Instruments and controls75Instruments and
controlsControls ....................................... 76
Steering wheel adjustment ........76
Steering wheel controls .............76
Heated steering wheel ...............76
Horn ........................................... 77
Windscreen wiper/washer .........77
Rear window wiper/washer .......79
Outside temperature ..................79
Clock ......................................... 80
Power outlets ............................. 82
Cigarette lighter ......................... 82
Ashtrays .................................... 83
Warning lights, gauges and indi‐ cators ........................................... 83
Instrument cluster ......................83
Speedometer ............................. 83
Odometer .................................. 83
Trip odometer ............................ 83
Tachometer ............................... 84
Fuel gauge ................................ 85
Fuel selector .............................. 85
Engine coolant temperature gauge ....................................... 86
Service display .......................... 86Control indicators ......................87
Turn signal ................................. 89
Seat belt reminder .....................90
Airbag and belt tensioners .........90
Airbag deactivation ....................91
Charging system .......................91
Malfunction indicator light ..........91
Service vehicle soon .................91
Brake and clutch system ...........92
Operate pedal ............................ 92
Antilock brake system (ABS) .....92
Gear shifting .............................. 92
Power steering .......................... 92
Lane departure warning ............92
Ultrasonic parking assist ...........93
Electronic Stability Control off ...93
Electronic Stability Control and Traction Control system ...........93
Traction Control system off .......93
Preheating ................................. 93
Diesel particle filter ....................93
Tyre pressure monitoring system ...................................... 94
Engine oil pressure ....................94
Low fuel ..................................... 94
Immobiliser ................................ 94
Reduced engine power .............94
Autostop .................................... 95
Exterior light .............................. 95
High beam ................................. 95High beam assist.......................95
Fog light ..................................... 95
Rear fog light ............................. 95
Cruise control ............................ 95
Vehicle detected ahead .............95
Speed limiter ............................. 95
Traffic sign assistant ..................95
Door open .................................. 95
Information displays .....................96
Driver Information Centre ..........96
Colour-Info-Display ..................101
Graphic-Info-Display ................102
Vehicle messages ......................103
Warning chimes .......................105
Battery voltage ........................ 106
Vehicle personalisation ..............106
OnStar® system ........................110

Instruments and controls83AshtraysCaution
To be used only for ash and not forcombustible rubbish.
The portable ashtray can be placed in
the cupholders.
Warning lights, gauges
and indicators
Instrument cluster
The needles of the instruments briefly
rotate to the end position when the
ignition is switched on.
Speedometer
Indicates vehicle speed.
Odometer
The bottom line displays the recorded distance in miles.
Trip odometer The recorded distance is displayedsince the last reset.
Trip odometer counts up to
9999 miles and then restarts at 0.

84Instruments and controlsBaselevel and Midlevel display
To reset, press SET/CLR on the turn
signal lever for a few seconds
3 96.
Uplevel display
Two trip odometer are selectable for
different trips.
Select menu Trip/Fuel Information
Menu ; by pressing Menu on the
turn signal lever. Turn adjuster wheel
on turn signal lever and select Trip 1
or Trip 2 . Each trip odometer can be
reset separately by pressing
SET/CLR on the turn signal lever for
a few seconds on the respective
menu.
Tachometer
Displays the engine speed.
Drive in a low engine speed range for each gear as much as possible.
Caution
If the needle is in the red warning
zone, the maximum permitted
engine speed is exceeded. Engine at risk.

96Instruments and controlsInformation displaysDriver Information Centre The Driver Information Centre is
located in the instrument cluster.
Depending on the version and
equipment, the Driver Information
Centre is available as Baselevel
display, Midlevel display or Uplevel
display.
Following menus are selectable in the
Driver Information Centre using the
buttons on the turn signal lever:
● trip odometer 3 83
● vehicle information and settings, see below
● trip/fuel information, see below ● economic information, see below
● navigation information
Following indication appears if
required:
● warning messages 3 103
● gear shift indication 3 92
● drive mode indication 3 143,
3 148
● tyre pressure warning 3 213● seat belt reminder indication
3 90
● Autostop indication 3 138
● service information 3 91
Baselevel-Display
Select submenus by turning the
adjuster wheel on turn signal lever. Selectable submenus are:
● engine oil life indication
● tyre pressure indication
● tyre loading
● unit setting
● language setting, if no Infotainment system is available
●clock, if no Infotainment system is
available
● outside temperature, if no Infotainment system is available
Some of the displayed functions differ
when the vehicle is being driven or at a standstill.
Midlevel display
The menu pages of the Midlevel
display are selected by pressing
MENU on the turn signal lever.

98Instruments and controlsTrip/Fuel Information Menu
Press MENU to select Trip/Fuel
Information Menu information
page ;.
Turn the adjuster wheel to select a
submenu.
The following list contains all possible Trip/Fuel Information Menu pages.
Some may not be available for your particular vehicle.
Follow the instructions given in the
submenus.
● trip odometer 1
● trip odometer 2
● average fuel economy 1
● average fuel economy 2
● digital speed
● fuel range
● fuel range LPG version
● fuel level LPG version
● instantaneous fuel economy
● average vehicle speed
● clock
● temperature
● blank pageSelection and indication is different
between Midlevel- and Uplevel-
Display.
Trip odometer 1 and 2
Trip odometer displays the current
distance since a certain reset.
Trip odometer counts up to a distance
of 2000 miles then restarts at 0.
Turn the adjuster wheel to select
between trip odometer 1 and 2.
To reset, press SET/CLR for a few
seconds while viewing this page.
Simultaneously average fuel
economy 1 and 2 is indicated together with trip odometer 1 and 2.
The information of trip page 1 and 2
can be reset separately while the
respective display is active.
Average fuel economy 1 and 2
Display of average consumption. The measurement can be reset at any
time and starts with a default value.
To reset, press SET/CLR for a few
seconds while viewing this page.Simultaneously trip odometer 1 and 2
is indicated together with average fuel
economy 1 and 2.
The information of trip page 1 and 2
can be reset separately while the
respective display is active.
On vehicles with LPG engines:
Average consumption is indicated for
the currently selected mode (LPG or
petrol).
Digital speed
Digital display of the instantaneous
speed.
Fuel range
Range is calculated from current fuel
tank level and current consumption.
The display shows average values.
After refuelling, the range is updated
automatically after a brief delay.
When the fuel level in the tank is low, a message appears on the display
and the control indicator Y in the fuel
gauge illuminates.
