Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9918169) - 2017 - CRC - 3/23/16
Lighting 135
Lights On with Wipers
If the windshield wipers are
activated in daylight with the engine
on, and the exterior lamp control is
in AUTO, the headlamps, parking
lamps, and other exterior lamps
come on. The transition time for the
lamps coming on varies based on
wiper speed. When the wipers are
not operating, these lamps turn off.
Move the exterior lamp control to
P
or;to disable this feature.
Hazard Warning Flashers
|:Press to make the front and
rear turn signal lamps flash on and
off. This warns others that you are
having trouble.
Press
|again to turn the
flashers off.
Turn and Lane-Change
Signals
Move the lever all the way up or
down to signal a turn.
An arrow on the instrument cluster
will flash in the direction of the turn
or lane change.
Raise or lower the lever until the
arrow starts to flash to signal a lane
change. Hold it there until the lane
change is complete. If the lever is
briefly pressed and released, the
turn signal flashes three times. The lever returns to its starting
position when it is released.
If after signaling a turn or a lane
change the arrows flash rapidly or
do not come on, a signal bulb may
be burned out.
Have any burned out bulbs
replaced. If a bulb is not burned out,
check the fuse; see
Fuses0227.
Fog Lamps
If equipped with fog lamps, the
control is on the turn signal lever.
Use the fog lamps for better vision
in foggy or misty conditions.
#FOG : Turn the fog lamp band on
the lever to
#FOG and release it,
to turn the fog lamps on or off. The
band will return to its original
position.
Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9918169) - 2017 - CRC - 3/23/16
Driving and Operating 195
When turning with a trailer, make
wider turns than normal so the
trailer will not strike soft shoulders,
curbs, road signs, trees or other
objects. Use the turn signal well in
advance and avoid jerky or sudden
maneuvers.
Turn Signals When Towing a
Trailer
The turn signal indicators on the
instrument panel flash whenever
signaling a turn or lane change.
Properly hooked up, the trailer
lamps also flash, telling other
drivers the vehicle is turning,
changing lanes or stopping.
When towing a trailer, the arrows on
the instrument panel flash for turns
even if the bulbs on the trailer are
burned out. Check occasionally to
be sure the trailer bulbs are still
working.
Driving on Grades
Reduce speed and shift to a lower
gear before starting down a long or
steep downgrade. If the
transmission is not shifted down, the
brakes might have to be used so
much that they would get hot and no
longer work well.
The vehicle can tow in D (Drive).
Use a lower gear if the transmission
shifts too often.
When towing at high altitude on
steep uphill grades, engine coolant
boils at a lower temperature than at
normal altitudes. If the engine is
turned off immediately after towing
at high altitude on steep uphill
grades, the vehicle could show
signs similar to engine overheating.
To avoid this, let the engine run
while parked, preferably on level
ground, with the transmission in
P (Park) for a few minutes before
turning the engine off. If the
overheat warning comes on, see
Engine Overheating0217.
Parking on Hills
{Warning
Parking the vehicle on a hill with
the trailer attached can be
dangerous. If something goes
wrong, the rig could start to move.
People can be injured, and both
the vehicle and the trailer can be
damaged. When possible, always
park the rig on a flat surface.
If parking the rig on a hill: 1. Press the brake pedal, but do not shift into P (Park) yet. Turn
the wheels into the curb if
facing downhill or into traffic if
facing uphill.
2. Have someone place chocks under the trailer wheels.
3. When the wheel chocks are in place, release the brake pedal
until the chocks absorb
the load.
Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9918169) - 2017 - CRC - 3/23/16
200 Vehicle Care
Vehicle Care
General Information
General Information . . . . . . . . . . 201
California Proposition65 Warning . . . . . . . . . . . . . . . . . 201
California Perchlorate Materials Requirements . . . . . 201
Accessories and Modifications . . . . . . . . . . . . . . . . 202
Vehicle Checks
Doing Your OwnService Work . . . . . . . . . . . . . . . 202
Hood . . . . . . . . . . . . . . . . . . . . . . . . . 203
Engine Compartment Overview . . . . . . . . . . . . . . . . . . . . 204
Engine Cover . . . . . . . . . . . . . . . . . 207
Engine Oil . . . . . . . . . . . . . . . . . . . . 207
Engine Oil Life System . . . . . . . 210
Automatic Transmission Fluid . . . . . . . . . . . . . . . . . . . . . . . . 211
Engine Air Cleaner/Filter . . . . . . 211
Cooling System . . . . . . . . . . . . . . 212
Engine Coolant . . . . . . . . . . . . . . . 213
Engine Overheating . . . . . . . . . . 217
Power Steering Fluid (2.4L L4 Engine) . . . . . . . . . . . . . . . . . . . . . 218 Power Steering Fluid (3.6L
V6 Engine) . . . . . . . . . . . . . . . . . . 218
Washer Fluid . . . . . . . . . . . . . . . . . 219
Brakes . . . . . . . . . . . . . . . . . . . . . . . 219
Brake Fluid . . . . . . . . . . . . . . . . . . . 220
Battery - North America . . . . . . 221
All-Wheel Drive . . . . . . . . . . . . . . . 222
Starter Switch Check . . . . . . . . . 222
Automatic Transmission Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 222
Ignition Transmission Lock Check . . . . . . . . . . . . . . . . . . . . . . . 223
Park Brake and P (Park) Mechanism Check . . . . . . . . . . 223
Wiper Blade Replacement . . . . 223
Headlamp Aiming
Headlamp Aiming . . . . . . . . . . . . 225
Bulb Replacement
Bulb Replacement . . . . . . . . . . . . 225
Halogen Bulbs . . . . . . . . . . . . . . . . 225
Fog Lamps . . . . . . . . . . . . . . . . . . . 225
Taillamps, Turn Signal, Stoplamps, and Back-Up
Lamps . . . . . . . . . . . . . . . . . . . . . . 226
License Plate Lamp . . . . . . . . . . 226
Replacement Bulbs . . . . . . . . . . . 227
Electrical System
Fuses . . . . . . . . . . . . . . . . . . . . . . . . 227
Engine Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 228
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 231
Wheels and Tires
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 232
All-Season Tires . . . . . . . . . . . . . . 233
Winter Tires . . . . . . . . . . . . . . . . . . 233
Summer Tires . . . . . . . . . . . . . . . . 234
Tire Sidewall Labeling . . . . . . . . 234
Tire Designations . . . . . . . . . . . . . 236
Tire Terminology and
Definitions . . . . . . . . . . . . . . . . . . 237
Tire Pressure . . . . . . . . . . . . . . . . . 240
Tire Pressure Monitor System . . . . . . . . . . . . . . . . . . . . . . 241
Tire Pressure Monitor Operation . . . . . . . . . . . . . . . . . . . 242
Tire Inspection . . . . . . . . . . . . . . . . 245
Tire Rotation . . . . . . . . . . . . . . . . . 245
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 246
Buying New Tires . . . . . . . . . . . . . 247
Different Size Tires and Wheels . . . . . . . . . . . . . . . . . . . . . . 248
Uniform Tire Quality Grading . . . . . . . . . . . . . . . . . . . . . 248
Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9918169) - 2017 - CRC - 3/23/16
226 Vehicle Care
Taillamps, Turn Signal,
Stoplamps, and Back-Up
Lamps
1. Back-up Lamp
2. Sidemarker
3. Stoplamp/Turn Signal Lamp/Taillamp
To replace one of these lamps:
1. Open the liftgate. See Liftgate 032.
2. Remove the two screw covers from the taillamp assembly.
3. Remove the two screws securing the taillamp assembly.
4. Pull the taillamp assembly out of the vehicle body.
5. Disconnect the lamp wiring harness.
6. Turn the bulb socket counterclockwise and pull
it out.
7. Pull the bulb straight out of the socket.
8. Install the new bulb.
9. Push the bulb socket in and turn it clockwise.
10. Reverse steps 2–5 to reinstall the lamp assembly.License Plate Lamp
Lamp Assembly
Bulb Assembly
1. Bulb Socket
Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9918169) - 2017 - CRC - 3/23/16
Vehicle Care 227
2. Bulb
3. Lamp Assembly
To replace one of these bulbs:1. Open the liftgate partway. See Liftgate 032.
2. Push the left end of the lamp assembly toward the right.
3. Pull the lamp assembly down to remove it from the liftgate.
4. Turn the bulb socket (1) counterclockwise to remove it
from the lamp assembly (3).
5. Pull the bulb (2) straight out of the bulb socket (1).
6. Push the replacement bulb straight into the bulb socket
and turn the bulb socket
clockwise to install it into the
lamp assembly. 7. Push the lamp assembly into
the liftgate engaging the clip
side first.
8. Push on the lamp side opposite the clip until the lamp assembly
snaps into place.
Replacement Bulbs
Exterior Lamp Bulb
Number
Back-Up Lamp 921
Fog Lamp Front H8LL
License Plate Lamp W5WLL
Taillamp/Turn Signal
Lamp/Stop Lamp 7443LL
For replacement bulbs not listed
here, contact your dealer.
Electrical System
Fuses
The wiring circuits in the vehicle are
protected from short circuits by
fuses. This greatly reduces the
chance of damage caused by
electrical problems.
Look at the silver-colored band
inside the fuse. If the band is broken
or melted, replace the fuse. Be sure
to replace a bad fuse with a new
one of the identical size and rating.
Replace a bad fuse with a new one
of the identical size and rating.
If there is a problem on the road and
a fuse needs to be replaced, the
same amperage fuse can be
borrowed. Choose some feature of
the vehicle that is not needed to use
and replace it as soon as possible.
Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9918169) - 2017 - CRC - 3/23/16
Index 317
Automatic TransmissionManual Mode . . . . . . . . . . . . . . . . . 172
Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 222
B
BatteryExterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 138
Load Management . . . . . . . . . . . . 137
Power Protection . . . . . . . . . . . . . 138
Voltage and Charging Messages . . . . . . . . . . . . . . . . . . . .117
Battery - North America . . . . 221, 260
Blade Replacement, Wiper . . . . . 223
Brake System Warning Light . . . . . . . . 108
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 219 Antilock . . . . . . . . . . . . . . . . . . . . . . . 173
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 175
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 220
Parking . . . . . . . . . . . . . . . . . . . . . . . 174
System Messages . . . . . . . . . . . . .117
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 149
Break-In, New Vehicle . . . . . . . . . . 163
Bulb Replacement . . . . . . . . . . . . . . 227 Fog Lamps . . . . . . . . . . . . . . . . . . . 225
Halogen Bulbs . . . . . . . . . . . . . . . . 225
Headlamp Aiming . . . . . . . . . . . . . 225 Bulb Replacement (cont'd)
Headlamps . . . . . . . . . . . . . . . . . . . 225
License Plate Lamps . . . . . . . . . 226
Taillamps, Turn Signal,
Stoplamps, and Back-up
Lamps . . . . . . . . . . . . . . . . . . . . . . 226
Buying New Tires . . . . . . . . . . . . . . . 247
C
Calibration . . . . . . . . . . . . . . . . . . . . . . . 98
California Fuel Requirements . . . . . . . . . . . 189
Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . 201
California Proposition
65 Warning . . . . . . . . . .201, 221, 260
Camera Rear Vision (RVC) . . . . . . . . . . . . 180
Canadian Vehicle Owners . . . . . . . . 2
Capacities and Specifications . . . . . . . . . . . . . . . . . 289
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 169
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . 32
Winter Driving . . . . . . . . . . . . . . . . 157
Cargo Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Tie-Downs . . . . . . . . . . . . . . . . . . . . . . 92 Caution, Danger, and Warning . . . . 3
Center Console Storage . . . . . . . . . 91
Chains, Tire . . . . . . . . . . . . . . . . . . . . 251
Charging System Light . . . . . . . . . 105
Check
Ignition Transmission Lock . . . 223
Malfunction IndicatorEngine Light . . . . . . . . . . . . . . . . 106
Child Restraints Infants and Young Children . . . . . 74
Lower Anchors and Tethersfor Children . . . . . . . . . . . . . . . . . . . 79
Older Children . . . . . . . . . . . . . . . . . . 72
Securing . . . . . . . . . . . . . . . . . . . . 85, 87
Systems . . . . . . . . . . . . . . . . . . . . . . . . 76
Cleaning
Exterior Care . . . . . . . . . . . . . . . . . 266
Interior Care . . . . . . . . . . . . . . . . . . 271
Climate Control Systems . . . . . . . 140 Air Conditioning . . . . . . . . . . . . . . 140
Automatic . . . . . . . . . . . . . . . . . . . . . 142
Heating . . . . . . . . . . . . . . . . . . . . . . . 140
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Cluster, Instrument . . . . . . . . . . . . . 101
Collision Damage Repair . . . . . . . 299
Compact Spare Tire . . . . . . . . . . . . 259
Compartments Storage . . . . . . . . . . . . . . . . . . . . . . . . . 91
Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9918169) - 2017 - CRC - 3/23/16
324 Index
Securing Child Restraints . . . . 85, 87
SecurityLight . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Messages . . . . . . . . . . . . . . . . . . . . 121
OnStar
®. . . . . . . . . . . . . . . . . . . . . . 307
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 36
Vehicle Alarm . . . . . . . . . . . . . . . . . . . 36
Service Accessories andModifications . . . . . . . . . . . . . . . . 202
Climate Control System . . . . . . . 140
Doing Your Own Work . . . . . . . . 202
Engine Soon Light . . . . . . . . . . . . 106
Maintenance Records . . . . . . . . 287
Maintenance, General Information . . . . . . . . . . . . . . . . . . 275
Parts Identification Label . . . . . 288
Publications Ordering Information . . . . . . . . . . . . . . . . . . 301
Scheduling Appointments . . . . . 298
Vehicle Messages . . . . . . . . . . . . 122
Services Special Application . . . . . . . . . . . 282
Servicing the Airbag . . . . . . . . . . . . . 70
Shift Lock Control Function Check, Automatic
Transmission . . . . . . . . . . . . . . . . . . 222 Shifting
Into Park . . . . . . . . . . . . . . . . . . . . . . 167
Out of Park . . . . . . . . . . . . . . . . . . . 168
Side Blind Zone Alert (SBZA) . . . 185
Signals, Turn and Lane-Change . . . . . . . . . . . . . . . . . 135
Spare Tire
Compact . . . . . . . . . . . . . . . . . . . . . . 259
Special Application Services . . . . 282
Specifications and Capacities . . . . . . . . . . . . . . . . . . . . . 289
Speedometer . . . . . . . . . . . . . . . . . . . 102
StabiliTrak OFF Light . . . . . . . . . . . . . . . . . . . . . .110
Start Assist, Hill . . . . . . . . . . . . . . . . . 175
Start Vehicle, Remote . . . . . . . . . . . 28
Starter Switch Check . . . . . . . . . . . 222
Starting the Engine . . . . . . . . . . . . . 165
Steering . . . . . . . . . . . . . . . . . . . . . . . . 149 Fluid, Power . . . . . . . . . . . . . . . . . . 218
Wheel Adjustment . . . . . . . . . . . . . . 96
Wheel Controls . . . . . . . . . . . . . . . . . 96
Stoplamps and Back-up Lamps Bulb Replacement . . . . . . . . . . . . 226
Storage Areas
Cargo Cover . . . . . . . . . . . . . . . . . . . . 92
Center Console . . . . . . . . . . . . . . . . . 91
Convenience Net . . . . . . . . . . . . . . . 93 Storage Areas (cont'd)
Glove Box . . . . . . . . . . . . . . . . . . . . . . 91
Roof Rack System . . . . . . . . . . . . . . 93
Storage Compartments . . . . . . . . . . 91
Stuck Vehicle . . . . . . . . . . . . . . . . . . . 158
Summer Tires . . . . . . . . . . . . . . . . . . 234
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . 42
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System
Forward CollisionAlert (FCA) . . . . . . . . . . . . . . . . . . 183
Infotainment . . . . . . . . . . . . . 139, 305
Roof Rack . . . . . . . . . . . . . . . . . . . . . . 93
T
Tachometer . . . . . . . . . . . . . . . . . . . . . 102
Taillamps Bulb Replacement . . . . . . . . . . . . 226
Text Telephone (TTY) Users . . . . 295
Theft-Deterrent Systems . . . . . . . . . 38 Immobilizer . . . . . . . . . . . . . . . . . . . . . 37
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232 All-Season . . . . . . . . . . . . . . . . . . . . 233
Buying New Tires . . . . . . . . . . . . . 247
Chains . . . . . . . . . . . . . . . . . . . . . . . . 251
Changing . . . . . . . . . . . . . . . . . . . . . 253
Compact Spare . . . . . . . . . . . . . . . 259
Chevrolet Equinox Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9918169) - 2017 - CRC - 3/23/16
Index 325
Tires (cont'd)Designations . . . . . . . . . . . . . . . . . 236
Different Size . . . . . . . . . . . . . . . . . 248
If a Tire Goes Flat . . . . . . . . . . . . 251
Inspection . . . . . . . . . . . . . . . . . . . . 245
Messages . . . . . . . . . . . . . . . . . . . . 122
Pressure Light . . . . . . . . . . . . . . . . .110
Pressure Monitor Operation . . 242
Pressure Monitor System . . . . . 241
Rotation . . . . . . . . . . . . . . . . . . . . . . 245
Sidewall Labeling . . . . . . . . . . . . . 234
Terminology and Definitions . . 237
Uniform Tire Quality
Grading . . . . . . . . . . . . . . . . . . . . . 248
Wheel Alignment and Tire Balance . . . . . . . . . . . . . . . . . . . . . 250
Wheel Replacement . . . . . . . . . . 250
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 246
Winter . . . . . . . . . . . . . . . . . . . . . . . . 233
Towing Driving Characteristics . . . . . . . . 193
Equipment . . . . . . . . . . . . . . . . . . . . 198
General Information . . . . . . . . . . 193
Recreational Vehicle . . . . . . . . . . 263
Trailer . . . . . . . . . . . . . . . . . . . . . . . . 196
Trailer Sway Control (TSC) . . . 198
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 263 Traction
Control System (TCS)/
StabiliTrak
®Light . . . . . . . . . . . . .110
Off Light . . . . . . . . . . . . . . . . . . . . . . 109
Traction Control/Electronic Stability Control . . . . . . . . . . . . . . . 175
Trailer
Sway Control (TSC) . . . . . . . . . . 198
Towing . . . . . . . . . . . . . . . . . . . . . . . . 196
Transmission Automatic . . . . . . . . . . . . . . . . . . . . . 170
Fluid, Automatic . . . . . . . . . . . . . . .211
Messages . . . . . . . . . . . . . . . . . . . . 122
Transportation Program, Courtesy . . . . . . . . . . . . . . . . . . . . . . 298
Turn and Lane-Change
Signals . . . . . . . . . . . . . . . . . . . . . . . . 135
Turn Signal Bulb Replacement . . . . . . . . . . . . 226
U
Uniform Tire Quality Grading . . . 248
Universal Remote System . . . . . . 130Operation . . . . . . . . . . . . . . . . . . . . . 132
Programming . . . . . . . . . . . . . . . . . 130
Using This Manual . . . . . . . . . . . . . . . . 2
V
Vehicle
Alarm System . . . . . . . . . . . . . . . . . . 36
Canadian Owners . . . . . . . . . . . . . . . 2
Control . . . . . . . . . . . . . . . . . . . . . . . 149
Identification Number (VIN) . . . 288
Load Limits . . . . . . . . . . . . . . . . . . . 159
Messages . . . . . . . . . . . . . . . . . . . . .116
Personalization . . . . . . . . . . . . . . . 123
Reminder Messages . . . . . . . . . . 123
Remote Start . . . . . . . . . . . . . . . . . . . 28
Security . . . . . . . . . . . . . . . . . . . . . . . . 36
Towing . . . . . . . . . . . . . . . . . . . . . . . . 263
Vehicle Ahead Indicator . . . . . . . . 109
Vehicle Care
Tire Pressure . . . . . . . . . . . . . . . . . 240
Vehicle Data Recording and Privacy . . . . . . . . . . . . . . . . . . . . . . . . 304
Ventilation, Air . . . . . . . . . . . . . . . . . . 145
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
W
Warning Brake System Light . . . . . . . . . . . 108
Caution and Danger . . . . . . . . . . . . . 3
Lane Departure (LDW) . . . . . . . 187
