulb check. During the bulb check, if the driver’s seat belt is unbuckled, a chime will
sound. After the bulb check or when driving, if the driver ’s seat belt remains unbuckled, the Seat
Belt Reminder Light will flash or remain on continuously and a chime will sound. Refer to “Oc-
cupant Restraint Systems” in “Safety” for further information.
134 GETTING TO KNOW YOUR INSTRUMENT PANEL

Hazard Warning Lights
Green TelltaleLight What It Means
Hazard Warning Lights
The hazard warning indicators light up when the vehicles Hazard Warning flasher switch has
been pushed.
Park/Headlight ON Indicator Light
Green Telltale
Light What It Means
Park/Headlight ON Indicator Light
This indicator will illuminate when the park lights or headlights are turned on.
Turn Signal Warning Lights
Green Telltale
Light What It Means
Turn Signal Indicator Lights
The instrument cluster arrow will flash independently for the left or right turn signal as selected,
as well as the exterior turn signal lamp(s) (front and rear) as selected when the multifunction le-
ver is moved down (left) or up (right).
160 GETTING TO KNOW YOUR INSTRUMENT PANEL

Set Speed Warning Light — If Equipped
White WarningLight What It Means
Set Speed Warning Light
When Set Speed Warning is turned on the speed warning telltale will illuminate in the instru-
ment cluster, with a number matching the set speed. Each time the set speed is exceeded, an au-
dible chime will sound for up to 10 seconds, or until the speed is no longer exceeded. The telltale
in the instrument cluster will also change from white to yellow, and a pop up warning message
will pop up on the instrument cluster display screen. Speed Warning can be turned on and off in
the instrument cluster display, for further information refer to “Instrument Cluster Display Menu
Items” in “Getting To Know Your Instrument Panel.”
NOTE:
The number “120” is only an example of a speed that can be set.
Gray Telltale Lights
Cruise Control Cancelled Light
White Telltale
Light What It Means
Cruise Control Cancelled Light
This light will turn on when the cruise control has been cancelled by the driver. Refer to “Speed
Control — If Equipped” in “Starting and Operating” for further information.
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 163

The BSM system notifies the driver of objects in the
detection zones by illuminating the BSM warning light
located in the outside mirrors in addition to sounding an
audible (chime) alert and reducing the radio volume. Refer
to “Modes Of Operation” for further information.The BSM system monitors the detection zone from three
different entry points (side, rear, front) while driving to see
if an alert is necessary. The BSM system will issue an alert
during these types of zone entries.
Entering From The Side
Vehicles that move into your adjacent lanes from either
side of the vehicle.
BSM Warning LightSide Monitoring
182 SAFETY
