Vehicle load limits
◆Total load capacity (vehicle capacity weight): (P. 416)
Total load capacity means the combined weight of occupants, cargo
and luggage.
◆Seating capacity: 4 occupants (Front 2, Rear 2)
Seating capacity means the maxi mum number of occupants whose
estimated average weight is 150 lb. (68 kg) per person.
◆Towing capacity
Toyota does not recommend towing a trailer with your vehicle.
◆Cargo capacity
Cargo capacity may increase or decrease depending on the weight
and the number of occupants.
■Total load capacity and seating capacity
These details are also described on the tire and loading information label.
(  P. 346)
Vehicle load limits include total load capacity, seating capacity,
towing capacity and cargo capacity.
WARNING
■Overloading the vehicle
Do not overload the vehicle.
It may not only cause damage to the tires, but also degrade steering
and braking ability, resu lting in an accident.

1705-1. Before driving
MIRAI_OM_USA_OM62004U
Trailer towing
Toyota does not recommend towing a trailer with your vehicle.
Toyota also does not recommend th e installation of a tow hitch
or the use of a tow hitch carrier for a wheelchair, scooter, bicy-
cle, etc. Your vehicle is not designed for trailer towing or for the
use of tow hitch mounted carriers.

1715-1. Before driving
5
Driving
MIRAI_OM_USA_OM62004U
Dinghy towing
Your vehicle is not designed to be dinghy towed (with 4 wheels
on the ground) behind a motor home.
NOTICE
■To avoid serious damage to your vehicle
Do not tow your vehicle with four wheels on the ground.

1725-2. Driving procedures
MIRAI_OM_USA_OM62004U
Power switch
Check that the parking brake is set.
Firmly depress the brake pedal.
will be displayed on the multi-information display.
If it is not displayed, the fuel cell system cannot be started.
When shift position N is selected, the fuel cell system cannot start. Select
the P position when starting the fuel cell system. (
P. 180)
Press the power switch.
If the “READY” indicator turns on,
the fuel cell system will operate
normally.
Continue depressing the brake
pedal until the “READY” indicator
is illuminated.
The fuel cell system can be started
from any power switch mode.
Check that the “READY” indicator is illuminated.
The vehicle will not move when the “READY” indicator is off.
Performing the following operati ons when carrying the elec-
tronic key on your person starts the fuel cell system or changes
power switch modes.
Starting the fuel cell system
1
2
3
4

1735-2. Driving procedures
5
Driving
MIRAI_OM_USA_OM62004U
Stop the vehicle completely.
Set the parking brake. (P. 186)
Press the P position switch.
(  P. 180)
Check that the shift position indica-
tor shows P. ( P. 179)
Press the power switch.
The meter display will turn off, indicating the fuel cell system has stopped.
(The shift position indicator is displayed for several seconds)
The H
2O indicator will illuminate, indicating exhaust water is being purged.
Release the brake pedal and check that the meter display is off.
When the fuel cell system is stoppe d, water is automatically purged
from the tailpipe. To minimize wate r accumulation at parking garages,
etc., purge can be done manually before parking.
While the “READY” indicator is
on, press the H
2O switch.
The H
2O indicator on the meter
turns on.
Press the switch again to stop the
purge.
Remember that water is being gen-
erated as long as the fuel cell sys-
tem is operating. So a small
amount of water will be generated
after manual purging and before
parking.
Stopping the fuel cell system
1
2
3
Water release (H2O switch)
4
5

1745-2. Driving procedures
MIRAI_OM_USA_OM62004U
Modes can be changed by pressing the power switch with brake pedal
released. (The mode c hanges each time the switch is pressed.)
Off
The emergency flashers can be
used.
ACCESSORY mode
Some electrical components such
as the audio system can be used.
“Accessory” will be displayed on
the main display.
ON mode
All electrical components can be
used.
“Ignition On” will be displayed on
the main display.
■ Auto power off function
If the vehicle is left in ACCESSORY mode for more than 20 minutes or ON
mode (the fuel cell system is not operating) for more than an hour with the
shift position in P, the power switch will automatically turn off. However, this
function cannot entirely prevent 12-volt battery discharge. Do not leave\
the
vehicle with the power switch in ACCESSORY or ON mode for long periods
of time when the fuel cell system is not operating.
■ Sounds and vibrations specific to a fuel cell vehicle
P. 8 0
■ Electronic key battery depletion
P. 1 1 8
Changing power switch modes
1
2
3

1755-2. Driving procedures
5
Driving
MIRAI_OM_USA_OM62004U■
Starting the fuel cell system in cold temperatures
●When the power switch is pressed and the fuel cell system starts ( P. 172)
during cold temperatures, the fuel cell stack is quickly warmed up using the
waste heat during power generation.
● When the temperatures is cold, it may take some time until the “READY”
indicator turns on.
● The power output will be temporarily limited until the fuel cell system
reaches full operating temperature.
● The fuel cell system noises may become louder when the temperature is
cold. This is the normal warm-up operation and is not a malfunction. In
some cases, operation noises may continue for a some time even after the
“READY” indicator has turned on. ( P. 80)
■ Stopping the fuel cell system in cold temperatures
●When the power switch is pressed and the fuel cell system is stopped
( P. 173) during cold temperatures, the time for water purge from the
tailpipe may be longer than usual to prevent liquid in the fuel cell stack
from freezing.
● The water purge time may also be long if the system is stopped before fuel
cell system warm-up is completed.
● It is normal to hear hissing and other sounds during purge. ( P. 80)
● The H
2O indicator on the meter will illuminate during purge.
●
In extremely cold temperatures, the
“READY” indicator may take more than
10 seconds to illuminate. In this case,
the status progression of the fuel cell
system startup is displayed on the multi-
information display.

1765-2. Driving procedures
MIRAI_OM_USA_OM62004U■
Parking in cold temperatures
●Water may automatically purge from the tailpipe, even when the fuel cell
system is off, in order to prevent liquid in the fuel cell stack, hydrogen pipe-
lines, etc., from freezing while parked during cold temperatures.
● It is normal to hear hissing and other sounds during purge. ( P. 80)
● The H
2O indicator on the meter will illuminate during purge.
● Before storing the vehicle for extended periods of time in a location with
freezing temperatures, perform a cold-weather manual purge:
Turn the power switch to ON mode and press the H
2O switch.
Check that the H
2O indicator on the meter turns on.
While depressing the brake, press the power switch to start the fuel cell
system.
Check that the “READY” indicator turns on.
Press the power switch to stop the fuel cell system.
The water release is automatically performed. During water purge, the
H
2O indicator turns on. (Longer than normal water purge)
■ Conditions affecting operation
P. 134
■ Notes for the entry function
P. 135
■ If the fuel cell system does not start
●The immobilizer system may not have been deactivated. ( P. 72)
Contact your Toyota dealer.
● Check that the shift position is P. ( P. 179)
The fuel cell system cannot be started when the shift position is N.
If P position is not selected, “Shift to P position to start” will be displayed on
the multi-information display.
● Check that the fuel door is closed.
When the fuel door is open, the fuel cell system cannot be started.
Close the fuel door before starting the system. ( P. 201)
■ If “Smart Entry & Start System malfunction See owner’s manual” is dis-
played on the multi-information display
The system may be malfunctioning. Have the vehicle inspected by your
Toyota dealer immediately.
■ If the “READY” indicator does not come on
In the event that the “READY” indicator does not come on even after perform-
ing the proper procedures for starting the vehicle, contact your Toyota dealer
immediately.
■ If the fuel cell system is malfunctioning
P. 376
