2016 TOYOTA LAND CRUISER remote control

540
LC200_OM_OM60M88U_(U)
7-2. Steps to take in an emergency
If the electronic key does not operate
properly
Use the mechanical key (P.
103) in order to perform the fol-
lowing operations (driver’s door
only):
Locks all the doors
Closes the windows and moon
roof
* (turn and hold)
Unlocks the doors
Turning the key rearward unlocks
the driver’s door. Turning the key
once again unlocks the other
doors.
Opens the windows and moon roof* (turn and hold)
*: These settings must be customized at your Toyota dealer.
If communication between the electronic key and vehicle is
interrupted ( P. 122) or the electronic key cannot be used
because the battery is depleted, the smart key system and
wireless remote control cannot be used. In such cases, the
doors can be opened and the engine can be started by follow-
ing the procedure below.
Locking and unlocking the doors and key linked functions
1
2
3
4

LC200_OM_OM60M88U_(U)
5758-2. Customization
8
Vehicle specifications
Some function settings are changed simultaneously with other func-
tions being customized. Contact your Toyota dealer for further details.
Settings that can be changed using the navigation system
Settings that can be changed using the multi-information display
Settings that can be changed by your Toyota dealer
Definition of symbols: O = Available, – =Not available
■
Smart key system ( P. 120)
■Wireless remote control ( P. 102)
Customizable features
1
2
3
FunctionDefault settingCustomized
setting
Smart key system OnOffO—O
Smart door unlockingDriver’s doorAll the doorsO—O
123
FunctionDefault settingCustomized
setting
Wireless remote control On Off——O
Unlocking operation
Driver’s door
unlocked in one
step, all doors
unlocked in two steps
All doors
unlocked in one step
O—O
Alarm (panic mode)OnOff——O
123

576
LC200_OM_OM60M88U_(U)
8-2. Customization
■Smart key system (P. 120) and wireless remote control
(  P. 102)
■Door lock ( P. 106)
FunctionDefault settingCustomized
setting
Operation signal (Emer-
gency flashers) On OffO—O
Time elapsed before
automatic door lock
function is activated if
door is not opened after
being unlocked
60 secondsOffO—O30 seconds
120 seconds
Operation signal
(Buzzers)5OffO—O1 to 7
Open door warning
function (when locking
the vehicle)
On Off
——O
123
FunctionDefault settingCustomized
setting
Unlocking using a
mechanical key
Driver’s door
unlocked in one step, all doors
unlocked in two
steps
All doors
unlocked in one step
——O
Automatic door lock Shifting the shift
lever to position other than P OffO—O
Vehicle speed is
approximately
12 mph
(20 km/h) or higher
Automatic door unlock Shifting the shift
lever to P OffO—O
Driver’s door is
opened
123

LC200_OM_OM60M88U_(U)
5778-2. Customization
8
Vehicle specifications
■Power windows (P. 150)
■Moon roof (P. 154)
*1: The settings can be changed when the mechanical key linked operation of
the power window is set to on.
*2: The settings can be changed when the wireless remote control linkedoperation of the power window is set to on.
FunctionDefault settingCustomized setting
Mechanical key linked
operation (close) Off On——O
Mechanical key linked
operation (open)Off On——O
Wireless remote control
linked operation (open)Off On——O
Open door reminder
buzzerOn Off——O
Buzzer sounds if oper-
ated using wireless
remote controlOn Off
——O
123
FunctionDefault settingCustomized
setting
Mechanical key linked
operation (open)
*1Off On——O
Mechanical key linked
operation (close)
*1OffOn——O
Linked operation of
components when door
key is used
Slide onlyTilt only——O
Wireless remote control
linked operation
(open)
*2OffOn——O
Linked operation of
components when wire-
less remote control
used
Slide onlyTilt only——O
Open moon roof
reminder buzzerOnOff——O
123

593Alphabetical index
LC200_OM_OM60M88U_(U)
Anti-lock brake system (ABS) ...................................... 357
Function ................................ 357
Warning light ......................... 511
Approach warning
Dynamic radar cruise control................................. 264
Armrest ..................................... 420
Assist grips .............................. 421
Audio input
*
Audio system*
Automatic air conditioning
systemAir conditioning filter ............. 477
Automatic air conditioning
system ......... ....................... 374
Automatic door locking and
unlocking systems ................ 110
Automatic headli ght leveling
system .................................... 207
Function ................................ 207
Automatic High Beam ............. 209
Automatic light control system .................................... 207 Automatic transmission ......... 199
2nd start switch..................... 200
Downshift restriction
warning buzzer ................... 202
If the shift lever cannot be
shifted from P ..................... 539
S mode ................................. 201
AUX port
*
Auxiliary boxes ........................ 403
Back door ................................. 114
Back door handle.................. 115
Wireless remote control ........ 106
Back-up lights Replacing light bulbs ............ 492
Wattage ................................ 559
Battery ...................................... 459 Battery checking ................... 459
If the vehicle battery is discharged ...................... 543
Preparing and checking before winter ...................... 369
Voltmeter ................................ 85
Warning light......................... 510
Blind Spot Monitor (BSM) ....... 343
Bluetooth
®*
B
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

600Alphabetical index
LC200_OM_OM60M88U_(U)
KDSS (Kinetic Dynamic Suspension System) ............. 357
Keyless entry Smart key system ................. 120
Wireless remote control ........ 102
Keys .......................................... 102 Battery-saving function ......... 122
Electronic key ....................... 102
Engine switch........................ 193
If the electronic key does not operate properly ........... 540
If you lose your keys ..... 103, 105
Key number plate.................. 102
Keyless entry ........................ 102
Keys ...................................... 102
Mechanical key ..................... 102
Replacing the battery ............ 479
Warning buzzer..................... 121
Kinetic dynamic suspension system (KDSS) ...................... 357
Knee airbags .............................. 38
Language (multi-information display)................................... 581
LATCH system ........................... 64
LDA (Lane Departure Alert) .... 248
Lever Auxiliary catch lever .............. 449
Hood lock release lever ........ 449
Shift lever .............................. 199
Turn signal lever ................... 203
Wiper lever............................ 215
License plate lights Light switch ........................... 205
Replacing light bulbs............. 496
Wattage ................................ 559 Light
Automatic High Beam
system .......... ...................... 209
Door courtesy lights .............. 393
Engine switch light (ignition switch light) ........... 393
Fog light switch ..................... 214
Headlight switch ................... 205
Illuminated entry system ....... 395
Inside door handle lights....... 393
Interior lights ......................... 394
Personal lights ...................... 395
Replacing light bulbs ............ 487
Turn signal lever ................... 203
Vanity lights .......................... 408
Wattage ................................ 559
Light bulbs
Replacing.............................. 487
Wattage ................................ 559
Lock steering column ............. 196
Maintenance
Do-it-yourself maintenance....................... 447
General maintenance ........... 443
Maintenance data ................. 552
Maintenance requirements ...................... 440
Scheduled maintenance ....... 440
Malfunction indicator lamp..... 510
K
L
M

604Alphabetical index
LC200_OM_OM60M88U_(U)
Shift leverAutomatic transmission......... 199
If the shift lever cannot be
shifted from P ..................... 539
Shift lock system ..................... 539
Side airbags ............................... 38
Side doors ................................ 106
Side marker lights ................... 205
Light switch ........................... 205
Replacing light bulbs..... 489, 497
Wattage ................................ 559
Side mirrors ............................. 147 Adjusting and folding ............ 147
Blind Spot Monitor ................ 343
Heaters ................................. 380
Mirror position memory ......... 136
Smart key system .................... 120
Antenna location ................... 120
Entry functions .............. 106, 114
Starting the engine................ 193
Snow tires ................................ 369
“SOS” button ........................... 427
Spare tire Inflation pressure .................. 558
Storage location .................... 525
Spark plug ................................ 556
Specifications .......................... 552
Speedometer .............................. 85
SRS airbags ............................... 38
Steering Column lock release ............. 196
Fluid ...................................... 558
Steering wheel ......................... 143
Adjustment ............................ 143
Audio switches
*
Heated steering wheel .......... 389
Meter control switches ............ 91
Telephone switches
*
Stop/tail lightsReplacing light bulbs ............ 497
Storage feature ........................ 396
Stuck If the vehicle becomes
stuck ................................... 549
Sun visors ................................ 408
Sunshade Roof ...................................... 155
Switch Audio remote control
switches
*
Automatic High Beam switch ................................. 209
Center differential lock/unlock switch .............. 281
Clock adjustment buttons ..... 409
Cruise control switch .... 269, 257
Door lock switch ................... 108
Driving position memory
switches ............................. 136
Emergency flashers switch ................................. 500
Engine switch ....................... 193
Fog light switch ..................... 214
Four-wheel drive control switch ................................. 280
Garage door opener switches ............................. 422
Headlight cleaner switch....... 221
Heated steering wheel .......... 389
Interior light switch ................ 394
Intuitive parking assist .......... 272
Ignition switch ....................... 193
LDA (Lane Departure Alert)................................... 251
Light switches ....................... 205

607Alphabetical index
LC200_OM_OM60M88U_(U)
Warning buzzers ...................... 510Approach warning ................. 264
Brake system ....... ................. 510
Downshifting ......................... 202
Driver’s seat belt reminder ............................. 512
Intuitive parking assist .......... 275
Lane departure ..................... 253
Master warning system ......... 512
Open back door .................... 512
Open door ............................. 512
Parking brake........................ 204
PCS ...................................... 511
Radar cruise control.............. 264
Seat belt reminder ................ 512
Warning lights.......................... 510 ABS....................................... 511
Brake system ....... ................. 510
Center differential lock .......... 514
Charging system ................... 510
Low fuel level ........................ 512
Low speed four-wheel drive.................................... 514
Malfunction indicator lamp .... 510
Master warning light.............. 512
Open door ............................. 512
Pre-collision system .............. 511
Seat belt reminder light ......... 512
Slip indicator ......................... 511
SRS ...................................... 510
Tire pressure......................... 512 Warning messages.................. 519
Warning reflector holder......... 404
Washer ............................. 215, 219
Checking............................... 462
Preparing and checking before winter ...................... 369
Switch ........................... 215, 219
Washing and waxing ............... 434
Weights
Cargo capacity...................... 175
Load limits ............................ 175
Weights................................. 552
What to do if... (Troubleshooting) ................. 588
Wheels ...................................... 475 Replacing wheels ................. 524
Size....................................... 558
Window glasses ...................... 150
Window lock switch ................ 150
Windows Power windows..................... 150
Rear window defogger.......... 380
Washer ......................... 215, 219
Windshield wiper de-icer ........ 380
Windshield wipers ................... 215 Intermittent windshield wipers ................................. 215
Rain-sensing windshield wipers ................................. 216
Winter driving tips ................... 369
Wireless charger ..................... 412
Wireless remote control key .......................................... 102
Battery-saving function ......... 122
Locking/Unlocking ................ 102
Panic mode........................... 103
Replacing the battery............ 479
WMA disc
*
W
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
