2016 SUBARU CROSSTREK Navigation Manual

ROUTE GUIDANCE
232
4.Select the route’s start point by using the same method
as selecting the destination.
5.Set the new start point and then select Go! (Go!).

” The vehicle marker goes clear on the map, indicating
that there is no GPS reception.

”If a route is already being navigated, it is recalculated
using the position selected at that time.

” To return to standard navigation, select
Turn on GPS (Turn on GPS), and if a warning
message is displayed, select which operation to
perform.
CREATING A ROUTE
You can create a route for each destination in the saved
routes menu.
1.Display the “Change Route (Change Route)” screen.

:3
2.SelectCreate Route (Create Route).

”
Create Route (Create Route) is displayed when a
route is not set.
3.Select to select a destination.

” Only one row showing the route’s start point (current
position displayed) is displayed in the route point list.

ROUTE GUIDANCE
233
NAVIGATION SYSTEM
8
4.6HDUFKIRUDGHVWLQDWLRQ
:3

”Select the route’s destination using the same method
as described previously.

” After selecting a new destination, you are returned to
the list.

” To add another destination, select
at the point
where you want to add a new route point to the list,
and repeat the steps above.
ROUTE ALTERNATIVES
Change the Route settings to perform a new search for the
route being navigated using a different method. You can
even search again by comparing different routes.
1.Display the “Change Route (Change Route)” screen.

:3
2.SelectMore (More).
3.SelectRoute Alternatives (Route Alternatives).
4.Select the desired route.

”
Using the current search method, three routes are
displayed in order of recommendation.

”
More Results (More Results): Select to search
using a different method. Also, if only a short distance
is being navigated or only a few search candidates
are found, each search method displays only one
route.
5.Select to return to the previous screen.

” The route is searched again using the selected
method. The new recommended route is indicated by
a blue line.

MEMORY POINTS
234
MEMORY POINTS
MEMORY POINTS SETTINGS
Home and preset destinations can be set as memory points.
The registered points can be used as the destinations.

:3
SETTING UP HOME
If home has been registered, that information can be
recalled by selecting
Go Home (Go Home) on the

MEMORY POINTS
235
NAVIGATION SYSTEM
8
SAVING DESTINATIONS
The destination list is a list of frequently used destinations.
Up to 100 destinations can be stored in the favorites list.
1.Select the desired item to search for the location.

:3

”The map is displayed in full-screen mode with the
selected point at the center.
2.SelectMore (More).
3.SelectAdd to Favorites (Add to Favorites).
4.Enter a name and then select OK (OK).

SETUP
236
SETUP
NAVIGATION SETTINGS
OPTIONAL FUNCTIONS
Various options are available from the “More (More)” menu.
1.SelectMenu (Menu) on the map screen.
2.SelectMore (More).
3.Select the items to be set.
No.
Function
6HOHFWWRFRQ¿JXUHSURJUDPVDQGFKDQJHRSHUDWLRQDO
patterns for the software. Performs functions such as
¿QHWXQLQJURXWHVHDUFKRSWLRQVFKDQJLQJWKHPDS
screen design, turning warnings on or off, and launching
WKH³&RQ¿JXUDWLRQ:L]DUG&RQ¿JXUDWLRQ:L]DUG´
No.Function
Select to check global sunrise and sunset times. Places
a mark on the map to show the user’s current position
and route points. Select Details button to check accurate
sunrise and sunset times for all points along the route
FXUUHQWSRVLWLRQDOOZD\SRLQWV¿QDOGHVWLQDWLRQ
Select to display a list of all trip logs, whether they are
saved by the user upon reaching the destination or
whether they are saved automatically. Select an item
from the trip that is displayed, you can check trip data,
speeds, and more detailed contents. When a path log
has been saved, you can display it on the map in the
color selected.
Select to display a tutorial allowing for a quick grasp
of the software’s functions, and starts a demonstration
showing a sample route simulation to check the
navigation functions. The about section displays
product information. Here you can view the software
and database user license agreements, search for the
contents license, and check the software ID. You can
check statistical data for program use.

SETUP
237
NAVIGATION SYSTEM
8
SCREENS FOR NAVIGATION SETTINGS
1.'LVSOD\WKH

SETUP
238
SOUND AND WARNINGS
WARNING
OBe sure to set the volume of the audio at an appropriate level.
Improper volume setting may result in hearing damage or a
WUDI¿FDFFLGHQW
1.'LVSOD\WKH

SETUP
239
NAVIGATION SYSTEM
8
TRAFFIC
1.'LVSOD\WKH
