2017 DODGE DURANGO automatic transmission fluid

CAUTION!
Towing the vehicle, coasting, or driving for any other
reason with the transmission in NEUTRAL can cause
severe transmission damage. Refer to “Recreational
Towing” in “Starting And Operating” and “Towing A
Disabled Vehicle” in “What To Do In Emergencies” for
further information.
DRIVE (D)
This range should be used for most city and highway
driving. It provides the smoothest upshifts and downshifts,
and the best fuel economy. The transmission automatically
upshifts through all forward gears. The DRIVE position
provides optimum driving characteristics under all normal
operating conditions.
When frequent transmission shifting occurs (such as when
operating the vehicle under heavy loading conditions, in
hilly terrain, traveling into strong head winds, or while
towing a heavy trailer), use the AutoStick shift control
(refer to AutoStick in this section for further information) to
select a lower gear. Under these conditions, using a lower
gear will improve performance and extend transmission
life by reducing excessive shifting and heat buildup. During cold temperatures, transmission operation may be
modified depending on engine and transmission tempera-
ture as well as vehicle speed. This feature improves warm
up time of the engine and transmission to achieve maxi-
mum efficiency. Engagement of the torque converter clutch
is inhibited until the transmission fluid is warm. Normal
operation will resume once the transmission temperature
has risen to a suitable level.
Transmission Limp Home Mode
Transmission function is monitored electronically for ab-
normal conditions. If a condition is detected that could
result in transmission damage, Transmission Limp Home
Mode is activated. In this mode, the transmission may
operate only in certain gears, or may not shift at all. Vehicle
performance may be severely degraded and the engine
may stall. In some situations, the transmission may not
re-engage if the engine is turned off and restarted. The
Malfunction Indicator Light (MIL) may be illuminated. A
message in the instrument cluster will inform the driver of
the more serious conditions, and indicate what actions may
be necessary.
392 STARTING AND OPERATING

MAINTAINING YOUR VEHICLE
CONTENTS
ENGINE COMPARTMENT — 3.6L ...........503
 ENGINE COMPARTMENT — 5.7L ...........504
 ONBOARD DIAGNOSTIC SYSTEM (OBD II) . . . .505
▫ Onboard Diagnostic System (OBD II)
Cybersecurity ........................ .505
 EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS .......................... .506
 REPLACEMENT PARTS ...................507
 DEALER SERVICE ...................... .507
 MAINTENANCE PROCEDURES .............508
▫ Engine Oil .......................... .508
▫ Engine Oil Filter .......................511
▫ Engine Air Cleaner Filter .................511
▫ Maintenance-Free Battery .................511
▫ Air Conditioner Maintenance ..............512▫
Body Lubrication ..................... .516
▫ Windshield Wiper Blades .................517
▫ Adding Washer Fluid ...................518
▫ Exhaust System ....................... .519
▫ Cooling System ....................... .520
▫ Brake System ........................ .525
▫ Front/Rear Axle Fluid ...................526
▫ Transfer Case ........................ .527
▫ Automatic Transmission ..................527
▫ Appearance Care And Protection
From Corrosion ....................... .528
 FUSES ............................... .533
▫ Power Distribution Center ................534
 VEHICLE STORAGE .....................540
7

Transfer Case
Fluid Level Check
For normal service, periodic fluid level checks are not
required. When the vehicle is serviced for other reasons the
exterior surfaces of the transfer case assembly should be
inspected. If oil leakage is suspected inspect the fluid level.
Refer to “Fluids, Lubricants, and Genuine Parts” in “Main-
taining Your Vehicle” for further information.
Adding Fluid
Add fluid at the filler hole, until it runs out of the hole,
when the vehicle is in a level position.
Drain
First remove fill plug, then remove drain plug. Recom-
mended tightening torque for drain and fill plugs is 15 to
25 ft lbs (20 to 34 N·m).
CAUTION!
When installing plugs, do not overtighten. You could
damage them and cause them to leak.
Selection Of Lubricant
Use only the manufacturer’s recommended fluid. Refer to
“Fluids, Lubricants, and Genuine Parts” in “Maintaining
Your Vehicle” for further information.
Automatic Transmission
Selection Of Lubricant
It is important to use the proper transmission fluid to ensure
optimum transmission performance and life. Use only the
manufacturer’s specified transmission fluid. Refer to “Fluids,
Lubricants, and Genuine Parts” in this section for fluid
specifications. It is important to maintain the transmission
fluid at the correct level using the recommended fluid.
NOTE:No chemical flushes should be used in any trans-
mission; only the approved lubricant should be used.
CAUTION!
Using a transmission fluid other than the manufacturer ’s
recommended fluid may cause deterioration in transmis-
sion shift quality and/or torque converter shudder. Refer
to “Fluids, Lubricants, And Genuine Parts” in this sec-
tion for fluid specifications.
7
MAINTAINING YOUR VEHICLE 527

Special Additives
The manufacturer strongly recommends against using any
special additives in the transmission.
Automatic Transmission Fluid (ATF) is an engineered
product and its performance may be impaired by supple-
mental additives. Therefore, do not add any fluid additives
to the transmission. Avoid using transmission sealers as
they may adversely affect seals.
CAUTION!
Do not use chemical flushes in your transmission as
the chemicals can damage your transmission compo-
nents. Such damage is not covered by the New Vehicle
Limited Warranty.
Fluid Level Check
The fluid level is preset at the factory and does not require
adjustment under normal operating conditions. Routine
fluid level checks are not required, therefore the transmis-
sion has no dipstick. Your authorized dealer can check
your transmission fluid level using special service tools.
If you notice fluid leakage or transmission malfunction,
visit your authorized dealer immediately to have thetransmission fluid level checked. Operating the vehicle
with an improper fluid level can cause severe transmission
damage.
CAUTION!
If a transmission fluid leak occurs, visit your autho-
rized dealer immediately. Severe transmission damage
may occur. Your authorized dealer has the proper tools
to adjust the fluid level accurately.
Fluid And Filter Changes
Under normal operating conditions, the fluid installed at
the factory will provide satisfactory lubrication for the life
of the vehicle.
Routine fluid and filter changes are not required. However,
change the fluid and filter if the fluid becomes contami-
nated (with water, etc.), or if the transmission is disas-
sembled for any reason.
Appearance Care And Protection From Corrosion
Protection Of Body And Paint From Corrosion
Vehicle body care requirements vary according to geographic
locations and usage. Chemicals that make roads passable in
snow and ice and those that are sprayed on trees and road
528 MAINTAINING YOUR VEHICLE

Chassis
ComponentFluid, Lubricant, or Genuine Part
Automatic Transmission
Use only MOPAR ZF 8&9 Speed ATF Automatic Transmis-
sion Fluid or equivalent. Failure to use the correct fluid may
affect the function or performance of your transmission.
Transfer Case – 3.6L Engine We recommend you use Shell Automatic Transmission
Fluid.
Transfer Case – 5.7L Engine We recommend you use MOPAR ATF+4 Automatic Trans-
mission Fluid.
Axle Differential (Front-Rear) We recommend you use MOPAR GL-5 Synthetic Axle
Lubricant SAE 75W-85.
Brake Master Cylinder We recommend you use MOPAR DOT 3 Brake Fluid, SAE
J1703. If DOT 3, SAE J1703 brake fluid is not available, then
DOT 4 is acceptable.
7
MAINTAINING YOUR VEHICLE 549

Jump Starting.......................... .488
Oil .............................. .508, 545
Oil Filler Cap .......................... .510
Oil Filter ...............................511
Oil Selection .....................509, 545, 547
Overheating ........................... .474
Starting .............................. .379
Engine Oil Viscosity ........................ .510
Engine Oil Viscosity Chart ....................510
Enhanced Accident Response Feature ..........60, 499
Entry System, Illuminated .....................18
Ethanol ................................. .446
Exhaust Gas Caution .....................85, 448
Exhaust System ........................ .85, 519
Exterior Lights ......................... .88, 540
Filters Air Cleaner .............................511
Air Conditioning .....................351, 513
Engine Oil .............................511
Engine Oil Disposal ...................... .510
Flashers ................................ .474
Hazard Warning ........................ .474
Turn Signal ....................88, 254, 543, 544
Flooded Engine Starting ..................... .382Fluid Capacities
........................... .545
Fluid Leaks ...............................88
Fluid Level Checks Automatic Transmission ....................528
Brake ................................ .525
Engine Oil ............................ .508
Fluids .................................. .549
Fluids, Lubricants And Genuine Parts ............547
Fog Lights .............................. .544
Fog Light Service .......................... .544
Folding Rear Seat ......................... .123
Forward Collision Warning ....................174
Four-Way Hazard Flasher .....................474
Freeing A Stuck Vehicle ..................... .491
Fr
ont Axle (Differential) ..................... .526
Fuel ................................... .444
Adding .............................. .449
Additives ............................. .446
Clean Air ............................. .445
Economy Mode ......................... .387
Ethanol .............................. .446
Gasoline .............................. .444
Light ................................ .250
Materials Added ........................ .446
Methanol ............................. .446
570 INDEX

Wheel Mounting........................ .487
Tire Safety Information ...................... .417
Tongue Weight/Trailer Weight .................459
Tow Hooks, Emergency ..................... .492
Towing ............................. .453, 496
Disabled Vehicle ........................ .496
Guide ................................ .457
Recreational ........................... .466
Weight ............................... .457
Towing Vehicle Behind A Motorhome ............466
Traction Control ...........................411
Trailer Sway Control (TSC) ....................416
Trailer Towing ............................ .453
Cooling System Tips ..................... .464
Hitches ............................... .456
Minimum Requirements ....................460
Trailer And Tongue Weight ..................459
Wiring ............................... .462
Trailer Towing Guide ....................... .457
Trailer Weight ............................ .457
Transfer Case ............................ .527
Electronically Shifted ..................... .395
Fluid ................................ .549
Maintenance ........................... .527
Transmission ............................. .388Automatic
......................... .388, 527
Fluid ................................ .549
Maintenance ........................... .527
Shifting .............................. .386
Transmitter, Garage Door Opener (HomeLink) ......196
Transporting Pets ...........................83
Tread Wear Indicators ...................... .435
Turn Signals ....................... .254, 543, 544
Uconnect Customer Programmable Features ..........26, 285
Operation ............................. .314
Scr
een Activated Features ...................19
Uconnect Settings ...................20, 26, 285
Uconnect 8.4/8.4 NAV ...................... .372
Uconnect Access Vehicle Health Alert ...................... .364
Uconnect Settings ........................ .19, 20
Customer Programmable Features .....28, 30, 36, 283
Passive Entry Programming .........28, 30, 36, 283
Uconnect Settings ..................... .36, 283
Uconnect Voice Command ....................354
Uniform Tire Quality Grades ..................563
Universal Transmitter ....................... .196
10
INDEX 579
