Instruments and controls111Control indicators in the centre
console
Overview
OTurn signal 3 112XSeat belt reminder 3 112vAirbag and belt tensioners
3 112VAirbag deactivation 3 112pCharging system 3 113ZMalfunction indicator light
3 113gService vehicle soon 3 113RBrake and clutch system
3 113-Operate pedal 3 113mElectric parking brake 3 113jElectric parking brake fault
3 114uAntilock brake system (ABS)
3 114[Upshift 3 114cPower steering 3 114)Lane departure warning 3 114rUltrasonic parking assist
3 115nElectronic Stability Control off
3 115bElectronic Stability Control and
Traction Control system 3 115kTraction Control system off
3 115!Preheating 3 115%Diesel particle filter 3 115wTyre pressure monitoring
system 3 116IEngine oil pressure 3 116iLow fuel 3 116dImmobiliser 3 117#Reduced engine power 3 1178Exterior light 3 117CHigh beam 3 117lHigh beam assist 3 117fAdaptive forward lighting
3 117>Fog light 3 117rRear fog light 3 117GLow washer fluid 3 117mCruise control 3 117 / Adaptive
cruise control 3 117AVehicle detected ahead 3 118hDoor open 3 118

Instruments and controls113Charging system
p illuminates red.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.
Illuminates when the engine is
running
Stop, switch off engine. Vehicle
battery is not charging. Engine
cooling may be interrupted. The
brake servo unit may cease to be effective. Seek the assistance of a
workshop.
Malfunction indicator light
Z illuminates or flashes yellow.
Illuminates when the ignition is
switched on and extinguishes shortly
after the engine starts.
Illuminates when the engine is
running
Fault in the emission control system.The permitted emission limits may be
exceeded. Seek the assistance of a
workshop immediately.Flashes when the engine is
running
Fault that could lead to catalytic
converter damage. Ease up on the
accelerator until the flashing stops.
Seek the assistance of a workshop
immediately.
Service vehicle soon
g illuminates yellow.
Additionally a warning message or a
warning code is displayed.
The vehicle needs a service.
Seek the assistance of a workshop.
Vehicle messages 3 124.
Brake and clutch system R illuminates red.
The brake and clutch fluid level is too
low 3 231.9 Warning
Stop. Do not continue your
journey. Consult a workshop.
Illuminates after the ignition is
switched on if the manual parking
brake is applied 3 176.
Operate pedal - illuminates or flashes yellow.
Illuminates
Brake pedal needs to be depressed
to release the electric parking brake
3 176.
Clutch pedal needs to be depressed
to start the engine in Autostop mode.
Stop-start system 3 166.
Flashes
Clutch pedal needs to be depressed
for a main start of the engine 3 18,
3 165.
On some versions the operate pedal
message is indicated in the Driver
Information Centre (DIC) 3 124.
Electric parking brake
m illuminates or flashes red.

114Instruments and controlsIlluminates
Electric parking brake is applied
3 176.
Flashes
Electric parking brake is not fully
applied or released. Switch on
ignition, depress brake pedal and
attempt to reset the system by first
releasing and then applying the
electric parking brake. If m remains
flashing, do not drive and seek the
assistance of a workshop.
Electric parking brake fault
j illuminates or flashes yellow.
Illuminates Electric parking brake is operating
with reduced performance 3 176.
Flashes
Electric parking brake is in service
mode. Stop vehicle, apply and
release the electric parking brake to
reset.9 Warning
Have the cause of the fault
remedied immediately by a
workshop.
Antilock brake system
(ABS)
u illuminates yellow.
Illuminates for a few seconds after the ignition is switched on. The system is
ready for operation when the control
indicator extinguishes.
If the control indicator does not go out after a few seconds, or if it illuminates while driving, there is a fault in the
ABS. The brake system remains
operational but without ABS
regulation.
Antilock brake system 3 175.
Upshift [ illuminates green as a control
indicator, or is shown as a symbol R
with the number of the next higher
gear in the Driver Information Centre
(DIC), when upshifting is
recommended for fuel saving
reasons.
On some versions, gearshift
indication is popped-up as full page in the DIC.
EcoFlex drive assistant 3 128.
Power steering
c illuminates yellow.
Illuminates with power steering
reduced
Power steering is reduced due to
overheating of the system. Control
indicator extinguishes when the
system has cooled down.
Stop-start system 3 166.
Illuminates with power steering disabled
Failure in the power steering system.
Consult a workshop.
Lane departure warning ) illuminates green or flashes yellow.

Driving and operating165Ignition switch positions0:ignition off1:steering wheel lock released,
ignition off2:ignition on, for diesel engine:
preheating3:starting
Retained power off
The following electronic systems can
work until the driver's door is opened
or at the latest for 10 minutes after the
ignition is switched off:
● power windows
● sunroof
● power outlets
Power to the Infotainment system will continue to operate for 30 minutes or
until the key is removed from the ignition switch, regardless of whether
any door will be opened.
Starting the engine
Manual transmission: operate clutch.
Automatic transmission: operate
brake and move the selector lever to
P or N.
Do not operate the accelerator pedal.
Diesel engine: turn the key to position 2 for preheating until control
indicator ! extinguishes.
Turn the key briefly to position 3 and
release: an automatic procedure
operates the starter with a short delay
as long as the engine is running, see
Automatic Starter Control.
Before restarting or to switch off the
engine, turn the key back to position
0 .
During an Autostop, the engine can
be started by depressing the clutch
pedal.
Starting the vehicle at low
temperatures
Starting the engine without additional
heaters is possible down to -25 °С for diesel engines and -30 °C for petrol
engines. Required is an engine oil
with the correct viscosity, the correct
fuel, performed services and a
sufficiently charged vehicle battery.
With temperatures below -30 °C the
automatic transmission needs a
warming phase of approx. 5 minutes.
The selector lever must be in position
P .
