2017 INFINITI Q60 COUPE Owner's Manual

2017 Infiniti Q60 Owner’s Manual and
Maintenance Information
Printing: June 2016 (01) / OM17E0 CV37U0 / Printed in U.S.A.
For your safety, read carefully and keep in this vehicle.2017 Infiniti Q60

Owner’s Manual Supplement
The information contained within this supplement updates the information in the
2017 INFINITI Q60 Owner’s Manual:
●Repairing a Flatinformation in the “In case of emergency” section of this
manual.
●Checking Tire Pressures and Tire Chains information in the “Do-it-yourself”
section of this manual.
●WHEELS AND TIRES information in the “Technical and consumers informa-
tion” section of this manual.
Read carefully and keep in vehicle
Printing: July 2016 (01)
Publication No. SU17E0 CV37U0

WARNING
●After using Emergency Tire Sealant to
repair a minor tire puncture, do not
drive the vehicle at speeds faster than
50 MPH (80 km/h).
● Immediately after using the Emergency
Tire Sealant to repair a minor tire punc-
ture, take your vehicle to inspect, and
repair or replace the tire. It is recom-
mended you visit an INFINITI retailer for
this service. The Emergency Tire Seal-
ant cannot permanently seal a punc-
tured tire. Continuing operation of the
vehicle without a permanent tire repair
can lead to a crash.
● INFINITI recommends using only Genu-
ine NISSAN Emergency Tire Sealant
provided with your vehicle. Other tire
sealants may damage the valve stem
seal which can cause the tire to lose air
pressure. It is recommended you visit
an INFINITI retailer as soon as possible
after using tire repair sealant.
This vehicle does not have a spare tire. The
emergency tire puncture repair kit (Emergency
Tire Sealant) is supplied with the vehicle instead
of a spare tire. It can be used to temporarily repair
minor tire punctures. If you have a flat tire, follow the instructions be-
low.
CAUTION
●
To avoid the emergency tire puncture
repair kit being damaged during stor-
age or use:
– Only use the emergency tire puncture repair kit on your vehicle. Do not use
it on other vehicles.
– Only use the kit to inflate the tires of your vehicle and to check the vehi-
cle’s tire pressure.
– Only plug the compressor into a 12V DC car power point.
– Keep the kit free of water and dirt.
– Do not disassemble or modify the kit.
– Do not drop the kit or allow hard impacts to the kit.
● Do not use the emergency tire puncture
repair kit under the following condi-
tions. It is recommended you visit an
INFINITI retailer or professional road
assistance. – when the sealant has passed its ex-
piration date (shown on the label at-
tached to the bottle)
– when the cut or the puncture is ap- proximately 0.25 in (6 mm) or longer
– when the tire sidewall is damaged
– when the vehicle has been driven with extremely low tire pressure
– when the tire has come off the inside or the outside of the wheel.
– when the tire wheel is damaged
– when two or more tires are flat
STOPPING THE VEHICLE
1. Safely move the vehicle off the road and away from traffic.
2. Turn on the hazard warning flashers.
3. Park on a level surface and apply the parking brake.
4. Move the shift lever to the P (Park) position.
5. Turn off the engine.
6. Raise the hood to warn other traffic and to signal professional road assistance person-
nel that you need assistance.
REPAIRING FLAT TIRE (for models
with emergency tire puncture repair
kit)

7. Have all passengers get out of the vehicleand stand in a safe place, away from traffic
and clear of the vehicle.
WARNING
●Make sure the parking brake is securely
applied and the transmission is shifted
into P (Park) .
● Never repair tires when the vehicle is on
a slope, ice or slippery areas. This is
hazardous.
● Never repair tires if oncoming traffic is
close to your vehicle. Wait for profes-
sional road assistance.
GETTING EMERGENCY TIRE
PUNCTURE REPAIR KIT
Take out the emergency tire puncture repair kit
located in the trunk. Remove the clips
1to open
the trunk trim as illustrated.
The repair kit consists of the following items:
● Tire sealant bottle
● Air compressor
● Speed restriction sticker
BEFORE USING EMERGENCY TIRE
PUNCTURE REPAIR KIT
●If any foreign object (for example, a screw or
nail) is embedded in the tire, do not remove
it.
● Check the expiration date of the sealant
(shown on the label attached to the bottle) .
Never use a sealant whose expiration date
has passed.
REPAIRING TIRE
WARNING
Observe the following precautions when
using the tire repair compound.
●Swallowing the compound is danger-
ous. Immediately drink as much water
as possible and seek prompt medical
assistance.
● Rinse well with lots of water if the com-
pound comes into contact with skin or
eyes. If irritation persists, seek prompt
medical attention.
● Keep the repair compound out of the
reach of children.
JVM0722X

NOTE:
Do not remove any nails or screws that
have penetrated the tire when performing
repairs.1. Take out the speed restriction sticker fromthe air compressor*, then put it in a location
where the driver can see it while driving.
*: The compressor shape may differ depending
on the models.
CAUTION
Do not put the speed restriction label on
the steering wheel pad, the speedometer
or the warning light locations. 2. Take the hose1and the power plug2out
of the air compressor. Remove the cap of the
bottle holder from the air compressor.
JVE0014X
SCE0868

3. Remove the cap from the tire sealant bottle,and screw the bottle clockwise onto the
bottle holder. (Leave the bottle seal intact.
Screwing the bottle onto the bottle holder
will pierce the seal of the bottle.)
4. Remove the cap from the tire valve on the flat tire. 5. Remove the protective capAof the hose
and screw the hose securely onto the tire
valve. Make sure that the pressure release
valve
Bis securely tightened. Make sure
that the air compressor switch is in the OFF
(O) position, and then insert its power plug
into the power outlet in the vehicle. 6. Push the ignition switch to the “ACC” posi-
tion. Then turn the compressor switch to the
ON () position and inflate the tire up to the
pressure that is specified on the tire and
loading information label affixed to the driv-
er’s side pillar if possible, or to the minimum
of 26 psi (180 kPa) . Turn the air compressor
off briefly in order to check the tire pressure
with the pressure gauge.
If the tire is inflated to higher than the specified
pressure, lower the tire pressure by releasing air
with the pressure release valve.
SCE0869SCE0870SCE0871

NOTE:
The compressor tire pressure gauge may
show a pressure reading of 87 psi (600 kPa)
for about 30 seconds while inflating the
tire. The pressure gauge is indicating the
pressure inside the sealant can. When the
sealant has been injected into the tire the
pressure gauge will drop and indicate ac-
tual tire pressure.
WARNING
●To avoid serious personal injury while
using the emergency tire puncture re-
pair kit:
– Securely tighten the compressor hose to the tire valve. Failure to do so
can cause the sealant to spray into
the air and get into your eyes or on
the skin.
● Do not stand directly beside the dam-
aged tire while it is being inflated be-
cause of the risk of the rupture. If there
are any cracks or bumps, turn the com-
pressor off immediately. If the tire pressure does not increase to
26 psi
(180 kPa) within 10 minutes, the tire may be
seriously damaged and the tire cannot be re-
paired with this tire puncture repair kit. It is
recommended you visit an INFINITI retailer for
servicing.
7. When the tire pressure is at the specified amount, turn the air compressor off. If the
pressure cannot be inflated to the specified
amount, the air compressor can be turned
off at the minimum of 26 psi (180 kPa) .
Remove the power plug from the power
outlet and quickly remove the hose from the
tire valve. Attach the protective cap and
valve cap. Properly stow the emergency tire
puncture repair kit in the trunk.
CAUTION
To avoid serious personal injury when
stowing the emergency tire puncture re-
pair kit:
●Keep the sealant bottle screwed into
the compressor. Failure to do so can
cause the sealant to spray into the air
and get into your eyes or on the skin. 8. Immediately drive the vehicle for 10 minutes
or 2 miles (3 km) at a speed of 50 MPH
(80 km/h) or less.
9. After driving, make sure that the air com- pressor switch is in the OFF (O) position,
then screw the hose securely onto the tire
valve. Check the tire pressure with the pres-
sure gauge. The temporary repair is com-
pleted if the tire pressure does not drop.
Make sure the pressure is adjusted to the
pressure that is specified on the tire and
loading information label before driving.
10. If the tire pressure drops, repeat the steps from 5 to 9. If the pressure drops again or
under 19 psi (130 kPa) , the tire cannot be
repaired with this tire puncture repair
kit. It is recommended you visit an INFINITI
retailer for this servicing.
The sealant bottle and hose cannot be re-
used to repair another punctured tire. It is
recommended you visit an INFINITI retailer
to purchase replacements.

AFTER REPAIRING TIRE
It is recommended you visit an INFINITI retailer for
tire repair/replacement as soon as possible.
WARNING
●After using Emergency Tire Sealant to
repair a minor tire puncture, do not
drive the vehicle at speeds faster than
50 MPH (80 km/h).
● Immediately after using Emergency Tire
Sealant to repair a minor tire puncture,
take your vehicle to inspect, and repair
or replace the tire. It is recommended
you visit an INFINITI retailer for this
service. The Emergency Tire Sealant
cannot permanently seal a punctured
tire. Continuing operation of the vehicle
without a permanent tire repair can lead
to a crash.
● INFINITI recommends using only Genu-
ine NISSAN Emergency Tire Sealant
provided with your vehicle. Other tire
sealants may damage the valve stem
seal which can cause the tire to lose air
pressure. It is recommended you visit
an INFINITI retailer as soon as possible
after using tire repair sealant. 1. Remove the valve stem cap from the tire.
2. Press the pressure gauge squarely onto the
valve stem. Do not press too hard or force
the valve stem sideways, or air will escape. If
the hissing sound of air escaping from the
tire is heard while checking the pressure,
reposition the gauge to eliminate this leak-
age.
3. Remove the gauge.
4. Read the tire pressure on the gauge stem and compare it to the specification shown
on the Tire and Loading Information label. 5. Add air to the tire as needed. If too much air
is added, press the core of the valve stem
briefly with the tip of the gauge stem to
release pressure. Recheck the pressure and
add or release air as needed.
6. Install the valve stem cap.
7. Check the pressure of all other tires, includ- ing the spare.
SIZE COLD
TIRE IN-
FLATION PRES-SURE
FRONT
ORIGINAL TIRE P255/
40RF19
96V
240 kPa,
35 PSI
245/
40RF19
94W 240 kPa,
35 PSI
P245/
40RF19
94V 240 kPa,
35 PSI
LDI0393
CHECKING TIRE PRESSURE
