2016 TOYOTA CAMRY HYBRID fuse

4277-3. Do-it-yourself maintenance
7
Maintenance and care
CAMRY_HV_U (OM33C35U)
Turn the power switch off.
Open the fuse box cover.
Checking and replacing fuses
If any of the electrical components do not operate, a fuse may
have blown. If this happens, check and replace the fuses as nec-
essary.
1
2
Engine compartment (type A)Engine compartment (type B)
Push the tabs in and lift the lid off. Push the tabs in and lift the lid off.
Under the driver’s side instru-
ment panel
Remove the lid.

4287-3. Do-it-yourself maintenance
CAMRY_HV_U (OM33C35U)
Remove the fuse with the pull-
out tool.
Only type A fuses can be removed
using the pullout tool.
Check if the fuse is blown.Normal fuse
Blown fuse
Type A and B:
Replace the blown fuse with a new fuse of an appropriate amperage rat-
ing. The amperage rating can be found on the fuse box lid.
Type C:
Contact your Toyota dealer.
3
4
Ty p e AType B
Ty p e C
1
2

4297-3. Do-it-yourself maintenance
7
Maintenance and care
CAMRY_HV_U (OM33C35U)
nAfter a fuse is replaced
lIf the lights do not turn on even after the fuse has been replaced, a bulb may
need replacement. ( P. 430)
l If the replaced fuse blows again, have the vehicle inspected by your Toyota
dealer.
n If there is an overload in a circuit
The fuses are designed to blow, protecting the wiring harness from damage.
n When replacing light bulbs
Toyota recommends that you use genuine Toyota products designed for this
vehicle. Because certain bulbs are connected to circuits designed to prevent
overload, non-genuine parts or parts not designed for this vehicle may be
unusable.
WARNING
nTo prevent system breakdowns and vehicle fire
Observe the following precautions.
Failure to do so may cause damage to the vehicle, and possibly a fire or
injury.
lNever use a fuse of a higher amperage rating than that indicated, or use\
any other object in place of a fuse.
l Always use a genuine Toyota fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix.
l Do not modify the fuses or fuse boxes.
NOTICE
nBefore replacing fuses
Have the cause of electrical overload determined and repaired by your
Toyota dealer as soon as possible.

4848-2. Steps to take in an emergency
CAMRY_HV_U (OM33C35U)
One of the following may be the cause of the problem:
lThe electronic key may not be functioning properly. ( P. 488)
l There may not be sufficient fuel in the vehicle’s tank.
Refuel the vehicle.
l There may be a malfunction in the immobilizer system.
(  P. 78)
l There may be a malfunction in the steering lock system.
l The hybrid system may be malfunctioning due to an electrical prob-
lem such as an open circuit or a blown fuse. However, depending
on the type of malfunction, an in terim measure is available to start
the hybrid system. ( P. 485)
One of the following may be the cause of the problem:
l The 12-volt battery may be discharged. ( P. 490)
l The 12-volt battery terminal connections may be loose or corroded.
( P. 404)
If the hybrid system will not star t
Reasons for the hybrid system not starting vary depending on
the situation. Check the follo wing and perform the appropriate
procedure:
The hybrid system will not start even though the correct starting
procedure is being followed. ( P. 161)
The interior lights and headlights are dim, or the horn does not
sound or sounds at a low volume.

4908-2. Steps to take in an emergency
CAMRY_HV_U (OM33C35U)
If you have a set of jumper (or booster) cables and a second vehicle
with a 12-volt battery, you can jump start your vehicle by following the
steps below.
Vehicles with an alarm, confirm
that the electronic key is being
carried.
When connecting the jumper (or
booster) cables, depending on the
situation, the alarm may activate
and doors locked. ( P. 81)
Open the hood and remove the
fuse box cover.
Push the tabs in and lift the lid off.
Open the exclusive jump start-
ing terminal cover.
Push the tab in and open the cover.
If the vehicle 12-volt batter y is discharged
The following procedures may be used to start the hybrid sys-
tem if the vehicle’s 12-volt battery is discharged.
You can also call your Toyota de aler or a qualified repair shop.
1
2
3

4928-2. Steps to take in an emergency
CAMRY_HV_U (OM33C35U)
Start the engine of the second vehicle. Increase the engine speed
slightly and maintain at that level for approximately 5 minutes to
recharge the 12-volt battery of your vehicle.
Open and close any of the doors of your vehicle with the power
switch off.
Maintain the engine speed of the second vehicle and turn the power
switch to ON mode, then start the vehicle's engine.
Make sure the “READY” indicato r comes on. If the indicator does
not come on, contact your Toyota dealer.
Once the hybrid system has start ed, remove the jumper cables in
the exact reverse order from which they were connected.
Close the exclusive jump starting terminal cover, and reinstall the
fuse box cover to its original position.
Once the hybrid system starts, have the vehicle inspected at your
Toyota dealer as soon as possible.5
6
7
8
9
10

562Alphabetical index
CAMRY_HV_U (OM33C35U)
Flat tire...................................... 473
Floor mats .................................. 26
FluidBrake .................................... 510
Hybrid transmission .............. 510
Washer ................................. 403
Front interior lights ................. 343 Wattage ................................ 512
Front passenger occupant classification system .............. 49
Front personal lights ............... 343
Wattage ................................ 512
Front seats ............................... 128 Adjustment ............................ 128
Cleaning................................ 381
Correct driving posture ........... 28
Head restraints ..................... 132
Seat heaters ......................... 341
Front side marker lights.......... 172 Light switch ........................... 172
Replacing light bulbs............. 432
Wattage ................................ 512
Front turn signal lights ........... 170
Replacing light bulbs............. 433
Turn signal lever ................... 170
Wattage ................................ 512
Fuel ........................................... 182
Capacity ................................ 506
Fuel gauge .............................. 88
Information ............................ 513
Refueling............................... 182
Type .............................. 182, 506
Warning light ......................... 448
Warning message ................. 463
Fuel consumption.................... 101
Fuel filler door.......................... 182 Refueling............................... 182
Fuses ........................................ 427 Garage door opener ................ 362
Gauges ....................................... 88
Glove box ................................. 346
Grocery bag hooks.................. 355
Hands-free system
(for cellular phone)
*............. 284
Head restraints ........................ 132
Headlights ................................ 172 Automatic High Beam
system .......... ...................... 175
Light switch ........................... 172
Replacing light bulbs .... 431, 437
Wattage ................................ 512
Heaters Outside rear view mirrors ..... 336
Seat heaters ......................... 341
High voltage components ........ 73
Hill-start assist control ........... 218
Hood ......................................... 394
Hooks Coat hooks ........................... 361
Grocery bag hooks ............... 355
Retaining hooks (floor mat) .... 26
Horn .......................................... 134
Hybrid battery (traction battery) ..................... 73
Hybrid battery (traction battery) air vent........ 74
FG
H

566Alphabetical index
CAMRY_HV_U (OM33C35U)
Parking brake ........................... 171Operation .............................. 171
Parking brake engaged
warning buzzer ........... 446, 457
Parking brake engaged
warning message ............... 457
Warning light ......................... 446
Parking lights ........................... 172
Light switch ........................... 172
Replacing light bulbs............. 433
Wattage ................................ 512
PCS (Pre-Collision System) .......... 224Function ................................ 224
PCS switch ........................... 225
Warning light ......................... 447
Personal lights ......................... 343
Wattage ................................ 512
Power control unit ..................... 73
Power control unit coolant ..... 400 Capacity ................................ 509
Checking ............................... 400
Preparing and checking before winter....................... 242
Power outlet ............................. 359
Power steering (Electric power steering) ...... 219
Warning light ......................... 447
Power switch............................ 161
Power windows........................ 140 Jam protection function......... 140
Operation .............................. 140
Window lock switch............... 140
Pre-Collision System (PCS) ...................................... 224Function ................................ 224
PCS switch ........................... 225
Warning light ......................... 447 Radar cruise control (dynamic
radar cruise control) ............. 189
Radiator .................................... 401
Radio
*...................................... 267
Rear interior lights .................. 343
Wattage ................................ 512
Rear personal lights ................ 343 Wattage ................................ 512
Rear seat Folding down ........................ 130
Rear side marker lights........... 172
Light switch ........................... 172
Replacing light bulbs ............ 434
Wattage ................................ 512
Rear turn signal lights ............ 170 Replacing light bulbs ............ 434
Turn signal lever ................... 170
Wattage ................................ 512
Rear view mirror Inside rear view mirror .......... 136
Outside rear view mirrors ..... 138
Rear view monitor system
*.... 208
Rear window defogger ............ 336
Refueling .................................. 182
Capacity................................ 506
Fuel types ............................. 506
Opening the fuel tank cap..... 184
Replacing Electronic key battery ........... 425
Fuses .................................... 427
Light bulbs ............................ 430
Tires...................................... 473
Reporting safety defects
for U.S. owners...................... 540
Resetting the message indicating maintenance is
required.................................. 385
Road accident cautions ............ 76
PR
