2016 SUBARU LEGACY navigation

BASIC INFORMATION BEFORE OPERATION
50
CHARACTER JUMP BUTTONS IN LISTS
Some lists contain character screen buttons, ABC (ABC),
DEF (DEF) etc., which allow a direct jump to list entries
that begin with the same letter as the character screen
button.
1. Select the desired character jump buttons.
NOTE
OEvery time the same character screen button is selected, the list
starting with the subsequent character is displayed.
SORTING (WITH NAVIGATION FUNCTION)
The order of a list displayed on the screen can be sorted in
the order of name, distance, detour, etc.
1. Select More (More).
2. Select the desired sorting criteria.

BASIC INFORMATION BEFORE OPERATION
52 XVideo (USB video/SD video*)
*: With navigation function
Screen button Function
“Brightness
(Brightness)”
Select to darken the screen.
Select to brighten the screen.
“Contrast
(Contrast)”
Select to weaken the contrast of
the screen.
Select to strengthen the contrast of
the screen.
“Tone (Tone)”
Select to weaken the tone of the
screen.
Select to strengthen the tone of the
screen.
“Color (Color)”
R (R)Select to strengthen the red color
of the screen.
G (G)Select to strengthen the green
color of the screen.
6. Select OK (OK).
CHANGING BETWEEN DAY AND NIGHT
MODE
Depending on the position of the headlight switch, the
screen changes to day or night mode.
NOTE
OIf the screen is set to day mode with the headlight switch turned
on, this condition is memorized even with the engine turned off.

BASIC OPERATION
58
QSAVING THE SOUND QUALITY
You can save the adjusted sound quality settings.
1. Adjust the sound quality.
2. Select EQ1 (EQ1) or EQ2 (EQ2) for 2 seconds or
more.

”Values cannot be saved for
FLAT (FLAT).
QUSING A PRESET SOUND QUALITY
1. Select EQ1 (EQ1) or EQ2 (EQ2) to activate the
corresponding preset sound quality.

”To reset the sound quality, select
FLAT (FLAT).

”This function can also be used at the “EQ Settings
(EQ Settings)”.
QRESETTING THE EQ CURVE
You can return the adjusted value for the currently stored
equalizer to its initial value.
1. Select and hold FLAT (FLAT) for 2 seconds or more.

”The adjusted values for the stored
EQ1 (EQ1) and
EQ2 (EQ2) are returned to their initial values.
AUDIO SCREEN ADJUSTMENT
The screen size can be selected for each type of media.
XUSB video/SD video*
*: With navigation function
1. Select on the audio control screen.
2. Select Screen Format (Screen Format).
3. Select the desired item to be adjusted.
No. Function
Select to display a screen with either side in black.
Select to enlarge the image horizontally to full screen.
Select to enlarge the image by the same ratio
horizontally and vertically.

MEDIA OPERATION
87
AUDIO
3
SD CARD (WITH NAVIGATION
FUNCTION)
$XGLR

AUDIO/VISUAL REMOTE CONTROLS
97
AUDIO
3
Mode Operation Function
Audio CD, MP3/
WMA/AAC disc,
SD*
1,USB,iPod,
Bluetooth audioPress6HOHFWDWUDFN¿OH
Press and hold Fast forward/rewind
Pandora*
2Press
Track up (“”only)
Press and hold Thumbs up/down
List screen Press Cursor left/right
*1: With navigation function
*2: Pandora is available in the United States, Australia, and New Zealand.
XMute/enter switch
Mode Operation Function
Except list
screenPress Mute/unmute
List screen Press Select cursor entry
XBack switch
Mode Operation Function
AllPressReturn to the previous screen
when
is displayed on
the screen.
Press and holdReturn to the “HOME
(HOME)” screen
XList switch
Mode Operation Function
Audio screen,
Navigation*
screenPress Show list screen
*: With navigation function
X“Source” switch
Mode Operation Function
All Press Change audio modes
NOTE
OIn the aha, Pandora* and STARLINK mode, some operation may
be done on the screen depend on the selected APPS.
*: Pandora is available in the United States, Australia, and New Zealand.

SETUP
99
AUDIO
3
No. Function Page
Select to specify the sound settings. 56
Select to change the number of preset radio
stations/channels displayed on the screen.99
Select to specify the iPod/SD*1/USB auto play
settings on/off.-
Select to specify the iPod sound signal input
settings.100
Unsupported. -
Select to specify cover art settings on/off. -
*2Select to specify automatic sound levelizer
settings.100
Select to enable cache radio. -
Select to reset all setup items. -
*1: With navigation function
*2 <0037004b004c005600030056004800570057004c0051004a0003004600440051000300450048000300500044004700480003004700480053004800510047004c0051004a00030052005100030057004b004800030046005200510051004800460057004800
470003004400500053004f004c00bf004800550003>W\SH
DISPLAYING THE “Audio Settings (Audio
Settings)” SCREEN IN A DIFFERENT WAY
XUSB video/SD video*
*: With navigation function
1. Select on the audio control screen.
2. Select Settings (Settings).
SETTING THE NUMBER OF RADIO PRESETS
1. Display the “Audio Settings (Audio Settings)” screen.

:3
2. Select Number of Radio Presets (Number of Radio
Presets).
3. Select the button with the desired number to be
displayed.

TIPS FOR OPERATING THE AUDIO/VISUAL SYSTEM
107
AUDIO
3
SD CARD (WITH NAVIGATION FUNCTION)
SD cards that are marked as follows can be used.

PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES)
11 4
PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES)
QUICK REFERENCE
The phone top screen can be used to make a phone call. To
display the hands-free operation screen, select
and
then select
PHONE (PHONE), select *, or press
the
switch on the steering wheel.
Several functions are available to operate on each screen
that is displayed by selecting the 4 tabs.
*: Without navigation function
Function Page
Phone
operationRegistering/connecting Bluetooth phone 174
Calling on the Bluetooth phone 118
Receiving on the Bluetooth phone 124
Talking on the Bluetooth phone 125
Message
functionUsing the Bluetooth phone message
function127
Setting up
a phonePhone settings 133
Bluetooth settings 179
