2016 TOYOTA LAND CRUISER navigation system

LC200_Navi_OM60N15U_(U)
15.07.08 16:48
Navigation system
3
752. Destination search
1Display the “Destination” screen.
(P.69)
2Select “Address Book”.
3Select the desired address book entry.
“Options”: Select to register or edit ad-
dress book entries. (P.93)
1Display the “Destination” screen.
(P.69)
2Select “Emergency”.
3Select the desired emergency catego-
ry.
4Select the desired destination.
Searching by address book
To use this function, it is necessary to
register an address book entry.
(P.92)Searching by emergency
INFORMATION
●The navigation system does not guide in
areas where route guidance is unavail-
able. (P.104)

LC200_Navi_OM60N15U_(U)
15.07.08 16:48
Navigation system
3
772. Destination search
1Display the “Destination” screen.
(P.69)
2Select “Map”.
3Scroll the map to the desired point and
select “Go to ”.
“Adjust Location”: Select to adjust the
position in smaller increments. (P.60)
If a destination has already been set, “Go
to ” and “Add to Route” will be dis-
played.
“Go to ”: Select to delete the existing
destination(s) and set a new one.
“Add to Route”: Select to add a destina-
tion.
The navigation system performs a search
for the route and the entire route map is
displayed. (P.78)
1Display the “Destination” screen.
(P.69)
2Select “Coordinates”.
3Enter the latitude and longitude and
select “OK”.
INFORMATION
●Be sure to use the complete name of the
freeway or highway, including the
hyphen, when entering the destination.
Freeways and interstates use an “I” (I-
405). US highways use the state desig-
nation before the number (CA-118).
Searching by map
By selecting “Map” the last displayed
location is displayed again on the map
screen. You can search for a destina-
tion from this map.
Searching by coordinates

LC200_Navi_OM60N15U_(U)
15.07.08 16:48
Navigation system
3
792. Destination search
■Displaying 3 routes information
1Select “Info”.
2Check that the “Information for Three
Routes” screen is displayed.
1Select “Turn List”.
2Check that the turn list is displayed.
No.Information
Time necessary for the entire trip
Distance of the entire trip
Distance of the toll road
Distance of the freeway
Distance of the ferry trip
Displaying turn list
A list of turn information from the cur-
rent position to the destination can be
displayed.
No.Information
Current position
Distance to the next turn
Turn direction at the intersection
Select to display the map of the se-
lected point.
INFORMATION
●However, not all road names on the
route may appear on the list. If a road
changes its name without requiring a
turn (such as on a street that runs
through 2 or more cities), the name
change will not appear on the list. The
street names will be displayed in order
from the starting point, along with the
distance to the next turn.

LC200_Navi_OM60N15U_(U)
15.07.08 16:48
Navigation system
3
813. Route guidance
1Select the route information bar ( ) or
the route information button ( ) to
change the display of the route infor-
mation bar.
Route guidance screen
During the route guidance, various
types of guidance screens can be dis-
played depending on conditions.
Screen for route guidance
No.Information
Distance to the next turn and an ar-
row indicating the turning direction
Guidance route
Current position
Current street name or route infor-
mation
INFORMATION
●If the vehicle goes off the guidance
route, the route is searched again.
●For some areas, the roads have not
been completely digitized in our data-
base. For this reason, the route guid-
ance may select a road that should not
be traveled on.
●When arriving at the set destination the
destination name will be displayed on
the upper part of the screen.
Changing route information bar
When the vehicle is on the guidance
route, the route information bar dis-
plays the current street name or the
distance with the estimated travel/ar-
rival time to the destination.
No.Information
Select to change the display be-
tween the estimated travel time and
the estimated arrival time.
Select to change the display be-
tween the current street name and
the distance with the estimated trav-
el/arrival time.
INFORMATION
●When the vehicle is on the guidance
route, the distance measured along the
route is displayed. Travel time and
arrival time are calculated based on the
average speed for the specified speed
limit.
●When the vehicle gets off the guidance
route, the arrow facing the destination is
displayed instead of the estimated
travel/arrival time.
●The route information bar fills from left to
right as the vehicle progresses on the
route.

LC200_Navi_OM60N15U_(U)
15.07.08 16:48
Navigation system
3
833. Route guidance
During freeway driving
During freeway driving, the freeway
exit information screen will be dis-
played.
No./
IconInformation/Function
Distance and time from the current
position to the road traffic facilities.
Name of the road traffic facilities.
POIs that are close to a freeway exit
Select to display the selected map of
the exit vicinity.
Select to scroll to farther road traffic
facilities.
Select to scroll to closer road traffic
facilities.
When approaching freeway exit
or junction
When the vehicle approaches an exit
or junction, the freeway guidance
screen will be displayed.
No.Information/Function
Next exit or junction name
Distance from the current position to
the exit or junction
Select to hide the freeway guidance
screen. To return to the freeway
guidance screen, select .
Bar showing the remaining distance
to the guidance point.

LC200_Navi_OM60N15U_(U)
15.07.08 16:48
Navigation system
3
853. Route guidance
1Select “Turn List” on the “Map Mode”
screen. (P.58)
2Check that the turn list screen is dis-
played.
When approaching intersection
When the vehicle approaches an inter-
section, the intersection guidance
screen will be displayed.
No.Information/Function
Next street name
Select to hide the intersection guid-
ance screen. To return to the inter-
section guidance screen, select
.
Distance to the intersection
Bar showing the remaining distance
to the guidance point.
Turn list screen
No.Information
Turn direction
Distance between turns
Next street or destination name

LC200_Navi_OM60N15U_(U)
15.07.08 16:48
Navigation system
3
873. Route guidance
1Press the “NAV” button.
2Select “Options”.
3Select “Edit Route”.
4Select the item to be set.
5Check that the entire route map is dis-
played. (P.78)
1Display the “Route” screen. (P.87)
2Select “Add”.
3Search for an additional destination in
the same way as a destination search.
(P.68)
4Select “Add Destination Here” to in-
sert the new destination into the route.
Editing routeNo.FunctionPage
Select to add destinations.87
Select to delete destina-
tions.88
Select to reorder destina-
tions.88
Select to set route prefer-
ences.88
Select to change route
type.88
Select to set detours.89
Select to start from adja-
cent road.89
Adding destinations

LC200_Navi_OM60N15U_(U)
15.07.08 16:48
Navigation system
3
893. Route guidance
4The entire route from the starting point
to the destination is displayed.
For details about this screen: P. 7 8
1Display the “Route” screen. (P.87)
2Select “Detour”.
3Select the desired detour distance.
1Display the “Route” screen. (P.87)
2Select “Start from Adjacent Road”.
Detour setting
During the route guidance, the route
can be changed to detour around a
section of the route where a delay is
caused by road repairs, an accident,
etc.
No.Function
Select to detour the route for the
next 1 mile.
Select to detour the route for the
next 3 miles.
Select to detour the route for the
next 5 miles.
Select to detour the entire route.
Select to make the system search
for the route based on traffic con-
gestion information received from
traffic information. (P.65)
INFORMATION
●This picture shows an example of how
the system would guide you around a
delay caused by a traffic jam.
This position indicates the location of a
traffic jam caused by road repairs, an
accident, etc.
This route indicates the detour sug-
gested by the system.
●When the vehicle is on a freeway, the
detour distance selections are 5, 15 and
25 miles (or 5, 15 and 25 km if units are
in km).
●The system may not be able to calculate
a detour route depending on the
selected distance and surrounding road
conditions.
Starting from adjacent road
When a freeway and a surface road
run in parallel, the system may show
the guidance route going on the free-
way while driving on the surface road,
or vice versa.
If this happens, you can instantly
choose the adjacent road for the route
guidance.
INFORMATION
●When there is no adjacent road, this
screen button will not be displayed.
