2017.5 OPEL ANTARA climate control

Introduction.................................... 2
In brief ............................................ 6
Keys, doors and windows ............20
Seats, restraints ........................... 35
Storage ........................................ 56
Instruments and controls .............71
Lighting ...................................... 105
Climate control ........................... 114
Driving and operating .................122
Vehicle care ............................... 156
Service and maintenance ..........201
Technical data ........................... 204
Customer information ................213
Index .......................................... 218Contents

In brief111Side air vents .....................119
2 Fixed air vents .................... 120
3 High beam .......................... 106
Headlight flash ...................106
Turn and lane-change
signals ................................ 108
Exit lighting ......................... 112
Parking lights .....................109
Cruise control ....................... 91
4 Remote control on
steering wheel ......................72
Trip computer .....................100
5 Horn ..................................... 72
6 Instruments .......................... 78
Driver Information Centre ...... 91
7 Windscreen wiper and
washer system, headlight
washer system .....................73
Rear window wiper and
washer system .....................748Info-Display .......................... 94
Check control, tyre
pressure monitoring
system ................................ 183
Trip computer .....................100
9 Centre air vents .................. 119
10 Hazard warning flashers ....107
Parking assist ..................... 148
Electronic Stability Control . 145
Descent control system ...... 146
Status LED for anti-theft
alarm system ........................ 26
Folding exterior mirrors ........29
Fuel economy mode ...........122
11 Infotainment system .............10
12 Front passenger airbag ........48
13 Status LEDs for front
passenger airbag .................50
Control indicator for front
passenger seat belt .............42
14 Glovebox .............................. 57
15 Fuse box ............................ 17616Climate control system ....... 114
17 Ignition switch with
steering wheel lock ............125
18 Accelerator pedal ...............124
19 Driver airbag ........................ 48
20 Brake pedal ........................ 142
21 Clutch pedal ....................... 123
22 Steering wheel adjustment ..72
23 Bonnet release ...................158
24 Coin storage ......................... 56
25 Card holder .......................... 56
26 Light switch ........................ 105
Automatic light control .......106
Instrument illumination .......110
Rear fog light ...................... 109
Front fog lights ...................108
Headlight range
adjustment ......................... 106

In brief15Windscreen and headlight
washer systems
Pull lever.
Windscreen and headlight washer
system 3 73, Washer fluid 3 161.
Rear window wiper and washer
systemWiper on:push leverWiper off:pull leverWash:press and hold button
Rear window wiper and washer
system 3 74, Wiper blade
replacement 3 165, Washer fluid
3 161.
Climate control
Heated rear window, heated
exterior mirrors
Heating is operated by pressing Ü.
Heated rear window 3 32, Heated
exterior mirrors 3 29.

16In briefDemisting and defrosting the
windows
Air distribution to V (or l).
Cooling A/C (or n) and air
recirculation 4 are switched on
automatically to improve defrosting
efficiency (air recirculation 4 is
automatically switched off in vehicles
with electronic climate control).
Set temperature to highest level.
Set fan speed to highest level.
Switch on heated rear window Ü.
Close centre air vents, open side air vents and direct them towards the
door windows.
Climate control system 3 114.Transmission
Manual transmission
Reverse: with the vehicle stationary,
wait 3 seconds after depressing
clutch pedal and engage the gear.
If the gear does not engage, set the
lever to neutral, release the clutch
pedal and depress again; then repeat
gear selection.
Manual transmission 3 139.

114Climate controlClimate controlClimate control systems.............114
Heating and ventilation system 114
Air conditioning system ...........115
Electronic climate control system .................................... 116
Air vents ..................................... 119
Adjustable air vents .................119
Fixed air vents ......................... 120
Maintenance .............................. 120
Air intake ................................. 120
Pollen filter ............................... 120
Air conditioning regular operation ................................ 121
Service .................................... 121Climate control systems
Heating and ventilation system
Controls for: ● Temperature
● Air distribution
● Fan speed
● Demisting and defrosting
Heated rear window Ü 3 32.
Heated seats ß 3 40.
Temperaturered:warmblue:cold
Heating will not be fully effective until
the engine has reached normal
operating temperature.
Air distribution
M:to head area via adjustable air
ventsL:to head area via adjustable air
vents and to foot wellsK:to foot wells and to windscreenJ:to windscreen, front door
windows and foot wellsl:to windscreen, front door
windows and head area via
adjustable air vents
All combinations are possible.
Fan speed
Adjust the air flow by switching the fan
to the desired speed.
x:off1:minimum speed4:maximum speed

Climate control115Demisting and defrosting● Set the air distribution switch to l or J
● Set temperature control to warmest level
● Set fan to highest level
● Close centre air vents
● Open side air vents and direct them towards the door windows
Heated rear window Ü 3 32.
Air conditioning system
In addition to the heating and
ventilation system, the air
conditioning system has controls for:n:cooling4:air recirculationÜ:demisting and defrosting
Heated seats ß 3 40.
Cooling n
Press n
to switch on cooling.
Activation is indicated by illumination
of the LED in the button. Cooling is
only functional when the engine is
running and climate control fan is switched on.
Press n again to switch off cooling.
The air conditioning system cools and
dehumidifies (dries) as soon as the
outside temperature is slightly above
freezing point. Therefore
condensation may form and drip from under the vehicle.
If no cooling or drying is required,
switch the cooling system off to save
fuel.
Activated cooling may inhibit
autostops. Stop-start system 3 126.
Air recirculation system 4
Press 4 to activate air recirculation
mode. Activation is indicated by
illumination of the LED in the button.
Press 4 again to deactivate
recirculation mode.9 Warning
The exchange of fresh air is
reduced in air recirculation mode.
In operation without cooling the air humidity increases, so the
windows may mist up from inside.
The quality of the passenger
compartment air deteriorates,
which may cause the vehicle
occupants to feel drowsy.
In warm and very humid ambient air conditions, the windscreen might mist up from outside, when cold air is

116Climate controldirected towards it. If windscreen
mists up from outside, activate
windscreen wiper and deactivate l.
Maximum cooling Briefly open the windows and sunroof
so that hot air can disperse quickly.
● Press n to activate air
conditioning.
● Press 4 to activate air
recirculation.
● Set air distribution switch to M.
● Set temperature control to coldest level.
● Set fan to highest level.
● Open all vents.Demisting and defrosting
● Set the air distribution switch to l or J.
● Set temperature control to warmest level.
● Set fan to highest level.
● Close centre air vents.
● Open side air vents and direct them towards the door windows.
● Switch on heated rear window Ü
3 32.
Air conditioning n and air
recirculation 4 are switched on
automatically to improve defrosting
efficiency when position l or J is
selected.
Activated demisting and defrosting
may inhibit autostops. Stop-start
system 3 126.
Electronic climate control system
The dual zone climate control allows
different climatisation temperatures
for driver and front passenger side.
In automatic mode, temperature, fan
speed and air distribution are
regulated automatically.

Climate control117
Controls for:● Temperature on driver side
● Air distribution
● Fan speed
● Temperature on front passenger side
AUTO:Automatic modet:Automatic air recirculationV:Demisting and defrosting
Cooling A/C, Air recirculation 4
3 115.
Note
Do not cover the interior
temperature sensor (located beside the fan switch) or the sunlight sensor
(located in front of the windscreen
defroster vents) as this could cause the system to malfunction.
Heated rear window RÜ 3 32,
Heated seats ß 3 40.
Automatic mode AUTO Basic setting for maximum comfort:
● Press AUTO; cooling A/C is
switched on and the air
distribution and fan speed are
regulated automatically.
● Open all air vents.
● Set the preselected temperatures for driver's side
and front passenger's side using the left and right rotary knobs.
Note
All air vents are actuated
automatically in Automatic mode.
The air vents should therefore
always be open.
Temperature preselection
Recommended comfort setting is
22 °C. Intermediate settings are
possible.
Press SYNC to automatically adjust
front passenger's side temperature to
match current driver's side
temperature. Activation is indicated
by illumination of the LED in the
button.
If temperature settings are different
between driver's side and front
passenger's side, LED in SYNC
button extinguishes.
