2016 YAMAHA YXZ1000R ESP

7-1
7
EBU31950
BASIC GUIDE FOR SAFE USE
EBU31960As a YXZ1000R owner you are responsible
for the safe and proper operation of this vehi-
cle. Read this chapter and review the safety
instructions in Chapter 2 before operating the
vehicle. Use these chapters and the labels on
the vehicle to instruct new operators and pas-
sengers. Do not allow anyone else to operate
the vehicle or ride as a passenger if you are
unsure that he/she is willing and able to follow
these instructions.
WARNING
EWB03340Follow these instructions to reduce your
risk of an accident and to reduce the risk
of serious injury or death in the event of an
accident.
EBU35761KNOW YOUR VEHICLEThis off-road vehicle will handle and maneu-
ver differently from cars, ATVs, go-carts, golf-
cars and grounds-keeping vehicles. The
YXZ1000R has higher ground clearance and
other features to handle rugged terrain, and,
as a result, can overturn in situations where
some vehicles may not. This would include
vehicles made primarily for pavement, roads,
improved paths, or grounds-keeping. If you
do not use care in maneuvering the
YXZ1000R, you can cause it to roll over even
on flat, open areas.
Doing things with a YXZ1000R that some
people do for thrills in other vehicles (such as
sideways sliding, skidding, back-wheel slid-
ing, or donuts) could lead to side rollovers.
These rollovers can result in crushed limbs
and other serious injuries or death to drivers
or passengers.
U2HC7LE0.book Page 1 Wednesday, October 7, 2015 12:09 PM

7-2
7
As the owner/operator, it is your responsibility
to protect yourself and your passenger from
accidents, including rollovers. The YXZ1000R
has many features, including a protective
structure and seat belts, to help protect occu-
pants, but the best way to avoid injuries is to
avoid accidents. There is a risk of injury or
death in any accident, even with these safety
features.
Driver requirements
This vehicle is intended for use only by an
operator 16 or older with a valid motor ve-
hicle license. Check country laws for mini-
mum age requirements. 
The driver must be able to place both feet
flat on the floorboard while seated upright
with his/her back against the backrest.
 Do not drive after using drugs or alcohol.
 Remove the ignition key when the vehicle is
not in use to prevent unauthorized use of
the machine.
Parents:
Many countries have implemented new mo-
tor vehicle licensing requirements for young
drivers. These requirements are in response
to the disproportionately high rate of crashes
involving youthful drivers. As with automo-
DRIVER
UNDER
16
U2HC7LE0.book Page 2 Wednesday, October 7, 2015 12:09 PM

7-3
7
biles, to promote safe driving behaviors, you
should supervise younger drivers and consid-
er setting rules and putting limits on how,
when, and where the YXZ1000R can be used.
Passenger requirements
This vehicle is designed for the operator and
one passenger. Allowing passengers to ride
improperly can lead to serious injury or death.
As the operator, you are responsible for your
passenger.
 Your passenger must be able to place both
feet on the floorboard while seated upright
with his/her back against the backrest.
 Your passenger must be able to reach and
hold the passenger handhold.
 Allow only one passenger in the vehicle and
only in the designated passenger seat. Do
not carry any other passengers. Do not car-
ry passengers in the cargo bed.
 Do not allow someone to ride as a passen-
ger who has been using drugs or alcohol. 
Do not allow children who need child safety
seats or booster seats in the YXZ1000R.
The seat belt is not designed to restrain au-
tomotive child safety seats.
Occupant protection system
WARNING
EWB03350Do not make changes to the occupant pro-
tection system. If you install aftermarket
products or have your vehicle modified,
you may put yourself and others at greater
risk of serious injury or death. You are re-
sponsible for any such changes to the ve-
hicle.
U2HC7LE0.book Page 3 Wednesday, October 7, 2015 12:09 PM

7-11
7
Floorboard
The floorboard allows you to brace your feet,
which helps you keep your body in the vehicle
in the event of an accident or rollover. Keep
your feet on the floorboard during operation.
Steering wheel
Keep both hands on the steering wheel ex-
pect when using your right hand to operate
the shift lever. Do not hold the steering wheel
with your thumbs inside the rim. Keep your
palms on the outside of the steering wheel.
Similar to other off-road vehicles, if the YXZ1000R hits a deep rut or large obstacle,
the steering wheel could briefly jerk in one di-
rection or back and forth as the tires and ve-
hicle respond to the obstacle. This quick
motion could injure your thumbs or wrist if
your thumbs or hand(s) are inside the steering
wheel. Grip the steering wheel so that your
thumbs will not be hit by the spokes. As an
example, see the illustration.U2HC7LE0.book Page 11 Wednesday, October 7, 2015 12:09 PM

9-2
9
7. Automotive-type wax may be applied toall painted and chrome-plated surfaces.
Avoid combination cleaner-waxes. Many
contain abrasives which may scratch the
paint or protective finish. When finished,
start the engine and let it idle for several
minutes.EBU32741StorageLong term storage (60 days or more) of your
vehicle will require some preventive proce-
dures to guard against deterioration. Make
any necessary repairs before storing the vehi-
cle.
After thoroughly cleaning the vehicle, prepare
for storage as follows:
1. Fill the fuel tank with fresh fuel and add the specified amount of Fuel Med Rx or
another high-quality fuel stabilizer prod-
uct. Follow the instructions on the prod- uct label. Operate the vehicle for at least
5 minutes to distribute treated fuel
through the fuel system.
2. Remove the spark plugs and pour one ta- blespoon of fresh engine oil into each cyl-
inder and then re-install the spark plugs.
Remove the spark plug wires and ground
them. Operate the electric starter to turn
the engine over several times and coat
the cylinder walls with oil.
3. Lubricate all control cables.
4. Put the frame on stands or blocks to raise all wheels off the ground.
5. Tie a plastic bag over the exhaust pipe outlet to prevent moisture from entering.
Specified amount:1 oz of stabilizer to each gallon of fuel (or
7.5 ml of stabilizer to each liter of fuel)
U2HC7LE0.book Page 2 Wednesday, October 7, 2015 12:09 PM
