2017 DODGE VIPER torque

Refer to “Tire Pressure Monitoring System (TPMS)” under
“Starting and Operating” for further information.
Coolant Temperature
Push and release theupordown arrow button until
“Coolant Temperature” is highlighted. Push and release
the right arrow button, and the coolant temperature will be
displayed.
Oil Temperature
Push and release the upordown arrow button until “Oil
Temperature” is highlighted. Push and release the right
arrow button, and the oil temperature will be displayed.
Engine Hours
Push and release the upordown arrow button until
“Engine Hours” is highlighted. Push and release the right
arrow button, and the engine hours will be displayed.
Intake Air Temp.
Push and release the upordown arrow button until
“Intake Air Temp.” is highlighted. Push and release the
right arrow button, and the intake air temperature will be
displayed. Current Torque
Push and release the
upordown arrow button until
“Current Torque” is highlighted. Push and release the right
arrow button, and the current torque will be displayed.
Current Power
Push and release the upordown arrow button until
“Current Power” is highlighted. Push and release the right
arrow button, and the current power will be displayed.
Fuel Economy
Push and release the upordown arrow button
until the Fuel Economy icon is highlighted and
the following will display:
Range To Empty (RTE)
Average Fuel Economy/Miles Per Gallon (MPG Bargraph)
Current Miles Per Gallon (MPG)
136 UNDERSTANDING YOUR INSTRUMENT PANEL

Engine
When selected, this screen displays the following values:
•Speed (mph)
Displays the actual speed.
• Horsepower (hp)
Displays the actual horsepower.
• Torque (ft-lb)
Displays the actual torque.
• Oil Pressure (psi)
Displays the actual oil pressure.
Options
When selected, this screen allows you to set your SRT
home page picture, and configure the vehicle color shown
in the G-Force screen.
UCONNECT RADIOS — IF EQUIPPED
For detailed information about your Uconnect radio, refer
to your Uconnect Owner ’s Manual Supplement.
IPOD/USB/MP3 CONTROL — IF EQUIPPED
Located at the rear area of the center console, this feature
allows an iPod or external USB device to be plugged into
the USB port.
SD Card Slot, AUX Jack, And USB Port
1 — SD Card Slot
2 — AUX Jack
3 — USB Port
158 UNDERSTANDING YOUR INSTRUMENT PANEL

If Engine Fails To Start
CAUTION!
To prevent damage to the starter, do not crank the
engine for more than 15 seconds at a time. Wait 10 to 15
seconds before trying again.
WARNING!
•Never pour fuel or other flammable liquids into the
throttle body air inlet opening in an attempt to start
the vehicle. This could result in a flash fire causing
serious personal injury.
• Do not attempt to push or tow your vehicle to get it
started. Unburned fuel could enter the catalytic con-
verter and once the engine has started, ignite and
damage the converter and vehicle. If the vehicle has
a discharged battery, booster cables may be used to
obtain a start from a booster battery or the battery in
another vehicle. This type of start can be dangerous
if done improperly, so follow this procedure care-
fully. Refer to “Jump-Starting” in “What To Do In
Emergencies” for further information. If the engine is flooded, it may start to run, but not have
enough power to continue running when the ENGINE
START button is released. If this occurs, continue cranking
up to 15 seconds with the accelerator pedal pushed all the
way to the floor. Release the accelerator pedal and the
ENGINE START button once the engine is running
smoothly.
If the engine shows no sign of starting after two 15 second
periods of cranking with the accelerator pedal held to the
floor, the “Normal Starting” procedure should be repeated.
After Starting
The idle speed is controlled automatically, and it will
decrease as the engine warms up.
MANUAL TRANSMISSION
NOTE:
The parking brake should be engaged and the gear
selector placed into REVERSE before leaving the vehicle,
especially when parked on an incline.
Your vehicle is equipped with a high torque capacity dual
disc clutch. The clutch pedal must be fully pressed to the
floor during each shift. As you release the clutch pedal,
lightly press the accelerator pedal.
192 STARTING AND OPERATING

WHAT TO DO IN EMERGENCIES
CONTENTS
HAZARD WARNING FLASHER .............246
 IF YOUR ENGINE OVERHEATS .............246
 WHEEL AND TIRE TORQUE
SPECIFICATIONS ...................... .247
▫ Torque Specifications ....................247
 TIRE SERVICE KIT — IF EQUIPPED ..........248
▫ Description .......................... .248
▫ Tire Service Kit Storage ...................249
▫ Tire Service Kit Components And Operation . . .249 ▫
Tire Service Kit Usage Precautions ..........250
▫ Sealing A Tire With Tire Service Kit .........252
 JUMP-STARTING PROCEDURES ............256
 FREEING A STUCK VEHICLE ..............259
 TOWING A DISABLED VEHICLE ............260
 ENHANCED ACCIDENT RESPONSE SYSTEM
(EARS) .............................. .260
 EVENT DATA RECORDER (EDR) ............260
6

WHEEL AND TIRE TORQUE SPECIFICATIONS
Proper lug nut/bolt torque is very important to ensure that
the wheel is properly mounted to the vehicle. Any time a
wheel has been removed and reinstalled on the vehicle, the
lug nuts/bolts should be torqued using a properly cali-
brated torque wrench.
Torque Specifications
Lug Nut/Bolt Torque **Lug Nut/Bolt SizeLug Nut/Bolt
Socket Size
107 Ft-Lbs (145 N·m) 1/2” x 20 19 mm
**Use only your authorized dealer recommended lug nuts/
bolts and clean or remove any dirt or oil before tightening. Inspect the wheel mounting surface prior to mounting the
tire and remove any corrosion or loose particles.
Wheel Mounting Surface
6
WHAT TO DO IN EMERGENCIES 247

Tighten the lug nuts/bolts in a star pattern until each
nut/bolt has been tightened twice.
After 25 miles (40 km), check the lug nut/bolt torque to be
sure that all the lug nuts/bolts are properly seated against
the wheel.WARNING!
To avoid the risk of forcing the vehicle off the jack, do
not tighten the lug nuts fully until the vehicle has been
lowered. Failure to follow this warning may result in
personal injury.
TIRE SERVICE KIT — IF EQUIPPED
Description
Small punctures up to 1/4 inch (6 mm) in the tire tread can
be sealed with Tire Service Kit. Foreign objects (e.g., screws
or nails) should not be removed from the tire. Tire Service
Kit can be used in outside temperatures down to approxi-
mately -4°F (-20°C).
This kit will provide a temporary tire seal, allowing you to
drive your vehicle up to 100 miles (160 km) with a
maximum speed of 55 mph (90 km/h).
Torque Patterns
248 WHAT TO DO IN EMERGENCIES
