2Source selection indicator
Touch the left/right rear display icon to dis-
play the operation screen. The currently se-
lected source on the corresponding rear dis-
play can be operated from the screen.
3Speaker status indicator
Indicates which of the audio sources is se-
lected to be heard from the speaker. Touch
to show the Rear Sound Control screen and
change the speaker setting.
4Setting menu
Various settings can be changed. Touch a
preferred menu to change the setting.
Available setting items
– L Display Power key/R Display
Power
Touch to turn on or off the rear display on
the left/right side.
– Mute
Touch to mute or unmute all the speakers
and the headphones.
– Select Rear Source
Touch to display the Select Rear Source
screen. Select the “Left Screen” key or
the “Right Screen” key and then select a
source to be played on the screen. –
Rear Sound Control
Touch to display the Rear Sound Control
screen. Select a sound setting from the
following items:
● No rear sound — front only
● Play sound for left display
● Play sound for right display
– Source Control
Touch to display the operation screen for
the currently selected source. Touch the
“Left Screen” key or the “Right Screen”
key to select which of the rear displays
you wish to operate.
– Remote Controller Lock
Touch to lock or unlock the remote con-
troller operation.
When the ignition switch is placed in the
OFF or LOCK position, the remote con-
troller will be unlocked.
– Rr Speaker Mute
Touch to mute or unmute the rear speakers
–Auto Display Power ON
Touch to turn on or off the setting for
automatic power on setting. When this
item is turned on, both the left and right
rear displays will turn on automatically
when the DVD is inserted into the front
unit and the movie will start to play.
OPERATING TIPS
● The rear USB (rear media interface) and the
rear HDMI cannot be played on the front
screen.
● Devices connected to the USB connection
port for the front display cannot be played on
the rear displays.
● When connecting a device to the USB port
for the first time, the system structures the
file list and this could slow down the opera-
tion speed. This is not a malfunction.
●
The operation speed of the system could slow
down when the left and right displays play
different files from the same device connected
to the USB port. This is not a malfunction.
● Images from DVDs or devices connected to
the USB port may not be displayed in ad-
equate ratio depending on the resolution. To
correct the ratio, adjust the aspect using the
remote controller. For additional information,
refer to “System settings” in this section.
● If a computer with an HDMI output terminal
is connected to the HDMI input terminal, the
computer may not automatically shift to the
output mode. To view images on the rear
displays, operate the computer and change
the mode to the output mode according to
the computer Owner’s Manual.
Monitor, climate, audio, phone and voice recognition systems4-113

5 Starting and driving
Precautions when starting and driving................5-4
Exhaust gas (carbon monoxide) ..................5-4
Three-way catalyst ..............................5-4
Tire Pressure Monitoring System (TPMS) ..........5-5
On-pavement and off-road driving
precautions ....................................5-9
Avoiding collision and rollover . . ..................5-9
Off-road recovery ...............................5-9
Rapid air pressure loss ......................... 5-10
Drinking alcohol/drugs and driving ...............5-10
Driving safety precautions ......................5-11
Intelligent All-Wheel Drive (AWD) driving
safety precautions (if so equipped) ..............5-13
Push-button ignition switch ........................5-13
Operating range ............................... 5-14
Push-button ignition switch positions . . . .........5-15
Emergency hybrid system shut off ...............5-15
INFINITI Intelligent Key battery discharge .........5-16
INFINITI Vehicle Immobilizer System .............5-16
Before starting the INFINITI Direct Response
Hybrid System ................................... 5-17
Starting the INFINITI Direct Response Hybrid
System .......................................... 5-17
Remote hybrid start (if so equipped) .............5-17Driving the vehicle
................................ 5-18
Continuously Variable Transmission (CVT) ........5-18
Parking brake .................................... 5-23
INFINITI Drive Mode Selector ......................5-23
Standard mode ................................ 5-24
Sport mode ................................... 5-24
Snow mode ................................... 5-24
ECO mode ................................... 5-24
Lane Departure Warning (LDW) (if so equipped) .....5-26
LDW system operation ......................... 5-27
How to enable/disable the LDW system .........5-28
LDW system limitations ........................ 5-29
System temporarily unavailable ..................5-30
System maintenance ........................... 5-30
Lane Departure Prevention (LDP) (if so equipped) ....5-31
LDP

system operation .......................... 5-32
How to enable/disable the LDP system ..........5-33
LDP system limitations ......................... 5-34
System temporarily unavailable ..................5-35
System maintenance ........................... 5-36
Blind Spot Warning (BSW) (if so equipped) .........5-37
BSW system operation ........................ 5-38
How to enable/disable the BSW system .........5-39

●Make sure the area around the vehicle is
clear.
● Check fluid levels such as engine oil, cool-
ant, brake fluid, and windshield-washer fluid
as frequently as possible, or at least when-
ever you refuel.
● Check that all windows and lights are clean.
● Visually inspect tires for their appearance
and condition. Also check tires for proper
inflation.
● Check that all doors are closed.
● Position seat and adjust head
restraints/headrests.
● Adjust inside and outside mirrors.
● Fasten seat belts and ask all passengers to
do likewise.
● Check the operation of warning lights when
the ignition switch is placed in the ON posi-
tion. For additional information, refer to
“Warning lights, indicator lights and audible
reminders” in the “Instruments and controls”
section of this manual. 1. Apply the parking brake.
2. Move the shift lever to P (Park) or N (Neu-
tral) . P (Park) is recommended.
The INFINITI Direct Response Hybrid
System is designed not to operate if
the shift lever is in any of the driving
positions.
3. Depress the brake pedal and push the igni- tion switch to start the hybrid system. The
READY to drive indicator will illuminate on
the meter.
When starting the hybrid system at
very low outside temperatures, the
READY to drive indicator light will flash
and it may take longer for the READY
to drive indicator light to illuminate.
When the READY to drive indicator
light is flashing, it cannot be shifted
out of P (Park) .
NOTE:
Do not start the vehicle in the N (Neutral)
position (cold conditions only) . ● The hybrid system may not start even with
the READY to drive indicator light illumi-
nated. Once the READY to drive indicator
light is illuminated you may begin driving the
vehicle. NOTE:
Care should be taken to avoid situations
that can lead to potential 12-volt battery
discharge and potential no-start conditions
such as:
1. Installation or extended use of elec-
tronic accessories that consume bat-
tery power when the engine is not run-
ning (Phone chargers, GPS, DVD
players, etc.) .
2. Vehicle is not driven regularly and/or
only driven short distances.
In these cases, the battery may need to be
charged to maintain 12-volt battery health.
REMOTE HYBRID START (if so
equipped)
Vehicles started with the remote hybrid start re-
quire the ignition switch to be placed in the ON
position before the shift lever can be moved from
the P (Park) position. To place the ignition switch
to the ON position, follow the steps: 1. Make sure that the Intelligent Key is on you.
2. Apply the brake.
3. Press the ignition switch once to the ON position.
BEFORE STARTING THE INFINITI
DIRECT RESPONSE HYBRID SYSTEM STARTING THE INFINITI DIRECT
RESPONSE HYBRID SYSTEM
Starting and driving5-17

1. Locate the fusible link box behind the engineair cleaner.
2. Push the tab in and lift up
Ato remove the
lid and expose the remote positive battery
terminal
B.
3. If the booster battery is in another vehicle position the two vehicles to bring their bat-
teries near each other.
Do not allow the two vehicles to touch.
4. Apply the parking brake. Move the shift lever to P (Park) . Switch off all unnecessary elec-
trical systems (lights, heater, air conditioner,
etc.) . 5. Ensure the vent caps are level and tight.
6. Connect jumper cables in the sequence il-
lustrated (
B,C,D,E).
CAUTION
●Always connect positive () to positive
() and negative () to body ground (for
example, strut mounting bolt, engine
lift bracket, etc.) — not to the battery.
● Make sure the jumper cables do not
touch moving parts in the engine com-
partment and that the cable clamps do
not contact any other metal. ●
Do not keep the starter motor engaged
for more than 10 seconds. If the engine
does not start right away, place the ig-
nition switch in the OFF position and
wait 10 seconds.
7. Start the engine of the booster vehicle and let it run for a few minutes.
8. Hold down the brake pedal and press the START button. The vehicle instruments and
gauges will light up, and the green READY
light will come on.
CAUTION
If the green READY light does not come
on, press the START button to turn the
hybrid system OFF. Carefully disconnect
the negative cable then the positive cable.
Have vehicle taken to dealership for
repair.
9. After the green READY light in the meter display comes on, carefully disconnect the
negative cable and then the positive cable.LCE2170
In case of emergency6-13

In-cabin microfilter................8-16
Increasing fuel economy ............5-130
Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders)...............2-7,2-8,2-13
INFINITI Drive mode selector ..........5-24
INFINITI Intelligent Key System .......3-2,3-7
INFINITI vehicle immobilizer
system................2-34,3-4,5-16
Informationdisplay............2-16,2-17
Inside automatic anti-glare mirror ........3-33
Instrument brightness control ..........2-45
Instrument panel ...............0-6,2-2
Instrument panel dimmer switch ........2-45
Intelligent cruise control (ICC) system Brake assist .................5-77
Intelligent Key system Key operating range ..............3-8
Key operation ................3-10
Mechanicalkey ................3-3
Remote keyless entry operation.......3-13
Troubleshooting guide ............3-17
Warning signals ...............3-17
Interiorlight....................2-70
Inverter Checking inverter coolant level ........8-6
Inverter cooling system ............8-6
iPod®Player ...............4-64,4-83
ISOFIX child restraints .............1-29
J
Jump starting ...............6-11,8-14 K
Key.........................3-2
Keyfobbatteryreplacement ..........8-21
Keyless entry With Intelligent Key system
(See Intelligent Key system) .........3-13
L
Label Tire and Loading Information label ....10-13
Labels Air conditioner specification label .....10-13
C.M.V.S.S. certification label .......10-12
Emission control information label ....10-12
Engine serial number ............10-12
F.M.V.S.S. certification label ........10-12
Tire and Loading Information label ....10-13
Vehicle identification number (VIN) ....10-11
Vehicle identification number (VIN) plate .10-11
Warning labels (for SRS) ..........1-66
Lane Departure Prevention (LDP)
system ...............5-26,5-31,5-34
Lane Departure Warning (LDW)
system ...............5-26,5-31,5-34
Language setting ................4-17
LATCH (Lower Anchors and Tethers for CHildren)
System ......................1-29
License plate Installing the license plate .........10-13
Liftgate ......................3-22
Liftgate release ..................3-27 Light
Air bag warning light .........1-67,2-13
Brake light (See stop light) .........8-24
Bulb check/instrument panel .........2-8
Bulbreplacement..............8-24
Charge warning light .............2-8
Exterior and Interior lights ..........8-24
Foglights...................8-23
Fog light switch ...............2-46
Headlightandturnsignalswitch......2-40
Headlight control switch ..........2-40
Headlights..................8-23
Interiorlight..................2-70
Lightbulbs..................8-23
Low tire pressure warning light .......2-10
Low windshield-washer fluid warning
light......................2-29
Passenger air bag and status light .....1-58
Personal lights ................2-71
Security

indicator light ............2-15
Warning/indicator lights and audible
reminders .............2-7,2-8,2-13
Lights.......................8-23 Maplights ..................2-71
Lock Child safety rear door lock ..........3-6
Gloveboxlock................2-57
Liftgate release ................3-27
Power door locks ............3-5,3-6
Loose fuel cap warning .............2-29
Low fuel warning light ........2-9,2-12,2-29
Low tire pressure warning light .........2-10
Low windshield-washer fluid warning light . . .2-29
Luggage hook ..................2-61
Luggage rack (see roof rack) ..........2-62
Luggage (See vehicle loading information) . .10-14
11-4

RecordersEventData .................10-32
Refrigerant recommendation ..........10-8
Regenerative brake .............. HEV-10
Registering a vehicle in another country . . .10-11
Remote controller (See INFINITI mobile
entertainment system) .............4-104
Remote Start ...............3-19,5-17
Reporting safety defects (US only) ......10-31
Road accident cautions ............HEV-3
Roof rack .....................2-62
S
Safety Child safety rear door lock ..........3-6
Childseatbelts.....1-28,1-34,1-40,1-46
Reporting safety defects (US only) ....10-31
Seat adjustment Front power seat adjustment .........1-3
Second row bench seats ........1-5,1-8
Seatback pockets ................2-56
Seat belt Childsafety..................1-25
Infantsandsmallchildren..........1-25
Injured Person ................1-19
Largerchildren................1-26
Precautionsonseatbeltusage.......1-16
Pregnant women ...............1-19
Seat belt extenders .............1-24
Seat belt maintenance ............1-24
Seat belts ................1-16,7-6
Three-point type with retractor .......1-20
Seat belt extenders ...............1-24
Seatbeltwarninglight..........1-19,2-12 Seats
2nd row bench seat adjustment ....1-5,1-8
Adjustment...................1-2
Armrests ....................1-8
Automatic drive positioner ......3-36,3-38
Frontseats...................1-2
Heatedseats.............2-47,2-48
Seats/floor mats ..................7-5
Security indicator light ..............2-15
Security system (INFINITI vehicle immobilizer system) ,
enginestart ...........2-34,3-4,5-16
Security systems Vehicle security system ...........2-33
Self-adjusting brakes ..............8-18
Service manual order form ...........10-33
Servicing air conditioner .............4-58
Setting button ...................4-5
Sparkplugreplacement.............8-15
Sparkplugs ...................8-15
Specifications ..................10-9
Speedometer ...................2-5
SRSwarninglabel................1-66
Stability control .................5-136
Standard maintenance ..............9-8
Starting Before starting the engine ..........5-17
Jump starting .............6-11,8-14
Precautions when starting and driving ....5-4
Push starting .................6-14
Starting the engine .............5-17
Starting the engine ...............5-17
Steering Heated steering wheel ...........2-50
Power steering fluid .............8-11
Power steering system ...........5-134 Steering wheel
..................3-31
Steering
wheel audio control switch . . .4-7, 4-72
Stoplight.....................8-24
Storage......................2-56
Storagebin....................2-61
Storage tray ...................2-57
Sunglasses case .................2-58
Sunglasses holder ................2-58
Sunroof.......................7-5
Sunroof(seeMoonroof).............2-66
Sun visors ....................3-32
Supplemental air bag warning labels ......1-66
Supplemental air bag warning light . . .1-67, 2-13
Supplemental front impact air bag system . . .1-56
Supplemental restraint system Information and warning labels .......1-66
Precautions on supplemental restraint
system ....................1-49
Supplemental restraint system
(Supplemental air bag system) .........1-49
Switch Autolightswitch...............2-41
Automatic power window switch ......2-65
Fog light switch ...............2-46
Hazard warning flasher switch ........6-2
Headlightandturnsignalswitch......2-40
Headlight control switch ..........2-40
Instrument brightness control ........2-45
Power door lock switch .........3-5,3-6
Power inverter switch ............2-52
Rearwindowdefrosterswitch .......2-39
Rear window wiper and washer
switches ...................2-38
Steering wheel switch for audio
control/Bluetooth® Hands-Free Phone
System ....................4-72
11-6
