2016 VAUXHALL ASTRA J Owner's Manual

In brief73-door hatchback
To open the tailgate, push the brand
emblem at the bottom half.
Press x on remote control to unlock
and open the tailgate. The doors
remain locked.
4-door saloon
Press x on the remote control for at
least 2 seconds; the boot lid opens
slightly.
Radio remote control 3 21, Central
locking system 3 23, Load
compartment 3 25.
Seat adjustment
Seat positioning
Pull handle, slide seat, release
handle. Try to move the seat back and forth to ensure that the seat is locked
in place.
Seat position 3 39, Seat adjustment
3 39.
9 Danger
Do not sit nearer than 25 cm from
the steering wheel, to permit safe
airbag deployment.

8In briefSeat backrests
Pull lever, adjust inclination and
release lever. Allow the seat to
engage audibly.
Seat position 3 39, Seat adjustment
3 39, Seat folding 3 42.
Seat height
Lever pumping motion
up:seat higherdown:seat lower
Seat position 3 39, Seat adjustment
3 39.
Seat inclination
Lever pumping motion
up:front end higherdown:front end lower
Seat position 3 39, Seat adjustment
3 39.

In brief9Power seat adjustment
Operate switch 1:
forwards/back‐
wards:length adjustmentupwards/down‐
wards:height adjustmentupwards/down‐
wards at front:inclination
adjustment
Operate switch 2:
forwards/
backwards at
the top:backrest adjustment
Power seat adjustment 3 43, Seat
folding 3 42.
Head restraint adjustment
Press release button, adjust height,
engage.
Head restraints 3 37.
Seat belt
Pull out the seat belt and engage in
belt buckle. The seat belt must not be twisted and must fit close against the
body. The backrest must not be tilted
back too far (maximum approx. 25 ° ).
To release belt, press red button on belt buckle.
Seat position 3 39, Seat belts
3 46, Airbag system 3 49.

10In briefMirror adjustment
Interior mirror
To reduce dazzle, adjust the lever on the underside of the mirror housing.
Interior mirror 3 31, Automatic anti-
dazzle interior mirror 3 32.
Exterior mirrors
Select the relevant exterior mirror and
adjust it.
Convex exterior mirrors 3 30,
Electric adjustment 3 30, Folding
exterior mirrors 3 30, Heated
exterior mirrors 3 31.
Steering wheel adjustment
Unlock the lever, adjust the steering
wheel, then engage the lever and
ensure it is fully locked.
Do not adjust the steering wheel
unless the vehicle is stationary and the steering wheel lock has been
released.
Airbag system 3 49, Ignition
positions 3 165.

In brief11Instrument panel overview

12In brief1Power windows .....................33
2 Exterior mirrors .....................30
3 Cruise control .....................183
Speed limiter ....................... 185
Adaptive cruise control .......186
Forward collision alert .........193
4 Side air vents ...................... 161
5 Windscreen wiper,
windscreen washer
system, headlight washer
system, rear window
wiper, rear window washer system ................................. 100
6 Instruments ........................ 106
7 Steering wheel controls .......99
8 Driver Information Centre .... 118
9 Turn and lane-change
signals, headlight flash,
low beam and high beam,
high beam assist .................147
Exit lighting ......................... 151
Parking lights ...................... 148
Buttons for Driver
Information Centre ..............11810Sport mode ........................ 180
Central locking system ..........23
Hazard warning flashers ....147
Fuel selector ....................... 107
Control indicator for airbag
deactivation ........................ 112
Control indicator for front
passenger seat belt ...........112
Tour mode .......................... 180
11 Info-Display ........................ 122
12 Anti-theft alarm system
status LED ........................... 28
13 Centre air vents .................. 161
14 Glovebox .............................. 59
15 Sport mode ........................ 180
Tour mode .......................... 180
Traction Control system
(TC) ..................................... 178
Electronic Stability Control (ESC) .................................. 179
Parking assist systems .......198Lane departure warning .....212
Eco button for stop-start
system ................................. 166
16 Climate control system ........ 153
17 AUX input, USB input ..........11
18 Power outlet ........................ 104
19 Selector lever, manual
transmission ....................... 175
Automatic transmission ......171
20 Electric parking brake .........176
21 Ignition switch with
steering wheel lock ............165
22 Horn ................................... 100
Driver airbag ........................ 49
23 Bonnet release lever ..........227
24 Storage compartment,
fuse box ............................. 255
25 Steering wheel adjustment ..99
26 Light switch ........................ 140
Headlight range
adjustment ......................... 143
Front fog lights ...................148

In brief13Rear fog light ...................... 148
Instrument illumination .......149Exterior lighting
Turn light switch:
7:lights off8:sidelights9:low beam
Automatic light control
AUTO:automatic light control:
exterior lighting is switched
on and off automaticallym:activation or deactivation of
the automatic light control8:sidelights9:low beam
Fog lights
Press light switch:
>:front fog lightsr:rear fog light
Lighting 3 140.

14In briefHeadlight flash, high beam and
low beamheadlight flash:pull leverhigh beam:push leverlow beam:push or pull lever
Automatic light control 3 141, High
beam 3 142, Headlight flash 3 142,
Adaptive forward lighting 3 144.
Turn and lane-change signalslever up:right turn signallever down:left turn signal
Turn and lane-change signals
3 147, Parking lights 3 148.
Hazard warning flashers
Operated by pressing ¨.
Hazard warning flashers 3 147.
