2016 YAMAHA XJR 1300 turn signal bulb

Table of contents
Replacing the headlight bulb.........6-30
Replacing the auxiliary light
bulb ............................................6-31
Brake/tail light ...............................6-32
Replacing a turn signal light bulb ............................................6-33
Replacing a license plate light bulb ............................................6-33
Supporting the motorcycle............6-35
Front wheel....................................6-35
Rear wheel.....................................6-37
Troubleshooting ............................6-38
Troubleshooting chart ...................6-40
Motorcycle care an d stora ge ..........7-1
Matte color caution .........................7-1
Care .................................................7-1
Storage ............................................7-3
Specifications ....................................8-1
Consumer information .....................9-1
Identification numbers .....................9-1
In dex ................................................10-1
U2PNE1E0.book Page 2 Monday, December 28, 2015 11:03 AM

Periodic maintenance an d a djustment
6-30
6
3. Turn the key to “ON” and turn on the electrical circuit in question to
check if the device operates.
4. If the fuse immediately blows again, have a Yamaha dealer
check the electrical system.
EAU63180
Replacin g the hea dlig ht bul bThis model is equipped with a halogen
bulb headlight. If the headlight bulb
burns out, replace it as follows.NOTICE
ECA10661
Do not touch the glass part of the
hea dlig ht bul b to keep it free from
oil, otherwise the transparency of
the glass, the luminosity of the bul b,
an d the bul b life will be ad versely af-
fected . Thorou ghly clean off any d irt
an d fin gerprints on the head light
b ul b using a cloth moistene d with al-
cohol or thinner.1. Remove the headlight unit by re- moving the screws. 2. Disconnect the headlight coupler,
and then remove the headlight
bulb cover.
3. Unhook the headlight bulb holder, and then remove the burnt-out
bulb.
Specifie d fuses:
Main fuse:
50.0 A
Headlight fuse:
15.0 A
Taillight fuse: 7.5 A
Signaling system fuse: 7.5 A
Ignition fuse:
15.0 A
Fuel injection system fuse: 15.0 A
Backup fuse: 7.5 A
1. Do not touch the glass part of the bulb.
1. Screw
1. Headlight coupler
2. Headlight bulb cover
2
1
U2PNE1E0.book Page 30 Monday, December 28, 2015 11:03 AM

Periodic maintenance an d a djustment
6-33
6
EAU24205
Replacin g a turn si gnal li ght
b ul b1. Remove the turn signal light lens
by removing the screw.
2. Remove the burnt-out bulb by pushing it in and turning it coun-
terclockwise. 3. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
4. Install the lens by installing the screw. NOTICE: Do not over-
ti g hten the screw, otherwise the
lens may break.
[ECA11192] EAU65451
Replacin
g a license plate li ght
b ul b1. Remove the reflector by removing
the nut.
2. Remove the license plate bracket by removing the bolts and collars.
1. Turn signal light lens
2. Screw
1
2
1. Turn signal light bulb
1
1. Reflector
2. Nut
2
1
U2PNE1E0.book Page 33 Monday, December 28, 2015 11:03 AM

Specifications
8-2
8
Front tire:Type:Tubeless
Size:
120/70 ZR17M/C (58W)
Manufacturer/model: DUNLOP/D252F LRear tire:Type:
Tubeless
Size: 180/55 ZR17M/C (73W)
Manufacturer/model: DUNLOP/D252 LLoa din g:Maximum load:
210 kg (463 lb)
(Total weight of rider, passenger, cargo
and accessories)Tire air pressure (measure d on col d
tires):Loading condition:
0–90 kg (0–198 lb)
Front:
250 kPa (2.50 kgf/cm², 36 psi)
Rear: 250 kPa (2.50 kgf/cm², 36 psi)
Loading condition: 90–210 kg (198–463 lb)
Front:
250 kPa (2.50 kgf/cm², 36 psi)
Rear: 290 kPa (2.90 kgf/cm², 42 psi)
Front wheel:Wheel type:Cast wheel
Rim size:
17M/C x MT3.50Rear wheel:Wheel type:Cast wheel
Rim size:
17M/C x MT5.50Front brake:Type:
Dual disc brake
Operation:
Right hand operation
Specified brake fluid: DOT 4Rear brake:Type:
Single disc brake
Operation: Right foot operation
Specified brake fluid: DOT 4Front suspension:Type:Telescopic fork
Spring/shock absorber type: Coil spring/oil damper
Wheel travel:
130 mm (5.1 in)Rear suspension:Type:Swingarm Spring/shock absorber type:
Coil spring/gas-oil damper
Wheel travel: 120 mm (4.7 in)
Electrical system:System voltage:12 V
Ignition system: TCI
Charging system:
AC generatorBattery:Model:YTZ14S
Voltage, capacity:
12 V, 11.2 AhHea dlig ht:Bulb type:
Halogen bulbBul b volta ge, watta ge × quantity:Headlight:
12 V, 60.0 W/55.0 W × 1
Brake/tail light: LED
Front turn signal light:
12 V, 10.0 W × 2
Rear turn signal light: 12 V, 10.0 W × 2
Auxiliary light: 12 V, 5.0 W × 1
License plate light:
12 V, 5.0 W × 1
Meter lighting: LED
U2PNE1E0.book Page 2 Monday, December 28, 2015 11:03 AM

Index
10-2
10
Troubleshooting .................................... 6-38
Troubleshooting chart........................... 6-40
Turn signal indicator lights ...................... 3-4
Turn signal light bulb, replacing............ 6-33
Turn signal switch ................................... 3-9VValve clearance..................................... 6-15
Vehicle identification number ................. 9-1WWheel bearings, checking..................... 6-27
Wheel (front).......................................... 6-35
Wheel (rear) ........................................... 6-37
Wheels .................................................. 6-18
