2016 TOYOTA 4RUNNER Owners Manual

2975-3. Using the storage features
5
Interior features
4RUNNER (U)_(OM35B23U)
The glove box can be opened by pressing the lock release button and
can be locked and unlocked by using the master key (vehicles without
a smart key system) or the mechanical key (vehicles with a smart key
system).
Open
Unlock
Lock
Lift the lid while pulling up the
knob to release the lock.
■The separator can be used in either of the positions shown in the illus-
tration
Glove box
1
2
3
Console box
Change the separator position.

2985-3. Using the storage features
4RUNNER (U)_(OM35B23U)
Cup holders
Front seatsRear seats (without third row
seats)
Pull down the rear seat center
armrest.
Second row seats (with third
row seats)Third row seats (if equipped)
Pull down the second row seat
center armrest and press down
the button on the armrest.

2995-3. Using the storage features
5
Interior features
4RUNNER (U)_(OM35B23U)
■Adjusting the size of the cup holders
Front seats
Rear seats (without third row seats) Remove the adapter.
Remove the adapter.
CAUTION
■Items unsuitable for the cup holders
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent
burns.
■When not in use (second row seat cup holders only)
Keep the cup holders closed. In the event of sudden braking, an accident
may occur due to an occupant being struck by the open cup holders or the
items stored inside.
NOTICE
■To prevent damage to the rear cup holders (second row seats only)
Stow the cup holders before stowing the armrest.

3005-3. Using the storage features
4RUNNER (U)_(OM35B23U)
Push the lid.
Auxiliary box (If equipped)
CAUTION
■Items unsuitable for storing
Do not store items heavier than 0.4 lb. (0.2 kg).
Doing so may cause the auxiliary box to open and the items inside may fall
out, resulting in an accident.

3015-3. Using the storage features
5
Interior features
4RUNNER (U)_(OM35B23U)
Lift the lid while pulling up the knob to release the lock.
Coin holder
Tissue pocket
Pen holder
Coin holder/tissue pocket/pen holder
1
2
3

3025-3. Using the storage features
4RUNNER (U)_(OM35B23U)
■When using the bottle holder
●When storing a bottle, close the cap.
●The bottle may not be stored depending on its size or shape.
Bottle holders
Front seatsRear seats (without third row
seats)/second row seats (with
third row seats)
CAUTION
■Items unsuitable for the bottle holder
Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
■Items that should not be stowed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glasses and paper cups containing liquid. The contents may
spill and glasses may break.

3035-3. Using the storage features
5
Interior features
4RUNNER (U)_(OM35B23U)■
Cargo hooks
Vehicles with third seats
Fold down the third seats. (P. 128)
Raise the hook to use.
The cargo hooks are provided
for securing loose items.
Vehicles without third seats
Raise the hook to use.
The cargo hooks are provided
for securing loose items.
Luggage compartment features
1
2

3045-3. Using the storage features
4RUNNER (U)_(OM35B23U)■
Cargo net hooks
The cargo net itself is not included as original equipment.
Vehicles with third seats (pattern 1)
Raise the rear cargo hook to
use.
Vehicles with third seats (pattern 2)
Fold down the third seats. (P. 128)
Raise the cargo hook to use.
Vehicles without third seats (pattern 1)
Raise the rear cargo hook to
use.
1
2
