Seat Belt Maintenance
Do not bleach, dye or clean the belts with chemical
solvents or abrasive cleaners. This will weaken the
fabric. Sun damage can also weaken the fabric.
If the belts need cleaning, use a mild soap solution or
lukewarm water. Do not remove the belts from the
vehicle to wash them. Dry with a soft cloth.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
NOTE:If the belts retract slowly, inspect the upper
turning loop for soiling. If soiling is present, clean with
a wet soft cloth until all residue is removed.
WARNING!
A frayed or torn belt could rip apart in a collision
and leave you with no protection. Inspect the belt
system periodically, checking for cuts, frays, or
loose parts. Damaged parts must be replaced imme-
diately. Do not disassemble or modify the system.
Seat belt assemblies must be replaced after a colli-
sion if they have been damaged (i.e., bent retractor,
torn webbing, etc.).
FUSES
WARNING!
• When replacing a blown fuse, always use an
appropriate replacement fuse with the same amp
rating as the original fuse. Never replace a fuse
with another fuse of higher amp rating. Never
replace a blown fuse with metal wires or any
other material. Failure to use proper fuses may
result in serious personal injury, fire and/or prop-
erty damage.
• Before replacing a fuse, make sure that the igni-
tion is off and that all the other services are
switched off and/or disengaged.
• If the replaced fuse blows again, contact an au-
thorized dealer.
• If a general protection fuse for safety systems (air
bag system, braking system), power unit systems
(engine system, gearbox system) or steering sys-
tem blows, contact an authorized dealer.
7
MAINTAINING YOUR VEHICLE 327

Underhood Fuses
The Front Distribution Unit is located on the right side
of the engine compartment, next to the battery. To
access the fuses, push the release tabs and remove the
cover.The ID number of the electrical component correspond-
ing to each fuse can be found on the back of the cover.
Cavity
Maxi Fuse Mini Fuse Description
F01 70 Amp Tan –Body Controller
F02 60 Amp Blue –Body Controller Rear Distribution Unit
F03 20 Amp Yellow –Ignition Switch
F04 40 Amp Orange –Anti-Lock Brake Pump
F05 70 Amp Tan –Electric Power Steering
Front Distribution Unit
328 MAINTAINING YOUR VEHICLE

CavityMaxi Fuse Mini Fuse Description
F06 30 Amp Green –Radiator Fan - Low Speed
F07 50 Amp Red –Radiator Fan - High Speed
F08 40 Amp Orange –Blower Motor
F09 – –Not Used
F09 –5 Amp Tan Transmission (Aisin)
F10 –15 Amp Blue Horn
F11 –10 Amp Red Powertrain
F14 –20 Amp Yellow Power Outlet 115V
F15 – –Not Used
F15 –10 Amp Red Transmission (Aisin)
F16 –7.5 Amp Brown Transmission Powertrain
F17 –10 Amp Red Powertrain
F18 –5 Amp Tan Powertrain (Multiair – If Equipped)
F19 –7.5 Amp Brown Air Conditioning
F20 –30 Amp Green Rear Defroster
F21 –15 Amp Blue Fuel Pump
F22 –20 Amp Yellow Powertrain
F23 –20 Amp Yellow Anti-Lock Brake Valves
F30 –5 Amp Tan After Run Pump
F81 70 Amp Tan –PTC (Secondary)
7
MAINTAINING YOUR VEHICLE 329

CavityMaxi Fuse Mini Fuse Description
F82 40 Amp Orange –Transmission
F83 40 Amp Orange –PTC (Primary)
F84 –7.5 Amp Brown Transmission
F85 –15 Amp Blue Front Power Outlet 12V
F88 –7.5 Amp Brown Heated Mirrors
Interior Fuses
The interior fuse panel is part of the Body Control
Module (BCM) and is located on the driver’s side under
the instrument panel.
Interior Fuse Panel
330 MAINTAINING YOUR VEHICLE

Cavity Vehicle Fuse Number Mini FuseDescription
1 F127.5 Amp Brown Right Low Beam
2 F327.5 Amp Brown Front and Rear Ceiling Lights Trunk and
Door Courtesy Lights
3 F537.5 Amp Brown Instrument Panel Node
Fuse Panel Cavity Locations
7
MAINTAINING YOUR VEHICLE 331

Cavity Vehicle Fuse Number Mini FuseDescription
4 F3820 Amp Yellow Central Door Locking
5 F3615 Amp Blue Diagnostic Socket, Vehicle Radio, Climate
Control System, TPMS, Sunroof
6 F907.5 Amp Brown Left High Beam
7 F917.5 Amp Brown Right High Beam
8 F927.5 Amp Brown Left Fog Light
9 F937.5 Amp Brown Right Fog Light
10 F425 Amp Tan BSM, ESP
11 F3320 Amp Yellow Rear Left Passenger Window
12 F3420 Amp Yellow Rear Right Passenger Window
13 F4320 Amp Yellow Bi-Directional Washer
14 F4820 Amp Yellow Passenger Power Window
15 F137.5 Amp Brown Left Low Beam, Headlamp Leveling
16 F507.5 Amp Brown Airbag
17 F515 Amp Tan Vehicle Radio Switch, Climate Control Sys-
tem, Stop Light, Reverse Gear, Sunroof,
Parking Sensor, Rear Camera
18 F377.5 Amp Brown Stop Light Switch, Instrument Panel Node
19 F495 Amp Tan Exterior Mirror, GPS, Electric Mirror, Park-
ing Sensor
332 MAINTAINING YOUR VEHICLE

Cavity Vehicle Fuse Number Mini FuseDescription
20 F315 Amp Tan Climate Control, Seat Regulation
21 F4720 Amp Yellow Driver Power Window
Rear Interior Fuses
The rear interior fuse panel is located on the driver’s
side in the rear compartment.
CavityVehicle Fuse Num-
ber Mini Fuse
Description
1 F6115 Amp Blue Lumbar Regulation Seats
2 F6215 Amp Blue Heated Seats
3 F6420 Amp Yellow Hi Fi System
4 F6520 Amp Yellow Sun Blind
5 F6620 Amp Yellow Sunroof
Rear Fuse Panel
7
MAINTAINING YOUR VEHICLE 333

VEHICLE STORAGE
If you will not be using your vehicle for more than 21
days, you may want to take steps to preserve your
battery.
•Disconnect the negative cable from the battery.
• Anytime you store your vehicle, or keep it out of
service (i.e., vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will ensure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
NOTE: When the vehicle has not been started or driven
for at least 30 days, an Extended Park Start Procedure is
required to start the vehicle. Refer to “Starting Proce-
dures” in “Starting And Operating” for further infor-
mation.
REPLACEMENT BULBS
Interior Bulbs
Bulb Number
Overhead Lamp C5W
Sun Visors C5W
Courtesy Lamp W5W
Glove Compartment C5W
Rear Courtesy Lamp C5W
