2017 JEEP COMPASS remote control

REMOTE STARTING SYSTEM — IF EQUIPPED
This system uses the key fob to remote start the
engine conveniently from outside the vehicle,
while still maintaining security. The system has a
range of approximately 328 ft (100 m). Obstruc-
tions between the vehicle and key fob may reduce this
range.
NOTE:
• The vehicle must be equipped with an automatic trans-
mission to be equipped with Remote Start.
• Obstructions between the vehicle and the key fob may
reduce this range.
How To Use Remote Start
All of the following conditions must be met before the
engine will remote start:
•Gear selector in PARK
• Doors closed
• Hood closed •
Hazard switch off
• Brake switch inactive (brake pedal not pushed)
• Ignition key removed from ignition
• Battery at an acceptable charge level
• PANIC button not pushed
• System not disabled from previous remote start event
• Vehicle Security Alarm not active
WARNING!
•Do not start or run an engine in a closed garage or
confined area. Exhaust gas contains Carbon Monox-
ide (CO) which is odorless and colorless. Carbon
Monoxide is poisonous and can cause serious injury
or death when inhaled.
• Keep key fobs away from children. Operation of the
Remote Start System, windows, door locks or other
controls could cause serious injury or death.
3
GETTING TO KNOW YOUR VEHICLE 27

NOTE:
•FCA or your dealer may contact you directly regarding
software updates.
• To help further improve vehicle security and minimize
the potential risk of a security breach, vehicle owners
should:
• Routinely check www.driveuconnect.com/software-
update to learn about available Uconnect software
updates.
• Only connect and use trusted media devices (e.g.
personal mobile phones, USBs, CDs).
Privacy of any wireless and wired communications cannot
be assured. Third parties may unlawfully intercept infor-
mation and private communications without your consent.
For further information, refer to “Onboard Diagnostic
System (OBD II) Cybersecurity” in “Getting To Know Your
Instrument Panel”.
STEERING WHEEL AUDIO CONTROLS
The remote sound system controls are located on the rear
surface of the steering wheel. Reach behind the wheel to
access the switches. The right-hand control is a rocker-type switch with a
pushbutton in the center and controls the volume and
mode of the sound system. Pushing the top of the rocker
switch will increase the volume, and pushing the bottom of
the rocker switch will decrease the volume.
Pushing the center button will make the radio switch
between the various modes available (AM/FM/SAT/CD/
HDD/AUX/VES, etc.).
Remote Sound System Controls (Back View Of Steering
Wheel)
10
MULTIMEDIA 365

Dimmer Switch, Headlight.....................47
Dipsticks Power Steering ..........................215
Disposal Antifreeze (Engine Coolant) .................298
Door Locks Child-Protection Door Lock — Rear Doors .......32
Door Locks ..............................29
KeyFob................................29
Remote ................................29
Remote Keyless Entry ......................29
Door Locks, Automatic .......................30
Door Opener, Garage .........................78
Downshifting ............................ .204
Driver’s Seat Back Tilt ........................35
Driving ................................. .236
Off-Pavement .......................... .236
Off-Road ............................. .236
Electrical Power Outlets .......................89
Electric Remote Mirrors .......................46
Electronic Brake Control System ................131
Anti-Lock Brake System ....................130
Electronic Roll Mitigation ...................138
Traction Control System ....................134 Electronic Speed Control (Cruise Control)
.........216
Electronic Stability Control (ESC) ...............134
Electronic Throttle Control Warning Light .........115
Emergency, In Case Of Jacking ............................251, 305
Jump Starting .......................... .267
Towing ............................... .274
Emission Control System Maintenance ............127
Engine ...............................284, 285
Air Cleaner ............................ .291
Block Heater ............................199
Break-In Recommendations .................199
Checking Oil Level .......................286
Coolant (Antifreeze) ................287, 295, 340
Cooling ............................286, 294
Exhaust Gas Caution ...................191, 338
Jump Starting .......................... .267
Oil ............................288, 339, 340
Oil
Filler Cap .....................284, 285, 288
Oil Filter ...............................289
Oil Selection ............................288
Oil Synthetic ............................289
Overheating ............................270
Enhanced Accident Response Feature .........173, 276
Ethanol ................................. .335
12
INDEX 415

Radio FrequencyGeneral Information .....................21, 25
Radio Operation .......................... .401
Rear Axle (Differential) ..................... .304
Rear Camera ............................. .219
Rear Drive Assembly ........................304
Rear Liftgate (Sedan) .........................74
Rear Seat, Folding ...........................38
Rearview Mirrors ...........................44
Rear Wiper/Washer ..........................54
Recreational Towing ........................ .235
Reformulated Gasoline .......................335
Refrigerant ...............................290
Reminder, Seat Belt ........................ .149
Remote Control Security Alarm ...........................25
Remote Sound System (Radio) Controls ...........365
Remote Starting System .......................27
Replacement Bulbs ........................ .245
Replacement Keys ...........................24
Replacement Tires ..........................318
Reporting Safety Defects .....................409
Restraint, Head .............................40
Restraints, Child .......................... .174
Retractable Cargo Area Cover ...................75 Roll Over Warning
...........................4
Roof Type Carrier ...........................92
Rotation, Tires ............................ .324
Safety Checks Inside Vehicle ...................192
Safety Checks Outside Vehicle .................194
Safety Defects, Reporting .....................409
Safety, Exhaust Gas ........................ .191
Safety Information, Tire ..................... .305
Safety Tips ...............................191
Satellite Radio Antenna ..................... .361
Schedule, Maintenance .......................279
Seat Belt Adjustable Upper Shoulder Belt Anchorage ......154
Automatic Locking Retractor (ALR) ...........159
Energy Management Feature ................159
Lap/Shoulder Belt Operation...............

.152
Lap/Shoulder Belts .......................150
Lap/Shoulder Belt Untwisting ...............154
Pregnant Women ........................ .158
Seat Belt Extender ........................157
Seat Belt Pretensioner .....................159
Seat Belt Reminder .......................149
Seat Belt Maintenance .......................328
Seat Belt Reminder ........................ .149
12
INDEX 421

Seat Belts............................ .148, 192
Adjustable Shoulder Belt ...................154
Adjustable Upper Shoulder Anchorage .........154
Child Restraint ..........................174
Extender ...............................157
Front Seat .......................148, 150, 152
Inspection ............................. .192
Operating Instructions .....................152
Pregnant Women ........................ .158
Pretensioners .......................... .159
Rear Seat ............................. .150
Reminder ..............................111
Untwisting Procedure .....................154
Seats ................................. .34, 37
Adjustment .......................... .34, 37
Heated .................................37
Lumbar Support ..........................35
Rear Folding .............................38
Seatback Release ..........................35
Tilting .................................35
Security Alarm ..........................25, 113
Selection Of Coolant (Antifreeze) ...............340
Sentry Key (Immobilizer) ......................23
Sentry Key Programming ......................24
Sentry Key Replacement ......................24 Service Assistance
..........................406
Service Contract .......................... .408
Service Manuals .......................... .409
Settings, Personal ..........................105
Setting The Clock .......................345, 353
Shift Lever Override ........................271
Shift Speeds, Manual Transmission ..............203
Shoulder Belts ............................ .150
Signals, Turn .......................123, 194, 247
Snow Chains (Tire Chains) ....................323
Snow Tires ...............................320
Spare Tire ........................ .252, 320, 321
Spark Plugs ............................. .340
Speed Contr

ol
Accel/Decel ............................219
Cancel ............................... .217
Resume ...............................217
Speed Control (Cruise Control) .................216
Starting .................................197
Automatic Transmission ....................197
Cold Weather .......................... .198
Engine Fails To Start ..................... .198
Manual Transmission ..................... .197
Remote ................................27
Starting Procedures ........................ .197
422 INDEX

Steering..................................43
Power ............................... .215
Tilt Column .............................43
Steering Wheel Audio Controls .................365
Steering Wheel Mounted Sound System Controls . . . .365
Storage Bin ................................87
Storage, Vehicle .............................66
Stuck, Freeing ............................ .272
Sunroof Closing ................................71
Opening ................................70
Sun Roof .................................70
Sun Visor Extension .........................47
Supplemental Restraint System - Air Bag ..........165
Synthetic Engine Oil ........................289
System, Remote Starting ......................27
Temperature Control, Automatic (ATC) ............64
Tie Down Hooks, Cargo .......................77
Tilt Down .................................37
Up....................................37
Tilt Steering Column .........................43
Tire And Loading Information Placard ............309
Tire Markings ............................ .305Tires.........................
.194, 313, 320, 324
Aging (Life Of Tires) ..................... .317
Air Pressure ............................313
Chains ............................... .323
Changing .......................... .251, 305
Compact Spare ..........................320
General Information ...................313, 320
High Speed ............................ .315
Inflation Pressures ........................314
Jacking ............................251, 305
Life Of Tires ............................317
Load Capacity .......................309, 310
Pressure Monitor System (TPMS) .............140
Pressure Warning Light ....................117
Quality Grading ........................ .324
Radial ............................... .315
Replacement ............................318
Rotation ...............................324
Safety ............................ .305, 313
Snow T

ires............................ .320
Spare Tire .......................252, 320, 321
Spinning ...............................316
Trailer Towing .......................... .230
Tread Wear Indicators .....................316
Tire Safety Information .......................305
12
INDEX 423
