5. Install the A/C air filter with the air filter positionindicators pointing in the same direction as removal.
CAUTION!
The cabin air filter is identified with an arrow to
indicate airflow direction through the filter. Failure
to properly install the filter will result in the need
to replace it more often.
6. Install the passenger side console closeout.
Refer to the “Maintenance Schedule” for the proper
maintenance intervals.
Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, door hinge pivot points and rollers, liftgate,
tailgate, decklid, sliding doors and hood hinges, should
be lubricated periodically with a lithium based grease,
such as MOPAR Spray White Lube to assure quiet, easy
operation and to protect against rust and wear. Prior to
the application of any lubricant, the parts concerned
should be wiped clean to remove dust and grit; after
lubricating excess oil and grease should be removed.
Particular attention should also be given to hood latch-
ing components to ensure proper function. When per-
forming other underhood services, the hood latch,
release mechanism and safety catch should be cleaned
and lubricated.
The external lock cylinders should be lubricated twice a
year, preferably in the Fall and Spring. Apply a small
amount of a high quality lubricant, such as MOPAR
Lock Cylinder Lubricant directly into the lock cylinder.
Wiper Blades
Clean the rubber edges of the wiper blades and the
windshield and rear window periodically with a
sponge or soft cloth and a mild nonabrasive cleaner.
A/C Air Filter7
MAINTAINING YOUR VEHICLE 291

MAINTENANCE SCHEDULE
Your vehicle is equipped with an automatic oil change
indicator system. The oil change indicator system will
remind you that it is time to take your vehicle in for
scheduled maintenance.
Based on engine operation conditions, the oil change
indicator message will illuminate. This means that
service is required for your vehicle. Operating condi-
tions such as frequent short-trips, trailer tow, extremely
hot or cold ambient temperatures, and E85 fuel usage
will influence when the “Change Oil” or “Oil Change
Required” message is displayed. Severe Operating Con-
ditions can cause the change oil message to illuminate
as early as 3,500 miles (5,600 km) since last reset. Have
your vehicle serviced as soon as possible, within the
next 500 miles (805 km).
Your authorized dealer will reset the oil change indica-
tor message after completing the scheduled oil change.
If a scheduled oil change is performed by someone
other than your authorized dealer, the message can be
reset by referring to the steps described under “Instru-
ment Cluster Display” in “Understanding Your Instru-
ment Panel” for further information.NOTE:
Under no circumstances should oil change
intervals exceed 10,000 miles (16,000 km), twelve
months or 350 hours of engine run time, whichever
comes first. The 350 hours of engine run or idle time is
generally only a concern for fleet customers.
Severe Duty All Models
Change Engine Oil at 4,000 miles (6,500 km) if the
vehicle is operated in a dusty and off road environment
or is operated predominantly at idle or only very low
engine RPM’s. This type of vehicle use is considered
Severe Duty.
Once A Month Or Before A Long Trip:
Check engine oil level.
Check windshield washer fluid level.
Check the tire inflation pressures and look for unusual
wear or damage.
Check the fluid levels of the coolant reservoir and brake
master cylinder, and fill as needed.
Check function of all interior and exterior lights.
324 MAINTENANCE SCHEDULES

Instrument Panel Cover..................... .308
Instrument Panel Lens Cleaning ................308
Interior Appearance Care .....................306
Interior Lighting ............................85
Introduction ................................4
Jacking Instructions ........................ .261
Jack Location ............................ .258
Jack Operation ........................ .258, 261
Jump Starting ............................ .268
Key Fob Disarm The Alarm ........................12
Key Fob Battery Service (Remote Keyless Entry) .....15
Key-In Reminder ............................10
Key, Replacement ...........................11
Keys .....................................9
Key, Sentry (Immobilizer) ......................11
Lane Change Assist ..........................84
Lap/Shoulder Belts ..........................24
Latches ..................................63
Hood ..................................81
Lead Free Gasoline ........................ .239
Leaks, Fluid ...............................63 Life Of Tires
............................. .227
Liftgate (Sedan) .............................20
Light Bulbs ........................... .63, 316
Lights ............................. .63, 82, 83
AirBag ............................ .61, 118
Brake Assist Warning ..................... .209
Brake Warning ..........................119
Bulb Replacement ....................... .317
Cruise ............................ .136, 137
Engine Temperature Warning ................123
Exterior ................................63
Fog ................................. .131
High Beam ..............................83
Malfunction Indicator (Check Engine) ..........130
Park .............................. .83, 136
Passing ................................83
Seat Belt Reminder .......................118
Service ............................... .317
Tire Pressure Monitoring (TPMS) .............126
Traction Control ........................ .209
T

urn Signal ....................... .63, 84, 135
Warning (Instrument Cluster Description) . . . .123, 135
Loading Vehicle Tires................................. .215
10
INDEX 341

LocksAutomatic Door ..........................19
Door ..................................17
Power Door .............................18
Lubrication, Body ......................... .291
Lug Nuts ............................... .256
Maintenance Free Battery .....................287
Maintenance, General ...................... .283
Maintenance Procedures ..................... .283
Maintenance Schedule ...................... .324
Maintenance Schedules ..................... .324
Malfunction Indicator Light (Check Engine) . . . .130, 281
Manual, Service ........................... .333
Manual Transmission ....................186, 302
Fluid Level Check ....................... .302
Frequency Of Fluid Change .................302
Lubricant Selection ....................302, 322
Master Cylinder (Brakes) .....................300
Methanol ............................... .239
Mirrors ..................................71
Automatic Dimming .......................71
Electric Powered ..........................72
Heated .................................73
Modifications/Alterations, Vehicle ................6Monitor, Tire Pressure System
..................232
MTBE/ETBE ............................. .239
Multi-Function Control Lever ...................83
New Vehicle Break-In Period ...................59
Occupant Restraints .........................21
Oil, Engine ....................... .283, 320, 321
Capacity .......................... .320, 321
Change Interval ........................ .284
Checking ............................. .283
Disposal .............................. .286
Filter ................................ .286
Filter Disposal .......................... .286
Identification Logo ...................... .285
Materials Added To ...................... .285
Pressure Warning Light ....................123
Recommendation .....................284,

320
Synthetic ............................. .285
Viscosity .............................. .285
Oil Filter, Change ......................... .286
Oil Filter, Selection ......................... .286
Oil Pressure Light ......................... .123
Onboard Diagnostic System ...................280
Operating Precautions ...................... .280
342 INDEX

SteeringPower ............................... .199
Tilt Column .............................89
Wheel, Tilt ..............................89
Steering Wheel Audio Controls .................165
Steering Wheel Mounted Sound System Controls . . . .165
Storage ................................. .315
Storage, Vehicle ........................... .178
Stuck, Freeing ............................ .271
Sun Roof .................................98
Supplemental Restraint System - Air Bag ...........32
Synthetic Engine Oil ....................... .285
Temperature Control, Automatic (ATC) ...........177
Tilt Steering Column .........................89
Tire And Loading Information Placard ........215, 216
Tire Markings ............................ .210
Tires ...................... .63, 219, 223, 224, 231
Aging (Life Of Tires) ..................... .227
Air Pressure ........................... .219
Chains ............................... .229
Changing ............................. .258
Compact Spare ......................... .224
General Information ................219, 223, 224
High Speed ............................ .221Inflation Pressures
....................... .220
Jacking ............................... .258
Life Of Tires ........................... .227
Load Capacity ...................... .215, 216
Pressure Monitor System (TPMS) .............232
Pressure Warning Light ....................126
Quality Grading ........................ .231
Radial ............................... .221
Replacement ........................... .228
Rotation .............................. .230
Safety ............................ .210, 219
Sizes .................................211
Snow Tires ............................ .223
Spare Tire ....................223,
224, 225, 226
Spinning .............................. .226
Tread Wear Indicators .....................226
Tire Safety Information ...................... .210
Tire Service Kit ............248, 249, 250, 252, 254, 255
To Open Hood .............................81
Towing ................................. .243
Disabled Vehicle ........................ .274
Recreational ........................... .244
Towing Vehicle Behind A Motorhome ............244
Traction ................................ .197
Traction Control .......................... .205
10
INDEX 345
