2017 JEEP COMPASS service indicator

WARNING!
You can be badly injured working on or around a
motor vehicle. Only do service work for which you
have the knowledge and the proper equipment. If you
have any doubt about your ability to perform a service
job, take your vehicle to a competent mechanic.
Engine Oil
Change Engine Oil
The oil change indicator system will remind you that it is
time to take your vehicle in for scheduled maintenance.
Refer to the “Maintenance Plan” for further information.
NOTE:Under no circumstances should oil change inter-
vals exceed 10,000 miles (16,000 km), twelve months or 350
hours of engine run time, whichever comes first. The 350
hours of engine run or idle time is generally only a concern
for fleet customers.
Engine Oil Selection
For best performance and maximum protection under all
types of operating conditions, the manufacturer only rec-
ommends engine oils that are API Certified and meet the
requirements of FCA Material Standard MS-6395.
American Petroleum Institute (API) Engine Oil
Identification Symbol
This symbol means that the oil has
been certified by the American Pe-
troleum Institute (API). The manu-
facturer only recommends API Cer-
tified engine oils.
This symbol certifies 0W-20, 5W-20,
0W-30, 5W-30 and 10W-30 engine
oils.
CAUTION!
Do not use chemical flushes in your engine oil as the
chemicals can damage your engine. Such damage is not
covered by the New Vehicle Limited Warranty.
Engine Oil Viscosity (SAE Grade) — 2.0L, 2.4L
Engine
MOPAR SAE 5W-20 engine oil approved to FCA Material
Standard MS-6395 such as Pennzoil, Shell Helix or equiva-
lent is recommended for all operating temperatures. This
engine oil improves low temperature starting and vehicle
fuel economy.
288 SERVICING AND MAINTENANCE

These indicators are molded into the bottom of the tread
grooves. They will appear as bands when the tread depth
becomes a 1/16 of an inch (1.6 mm). When the tread is
worn to the tread wear indicators, the tire should be
replaced. Refer to “Replacement Tires” in this section for
further information.
Life Of Tire
The service life of a tire is dependent upon varying factors
including, but not limited to:
•Driving style.
• Tire pressure - Improper cold tire inflation pressures can
cause uneven wear patterns to develop across the tire
tread. These abnormal wear patterns will reduce tread
life, resulting in the need for earlier tire replacement.
• Distance driven.
• Performance tires, tires with a speed rating of V or
higher, and Summer tires typically have a reduced tread
life. Rotation of these tires per the vehicle maintenance
schedule is highly recommended.
WARNING!
Tires and the spare tire should be replaced after six
years, regardless of the remaining tread. Failure to
follow this warning can result in sudden tire failure.
You could lose control and have a collision resulting in
serious injury or death.
Tire Tread
1—WornTire
2—NewTire
8
SERVICING AND MAINTENANCE 317

FUEL REQUIREMENTS
2.0L And 2.4L Engine
These engines are designed to meet all
emissions regulations and provide opti-
mum fuel economy and performance
when using high quality unleaded
“Regular” gasoline having a posted oc-
tane number of 87 as specified by the
(R+M)/2 method. The use of higher
octane “Premium” gasoline is not required, as it will not
provide any benefit over “Regular” gasoline in these
engines.
While operating on gasoline with an octane number of 87,
hearing a light knocking sound from the engine is not a
cause for concern. However, if the engine is heard making
a heavy knocking sound, see your dealer immediately. Use
of gasoline with an octane number lower than 87 can cause
engine failure and may void or not be covered by the New
Vehicle Limited Warranty.
Poor quality gasoline can cause problems such as hard
starting, stalling, and hesitations. If you experience these
symptoms, try another brand of gasoline before consider-
ing service for the vehicle.
Reformulated Gasoline
Many areas of the country require the use of cleaner
burning gasoline referred to as “Reformulated Gasoline”.
Reformulated gasoline contains oxygenates and are specifi-
cally blended to reduce vehicle emissions and improve air
quality.
The use of reformulated gasoline is recommended. Prop-
erly blended reformulated gasoline will provide improved
performance and durability of engine and fuel system
components.
Gasoline/Oxygenate Blends
Some fuel suppliers blend unleaded gasoline with oxygen-
ates such as ethanol.
CAUTION!
DO NOT use gasoline containing methanol or gasoline
containing more than 15% ethanol (E-15). Use of these
blends may result in starting and drivability problems,
damage critical fuel system components, cause emis-
sions to exceed the applicable standard, and/or cause
the “Malfunction Indicator Light” to illuminate. Please
(Continued)
9
TECHNICAL SPECIFICATIONS 335

Automatic Door..........................30
Child Protection ..........................32
Door ..................................29
Power Door .............................30
Lubrication, Body ..........................292
Luggage Rack (Roof Rack) .....................92
Lug Nuts ............................... .333
Lumbar Support ............................35
Maintenance Schedule .......................279
Malfunction Indicator Light (Check Engine) .....116,127
Manual, Service ............................409
Manual Transaxle Fluid Level Check ........................304
Manual Transmission ........................301
Fluid Level Check ........................301
Frequency Of Fluid Change .................301
Lubricant Selection .................301, 304, 342
Map/Reading Lights .........................50
Master Cylinder (Brakes) .....................299
Methanol ............................... .335
Mini-Trip Computer ........................ .109
Mirrors ..................................44
Automatic Dimming .......................44
Electric Powered ..........................46 Exterior Folding
..........................45
Heated .................................46
Outside ................................45
Rearview ...............................44
Vanity .................................46
Modifications/Alterations, Vehicle ................7
Monitor, Tire Pressure System ..................140
MOPAR Parts ............................ .409
New Vehicle Break-In Period ..................199
Occupant Restraints ........................ .147
Octane Rating, Gasoline (Fuel) .................335
Oil, Engine ........................288, 339, 340
Capacity ...............................339
Change Interval ........................ .288
Checking ............................. .286
Disposal ...............................289
Filter ............................. .289, 340
Filter Disposal .......................... .289
Identification

Logo.......................288
Materials Added To .......................289
Pressure Warning Light ....................114
Recommendation .....................288, 339
Synthetic ............................. .289
12
INDEX 419

Tire Service Kit........260, 261, 263, 264, 265, 266, 267
Tongue Weight/Trailer Weight .................229
Towing ................................. .224
24-Hour Towing Assistance .................382
Disabled Vehicle ........................ .274
Guide .................................228
Recreational ............................235
Weight ............................... .228
Towing Assistance ..........................382
Towing Vehicle Behind A Motorhome ............235
Traction Control .......................... .134
Trailer Towing ............................ .224
Cooling System Tips ..................... .234
Hitches ............................... .227
Minimum Requirements ....................229
Tips ................................. .233
Trailer And Tongue Weight ..................229
Wiring ............................... .232
Trailer Towing Guide ........................228
Trailer Weight ............................ .228
Transaxle Automatic ..............................21
Transmission Automatic ....................204, 205, 301, 302
Fluid .......................... .301, 302, 342Transmitter, Garage Door Opener (HomeLink)
.......78
Transporting Pets ..........................191
Tread Wear Indicators .......................316
Trip Computer ............................109
Turn Signals ........................49, 123, 247
UCI Connector ............................366
Uconnect Advanced Phone Connectivity ...............385
Phone Call Features .......................378
Phone Features ..........................381
Uconnect (Hands-Free Phone) ..................371
Uniform Tire Quality Grades ..................324
Universal Consumer Interface

(UCI) Connector .....366
Universal Transmitter ........................78
Untwisting Procedure, Seat Belt ................154
Vanity Mirrors .............................46
Variance, Compass ..........................108
Vehicle Identification Number (VIN) .............332
Vehicle Loading ........................222, 310
Vehicle Modifications/Alterations .................7
Vehicle Security Alarm (Security Alarm) ...........25
Vehicle Storage .............................66
424 INDEX
